Here's an example of a constraint implemented as a score rule in such a DRL file:

rule "multipleQueensHorizontal" when $q1 : Queen($id : id, $y : y); $q2 : Queen(id > $id, y == $y); then insertLogical(new UnweightedConstraintOccurrence("multipleQueensHorizontal", $q1, $q2)); end

global SimpleScoreHolder scoreHolder; rule "multipleQueensHorizontal" when $q1 : Queen($id : id, $y : y); $q2 : Queen(id > $id, y == $y); then insertLogical(new UnweightedConstraintOccurrence("multipleQueensHorizontal", $q1, $q2)); end // multipleQueensVertical is obsolete because it is always 0 rule "multipleQueensAscendingDiagonal" when $q1 : Queen($id : id, $ascendingD : ascendingD); $q2 : Queen(id > $id, ascendingD == $ascendingD); then insertLogical(new UnweightedConstraintOccurrence("multipleQueensAscendingDiagonal", $q1, $q2)); end rule "multipleQueensDescendingDiagonal" when $q1 : Queen($id : id, $descendingD : descendingD); $q2 : Queen(id > $id, descendingD == $descendingD); then insertLogical(new UnweightedConstraintOccurrence("multipleQueensDescendingDiagonal", $q1, $q2)); end rule "hardConstraintsBroken" when $occurrenceCount : Number() from accumulate( $unweightedConstraintOccurrence : UnweightedConstraintOccurrence(), count($unweightedConstraintOccurrence) ); then scoreHolder.setScore(- $occurrenceCount.intValue()); end

// RoomCapacity: For each lecture, the number of students that attend the course must be less or equal // than the number of seats of all the rooms that host its lectures. // Each student above the capacity counts as 1 point of penalty. rule "roomCapacity" when ... then insertLogical(new IntConstraintOccurrence("roomCapacity", ConstraintType.NEGATIVE_SOFT, ($studentSize - $capacity), ...)); end // CurriculumCompactness: Lectures belonging to a curriculum should be adjacent // to each other (i.e., in consecutive periods). // For a given curriculum we account for a violation every time there is one lecture not adjacent // to any other lecture within the same day. // Each isolated lecture in a curriculum counts as 2 points of penalty. rule "curriculumCompactness" when ... then insertLogical(new IntConstraintOccurrence("curriculumCompactness", ConstraintType.NEGATIVE_SOFT, 2, ...)); end // Accumulate soft constraints rule "softConstraintsBroken" salience -1 // Do the other rules first (optional, for performance) when $softTotal : Number() from accumulate( IntConstraintOccurrence(constraintType == ConstraintType.NEGATIVE_SOFT, $weight : weight), sum($weight) ) then scoreHolder.setSoftConstraintsBroken($softTotal.intValue()); end
