Hibernate ORM 5.3.36.Final User Guide

/*
 * Hibernate, Relational Persistence for Idiomatic Java
 *
 * License: GNU Lesser General Public License (LGPL), version 2.1 or later.
 * See the lgpl.txt file in the root directory or <http://www.gnu.org/licenses/lgpl-2.1.html>.
 */
package org.hibernate.userguide.naming;

import java.util.LinkedList;
import java.util.List;
import java.util.Locale;
import java.util.Map;
import java.util.TreeMap;

import org.hibernate.boot.model.naming.Identifier;
import org.hibernate.boot.model.naming.PhysicalNamingStrategy;
import org.hibernate.engine.jdbc.env.spi.JdbcEnvironment;

import org.apache.commons.lang3.StringUtils;

/**
 * An example PhysicalNamingStrategy that implements database object naming standards
 * for our fictitious company Acme Corp.
 * <p/>
 * In general Acme Corp prefers underscore-delimited words rather than camel casing.
 * <p/>
 * Additionally standards call for the replacement of certain words with abbreviations.
 *
 * @author Steve Ebersole
 */
public class AcmeCorpPhysicalNamingStrategy implements PhysicalNamingStrategy {
	private static final Map<String,String> ABBREVIATIONS = buildAbbreviationMap();

	@Override
	public Identifier toPhysicalCatalogName(Identifier name, JdbcEnvironment jdbcEnvironment) {
		// Acme naming standards do not apply to catalog names
		return name;
	}

	@Override
	public Identifier toPhysicalSchemaName(Identifier name, JdbcEnvironment jdbcEnvironment) {
		// Acme naming standards do not apply to schema names
		return name;
	}

	@Override
	public Identifier toPhysicalTableName(Identifier name, JdbcEnvironment jdbcEnvironment) {
		final List<String> parts = splitAndReplace( name.getText() );
		return jdbcEnvironment.getIdentifierHelper().toIdentifier(
				join( parts ),
				name.isQuoted()
		);
	}

	@Override
	public Identifier toPhysicalSequenceName(Identifier name, JdbcEnvironment jdbcEnvironment) {
		final LinkedList<String> parts = splitAndReplace( name.getText() );
		// Acme Corp says all sequences should end with _seq
		if ( !"seq".equalsIgnoreCase( parts.getLast() ) ) {
			parts.add( "seq" );
		}
		return jdbcEnvironment.getIdentifierHelper().toIdentifier(
				join( parts ),
				name.isQuoted()
		);
	}

	@Override
	public Identifier toPhysicalColumnName(Identifier name, JdbcEnvironment jdbcEnvironment) {
		final List<String> parts = splitAndReplace( name.getText() );
		return jdbcEnvironment.getIdentifierHelper().toIdentifier(
				join( parts ),
				name.isQuoted()
		);
	}

	private static Map<String, String> buildAbbreviationMap() {
		TreeMap<String,String> abbreviationMap = new TreeMap<> ( String.CASE_INSENSITIVE_ORDER );
		abbreviationMap.put( "account", "acct" );
		abbreviationMap.put( "number", "num" );
		return abbreviationMap;
	}

	private LinkedList<String> splitAndReplace(String name) {
		LinkedList<String> result = new LinkedList<>();
		for ( String part : StringUtils.splitByCharacterTypeCamelCase( name ) ) {
			if ( part == null || part.trim().isEmpty() ) {
				// skip null and space
				continue;
			}
			part = applyAbbreviationReplacement( part );
			result.add( part.toLowerCase( Locale.ROOT ) );
		}
		return result;
	}

	private String applyAbbreviationReplacement(String word) {
		if ( ABBREVIATIONS.containsKey( word ) ) {
			return ABBREVIATIONS.get( word );
		}

		return word;
	}

	private String join(List<String> parts) {
		boolean firstPass = true;
		String separator = "";
		StringBuilder joined = new StringBuilder();
		for ( String part : parts ) {
			joined.append( separator ).append( part );
			if ( firstPass ) {
				firstPass = false;
				separator = "_";
			}
		}
		return joined.toString();
	}
}

@Entity(name = "Product")
public class Product {

	@Id
	@Basic
	private Integer id;

	@Basic
	private String sku;

	@Basic
	private String name;

	@Basic
	private String description;
}

@Entity(name = "Product")
public class Product {

	@Id
	private Integer id;

	private String sku;

	private String name;

	private String description;
}

@Entity(name = "Product")
public class Product {

	@Id
	private Integer id;

	private String sku;

	private String name;

	@Column( name = "NOTES" )
	private String description;
}

@Entity(name = "Product")
public class Product {

	@Id
	private Integer id;

	private String sku;

	@org.hibernate.annotations.Type( type = "nstring" )
	private String name;

	@org.hibernate.annotations.Type( type = "materialized_nclob" )
	private String description;
}

CREATE TABLE Product (
    id INTEGER NOT NULL ,
    name VARCHAR(255) ,
    warranty NVARCHAR(255) ,
    PRIMARY KEY ( id )
)

@Entity(name = "Product")
public static class Product {

    @Id
    private Integer id;

    private String name;

    @Nationalized
    private String warranty;

    //Getters and setters are omitted for brevity

}

CREATE TABLE Product (
    id INTEGER NOT NULL ,
    name VARCHAR(255) ,
    warranty nclob ,
    PRIMARY KEY ( id )
)

@Entity(name = "Product")
public static class Product {

    @Id
    private Integer id;

    private String name;

    @Lob
    @Nationalized
    // Clob also works, because NClob extends Clob.
    // The database type is still NCLOB either way and handled as such.
    private NClob warranty;

    //Getters and setters are omitted for brevity

}

String warranty = "My product warranty";

final Product product = new Product();
product.setId( 1 );
product.setName( "Mobile phone" );

product.setWarranty( NClobProxy.generateProxy( warranty ) );

entityManager.persist( product );

Product product = entityManager.find( Product.class, productId );

try (Reader reader = product.getWarranty().getCharacterStream()) {
    assertEquals( "My product warranty", toString( reader ) );
}

@Entity(name = "Product")
public static class Product {

    @Id
    private Integer id;

    private String name;

    @Lob
    @Nationalized
    private String warranty;

    //Getters and setters are omitted for brevity

}

@Entity(name = "Product")
public static class Product {

    @Id
    private Integer id;

    private String name;

    @Lob
    @Nationalized
    private char[] warranty;

    //Getters and setters are omitted for brevity

}

@Entity(name = "DateEvent")
public static class DateEvent {

	@Id
	@GeneratedValue
	private Long id;

	@Column(name = "`timestamp`")
	@Temporal(TemporalType.DATE)
	private Date timestamp;

	//Getters and setters are omitted for brevity

}

DateEvent dateEvent = new DateEvent( new Date() );
entityManager.persist( dateEvent );

INSERT INTO DateEvent ( timestamp, id )
VALUES ( '2015-12-29', 1 )

@Column(name = "`timestamp`")
@Temporal(TemporalType.TIME)
private Date timestamp;

INSERT INTO DateEvent ( timestamp, id )
VALUES ( '16:51:58', 1 )

@Column(name = "`timestamp`")
@Temporal(TemporalType.TIMESTAMP)
private Date timestamp;

INSERT INTO DateEvent ( timestamp, id )
VALUES ( '2015-12-29 16:54:04.544', 1 )

@Converter
public class PeriodStringConverter
        implements AttributeConverter<Period, String> {

    @Override
    public String convertToDatabaseColumn(Period attribute) {
        return attribute.toString();
    }

    @Override
    public Period convertToEntityAttribute(String dbData) {
        return Period.parse( dbData );
    }
}

@Entity(name = "Event")
public static class Event {

    @Id
    @GeneratedValue
    private Long id;

    @Convert(converter = PeriodStringConverter.class)
    @Column(columnDefinition = "")
    private Period span;

    //Getters and setters are omitted for brevity

}

INSERT INTO Event ( span, id )
VALUES ( 'P1Y2M3D', 1 )

@Entity(name = "Product")
public static class Product {

	@Id
	private Long id;

	@Column(name = "`name`")
	private String name;

	@Column(name = "`number`")
	private String number;

	//Getters and setters are omitted for brevity

}

@Entity(name = "Product")
public static class Product {

	@Id
	private Long id;

	@Column(name = "\"name\"")
	private String name;

	@Column(name = "\"number\"")
	private String number;

	//Getters and setters are omitted for brevity

}

Product product = new Product();
product.setId( 1L );
product.setName( "Mobile phone" );
product.setNumber( "123-456-7890" );
entityManager.persist( product );

INSERT INTO Product ("name", "number", id)
VALUES ('Mobile phone', '123-456-7890', 1)

@Entity(name = "Employee")
public static class Employee {

	@Id
	private Long id;

	@NaturalId
	private String username;

	@Column(name = "pswd")
	@ColumnTransformer(
		read = "decrypt( 'AES', '00', pswd  )",
		write = "encrypt('AES', '00', ?)"
	)
	private String password;

	private int accessLevel;

	@ManyToOne(fetch = FetchType.LAZY)
	private Department department;

	@ManyToMany(mappedBy = "employees")
	private List<Project> projects = new ArrayList<>();

	//Getters and setters omitted for brevity
}

@Entity(name = "Savings")
public static class Savings {

	@Id
	private Long id;

	@Type(type = "org.hibernate.userguide.mapping.basic.MonetaryAmountUserType")
	@Columns(columns = {
		@Column(name = "money"),
		@Column(name = "currency")
	})
	@ColumnTransformer(
		forColumn = "money",
		read = "money / 100",
		write = "? * 100"
	)
	private MonetaryAmount wallet;

	//Getters and setters omitted for brevity

}

doInJPA( this::entityManagerFactory, entityManager -> {
	Savings savings = new Savings( );
	savings.setId( 1L );
	savings.setWallet( new MonetaryAmount( BigDecimal.TEN, Currency.getInstance( Locale.US ) ) );
	entityManager.persist( savings );
} );

doInJPA( this::entityManagerFactory, entityManager -> {
	Savings savings = entityManager.find( Savings.class, 1L );
	assertEquals( 10, savings.getWallet().getAmount().intValue());
} );

INSERT INTO Savings (money, currency, id)
VALUES (10 * 100, 'USD', 1)

SELECT
    s.id as id1_0_0_,
    s.money / 100 as money2_0_0_,
    s.currency as currency3_0_0_
FROM
    Savings s
WHERE
    s.id = 1

@Entity(name = "Account")
public static class Account {

	@Id
	private Long id;

	private Double credit;

	private Double rate;

	@Formula(value = "credit * rate")
	private Double interest;

	//Getters and setters omitted for brevity

}

doInJPA( this::entityManagerFactory, entityManager -> {
	Account account = new Account( );
	account.setId( 1L );
	account.setCredit( 5000d );
	account.setRate( 1.25 / 100 );
	entityManager.persist( account );
} );

doInJPA( this::entityManagerFactory, entityManager -> {
	Account account = entityManager.find( Account.class, 1L );
	assertEquals( Double.valueOf( 62.5d ), account.getInterest());
} );

INSERT INTO Account (credit, rate, id)
VALUES (5000.0, 0.0125, 1)

SELECT
    a.id as id1_0_0_,
    a.credit as credit2_0_0_,
    a.rate as rate3_0_0_,
    a.credit * a.rate as formula0_0_
FROM
    Account a
WHERE
    a.id = 1

public enum AccountType {
	DEBIT,
	CREDIT
}

@Entity(name = "Client")
public static class Client {

	@Id
	private Long id;

	private String name;

	@Where( clause = "account_type = 'DEBIT'")
	@OneToMany(mappedBy = "client")
	private List<Account> debitAccounts = new ArrayList<>( );

	@Where( clause = "account_type = 'CREDIT'")
	@OneToMany(mappedBy = "client")
	private List<Account> creditAccounts = new ArrayList<>( );

	//Getters and setters omitted for brevity

}

@Entity(name = "Account")
@Where( clause = "active = true" )
public static class Account {

	@Id
	private Long id;

	@ManyToOne
	private Client client;

	@Column(name = "account_type")
	@Enumerated(EnumType.STRING)
	private AccountType type;

	private Double amount;

	private Double rate;

	private boolean active;

	//Getters and setters omitted for brevity

}

doInJPA( this::entityManagerFactory, entityManager -> {

	Client client = new Client();
	client.setId( 1L );
	client.setName( "John Doe" );
	entityManager.persist( client );

	Account account1 = new Account( );
	account1.setId( 1L );
	account1.setType( AccountType.CREDIT );
	account1.setAmount( 5000d );
	account1.setRate( 1.25 / 100 );
	account1.setActive( true );
	account1.setClient( client );
	client.getCreditAccounts().add( account1 );
	entityManager.persist( account1 );

	Account account2 = new Account( );
	account2.setId( 2L );
	account2.setType( AccountType.DEBIT );
	account2.setAmount( 0d );
	account2.setRate( 1.05 / 100 );
	account2.setActive( false );
	account2.setClient( client );
	client.getDebitAccounts().add( account2 );
	entityManager.persist( account2 );

	Account account3 = new Account( );
	account3.setType( AccountType.DEBIT );
	account3.setId( 3L );
	account3.setAmount( 250d );
	account3.setRate( 1.05 / 100 );
	account3.setActive( true );
	account3.setClient( client );
	client.getDebitAccounts().add( account3 );
	entityManager.persist( account3 );
} );

INSERT INTO Client (name, id)
VALUES ('John Doe', 1)

INSERT INTO Account (active, amount, client_id, rate, account_type, id)
VALUES (true, 5000.0, 1, 0.0125, 'CREDIT', 1)

INSERT INTO Account (active, amount, client_id, rate, account_type, id)
VALUES (false, 0.0, 1, 0.0105, 'DEBIT', 2)

INSERT INTO Account (active, amount, client_id, rate, account_type, id)
VALUES (true, 250.0, 1, 0.0105, 'DEBIT', 3)

doInJPA( this::entityManagerFactory, entityManager -> {
	List<Account> accounts = entityManager.createQuery(
		"select a from Account a", Account.class)
	.getResultList();
	assertEquals( 2, accounts.size());
} );

SELECT
    a.id as id1_0_,
    a.active as active2_0_,
    a.amount as amount3_0_,
    a.client_id as client_i6_0_,
    a.rate as rate4_0_,
    a.account_type as account_5_0_
FROM
    Account a
WHERE ( a.active = true )

doInJPA( this::entityManagerFactory, entityManager -> {
	Client client = entityManager.find( Client.class, 1L );
	assertEquals( 1, client.getCreditAccounts().size() );
	assertEquals( 1, client.getDebitAccounts().size() );
} );

SELECT
    c.client_id as client_i6_0_0_,
    c.id as id1_0_0_,
    c.id as id1_0_1_,
    c.active as active2_0_1_,
    c.amount as amount3_0_1_,
    c.client_id as client_i6_0_1_,
    c.rate as rate4_0_1_,
    c.account_type as account_5_0_1_
FROM
    Account c
WHERE ( c.active = true and c.account_type = 'CREDIT' ) AND c.client_id = 1

SELECT
    d.client_id as client_i6_0_0_,
    d.id as id1_0_0_,
    d.id as id1_0_1_,
    d.active as active2_0_1_,
    d.amount as amount3_0_1_,
    d.client_id as client_i6_0_1_,
    d.rate as rate4_0_1_,
    d.account_type as account_5_0_1_
FROM
    Account d
WHERE ( d.active = true and d.account_type = 'DEBIT' ) AND d.client_id = 1

@Entity(name = "Book")
public static class Book {

	@Id
	private Long id;

	private String title;

	private String author;

	@ManyToMany
	@JoinTable(
		name = "Book_Reader",
		joinColumns = @JoinColumn(name = "book_id"),
		inverseJoinColumns = @JoinColumn(name = "reader_id")
	)
	@WhereJoinTable( clause = "created_on > DATEADD( 'DAY', -7, CURRENT_TIMESTAMP() )")
	private List<Reader> currentWeekReaders = new ArrayList<>( );

	//Getters and setters omitted for brevity

}

@Entity(name = "Reader")
public static class Reader {

	@Id
	private Long id;

	private String name;

	//Getters and setters omitted for brevity

}

create table Book (
    id bigint not null,
    author varchar(255),
    title varchar(255),
    primary key (id)
)

create table Book_Reader (
    book_id bigint not null,
    reader_id bigint not null
)

create table Reader (
    id bigint not null,
    name varchar(255),
    primary key (id)
)

alter table Book_Reader
    add constraint FKsscixgaa5f8lphs9bjdtpf9g
    foreign key (reader_id)
    references Reader

alter table Book_Reader
    add constraint FKoyrwu9tnwlukd1616qhck21ra
    foreign key (book_id)
    references Book

alter table Book_Reader
    add created_on timestamp
    default current_timestamp

Book book = new Book();
book.setId( 1L );
book.setTitle( "High-Performance Java Persistence" );
book.setAuthor( "Vad Mihalcea" );
entityManager.persist( book );

Reader reader1 = new Reader();
reader1.setId( 1L );
reader1.setName( "John Doe" );
entityManager.persist( reader1 );

Reader reader2 = new Reader();
reader2.setId( 2L );
reader2.setName( "John Doe Jr." );
entityManager.persist( reader2 );

statement.executeUpdate(
	"INSERT INTO Book_Reader " +
	"	(book_id, reader_id) " +
	"VALUES " +
	"	(1, 1) "
);
statement.executeUpdate(
	"INSERT INTO Book_Reader " +
	"	(book_id, reader_id, created_on) " +
	"VALUES " +
	"	(1, 2, DATEADD( 'DAY', -10, CURRENT_TIMESTAMP() )) "
);

Book book = entityManager.find( Book.class, 1L );
assertEquals( 1, book.getCurrentWeekReaders().size() );

@Entity(name = "Account")
@FilterDef(
    name="activeAccount",
    parameters = @ParamDef(
        name="active",
        type="boolean"
    )
)
@Filter(
    name="activeAccount",
    condition="active_status = :active"
)
public static class Account {

    @Id
    private Long id;

    @ManyToOne(fetch = FetchType.LAZY)
    private Client client;

    @Column(name = "account_type")
    @Enumerated(EnumType.STRING)
    private AccountType type;

    private Double amount;

    private Double rate;

    @Column(name = "active_status")
    private boolean active;

    //Getters and setters omitted for brevity
}

@Entity(name = "Client")
public static class Client {

    @Id
    private Long id;

    private String name;

    @OneToMany(
        mappedBy = "client",
        cascade = CascadeType.ALL
    )
    @Filter(
        name="activeAccount",
        condition="active_status = :active"
    )
    private List<Account> accounts = new ArrayList<>( );

    //Getters and setters omitted for brevity

    public void addAccount(Account account) {
        account.setClient( this );
        this.accounts.add( account );
    }
}

Client client = new Client()
.setId( 1L )
.setName( "John Doe" );

client.addAccount(
    new Account()
    .setId( 1L )
    .setType( AccountType.CREDIT )
    .setAmount( 5000d )
    .setRate( 1.25 / 100 )
    .setActive( true )
);

client.addAccount(
    new Account()
    .setId( 2L )
    .setType( AccountType.DEBIT )
    .setAmount( 0d )
    .setRate( 1.05 / 100 )
    .setActive( false )
);

client.addAccount(
    new Account()
    .setType( AccountType.DEBIT )
    .setId( 3L )
    .setAmount( 250d )
    .setRate( 1.05 / 100 )
    .setActive( true )
);

entityManager.persist( client );

INSERT INTO Client (name, id)
VALUES ('John Doe', 1)

INSERT INTO Account (active_status, amount, client_id, rate, account_type, id)
VALUES (true, 5000.0, 1, 0.0125, 'CREDIT', 1)

INSERT INTO Account (active_status, amount, client_id, rate, account_type, id)
VALUES (false, 0.0, 1, 0.0105, 'DEBIT', 2)

INSERT INTO Account (active_status, amount, client_id, rate, account_type, id)
VALUES (true, 250.0, 1, 0.0105, 'DEBIT', 3)

List<Account> accounts = entityManager.createQuery(
    "select a from Account a", Account.class)
.getResultList();

assertEquals( 3, accounts.size());

SELECT
    a.id as id1_0_,
    a.active_status as active2_0_,
    a.amount as amount3_0_,
    a.client_id as client_i6_0_,
    a.rate as rate4_0_,
    a.account_type as account_5_0_
FROM
    Account a

entityManager
    .unwrap( Session.class )
    .enableFilter( "activeAccount" )
    .setParameter( "active", true);

List<Account> accounts = entityManager.createQuery(
    "select a from Account a", Account.class)
.getResultList();

assertEquals( 2, accounts.size());

SELECT
    a.id as id1_0_,
    a.active_status as active2_0_,
    a.amount as amount3_0_,
    a.client_id as client_i6_0_,
    a.rate as rate4_0_,
    a.account_type as account_5_0_
FROM
    Account a
WHERE
    a.active_status = true

Client client = entityManager.find( Client.class, 1L );

assertEquals( 3, client.getAccounts().size() );

SELECT
    c.id as id1_1_0_,
    c.name as name2_1_0_
FROM
    Client c
WHERE
    c.id = 1

SELECT
    a.id as id1_0_,
    a.active_status as active2_0_,
    a.amount as amount3_0_,
    a.client_id as client_i6_0_,
    a.rate as rate4_0_,
    a.account_type as account_5_0_
FROM
    Account a
WHERE
    a.client_id = 1

entityManager
    .unwrap( Session.class )
    .enableFilter( "activeAccount" )
    .setParameter( "active", true);

Client client = entityManager.find( Client.class, 1L );

assertEquals( 2, client.getAccounts().size() );

SELECT
    c.id as id1_1_0_,
    c.name as name2_1_0_
FROM
    Client c
WHERE
    c.id = 1

SELECT
    a.id as id1_0_,
    a.active_status as active2_0_,
    a.amount as amount3_0_,
    a.client_id as client_i6_0_,
    a.rate as rate4_0_,
    a.account_type as account_5_0_
FROM
    Account a
WHERE
    accounts0_.active_status = true
    and a.client_id = 1

@Entity(name = "Client")
@FilterDef(
    name="firstAccounts",
    parameters=@ParamDef(
        name="maxOrderId",
        type="int"
    )
)
@Filter(
    name="firstAccounts",
    condition="order_id <= :maxOrderId"
)
public static class Client {

    @Id
    private Long id;

    private String name;

    @OneToMany(cascade = CascadeType.ALL)
    @OrderColumn(name = "order_id")
    @FilterJoinTable(
        name="firstAccounts",
        condition="order_id <= :maxOrderId"
    )
    private List<Account> accounts = new ArrayList<>( );

    //Getters and setters omitted for brevity

    public void addAccount(Account account) {
        this.accounts.add( account );
    }
}

@Entity(name = "Account")
public static class Account {

    @Id
    private Long id;

    @Column(name = "account_type")
    @Enumerated(EnumType.STRING)
    private AccountType type;

    private Double amount;

    private Double rate;

    //Getters and setters omitted for brevity
}

Client client = new Client()
.setId( 1L )
.setName( "John Doe" );

client.addAccount(
    new Account()
    .setId( 1L )
    .setType( AccountType.CREDIT )
    .setAmount( 5000d )
    .setRate( 1.25 / 100 )
);

client.addAccount(
    new Account()
    .setId( 2L )
    .setType( AccountType.DEBIT )
    .setAmount( 0d )
    .setRate( 1.05 / 100 )
);

client.addAccount(
    new Account()
    .setType( AccountType.DEBIT )
    .setId( 3L )
    .setAmount( 250d )
    .setRate( 1.05 / 100 )
);

entityManager.persist( client );

INSERT INTO Client (name, id)
VALUES ('John Doe', 1)

INSERT INTO Account (amount, client_id, rate, account_type, id)
VALUES (5000.0, 1, 0.0125, 'CREDIT', 1)

INSERT INTO Account (amount, client_id, rate, account_type, id)
VALUES (0.0, 1, 0.0105, 'DEBIT', 2)

INSERT INTO Account (amount, client_id, rate, account_type, id)
VALUES (250.0, 1, 0.0105, 'DEBIT', 3)

INSERT INTO Client_Account (Client_id, order_id, accounts_id)
VALUES (1, 0, 1)

INSERT INTO Client_Account (Client_id, order_id, accounts_id)
VALUES (1, 0, 1)

INSERT INTO Client_Account (Client_id, order_id, accounts_id)
VALUES (1, 1, 2)

INSERT INTO Client_Account (Client_id, order_id, accounts_id)
VALUES (1, 2, 3)

Client client = entityManager.find( Client.class, 1L );

assertEquals( 3, client.getAccounts().size());

SELECT
    ca.Client_id as Client_i1_2_0_,
    ca.accounts_id as accounts2_2_0_,
    ca.order_id as order_id3_0_,
    a.id as id1_0_1_,
    a.amount as amount3_0_1_,
    a.rate as rate4_0_1_,
    a.account_type as account_5_0_1_
FROM
    Client_Account ca
INNER JOIN
    Account a
ON  ca.accounts_id=a.id
WHERE
    ca.Client_id = ?

-- binding parameter [1] as [BIGINT] - [1]

Client client = entityManager.find( Client.class, 1L );

entityManager
    .unwrap( Session.class )
    .enableFilter( "firstAccounts" )
    .setParameter( "maxOrderId", 1);

assertEquals( 2, client.getAccounts().size());

SELECT
    ca.Client_id as Client_i1_2_0_,
    ca.accounts_id as accounts2_2_0_,
    ca.order_id as order_id3_0_,
    a.id as id1_0_1_,
    a.amount as amount3_0_1_,
    a.rate as rate4_0_1_,
    a.account_type as account_5_0_1_
FROM
    Client_Account ca
INNER JOIN
    Account a
ON  ca.accounts_id=a.id
WHERE
    ca.order_id <= ?
    AND ca.Client_id = ?

-- binding parameter [1] as [INTEGER] - [1]
-- binding parameter [2] as [BIGINT] - [1]

@Entity(name = "Account")
@Table(name = "account")
@SecondaryTable(
	name = "account_details"
)
@SQLDelete(
	sql = "UPDATE account_details SET deleted = true WHERE id = ? "
)
@FilterDef(
	name="activeAccount",
	parameters = @ParamDef(
		name="active",
		type="boolean"
	)
)
@Filter(
	name="activeAccount",
	condition="{a}.active = :active and {ad}.deleted = false",
	aliases = {
		@SqlFragmentAlias( alias = "a", table= "account"),
		@SqlFragmentAlias( alias = "ad", table= "account_details"),
	}
)
public static class Account {

	@Id
	private Long id;

	private Double amount;

	private Double rate;

	private boolean active;

	@Column(table = "account_details")
	private boolean deleted;

	//Getters and setters omitted for brevity

}

entityManager
	.unwrap( Session.class )
	.enableFilter( "activeAccount" )
	.setParameter( "active", true);

List<Account> accounts = entityManager.createQuery(
	"select a from Account a", Account.class)
.getResultList();

select
    filtersqlf0_.id as id1_0_,
    filtersqlf0_.active as active2_0_,
    filtersqlf0_.amount as amount3_0_,
    filtersqlf0_.rate as rate4_0_,
    filtersqlf0_1_.deleted as deleted1_1_
from
    account filtersqlf0_
left outer join
    account_details filtersqlf0_1_
        on filtersqlf0_.id=filtersqlf0_1_.id
where
    filtersqlf0_.active = ?
    and filtersqlf0_1_.deleted = false

-- binding parameter [1] as [BOOLEAN] - [true]

public interface Property<T> {

    String getName();

    T getValue();
}


@Entity
@Table(name="integer_property")
public class IntegerProperty implements Property<Integer> {

    @Id
    private Long id;

    @Column(name = "`name`")
    private String name;

    @Column(name = "`value`")
    private Integer value;

    @Override
    public String getName() {
        return name;
    }

    @Override
    public Integer getValue() {
        return value;
    }

    //Getters and setters omitted for brevity
}


@Entity
@Table(name="string_property")
public class StringProperty implements Property<String> {

    @Id
    private Long id;

    @Column(name = "`name`")
    private String name;

    @Column(name = "`value`")
    private String value;

    @Override
    public String getName() {
        return name;
    }

    @Override
    public String getValue() {
        return value;
    }

    //Getters and setters omitted for brevity
}

@Entity
@Table( name = "property_holder" )
public class PropertyHolder {

    @Id
    private Long id;

    @Any(
        metaDef = "PropertyMetaDef",
        metaColumn = @Column( name = "property_type" )
    )
    @JoinColumn( name = "property_id" )
    private Property property;

    //Getters and setters are omitted for brevity

}

CREATE TABLE property_holder (
    id BIGINT NOT NULL,
    property_type VARCHAR(255),
    property_id BIGINT,
    PRIMARY KEY ( id )
)

@AnyMetaDef( name= "PropertyMetaDef", metaType = "string", idType = "long",
    metaValues = {
            @MetaValue(value = "S", targetEntity = StringProperty.class),
            @MetaValue(value = "I", targetEntity = IntegerProperty.class)
        }
    )
package org.hibernate.userguide.mapping.basic.any;

import org.hibernate.annotations.AnyMetaDef;
import org.hibernate.annotations.MetaValue;

IntegerProperty ageProperty = new IntegerProperty();
ageProperty.setId( 1L );
ageProperty.setName( "age" );
ageProperty.setValue( 23 );

session.persist( ageProperty );

StringProperty nameProperty = new StringProperty();
nameProperty.setId( 1L );
nameProperty.setName( "name" );
nameProperty.setValue( "John Doe" );

session.persist( nameProperty );

PropertyHolder namePropertyHolder = new PropertyHolder();
namePropertyHolder.setId( 1L );
namePropertyHolder.setProperty( nameProperty );

session.persist( namePropertyHolder );

INSERT INTO integer_property
       ( "name", "value", id )
VALUES ( 'age', 23, 1 )

INSERT INTO string_property
       ( "name", "value", id )
VALUES ( 'name', 'John Doe', 1 )

INSERT INTO property_holder
       ( property_type, property_id, id )
VALUES ( 'S', 1, 1 )

PropertyHolder propertyHolder = session.get( PropertyHolder.class, 1L );

assertEquals("name", propertyHolder.getProperty().getName());
assertEquals("John Doe", propertyHolder.getProperty().getValue());

SELECT ph.id AS id1_1_0_,
       ph.property_type AS property2_1_0_,
       ph.property_id AS property3_1_0_
FROM   property_holder ph
WHERE  ph.id = 1


SELECT sp.id AS id1_2_0_,
       sp."name" AS name2_2_0_,
       sp."value" AS value3_2_0_
FROM   string_property sp
WHERE  sp.id = 1

@Entity(name = "User")
@Table(name = "users")
public static class User {

	@Id
	private Long id;

	private String firstName;

	private String lastName;

	private String phoneNumber;

	@ManyToOne
	@JoinFormula( "REGEXP_REPLACE(phoneNumber, '\\+(\\d+)-.*', '\\1')::int" )
	private Country country;

	//Getters and setters omitted for brevity

}

@Entity(name = "Country")
@Table(name = "countries")
public static class Country {

	@Id
	private Integer id;

	private String name;

	//Getters and setters, equals and hashCode methods omitted for brevity

}

CREATE TABLE countries (
    id int4 NOT NULL,
    name VARCHAR(255),
    PRIMARY KEY ( id )
)

CREATE TABLE users (
    id int8 NOT NULL,
    firstName VARCHAR(255),
    lastName VARCHAR(255),
    phoneNumber VARCHAR(255),
    PRIMARY KEY ( id )
)

Country US = new Country();
US.setId( 1 );
US.setName( "United States" );

Country Romania = new Country();
Romania.setId( 40 );
Romania.setName( "Romania" );

doInJPA( this::entityManagerFactory, entityManager -> {
	entityManager.persist( US );
	entityManager.persist( Romania );
} );

doInJPA( this::entityManagerFactory, entityManager -> {
	User user1 = new User( );
	user1.setId( 1L );
	user1.setFirstName( "John" );
	user1.setLastName( "Doe" );
	user1.setPhoneNumber( "+1-234-5678" );
	entityManager.persist( user1 );

	User user2 = new User( );
	user2.setId( 2L );
	user2.setFirstName( "Vlad" );
	user2.setLastName( "Mihalcea" );
	user2.setPhoneNumber( "+40-123-4567" );
	entityManager.persist( user2 );
} );

doInJPA( this::entityManagerFactory, entityManager -> {
	log.info( "Fetch User entities" );

	User john = entityManager.find( User.class, 1L );
	assertEquals( US, john.getCountry());

	User vlad = entityManager.find( User.class, 2L );
	assertEquals( Romania, vlad.getCountry());
} );

-- Fetch User entities

SELECT
    u.id as id1_1_0_,
    u.firstName as firstNam2_1_0_,
    u.lastName as lastName3_1_0_,
    u.phoneNumber as phoneNum4_1_0_,
    REGEXP_REPLACE(u.phoneNumber, '\+(\d+)-.*', '\1')::int as formula1_0_,
    c.id as id1_0_1_,
    c.name as name2_0_1_
FROM
    users u
LEFT OUTER JOIN
    countries c
        ON REGEXP_REPLACE(u.phoneNumber, '\+(\d+)-.*', '\1')::int = c.id
WHERE
    u.id=?

-- binding parameter [1] as [BIGINT] - [1]

SELECT
    u.id as id1_1_0_,
    u.firstName as firstNam2_1_0_,
    u.lastName as lastName3_1_0_,
    u.phoneNumber as phoneNum4_1_0_,
    REGEXP_REPLACE(u.phoneNumber, '\+(\d+)-.*', '\1')::int as formula1_0_,
    c.id as id1_0_1_,
    c.name as name2_0_1_
FROM
    users u
LEFT OUTER JOIN
    countries c
        ON REGEXP_REPLACE(u.phoneNumber, '\+(\d+)-.*', '\1')::int = c.id
WHERE
    u.id=?

-- binding parameter [1] as [BIGINT] - [2]

@Entity(name = "User")
@Table(name = "users")
public static class User {

	@Id
	private Long id;

	private String firstName;

	private String lastName;

	private String language;

	@ManyToOne
	@JoinColumnOrFormula( column =
		@JoinColumn(
			name = "language",
			referencedColumnName = "primaryLanguage",
			insertable = false,
			updatable = false
		)
	)
	@JoinColumnOrFormula( formula =
		@JoinFormula(
			value = "true",
			referencedColumnName = "is_default"
		)
	)
	private Country country;

	//Getters and setters omitted for brevity

}

@Entity(name = "Country")
@Table(name = "countries")
public static class Country implements Serializable {

	@Id
	private Integer id;

	private String name;

	private String primaryLanguage;

	@Column(name = "is_default")
	private boolean _default;

	//Getters and setters, equals and hashCode methods omitted for brevity

}

CREATE TABLE countries (
    id INTEGER NOT NULL,
    is_default boolean,
    name VARCHAR(255),
    primaryLanguage VARCHAR(255),
    PRIMARY KEY ( id )
)

CREATE TABLE users (
    id BIGINT NOT NULL,
    firstName VARCHAR(255),
    language VARCHAR(255),
    lastName VARCHAR(255),
    PRIMARY KEY ( id )
)

Country US = new Country();
US.setId( 1 );
US.setDefault( true );
US.setPrimaryLanguage( "English" );
US.setName( "United States" );

Country Romania = new Country();
Romania.setId( 40 );
Romania.setDefault( true );
Romania.setName( "Romania" );
Romania.setPrimaryLanguage( "Romanian" );

doInJPA( this::entityManagerFactory, entityManager -> {
	entityManager.persist( US );
	entityManager.persist( Romania );
} );

doInJPA( this::entityManagerFactory, entityManager -> {
	User user1 = new User( );
	user1.setId( 1L );
	user1.setFirstName( "John" );
	user1.setLastName( "Doe" );
	user1.setLanguage( "English" );
	entityManager.persist( user1 );

	User user2 = new User( );
	user2.setId( 2L );
	user2.setFirstName( "Vlad" );
	user2.setLastName( "Mihalcea" );
	user2.setLanguage( "Romanian" );
	entityManager.persist( user2 );

} );

doInJPA( this::entityManagerFactory, entityManager -> {
	log.info( "Fetch User entities" );

	User john = entityManager.find( User.class, 1L );
	assertEquals( US, john.getCountry());

	User vlad = entityManager.find( User.class, 2L );
	assertEquals( Romania, vlad.getCountry());
} );

SELECT
    u.id as id1_1_0_,
    u.language as language3_1_0_,
    u.firstName as firstNam2_1_0_,
    u.lastName as lastName4_1_0_,
    1 as formula1_0_,
    c.id as id1_0_1_,
    c.is_default as is_defau2_0_1_,
    c.name as name3_0_1_,
    c.primaryLanguage as primaryL4_0_1_
FROM
    users u
LEFT OUTER JOIN
    countries c
        ON u.language = c.primaryLanguage
        AND 1 = c.is_default
WHERE
    u.id = ?

-- binding parameter [1] as [BIGINT] - [1]

SELECT
    u.id as id1_1_0_,
    u.language as language3_1_0_,
    u.firstName as firstNam2_1_0_,
    u.lastName as lastName4_1_0_,
    1 as formula1_0_,
    c.id as id1_0_1_,
    c.is_default as is_defau2_0_1_,
    c.name as name3_0_1_,
    c.primaryLanguage as primaryL4_0_1_
FROM
    users u
LEFT OUTER JOIN
    countries c
        ON u.language = c.primaryLanguage
        AND 1 = c.is_default
WHERE
    u.id = ?

-- binding parameter [1] as [BIGINT] - [2]

public interface Coordinates {
	double x();
	double y();
}

@Embeddable
public static class GPS implements Coordinates {

	private double latitude;

	private double longitude;

	private GPS() {
	}

	public GPS(double latitude, double longitude) {
		this.latitude = latitude;
		this.longitude = longitude;
	}

	@Override
	public double x() {
		return latitude;
	}

	@Override
	public double y() {
		return longitude;
	}
}

@Entity(name = "City")
public static class City {

	@Id
	@GeneratedValue
	private Long id;

	private String name;

	@Embedded
	@Target( GPS.class )
	private Coordinates coordinates;

	//Getters and setters omitted for brevity

}

doInJPA( this::entityManagerFactory, entityManager -> {

	City cluj = new City();
	cluj.setName( "Cluj" );
	cluj.setCoordinates( new GPS( 46.77120, 23.62360 ) );

	entityManager.persist( cluj );
} );

doInJPA( this::entityManagerFactory, entityManager -> {

	City cluj = entityManager.find( City.class, 1L );

	assertEquals( 46.77120, cluj.getCoordinates().x(), 0.00001 );
	assertEquals( 23.62360, cluj.getCoordinates().y(), 0.00001 );
} );

SELECT
    c.id as id1_0_0_,
    c.latitude as latitude2_0_0_,
    c.longitude as longitud3_0_0_,
    c.name as name4_0_0_
FROM
    City c
WHERE
    c.id = ?

-- binding parameter [1] as [BIGINT] - [1]

-- extracted value ([latitude2_0_0_] : [DOUBLE])  - [46.7712]
-- extracted value ([longitud3_0_0_] : [DOUBLE])  - [23.6236]
-- extracted value ([name4_0_0_]     : [VARCHAR]) - [Cluj]

@Embeddable
public static class GPS {

	private double latitude;

	private double longitude;

	@Parent
	private City city;

	//Getters and setters omitted for brevity

}

@Entity(name = "City")
public static class City {

	@Id
	@GeneratedValue
	private Long id;

	private String name;

	@Embedded
	@Target( GPS.class )
	private GPS coordinates;

	//Getters and setters omitted for brevity

}

doInJPA( this::entityManagerFactory, entityManager -> {

	City cluj = new City();
	cluj.setName( "Cluj" );
	cluj.setCoordinates( new GPS( 46.77120, 23.62360 ) );

	entityManager.persist( cluj );
} );

doInJPA( this::entityManagerFactory, entityManager -> {

	City cluj = entityManager.find( City.class, 1L );

	assertSame( cluj, cluj.getCoordinates().getCity() );
} );

@Entity(name = "Book")
public static class Book {

	@Id
	@GeneratedValue
	private Long id;

	private String title;

	private String author;

	private Publisher publisher;

	//Getters and setters are omitted for brevity
}

@Embeddable
public static class Publisher {

	@Column(name = "publisher_name")
	private String name;

	@Column(name = "publisher_country")
	private String country;

	//Getters and setters, equals and hashCode methods omitted for brevity

}

create table Book (
    id bigint not null,
    author varchar(255),
    publisher_country varchar(255),
    publisher_name varchar(255),
    title varchar(255),
    primary key (id)
)

@Entity(name = "Book")
public static class Book {

	@Id
	@GeneratedValue
	private Long id;

	private String title;

	private String author;

	@Column(name = "publisher_name")
	private String publisherName;

	@Column(name = "publisher_country")
	private String publisherCountry;

	//Getters and setters are omitted for brevity
}

@Embeddable
public static class Publisher {

	private String name;

	@ManyToOne(fetch = FetchType.LAZY)
	private Country country;

	//Getters and setters, equals and hashCode methods omitted for brevity

}

@Entity(name = "Country")
public static class Country {

	@Id
	@GeneratedValue
	private Long id;

	@NaturalId
	private String name;

	//Getters and setters are omitted for brevity
}

create table Country (
    id bigint not null,
    name varchar(255),
    primary key (id)
)

alter table Country
    add constraint UK_p1n05aafu73sbm3ggsxqeditd
    unique (name)

@Entity(name = "Book")
@AttributeOverrides({
	@AttributeOverride(
		name = "ebookPublisher.name",
		column = @Column(name = "ebook_publisher_name")
	),
	@AttributeOverride(
		name = "paperBackPublisher.name",
		column = @Column(name = "paper_back_publisher_name")
	)
})
@AssociationOverrides({
	@AssociationOverride(
		name = "ebookPublisher.country",
		joinColumns = @JoinColumn(name = "ebook_publisher_country_id")
	),
	@AssociationOverride(
		name = "paperBackPublisher.country",
		joinColumns = @JoinColumn(name = "paper_back_publisher_country_id")
	)
})
public static class Book {

	@Id
	@GeneratedValue
	private Long id;

	private String title;

	private String author;

	private Publisher ebookPublisher;

	private Publisher paperBackPublisher;

	//Getters and setters are omitted for brevity
}

create table Book (
    id bigint not null,
    author varchar(255),
    ebook_publisher_name varchar(255),
    paper_back_publisher_name varchar(255),
    title varchar(255),
    ebook_publisher_country_id bigint,
    paper_back_publisher_country_id bigint,
    primary key (id)
)

alter table Book
    add constraint FKm39ibh5jstybnslaoojkbac2g
    foreign key (ebook_publisher_country_id)
    references Country

alter table Book
    add constraint FK7kqy9da323p7jw7wvqgs6aek7
    foreign key (paper_back_publisher_country_id)
    references Country

@Entity(name = "Book")
public static class Book {

	@Id
	@GeneratedValue
	private Long id;

	private String title;

	private String author;

	private Publisher ebookPublisher;

	private Publisher paperBackPublisher;

	//Getters and setters are omitted for brevity
}

@Embeddable
public static class Publisher {

	private String name;

	@ManyToOne(fetch = FetchType.LAZY)
	private Country country;

	//Getters and setters, equals and hashCode methods omitted for brevity
}

@Entity(name = "Country")
public static class Country {

	@Id
	@GeneratedValue
	private Long id;

	@NaturalId
	private String name;

	//Getters and setters are omitted for brevity
}

metadataBuilder.applyImplicitNamingStrategy(
	ImplicitNamingStrategyComponentPathImpl.INSTANCE
);

@Id
private Long id;

@Entity(name = "Book")
public static class Book {

	@Id
	private Long id;

	private String title;

	private String author;

	//Getters and setters are omitted for brevity
}

@Entity(name = "Book")
@Table(
	catalog = "public",
	schema = "store",
	name = "book"
)
public static class Book {

	@Id
	private Long id;

	private String title;

	private String author;

	//Getters and setters are omitted for brevity
}

Book book1 = entityManager.find( Book.class, 1L );
Book book2 = entityManager.find( Book.class, 1L );

assertTrue( book1 == book2 );

@Entity(name = "Library")
public static class Library {

	@Id
	private Long id;

	private String name;

	@OneToMany(cascade = CascadeType.ALL)
	@JoinColumn(name = "book_id")
	private Set<Book> books = new HashSet<>();

	//Getters and setters are omitted for brevity
}

Library library = entityManager.find( Library.class, 1L );

Book book1 = entityManager.find( Book.class, 1L );
Book book2 = entityManager.find( Book.class, 1L );

library.getBooks().add( book1 );
library.getBooks().add( book2 );

assertEquals( 1, library.getBooks().size() );

Book book1 = doInJPA( this::entityManagerFactory, entityManager -> {
	return entityManager.find( Book.class, 1L );
} );

Book book2 = doInJPA( this::entityManagerFactory, entityManager -> {
	return entityManager.find( Book.class, 1L );
} );

assertFalse( book1 == book2 );

doInJPA( this::entityManagerFactory, entityManager -> {
	Set<Book> books = new HashSet<>();

	books.add( book1 );
	books.add( book2 );

	assertEquals( 2, books.size() );
} );

Library library = entityManager.find( Library.class, 1L );

Book book1 = new Book();
book1.setId( 100L );
book1.setTitle( "High-Performance Java Persistence" );

Book book2 = new Book();
book2.setId( 101L );
book2.setTitle( "Java Persistence with Hibernate" );

library.getBooks().add( book1 );
library.getBooks().add( book2 );

assertEquals( 2, library.getBooks().size() );

@Entity(name = "Library")
public static class Library {

	@Id
	private Long id;

	private String name;

	@OneToMany(cascade = CascadeType.ALL)
	@JoinColumn(name = "book_id")
	private Set<Book> books = new HashSet<>();

	//Getters and setters are omitted for brevity
}

@Entity(name = "Book")
public static class Book {

	@Id
	@GeneratedValue
	private Long id;

	private String title;

	private String author;

	//Getters and setters are omitted for brevity

	@Override
	public boolean equals(Object o) {
		if ( this == o ) {
			return true;
		}
		if ( o == null || getClass() != o.getClass() ) {
			return false;
		}
		Book book = (Book) o;
		return Objects.equals( id, book.id );
	}

	@Override
	public int hashCode() {
		return Objects.hash( id );
	}
}

Book book1 = new Book();
book1.setTitle( "High-Performance Java Persistence" );

Book book2 = new Book();
book2.setTitle( "Java Persistence with Hibernate" );

Library library = doInJPA( this::entityManagerFactory, entityManager -> {
	Library _library = entityManager.find( Library.class, 1L );

	_library.getBooks().add( book1 );
	_library.getBooks().add( book2 );

	return _library;
} );

assertFalse( library.getBooks().contains( book1 ) );
assertFalse( library.getBooks().contains( book2 ) );

Book book1 = new Book();
book1.setTitle( "High-Performance Java Persistence" );

Book book2 = new Book();
book2.setTitle( "Java Persistence with Hibernate" );

Library library = doInJPA( this::entityManagerFactory, entityManager -> {
	Library _library = entityManager.find( Library.class, 1L );

	entityManager.persist( book1 );
	entityManager.persist( book2 );
	entityManager.flush();

	_library.getBooks().add( book1 );
	_library.getBooks().add( book2 );

	return _library;
} );

assertTrue( library.getBooks().contains( book1 ) );
assertTrue( library.getBooks().contains( book2 ) );

@Entity(name = "Library")
public static class Library {

	@Id
	private Long id;

	private String name;

	@OneToMany(cascade = CascadeType.ALL)
	@JoinColumn(name = "book_id")
	private Set<Book> books = new HashSet<>();

	//Getters and setters are omitted for brevity
}

@Entity(name = "Book")
public static class Book {

	@Id
	@GeneratedValue
	private Long id;

	private String title;

	private String author;

	@NaturalId
	private String isbn;

	//Getters and setters are omitted for brevity

	@Override
	public boolean equals(Object o) {
		if ( this == o ) {
			return true;
		}
		if ( o == null || getClass() != o.getClass() ) {
			return false;
		}
		Book book = (Book) o;
		return Objects.equals( isbn, book.isbn );
	}

	@Override
	public int hashCode() {
		return Objects.hash( isbn );
	}
}

Book book1 = new Book();
book1.setTitle( "High-Performance Java Persistence" );
book1.setIsbn( "978-9730228236" );

Library library = doInJPA( this::entityManagerFactory, entityManager -> {
	Library _library = entityManager.find( Library.class, 1L );

	_library.getBooks().add( book1 );

	return _library;
} );

assertTrue( library.getBooks().contains( book1 ) );

@Entity(name = "Client")
@Table(name = "client")
public static class Client {

	@Id
	private Long id;

	@Column(name = "first_name")
	private String firstName;

	@Column(name = "last_name")
	private String lastName;

	//Getters and setters omitted for brevity

}

@Entity(name = "Account")
@Table(name = "account")
public static class Account {

	@Id
	private Long id;

	@ManyToOne
	private Client client;

	private String description;

	//Getters and setters omitted for brevity

}

@Entity(name = "AccountTransaction")
@Table(name = "account_transaction")
public static class AccountTransaction {

	@Id
	@GeneratedValue
	private Long id;

	@ManyToOne
	private Account account;

	private Integer cents;

	private String description;

	//Getters and setters omitted for brevity

}

@Entity(name = "AccountSummary")
@Subselect(
	"select " +
	"	a.id as id, " +
	"	concat(concat(c.first_name, ' '), c.last_name) as clientName, " +
	"	sum(at.cents) as balance " +
	"from account a " +
	"join client c on c.id = a.client_id " +
	"join account_transaction at on a.id = at.account_id " +
	"group by a.id, concat(concat(c.first_name, ' '), c.last_name)"
)
@Synchronize( {"client", "account", "account_transaction"} )
public static class AccountSummary {

	@Id
	private Long id;

	private String clientName;

	private int balance;

	//Getters and setters omitted for brevity

}

doInJPA( this::entityManagerFactory, entityManager -> {
	Client client = new Client();
	client.setId( 1L );
	client.setFirstName( "John" );
	client.setLastName( "Doe" );
	entityManager.persist( client );

	Account account = new Account();
	account.setId( 1L );
	account.setClient( client );
	account.setDescription( "Checking account" );
	entityManager.persist( account );

	AccountTransaction transaction = new AccountTransaction();
	transaction.setAccount( account );
	transaction.setDescription( "Salary" );
	transaction.setCents( 100 * 7000 );
	entityManager.persist( transaction );

	AccountSummary summary = entityManager.createQuery(
		"select s " +
		"from AccountSummary s " +
		"where s.id = :id", AccountSummary.class)
	.setParameter( "id", account.getId() )
	.getSingleResult();

	assertEquals( "John Doe", summary.getClientName() );
	assertEquals( 100 * 7000, summary.getBalance() );
} );

doInJPA( this::entityManagerFactory, entityManager -> {
	AccountSummary summary = entityManager.find( AccountSummary.class, 1L );
	assertEquals( "John Doe", summary.getClientName() );
	assertEquals( 100 * 7000, summary.getBalance() );

	AccountTransaction transaction = new AccountTransaction();
	transaction.setAccount( entityManager.getReference( Account.class, 1L ) );
	transaction.setDescription( "Shopping" );
	transaction.setCents( -100 * 2200 );
	entityManager.persist( transaction );
	entityManager.flush();

	entityManager.refresh( summary );
	assertEquals( 100 * 4800, summary.getBalance() );
} );

public interface Identifiable {

	Long getId();

	void setId(Long id);
}

@Entity( name = "Book" )
@Proxy(proxyClass = Identifiable.class)
public static final class Book implements Identifiable {

	@Id
	private Long id;

	private String title;

	private String author;

	@Override
	public Long getId() {
		return id;
	}

	@Override
	public void setId(Long id) {
		this.id = id;
	}

	//Other getters and setters omitted for brevity
}

doInHibernate( this::sessionFactory, session -> {
	Book book = new Book();
	book.setId( 1L );
	book.setTitle( "High-Performance Java Persistence" );
	book.setAuthor( "Vlad Mihalcea" );

	session.persist( book );
} );

doInHibernate( this::sessionFactory, session -> {
	Identifiable book = session.getReference( Book.class, 1L );

	assertTrue(
		"Loaded entity is not an instance of the proxy interface",
		book instanceof Identifiable
	);
	assertFalse(
		"Proxy class was not created",
		book instanceof Book
	);
} );

insert
into
    Book
    (author, title, id)
values
    (?, ?, ?)

-- binding parameter [1] as [VARCHAR] - [Vlad Mihalcea]
-- binding parameter [2] as [VARCHAR] - [High-Performance Java Persistence]
-- binding parameter [3] as [BIGINT]  - [1]

@Entity
@Tuplizer(impl = DynamicEntityTuplizer.class)
public interface Cuisine {

    @Id
    @GeneratedValue
    Long getId();
    void setId(Long id);

    String getName();
    void setName(String name);

    @Tuplizer(impl = DynamicEmbeddableTuplizer.class)
    Country getCountry();
    void setCountry(Country country);
}

@Embeddable
public interface Country {

    @Column(name = "CountryName")
    String getName();

    void setName(String name);
}

public class DynamicEntityTuplizer extends PojoEntityTuplizer {

    public DynamicEntityTuplizer(
            EntityMetamodel entityMetamodel,
            PersistentClass mappedEntity) {
        super( entityMetamodel, mappedEntity );
    }

    @Override
    protected Instantiator buildInstantiator(
            EntityMetamodel entityMetamodel,
            PersistentClass persistentClass) {
        return new DynamicInstantiator(
            persistentClass.getClassName()
        );
    }

    @Override
    protected ProxyFactory buildProxyFactory(
            PersistentClass persistentClass,
            Getter idGetter,
            Setter idSetter) {
        return super.buildProxyFactory(
            persistentClass, idGetter,
            idSetter
        );
    }
}

public class DynamicEmbeddableTuplizer
        extends PojoComponentTuplizer {

    public DynamicEmbeddableTuplizer(Component embeddable) {
        super( embeddable );
    }

    protected Instantiator buildInstantiator(Component embeddable) {
        return new DynamicInstantiator(
            embeddable.getComponentClassName()
        );
    }
}

public class DynamicInstantiator
        implements Instantiator {

    private final Class targetClass;

    public DynamicInstantiator(String targetClassName) {
        try {
            this.targetClass = Class.forName( targetClassName );
        }
        catch (ClassNotFoundException e) {
            throw new HibernateException( e );
        }
    }

    public Object instantiate(Serializable id) {
        return ProxyHelper.newProxy( targetClass, id );
    }

    public Object instantiate() {
        return instantiate( null );
    }

    public boolean isInstance(Object object) {
        try {
            return targetClass.isInstance( object );
        }
        catch( Throwable t ) {
            throw new HibernateException(
                "could not get handle to entity as interface : " + t
            );
        }
    }
}

public class ProxyHelper {

    public static <T> T newProxy(Class<T> targetClass, Serializable id) {
        return ( T ) Proxy.newProxyInstance(
            targetClass.getClassLoader(),
            new Class[] {
                targetClass
            },
            new DataProxyHandler(
                targetClass.getName(),
                id
            )
        );
    }

    public static String extractEntityName(Object object) {
        if ( Proxy.isProxyClass( object.getClass() ) ) {
            InvocationHandler handler = Proxy.getInvocationHandler(
                object
            );
            if ( DataProxyHandler.class.isAssignableFrom( handler.getClass() ) ) {
                DataProxyHandler myHandler = (DataProxyHandler) handler;
                return myHandler.getEntityName();
            }
        }
        return null;
    }
}

public final class DataProxyHandler implements InvocationHandler {

    private String entityName;

    private Map<String, Object> data = new HashMap<>();

    public DataProxyHandler(String entityName, Serializable id) {
        this.entityName = entityName;
        data.put( "Id", id );
    }

    public Object invoke(Object proxy, Method method, Object[] args) throws Throwable {
        String methodName = method.getName();
        if ( methodName.startsWith( "set" ) ) {
            String propertyName = methodName.substring( 3 );
            data.put( propertyName, args[0] );
        }
        else if ( methodName.startsWith( "get" ) ) {
            String propertyName = methodName.substring( 3 );
            return data.get( propertyName );
        }
        else if ( "toString".equals( methodName ) ) {
            return entityName + "#" + data.get( "Id" );
        }
        else if ( "hashCode".equals( methodName ) ) {
            return this.hashCode();
        }
        return null;
    }

    public String getEntityName() {
        return entityName;
    }
}

Cuisine _cuisine = doInHibernateSessionBuilder(
		() -> sessionFactory()
				.withOptions()
				.interceptor( new EntityNameInterceptor() ),
		session -> {
	Cuisine cuisine = ProxyHelper.newProxy( Cuisine.class, null );
	cuisine.setName( "Française" );

	Country country = ProxyHelper.newProxy( Country.class, null );
	country.setName( "France" );

	cuisine.setCountry( country );
	session.persist( cuisine );

	return cuisine;
} );

doInHibernateSessionBuilder(
		() -> sessionFactory()
				.withOptions()
				.interceptor( new EntityNameInterceptor() ),
		session -> {
	Cuisine cuisine = session.get( Cuisine.class, _cuisine.getId() );

	assertEquals( "Française", cuisine.getName() );
	assertEquals( "France", cuisine.getCountry().getName() );
} );

@Entity
@Persister( impl = EntityPersister.class )
public class Author {

    @Id
    public Integer id;

    @OneToMany( mappedBy = "author" )
    @Persister( impl = CollectionPersister.class )
    public Set<Book> books = new HashSet<>();

    //Getters and setters omitted for brevity

    public void addBook(Book book) {
        this.books.add( book );
        book.setAuthor( this );
    }
}

@Entity
@Persister( impl = EntityPersister.class )
public class Book {

    @Id
    public Integer id;

    private String title;

    @ManyToOne(fetch = FetchType.LAZY)
    public Author author;

    //Getters and setters omitted for brevity
}

@Entity(name = "SystemUser")
public static class SystemUser {

	@EmbeddedId
	private PK pk;

	private String name;

	//Getters and setters are omitted for brevity
}

@Embeddable
public static class PK implements Serializable {

	private String subsystem;

	private String username;

	public PK(String subsystem, String username) {
		this.subsystem = subsystem;
		this.username = username;
	}

	private PK() {
	}

	@Override
	public boolean equals(Object o) {
		if ( this == o ) {
			return true;
		}
		if ( o == null || getClass() != o.getClass() ) {
			return false;
		}
		PK pk = (PK) o;
		return Objects.equals( subsystem, pk.subsystem ) &&
				Objects.equals( username, pk.username );
	}

	@Override
	public int hashCode() {
		return Objects.hash( subsystem, username );
	}
}

@Entity(name = "SystemUser")
public static class SystemUser {

	@EmbeddedId
	private PK pk;

	private String name;

	//Getters and setters are omitted for brevity
}

@Entity(name = "Subsystem")
public static class Subsystem {

	@Id
	private String id;

	private String description;

	//Getters and setters are omitted for brevity
}

@Embeddable
public static class PK implements Serializable {

	@ManyToOne(fetch = FetchType.LAZY)
	private Subsystem subsystem;

	private String username;

	public PK(Subsystem subsystem, String username) {
		this.subsystem = subsystem;
		this.username = username;
	}

	private PK() {
	}

	@Override
	public boolean equals(Object o) {
		if ( this == o ) {
			return true;
		}
		if ( o == null || getClass() != o.getClass() ) {
			return false;
		}
		PK pk = (PK) o;
		return Objects.equals( subsystem, pk.subsystem ) &&
				Objects.equals( username, pk.username );
	}

	@Override
	public int hashCode() {
		return Objects.hash( subsystem, username );
	}
}

@Entity(name = "SystemUser")
@IdClass( PK.class )
public static class SystemUser {

	@Id
	private String subsystem;

	@Id
	private String username;

	private String name;

	public PK getId() {
		return new PK(
			subsystem,
			username
		);
	}

	public void setId(PK id) {
		this.subsystem = id.getSubsystem();
		this.username = id.getUsername();
	}

	//Getters and setters are omitted for brevity
}

public static class PK implements Serializable {

	private String subsystem;

	private String username;

	public PK(String subsystem, String username) {
		this.subsystem = subsystem;
		this.username = username;
	}

	private PK() {
	}

	//Getters and setters are omitted for brevity

	@Override
	public boolean equals(Object o) {
		if ( this == o ) {
			return true;
		}
		if ( o == null || getClass() != o.getClass() ) {
			return false;
		}
		PK pk = (PK) o;
		return Objects.equals( subsystem, pk.subsystem ) &&
				Objects.equals( username, pk.username );
	}

	@Override
	public int hashCode() {
		return Objects.hash( subsystem, username );
	}
}

@Entity(name = "SystemUser")
@IdClass( PK.class )
public static class SystemUser {

	@Id
	@ManyToOne(fetch = FetchType.LAZY)
	private Subsystem subsystem;

	@Id
	private String username;

	private String name;

	//Getters and setters are omitted for brevity
}

@Entity(name = "Subsystem")
public static class Subsystem {

	@Id
	private String id;

	private String description;

	//Getters and setters are omitted for brevity
}

public static class PK implements Serializable {

	private Subsystem subsystem;

	private String username;

	public PK(Subsystem subsystem, String username) {
		this.subsystem = subsystem;
		this.username = username;
	}

	private PK() {
	}

	//Getters and setters are omitted for brevity
}

@Entity(name = "SystemUser")
@IdClass( PK.class )
public static class SystemUser {

	@Id
	private String subsystem;

	@Id
	private String username;

	@Id
	@GeneratedValue
	private Integer registrationId;

	private String name;

	public PK getId() {
		return new PK(
			subsystem,
			username,
			registrationId
		);
	}

	public void setId(PK id) {
		this.subsystem = id.getSubsystem();
		this.username = id.getUsername();
		this.registrationId = id.getRegistrationId();
	}

	//Getters and setters are omitted for brevity
}

public static class PK implements Serializable {

	private String subsystem;

	private String username;

	private Integer registrationId;

	public PK(String subsystem, String username) {
		this.subsystem = subsystem;
		this.username = username;
	}

	public PK(String subsystem, String username, Integer registrationId) {
		this.subsystem = subsystem;
		this.username = username;
		this.registrationId = registrationId;
	}

	private PK() {
	}

	//Getters and setters are omitted for brevity

	@Override
	public boolean equals(Object o) {
		if ( this == o ) {
			return true;
		}
		if ( o == null || getClass() != o.getClass() ) {
			return false;
		}
		PK pk = (PK) o;
		return Objects.equals( subsystem, pk.subsystem ) &&
				Objects.equals( username, pk.username ) &&
				Objects.equals( registrationId, pk.registrationId );
	}

	@Override
	public int hashCode() {
		return Objects.hash( subsystem, username, registrationId );
	}
}

@Entity(name = "Book")
public static class Book implements Serializable {

	@Id
	@ManyToOne(fetch = FetchType.LAZY)
	private Author author;

	@Id
	@ManyToOne(fetch = FetchType.LAZY)
	private Publisher publisher;

	@Id
	private String title;

	public Book(Author author, Publisher publisher, String title) {
		this.author = author;
		this.publisher = publisher;
		this.title = title;
	}

	private Book() {
	}

	//Getters and setters are omitted for brevity


	@Override
	public boolean equals(Object o) {
		if ( this == o ) {
			return true;
		}
		if ( o == null || getClass() != o.getClass() ) {
			return false;
		}
		Book book = (Book) o;
		return Objects.equals( author, book.author ) &&
				Objects.equals( publisher, book.publisher ) &&
				Objects.equals( title, book.title );
	}

	@Override
	public int hashCode() {
		return Objects.hash( author, publisher, title );
	}
}

@Entity(name = "Author")
public static class Author implements Serializable {

	@Id
	private String name;

	//Getters and setters are omitted for brevity

	@Override
	public boolean equals(Object o) {
		if ( this == o ) {
			return true;
		}
		if ( o == null || getClass() != o.getClass() ) {
			return false;
		}
		Author author = (Author) o;
		return Objects.equals( name, author.name );
	}

	@Override
	public int hashCode() {
		return Objects.hash( name );
	}
}

@Entity(name = "Publisher")
public static class Publisher implements Serializable {

	@Id
	private String name;

	//Getters and setters are omitted for brevity

	@Override
	public boolean equals(Object o) {
		if ( this == o ) {
			return true;
		}
		if ( o == null || getClass() != o.getClass() ) {
			return false;
		}
		Publisher publisher = (Publisher) o;
		return Objects.equals( name, publisher.name );
	}

	@Override
	public int hashCode() {
		return Objects.hash( name );
	}
}

Book book = entityManager.find( Book.class, new Book(
	author,
	publisher,
	"High-Performance Java Persistence"
) );

assertEquals( "Vlad Mihalcea", book.getAuthor().getName() );

@Entity(name = "Product")
public static class Product {

	@Id
	@GeneratedValue(
		strategy = GenerationType.SEQUENCE
	)
	private Long id;

	@Column(name = "product_name")
	private String name;

	//Getters and setters are omitted for brevity

}

@Entity(name = "Product")
public static class Product {

	@Id
	@GeneratedValue(
		strategy = GenerationType.SEQUENCE,
		generator = "sequence-generator"
	)
	@SequenceGenerator(
		name = "sequence-generator",
		sequenceName = "product_sequence"
	)
	private Long id;

	@Column(name = "product_name")
	private String name;

	//Getters and setters are omitted for brevity

}

@Entity(name = "Product")
public static class Product {

	@Id
	@GeneratedValue(
		strategy = GenerationType.SEQUENCE,
		generator = "sequence-generator"
	)
	@SequenceGenerator(
		name = "sequence-generator",
		sequenceName = "product_sequence",
		allocationSize = 5
	)
	private Long id;

	@Column(name = "product_name")
	private String name;

	//Getters and setters are omitted for brevity

}

@Entity(name = "Product")
public static class Product {

	@Id
	@GeneratedValue(
		strategy = GenerationType.TABLE
	)
	private Long id;

	@Column(name = "product_name")
	private String name;

	//Getters and setters are omitted for brevity

}

create table hibernate_sequences (
    sequence_name varchar2(255 char) not null,
    next_val number(19,0),
    primary key (sequence_name)
)

@Entity(name = "Product")
public static class Product {

	@Id
	@GeneratedValue(
		strategy = GenerationType.TABLE,
		generator = "table-generator"
	)
	@TableGenerator(
		name =  "table-generator",
		table = "table_identifier",
		pkColumnName = "table_name",
		valueColumnName = "product_id",
		allocationSize = 5
	)
	private Long id;

	@Column(name = "product_name")
	private String name;

	//Getters and setters are omitted for brevity

}

create table table_identifier (
    table_name varchar2(255 char) not null,
    product_id number(19,0),
    primary key (table_name)
)

for ( long i = 1; i <= 3; i++ ) {
	Product product = new Product();
	product.setName( String.format( "Product %d", i ) );
	entityManager.persist( product );
}

select
    tbl.product_id
from
    table_identifier tbl
where
    tbl.table_name = ?
for update

-- binding parameter [1] - [Product]

insert
into
    table_identifier
    (table_name, product_id)
values
    (?, ?)

-- binding parameter [1] - [Product]
-- binding parameter [2] - [1]

update
    table_identifier
set
    product_id= ?
where
    product_id= ?
    and table_name= ?

-- binding parameter [1] - [6]
-- binding parameter [2] - [1]

select
    tbl.product_id
from
    table_identifier tbl
where
    tbl.table_name= ? for update

update
    table_identifier
set
    product_id= ?
where
    product_id= ?
    and table_name= ?

-- binding parameter [1] - [11]
-- binding parameter [2] - [6]

insert
into
    Product
    (product_name, id)
values
    (?, ?)

-- binding parameter [1] as [VARCHAR] - [Product 1]
-- binding parameter [2] as [BIGINT]  - [1]

insert
into
    Product
    (product_name, id)
values
    (?, ?)

-- binding parameter [1] as [VARCHAR] - [Product 2]
-- binding parameter [2] as [BIGINT]  - [2]

insert
into
    Product
    (product_name, id)
values
    (?, ?)

-- binding parameter [1] as [VARCHAR] - [Product 3]
-- binding parameter [2] as [BIGINT]  - [3]

@Entity(name = "Book")
public static class Book {

	@Id
	@GeneratedValue
	private UUID id;

	private String title;

	private String author;

	//Getters and setters are omitted for brevity
}

@Entity(name = "Book")
public static class Book {

	@Id
	@GeneratedValue( generator = "custom-uuid" )
	@GenericGenerator(
		name = "custom-uuid",
		strategy = "org.hibernate.id.UUIDGenerator",
		parameters = {
			@Parameter(
				name = "uuid_gen_strategy_class",
				value = "org.hibernate.id.uuid.CustomVersionOneStrategy"
			)
		}
	)
	private UUID id;

	private String title;

	private String author;

	//Getters and setters are omitted for brevity
}

@Entity(name = "Product")
public static class Product {

	@Id
	@GeneratedValue(
		strategy = GenerationType.SEQUENCE,
		generator = "product_generator"
	)
	@GenericGenerator(
		name = "product_generator",
		strategy = "org.hibernate.id.enhanced.SequenceStyleGenerator",
		parameters = {
			@Parameter(name = "sequence_name", value = "product_sequence"),
			@Parameter(name = "initial_value", value = "1"),
			@Parameter(name = "increment_size", value = "3"),
			@Parameter(name = "optimizer", value = "pooled-lo")
		}
	)
	private Long id;

	@Column(name = "p_name")
	private String name;

	@Column(name = "p_number")
	private String number;

	//Getters and setters are omitted for brevity

}

for ( long i = 1; i <= 5; i++ ) {
	if(i % 3 == 0) {
		entityManager.flush();
	}
	Product product = new Product();
	product.setName( String.format( "Product %d", i ) );
	product.setNumber( String.format( "P_100_%d", i ) );
	entityManager.persist( product );
}

CALL NEXT VALUE FOR product_sequence

INSERT INTO Product (p_name, p_number, id)
VALUES (?, ?, ?)

-- binding parameter [1] as [VARCHAR] - [Product 1]
-- binding parameter [2] as [VARCHAR] - [P_100_1]
-- binding parameter [3] as [BIGINT]  - [1]

INSERT INTO Product (p_name, p_number, id)
VALUES (?, ?, ?)

-- binding parameter [1] as [VARCHAR] - [Product 2]
-- binding parameter [2] as [VARCHAR] - [P_100_2]
-- binding parameter [3] as [BIGINT]  - [2]

CALL NEXT VALUE FOR product_sequence

INSERT INTO Product (p_name, p_number, id)
VALUES (?, ?, ?)

-- binding parameter [1] as [VARCHAR] - [Product 3]
-- binding parameter [2] as [VARCHAR] - [P_100_3]
-- binding parameter [3] as [BIGINT]  - [3]

INSERT INTO Product (p_name, p_number, id)
VALUES (?, ?, ?)

-- binding parameter [1] as [VARCHAR] - [Product 4]
-- binding parameter [2] as [VARCHAR] - [P_100_4]
-- binding parameter [3] as [BIGINT]  - [4]

INSERT INTO Product (p_name, p_number, id)
VALUES (?, ?, ?)

-- binding parameter [1] as [VARCHAR] - [Product 5]
-- binding parameter [2] as [VARCHAR] - [P_100_5]
-- binding parameter [3] as [BIGINT]  - [5]

@Entity(name = "Person")
public static class Person  {

	@Id
	private Long id;

	@NaturalId
	private String registrationNumber;

	public Person() {}

	public Person(String registrationNumber) {
		this.registrationNumber = registrationNumber;
	}

	//Getters and setters are omitted for brevity
}

@Entity(name = "PersonDetails")
public static class PersonDetails  {

	@Id
	private Long id;

	private String nickName;

	@OneToOne
	@MapsId
	private Person person;

	//Getters and setters are omitted for brevity
}

doInJPA( this::entityManagerFactory, entityManager -> {
	Person person = new Person( "ABC-123" );
	person.setId( 1L );
	entityManager.persist( person );

	PersonDetails personDetails = new PersonDetails();
	personDetails.setNickName( "John Doe" );
	personDetails.setPerson( person );

	entityManager.persist( personDetails );
} );

doInJPA( this::entityManagerFactory, entityManager -> {
	PersonDetails personDetails = entityManager.find( PersonDetails.class, 1L );

	assertEquals("John Doe", personDetails.getNickName());
} );

@Entity(name = "Person")
public static class Person  {

	@Id
	private Long id;

	@NaturalId
	private String registrationNumber;

	public Person() {}

	public Person(String registrationNumber) {
		this.registrationNumber = registrationNumber;
	}

	//Getters and setters are omitted for brevity
}

@Entity(name = "PersonDetails")
public static class PersonDetails  {

	@Id
	private Long id;

	private String nickName;

	@OneToOne
	@PrimaryKeyJoinColumn
	private Person person;

	public void setPerson(Person person) {
		this.person = person;
		this.id = person.getId();
	}

	//Other getters and setters are omitted for brevity
}

@Entity(name = "Product")
@RowId("ROWID")
public static class Product {

	@Id
	private Long id;

	@Column(name = "`name`")
	private String name;

	@Column(name = "`number`")
	private String number;

	//Getters and setters are omitted for brevity

}

Product product = entityManager.find( Product.class, 1L );

product.setName( "Smart phone" );

SELECT
    p.id as id1_0_0_,
    p."name" as name2_0_0_,
    p."number" as number3_0_0_,
    p.ROWID as rowid_0_
FROM
    Product p
WHERE
    p.id = ?

-- binding parameter [1] as [BIGINT] - [1]

-- extracted value ([name2_0_0_] : [VARCHAR]) - [Mobile phone]
-- extracted value ([number3_0_0_] : [VARCHAR]) - [123-456-7890]
-- extracted ROWID value: AAAwkBAAEAAACP3AAA

UPDATE
    Product
SET
    "name" = ?,
    "number" = ?
WHERE
    ROWID = ?

-- binding parameter [1] as [VARCHAR] - [Smart phone]
-- binding parameter [2] as [VARCHAR] - [123-456-7890]
-- binding parameter [3] as ROWID     - [AAAwkBAAEAAACP3AAA]

@Entity(name = "Person")
public static class Person {

	@Id
	@GeneratedValue
	private Long id;

	//Getters and setters are omitted for brevity

}

@Entity(name = "Phone")
public static class Phone {

	@Id
	@GeneratedValue
	private Long id;

	@Column(name = "`number`")
	private String number;

	@ManyToOne
	@JoinColumn(name = "person_id",
			foreignKey = @ForeignKey(name = "PERSON_ID_FK")
	)
	private Person person;

	//Getters and setters are omitted for brevity

}

CREATE TABLE Person (
    id BIGINT NOT NULL ,
    PRIMARY KEY ( id )
)

CREATE TABLE Phone (
    id BIGINT NOT NULL ,
    number VARCHAR(255) ,
    person_id BIGINT ,
    PRIMARY KEY ( id )
 )

ALTER TABLE Phone
ADD CONSTRAINT PERSON_ID_FK
FOREIGN KEY (person_id) REFERENCES Person

Person person = new Person();
entityManager.persist( person );

Phone phone = new Phone( "123-456-7890" );
phone.setPerson( person );
entityManager.persist( phone );

entityManager.flush();
phone.setPerson( null );

INSERT INTO Person ( id )
VALUES ( 1 )

INSERT INTO Phone ( number, person_id, id )
VALUES ( '123-456-7890', 1, 2 )

UPDATE Phone
SET    number = '123-456-7890',
       person_id = NULL
WHERE  id = 2

@Entity(name = "Person")
@Table(name = "Person")
public static class Person {

	@Id
	private Integer id;
	private String name;

	@ManyToOne
	@NotFound(action = NotFoundAction.IGNORE)
	@JoinColumn(name = "city_fk", referencedColumnName = "id", foreignKey = @ForeignKey(value = ConstraintMode.NO_CONSTRAINT))
	private City city;

	//Getters and setters are omitted for brevity

}

@Entity(name = "City")
@Table(name = "City")
public static class City implements Serializable {

	@Id
	private Integer id;

	private String name;

	//Getters and setters are omitted for brevity

}

City newYork = new City( 1, "New York" );
entityManager.persist( newYork );

Person person = new Person( 1, "John Doe", newYork );
entityManager.persist( person );

Person person = entityManager.find(Person.class, 1);
assertEquals("New York", person.getCity().getName());

// the database allows this because there is no physical foreign-key
em.createQuery( "delete City" ).executeUpdate();

Person person = entityManager.find(Person.class, 1);

assertNull(null, person.getCity());

final List<Person> nullResults = entityManager
		.createQuery( "from Person p where p.city.id is null", Person.class )
		.list();
assertThat( nullResults.size(), is( 0 ) );

final List<Person> nonNullResults = entityManager
		.createQuery( "from Person p where p.city.id is not null", Person.class )
		.list();
assertThat( nonNullResults.size(), is( 0 ) );

final List<String> nullResults = entityManager
		.createQuery( "select p.name from Person p where fk( p.city ) is null", String.class )
		.list();

assertThat( nullResults.size(), is( 0 ) );

final List<String> nonNullResults = entityManager
		.createQuery( "select p.name from Person p where fk( p.city ) is not null", String.class )
		.list();
assertThat( nonNullResults.size(), is( 1 ) );
assertThat( nonNullResults.get( 0 ), is( "John Doe" ) );

Criteria criteria = session.createCriteria( Person.class );
ProjectionList projList = Projections.projectionList();
projList.add( Projections.property( "name" ) );
criteria.setProjection( projList );
criteria.add( Restrictions.fkIsNull( "city" ) );
final List<Integer> nullResults = criteria.list();

assertThat( nullResults.size(), is( 0 ) );

criteria = session.createCriteria( Person.class );
projList = Projections.projectionList();
projList.add( Projections.property( "name" ) );
criteria.setProjection( projList );
criteria.add( Restrictions.fkIsNotNull( "city" ) );
final List<String> nonNullResults = criteria.list();

assertThat( nonNullResults.size(), is( 1 ) );
assertThat( nonNullResults.get( 0 ), is( "John Doe" ) );

// selecting Person -> city Foreign key
criteria = session.createCriteria( Person.class );
projList = Projections.projectionList();
projList.add( Projections.fk( "city" ) );
criteria.setProjection( projList );
criteria.add( Restrictions.fkIsNotNull( "city" ) );

final List<Integer> foreigKeyResults = criteria.list();
assertThat( foreigKeyResults.size(), is( 1 ) );
assertThat( foreigKeyResults.get( 0 ), is( 1 ) );

person.getPhones().clear();
person.getPhones().add( "123-456-7890" );
person.getPhones().add( "456-000-1234" );

DELETE FROM Person_phones WHERE   Person_id = 1

INSERT INTO Person_phones ( Person_id, phones )
VALUES ( 1, '123-456-7890' )

INSERT INTO Person_phones  (Person_id, phones)
VALUES  ( 1, '456-000-1234' )

person.getPhones().remove( 0 );

DELETE FROM Person_phones WHERE Person_id = 1

INSERT INTO Person_phones ( Person_id, phones )
VALUES ( 1, '456-000-1234' )

@ElementCollection
@OrderColumn(name = "order_id")
private List<String> phones = new ArrayList<>();

person.getPhones().remove( 0 );

DELETE FROM Person_phones
WHERE  Person_id = 1
       AND order_id = 1

UPDATE Person_phones
SET    phones = '456-000-1234'
WHERE  Person_id = 1
       AND order_id = 0

@Entity(name = "Person")
public static class Person {

	@Id
	private Long id;

	@ElementCollection
	private List<Phone> phones = new ArrayList<>();

	//Getters and setters are omitted for brevity

}

@Embeddable
public static class Phone {

	private String type;

	@Column(name = "`number`")
	private String number;

	//Getters and setters are omitted for brevity

}

person.getPhones().add( new Phone( "landline", "028-234-9876" ) );
person.getPhones().add( new Phone( "mobile", "072-122-9876" ) );

INSERT INTO Person_phones ( Person_id, number, type )
VALUES ( 1, '028-234-9876', 'landline' )

INSERT INTO Person_phones ( Person_id, number, type )
VALUES ( 1, '072-122-9876', 'mobile' )
