Seam is a collaborative project created by the Open Source community. We would like to thank all of the following people for their contributions, without which Seam would not have been possible.
We are looking for talented people to help us in making Seam the best application framework in the world. Seam is an Open Source project with an extensive developer and user community, consisting of both full time and volunteer team members from all over the world.
There are many ways to contribute, such as:
If you would like to be involved in the ongoing development of Seam please visit us at http://www.seamframework.org/Seam3/Contribute to find out more.
Seam's mission is to provide a fully-integrated development platform for building rich, standards-based Internet applications tailored for traditional and cloud deployments.
The Seam 3 project is organized as a collection of modules and developer tooling tailored for Java EE 6 application development, built on top of the component model defined by JSR-299 Context and Dependency Injection (CDI). CDI is a JCP standard, you can find out more about it at http://jcp.org/en/jsr/summary?id=299.
Seam's modules leverage portable CDI extensions to build on the core Java EE functionality and integrate with JBoss and third-party projects. Together, these modules provide many of the popular features and integrations from Seam 2 (security, internationalization, JSF, rules, BPM) while also exploring new integrations and designs.
The developer tooling for Seam is provided by JBoss Tools and Seam Forge. JBoss Tools enhances Eclipse with features designed to help developers write, test and deploy enterprise Java applications. Seam Forge is an incremental project enhancement API and shell.
This guide steps you through the modules and select tooling, covering the purpose, APIs and usage scenarios for each. Collectively, this software should give you everything you need to develop comprehensive, robust and compelling enterprise applications.
The Seam 3 build is based on Maven 3. Each Seam module is a separate project, with its own release cycle. Each Seam module is a multi-module project contains the api, implementation, examples and documentation. Select modules are assembled together to create a Seam distribution, or stack release.
To keep the modules in sync, the Seam project publishes a special Maven POM known as a "Bill of Materials" (BOM), which we'll refer to as the Seam BOM. The Seam BOM defines the versions of all the Seam modules and third-party libraries that are used in the Seam stack using Maven's dependency management facility.
You can import these version definitions into your project by adding
the Seam BOM as a dependency with scope import
.
The benefit of doing so is that it relieves you from having to specify
the version of any Seam module explicitly. It also means you can
upgrade all your Seam modules at once by just updating the version of
the BOM.
Generally, the easiest way to accomplish this import is by first defining a property for the Seam BOM version:
<properties>
<seam.version>3.1.0.Final</seam.version>
</properties>
Then you add the following dependency declaration to the
dependencyManagement
section of your project's POM
file (or parent POM, if you use one).
<dependencyManagement>
<dependencies>
<dependency>
<groupId>org.jboss.seam</groupId>
<artifactId>seam-bom</artifactId>
<version>${seam.version}</version>
<type>pom</type>
<scope>import</scope>
</dependency>
</dependencies>
</dependencyManagement>
Then, it's a simple matter to declare which Seam module dependencies
your project requires by adding them inside the
dependencies
section. There's no need to specify a
version of the module as it gets inherited from the Seam BOM.
<dependency>
<groupId>org.jboss.seam.solder</groupId>
<artifactId>seam-solder</artifactId>
</dependency>
To see which version is going to get selected, use the dependency analysis tools in Maven:
mvn dependency:tree
You may upgrade an individual module by specifying the version explicitly. There's no crime in doing so. The Seam BOM is there as a convenience and a reference point for the recommended module version matrix. It's up to you how closely to follow it.
Each of the Seam modules also use the Seam BOM to keep the versions of related modules in sync. Once in a while, a module may specify a version of another module that's different from the Seam BOM. We usually try to get this worked out by the time we make a Seam stack release to fix the version matrix.
Refer to the Build System Architecture page on the Seam website for more detail about how the Seam 3 project is structured. Though, for the purpose of using Seam, how to import the module artifacts is likely all you need to know about the project's build.
Table of Contents
Solder is a library of Generally Useful Stuff (TM), particularly if you are developing an application based on CDI (JSR-299 Java Contexts and Dependency Injection), or a CDI based library or framework.
This guide is split into three parts. ??? details extensions and utilities which are likely to be of use to any developer using CDI; ??? describes utilities which are likely to be of use to developers writing libraries and frameworks that work with CDI; ??? discusses extensions which can be used to implement configuration for a framework
Getting started with Solder is easy. All you need to do is put the API and implementation JARs on the classpath of your CDI application. The features provided by Solder will be enabled automatically.
Some additional configuration, covered at the end of this chapter, is required if you are using a pre-Servlet 3.0 environment.
If you are using Maven as your build tool, first make sure you
have configured your build to use the JBoss Community repository, where you
can find all the Seam artifacts. Then, add the following dependencies to your pom.xml
file to get started using Solder:
<dependency>
<groupId>org.jboss.solder</groupId>
<artifactId>solder-api</artifactId>
<version>${solder.version}</version>
<scope>compile</scope>
</dependency>
<dependency>
<groupId>org.jboss.solder</groupId>
<artifactId>solder-impl</artifactId>
<version>${solder.version}</version>
<scope>runtime</scope>
</dependency>
Substitute the expression ${solder.version} with the most recent or appropriate version of Solder. Alternatively, you can create a Maven user-defined property to satisfy this substitution so you can centrally manage the version.
In a Servlet 3.0 or Java EE 6 environment, your configuration is now complete!
Most of Solder has very few dependencies, only one of which is not provided by Java EE 6:
javax.enterprise:cdi-api
(provided by Java EE 6)
javax.inject:javax:inject
(provided by Java EE 6)
javax.annotation:jsr250-api
(provided by Java EE 6)
javax.interceptor:interceptor-api
(provided by Java EE 6)
javax.el:el-api
(provided by Java EE 6)
The POM for Solder specifies the versions required. If you are using Maven 3, you can easily import
the dependencyManagement
into your POM by declaring the following in your
depdendencyManagement
section:
<dependency>
<groupId>org.jboss.solder</groupId>
<artifactId>seam-solder-impl</artifactId>
<version>${solder.version}</version>
<type>pom</type>
<scope>import</scope>
</dependency>
Some features of Solder require additional dependencies (which are declared optional, so will not be added as transitive dependencies):
org.javassist:javassist
Service Handlers, Unwrapping Producer Methods
javax.servlet:servlet-api
Accessing resources from the Servlet Context
In addition, a logger implementation (SLF4J, Log4J, JBoss Log Manager or the JDK core logging facility) is required. Refer to Chapter 8, Logging, redesigned for more information about how logging is handled in Solder.
If you are using Java EE 5 or some other Servlet 2.5 container, then you need to manually register a Servlet component in your application's web.xml to access resources from the Servlet Context.
<listener>
<listener-class>org.jboss.solder.resourceLoader.servlet.ResourceListener</listener-class>
</listener>
This registration happens automatically in a Servlet 3.0 environment through the use of a /META-INF/web-fragment.xml included in the Solder implementation.
You're all setup. It's time to dive into all the useful stuff that Solder provides!
Solder provides a number enhancements to the CDI programming model which are under trial and may be included in later releases of Contexts and Dependency Injection.
Annotating a class @Veto
will cause the type to be ignored, such that any definitions on the
type will not be processed, including:
the managed bean, decorator, interceptor or session bean defined by the type
any producer methods or producer fields defined on the type
any observer methods defined on the type
For example:
@Veto
class Utilities {
...
}
Besides, a package can be annotated with @Veto
, causing all beans in the package to be prevented
from registration.
The ProcessAnnotatedType
container lifecycle event will be called for vetoed types.
Annotating a class with @Requires
will cause the type to be ignored if the class dependencies
cannot be satisfied. Any definitions on the type will not be processed:
the managed bean, decorator, interceptor or session bean defined by the type
any producer methods or producer fields defined on the type
any observer methods defined on the type
Solder will use the Thread Context ClassLoader, as well as the classloader of the type annotated
@Requires
to attempt to satisfy the class dependency.
For example:
@Requires("javax.persistence.EntityManager")
class EntityManagerProducer {
@Produces
EntityManager getEntityManager() {
...
}
}
Annotating a package with @Requires
causes all beans in the package to be ignored if the class dependencies
cannot be satisfied. If both a class and it's package are annotated with @Requires
, both package-level and
class-level dependencies have to be satisfied for the bean to be installed.
The ProcessAnnotatedType
container lifecycle event will be called for required types.
Annotating an injection point with @Exact
allows you to select an exact implementation of the
injection point type to inject. For example:
interface PaymentService {
...
}
class ChequePaymentService implements PaymentService {
...
}
class CardPaymentService implements PaymentService {
...
}
class PaymentProcessor {
@Inject @Exact(CardPaymentService.class)
PaymentService paymentService;
...
}
It is common to want to qualify a bean as belonging to the current client (for example we want to differentiate
the default system locale from the current client's locale). Solder provides a built in qualifier,
@Client
for this purpose.
Solder allows you to annotate the package @Named
, which causes every bean defined in the
package to be given its default name. Package annotations are defined in the file
package-info.java
. For example, to cause any beans defined in com.acme
to be given
their default name:
@Named
package com.acme
According to the CDI standard, the @Named
annotation assigns a name to a bean equal to the value
specified in the @Named
annotation or, if a value is not provided, the simple name of the bean class.
This behavior aligns with the needs of most application developers. However, framework writers should avoid
trampling on the "root" bean namespace. Instead, frameworks should specify qualified names for built-in components.
The motivation is the same as qualifying Java types. The @FullyQualified
provides this facility without
sacrificing type-safety.
Solder allows you to customize the bean name using the complementary @FullyQualified
annotation. When the @FullyQualified
annotation is added to a @Named
bean type, producer
method or producer field, the standard bean name is prefixed with the name of the Java package in which the bean
resides, the segments separated by a period. The resulting fully-qualified bean name (FQBN) replaces the standard
bean name.
package com.acme;
@FullyQualified @Named
public class NamedBean {
public int getAge()
{
return 5;
}
}
The bean in the previous code listing is assigned the name com.acme.namedBean
. The value of its
property age
would be referenced in an EL expression (perhaps in a JSF view template) as follows:
#{com.acme.namedBean.age}
The @FullyQualified
annotation is permitted on a bean type, producer method or producer field. It can
also be used on a Java package, in which case all @Named
beans in that package get a bean name which is
fully-qualified.
@FullyQualified
package com.acme;
If you want to use a different Java package as the namespace of the bean, rather than the Java package of the bean, you specify any class in that alternative package in the annotation value.
package com.acme;
@FullyQualified(ClassInOtherPackage.class) @Named
public class CustomNamespacedNamedBean {
...
}
Solder provides a complete set of AnnotationLiteral
classes corresponding to the
annotation types defined in the CDI (JSR-299) and Injection (JSR-330) specifications. These literals are located
in the org.jboss.solder.literal
package.
For any annotation that does not define an attribute, its corresponding AnnotationLiteral
contains a static INSTANCE
member. You should use this static member whenever you need a
reference to an annotation instance rather than creating a new instance explicitly.
new AnnotatedTypeBuilder<X>().readFromType(type).addToClass(NamedLiteral.INSTANCE);
Literals are provided for the following annotations from Context and Dependency Injection (including annotations from Dependency Injection for Java):
@Alternative
@Any
@ApplicationScoped
@ConversationScoped
@Decorator
@Default
@Delegate
@Dependent
@Disposes
@Inject
@Model
@Named
@New
@Nonbinding
@NormalScope
@Observes
@Produces
@RequestScoped
@SessionScoped
@Specializes
@Stereotype
@Typed
Literals are also provided for the following annotations from Solder:
@Client
@DefaultBean
@Exact
@Generic
@GenericType
@Mapper
@MessageBundle
@Requires
@Resolver
@Resource
@Unwraps
@Veto
For more information about these annotations, consult the corresponding API documentation.
Solder provides a method to evaluate EL that is not dependent on JSF or JSP, a facility sadly missing in
Java EE. To use it inject Expressions
into your bean. You can evaluate value expressions, or method
expressions. The Solder API provides type inference for you. For example:
class FruitBowl {
@Inject Expressions expressions;
public void run() {
String fruitName = expressions.evaluateValueExpression("#{fruitBowl.fruitName}");
Apple fruit = expressions.evaluateMethodExpression("#{fruitBown.getFruit}");
}
}
Solder provides an extensible, injectable resource loader. The resource loader can provide URLs or managed input streams. By default the resource loader will look at the classpath, and the servlet context if available.
If the resource name is known at development time, the resource can be injected, either as a URL or an InputStream:
@Inject
@Resource("WEB-INF/beans.xml")
URL beansXml;
@Inject
@Resource("WEB-INF/web.xml")
InputStream webXml;
If the resource name is not known, the ResourceProvider
can be injected, and the resource looked up
dynamically:
@Inject
void readXml(ResourceProvider provider, String fileName) {
InputStream is = provider.loadResourceStream(fileName);
}
If you need access to all resources under a given name known to the resource loader (as opposed to first resource loaded), you can inject a collection of resources:
@Inject
@Resource("WEB-INF/beans.xml")
Collection<URL> beansXmls;
@Inject
@Resource("WEB-INF/web.xml")
Collection<InputStream> webXmls;
Any input stream injected, or created directly by the ResourceProvider
is managed, and will be
automatically closed when the bean declaring the injection point of the resource or provider is destroyed.
If the resource is a Properties bundle, you can also inject it as a set of Properties
:
@Inject
@Resource("META-INF/aws.properties")
Properties awsProperties;
If you want to load resources from another location, you can provide an additional resource loader. First, create the resource loader implementation:
class MyResourceLoader implements ResourceLoader {
...
}
And then register it as a service by placing the fully qualified class name of the implementation in a file
called META-INF/services/org.jboss.solder.resourceLoader.ResourceLoader
.
Solder allows system properties to be easily injected using the @System
qualifier. The following
code snippet shows how you can inject system properties directly into your own bean:
import java.util.Properties; import org.jboss.solder.core.System; import javax.inject.Inject; public class Foo { @Inject @System Properties properties; //.. }
Solder also exposes the system properties as a named bean called sysProp
, allowing them to be
referenced directly via EL (Expression Language), for example from a JSF page definition. Please refer to the
org.jboss.solder.system.SystemProperties
class in the Solder API documentation for a list of the
available methods.
Solder brings a fresh perspective to the ancient art of logging. Rather than just giving you an injectable version of the same old logging APIs, Solder goes the extra mile by embracing the type-safety of CDI and eliminating brittle, boilerplate logging statements. The best part is, no matter how you decide to roll it out, you still get to keep your logging engine of choice (for the logging wars will never end!).
Before talking about Solder Logging, you need to first be introduced to JBoss Logging 3. The reason is, JBoss Logging provides the foundation on which Solder's declarative programming model for logging is built. Plus, we have to convince you that you aren't tied to JBoss AS by using it.
JBoss Logging acts as a logging bridge. If you don't add any other logging libraries to your project, it will delegate all logging calls it handles to the logging facility built into the Java platform (commonly referred to as JDK logging). That's nice, because it means your deployment headaches caused by missing logging jars are gone. And you accomplish it all through the use of the Logger type. It has the usual level-based log methods and complimentary ones that provide formatting.
Here's an example of how you obtain a logger and log a basic message:
Logger log = Logger.getLogger(Bean.class);
// log a plain text method
log.debug("I'm using JBoss Logging.");
If you want to use another logging engine, such as SLF4J or Log4J, you just have to add the native library to the deployment. Keep in mind, though, if your application server provides one of these frameworks, it will get chosen instead. On JBoss AS, JBoss Logging will prefer the JBoss LogManager because it's the built-in logging engine. (We are looking into more sophisticated runtime selection of the logging engine).
Here are the providers JBoss Logging supports (and the order in which it looks for them):
JBoss LogManager
Log4J
SLF4J
JDK logging
So you get that JBoss Logging is an abstraction. What else is it good for?
JBoss Logging has a facility for formatting log messages, using either the printf syntax or
MessageFormat
. This makes it possible to use positional parameters to build dynamic log
messages based on contextual information.
Logger log = Logger.getLogger(Bean.class);
// log a message formatted using printf-style substitutions
log.infof("My name is %s.", "David");
// log a message formatted using MessageFormat-style substitutions
log.errorv("The license for Solder is the {0}", "APL");
The most significant and distinguishing feature of JBoss Logging is support for typed loggers. A typed logger is an interface that defines methods which serve as logging operations. When a method is invoked on one of these interfaces, the message defined in an annotation on the method is interpolated and written to the underlying logging engine.
Here's an example of a typed logger:
import org.jboss.logging.Message;
import org.jboss.logging.LogMessage;
import org.jboss.logging.MessageLogger;
@MessageLogger
public interface CelebritySightingLog {
@LogMessage @Message("Spotted celebrity %s!")
void spottedCelebrity(String name);
}
JBoss Logging has parallel support for typed message bundles, whose methods return a formatted message rather than log it. Combined, these features form the centerpiece of Solder's logging and message bundle programming model (and a foundation for additional support provided by the Seam international module). After looking at the samples provided so far, don't pull out your IDE just yet. We'll get into the details of typed loggers and how to use them in Solder in a later section.
There you have it! JBoss Logging is a low-level API that provides logging abstraction, message formatting and internationalization, and typed loggers. But it doesn't tie you to JBoss AS!
With that understanding, we'll now move on to what Solder does to turn this foundation into a programming model and how to use it in your CDI-based application.
Solder builds on JBoss Logging 3 to provide the following feature set:
An abstraction over common logging backends and frameworks (such as JDK Logging, log4j and slf4j)
Injectable loggers and message bundles
Innovative, typed message loggers and message bundles defined using interfaces
Build time tooling to generate typed loggers for production
Full support for internationalization and localization:
Developers work with interfaces and annotations only
Translators work with message bundles in properties files
Access to the "Mapped Diagnostic Context" (MDC) and/or the "Nested Diagnostic Context" (NDC) (if the underlying logger supports it)
Serializable loggers for use in contextual components
Seam's international module builds on this programming model to provide even more features for producing localized message strings.
Without further discussion, let's get into it.
To define a typed logger, first create an interface, annotate it, then add methods that will act as log operations and configure the message it will print using another annotation:
import org.jboss.solder.messages.Message;
import org.jboss.solder.logging.Log;
import org.jboss.solder.logging.MessageLogger;
@MessageLogger
public interface TrainSpotterLog {
@Log @Message("Spotted %s diesel trains")
void dieselTrainsSpotted(int number);
}
We have configured the log messages to use printf-style interpolations of parameters (%s).
Make sure you are using the annotations from Solder (org.jboss.solder.messages
and org.jboss.solder.logging
packages only).
You can then inject the typed logger with no further configuration necessary. We use another optional annotation to set the category of the logger to "trains" at the injection point, overriding the default category of the fully-qualified class name of the component receiving the injection:
@Inject @Category("trains")
private TrainSpotterLog log;
We log a message by simply invoking a method of the typed logger interface:
log.dieselTrainsSpotted(7);
The default locale will be used unless overridden. Here we configure the logger to use the UK locale:
@Inject @Category("trains") @Locale("en_GB")
private TrainSpotterLog log;
You can also log exceptions.
import org.jboss.solder.messages.Message;
import org.jboss.solder.messages.Cause;
import org.jboss.solder.logging.Log;
import org.jboss.solder.logging.MessageLogger;
@MessageLogger
public interface TrainSpotterLog {
@Log @Message("Failed to spot train %s")
void missedTrain(String trainNumber, @Cause Exception exception);
}
You can then log a message with an exception as follows:
try {
...
} catch (Exception e) {
log.missedTrain("RH1", e);
}
The stacktrace of the exception parameter will be written to the log along with the message.
Typed loggers also provide internationalization support. Simply add the @MessageBundle
annotation to the logger
interface.
If injecting a typed logger seems too "enterprisy" to you, or you need to get a reference to it from outside of
CDI, you can use a static accessor method on Logger
:
TrainSpotterLog log = Logger.getMessageLogger(TrainSpotterLog.class, "trains");
log.dieselTrainsSpotted(7);
The injected version is a convenience for those who prefer the declarative style of programming. If you are
looking for a simpler starting point, you can simply use the Logger
directly.
You can also inject a "plain old" Logger (from the JBoss Logging API):
import javax.inject.Inject;
import org.jboss.solder.logging.Logger;
public class LogService {
@Inject
private Logger log;
public void logMessage() {
log.info("Hey sysadmins!");
}
}
Log messages created from this Logger will have a category (logger name) equal to the fully-qualified class name of the bean implementation class. You can specify a category explicitly using an annotation.
@Inject @Category("billing")
private Logger log;
You can also specify a category using a reference to a type:
@Inject @TypedCategory(BillingService.class)
private Logger log;
Often times you need to access a localized message. For example, you need to localize an exception message. Solder let's you retrieve this message from a typed message logger to avoid having to use hard-coded string messages.
To define a typed message bundle, first create an interface, annotate it, then add methods that will act as message retrievers and configure the message to produce using another annotation:
import org.jboss.solder.messages.Message;
import org.jboss.solder.messages.MessageBundle;
@MessageBundle
public interface TrainMessages {
@Message("No trains spotted due to %s")
String noTrainsSpotted(String cause);
}
Inject it:
@Inject @MessageBundle
private TrainMessages messages;
And use it:
throw new BadDayException(messages.noTrainsSpotted("leaves on the line"));
You may have noticed that throughout this chapter, we've only defined interfaces. Yet, we are injecting and invoking them as though they are concrete classes. So where's the implementation?
Good news. The typed logger and message bundle implementations are generated automatically! You'll see this strategy used often in Seam 3. It's declarative programming at its finest (or to an extreme, depending on how you look at it). Either way, it saves you from a whole bunch of typing.
So how are they generated? Let's find out!
The first time you need logging in your application, you'll likely start with the more casual approach of
using the Logger
API directly. There's no harm in that, but it's certainly cleaner to use
the typed loggers, and at the same time leverage the parallel benefits of the typed bundles. So we recommend
that as your long term strategy.
Once you are ready to move to the the typed loggers and message bundles, you'll need to generate the concrete implementation classes as part of the build. These classes are generated by using an annotation processor that is provided by Solder and based on the JBoss Logging tools project. Don't worry, setting it up is a lot simpler than it sounds. You just need to do these two simple steps:
Set the Java compliance to 1.6 (or better)
Add the Solder tooling library to the build classpath
If you forget to add the annotation processor to your build, you'll get an error when you deploy the application that reports: "Invalid bundle interface (implementation not found)". This error occurs because the concrete implementation classes are missing.
Setting the Java compliance to 1.6 enables any annotation processors on the classpath to be activated during compilation.
If you're using Maven, here's how the configuration in your POM file looks:
<dependencies>
<!-- Annotation processor for generating typed logger and message bundle classes -->
<dependency>
<groupId>org.jboss.solder</groupId>
<artifactId>solder-tooling</artifactId>
<scope>provided</scope>
<optional>true</optional>
</dependency>
...
</dependencies>
<build>
<plugins>
<plugin>
<groupId>org.apache.maven.plugins</groupId>
<artifactId>maven-compiler-plugin</artifactId>
<configuration>
<source>1.6</source>
<target>1.6</target>
</configuration>
</plugin>
</plugins>
</build>
In the future, you can expect IDE plugins like JBoss Tools to setup this configuration automatically.
Here are the classes that will be generated for the examples above:
TrainSpotterLog_$logger.java TrainSpotterLog_$logger_en_GB.java TrainMessages_$bundle.java
Classes are generated for each language referenced by an annotation or if there is a .i18n.properties language
file in the same package as the interface and has the same root name. For instance, if we wanted to generate
a French version of TrainMessages
, we would have to create the following properties file
in the same package as the interface:
TrainMessages.i18n_fr.properties
Then populate it with the translations (Note the property key is the method name):
noTrainsSpotted=pas de trains repéré en raison de %s
Now the annotation processor will generate the following class:
TrainMessages_$bundle_fr.java
Now you can add typed loggers and message bundles at will (and you won't have to worry about unsatisfied dependencies).
If you are writing an Arquillian test, be sure to include the concrete classes in the ShrinkWrap archive. Otherwise, you may receive an exception like:
Invalid bundle interface org.example.log.AppLog (implementation not found)
The best approach is to put your typed message loggers and bundles in their own package. Then, you include the package in the ShrinkWrap archive:
ShrinkWrap.create(JavaArchive.class, "test.jar") .addPackage(AppLog.class.getPackage());
This strategy will effectively package the interface and the generated implementation class(es) (even though you can't see the generated implementation classes in your source tree).
Solder provides a number of utility classes that make working with annotations and
AnnotatedType
s easier. This chapter walks you through each utility, and gives you some ideas about
how to use it. For more detail, take a look at the JavaDoc on each class.
Solder provides an AnnotatedType
implementation that should be suitable for the needs of most
portable extensions. The AnnotatedType
is created from AnnotatedTypeBuilder
,
typically in an extension's observer method, as follows:
AnnotatedTypeBuilder builder = new AnnotatedTypeBuilder()
.readFromType(type, true) /* readFromType can read from an AnnotatedType or a class */
.addToClass(ModelLiteral.INSTANCE); /* add the @Model annotation */
.create()
Here we create a new builder, and initialize it using an existing AnnotatedType
. We can then
add or remove annotations from the class, and its members. When we have finished modifying the type, we call
create()
to spit out a new, immutable, AnnotatedType
.
AnnotatedType redefinedType = builder.create();
One place this is immensely useful is for replacing the AnnotatedType
in an extension that
observes the ProcessAnnotatedType
event:
public <X> void processAnnotatedType(@Observes ProcessAnnotatedType<X> evt) {
AnnotatedTypeBuilder builder = new AnnotatedTypeBuilder()
.readFromType(evt.getAnnotatedType(), true)
.addToClass(ModelLiteral.INSTANCE);
evt.setAnnotatedType(builder.create());
}
This type is now effectively annotated with @Model
, even if the annotation is not present on the
class definition in the Java source file.
AnnotatedTypeBuilder
also allows you to specify a "redefinition", which can be applied to the type,
a type of member, or all members. The redefiner will receive a callback for any annotations present which match
the annotation type for which the redefinition is applied.
For example, to remove the qualifier @Unique
from the type and any of its members, use this:
AnnotatedTypeBuilder builder = new AnnotatedTypeBuilder()
.readFromType(type, true)
.redefine(Unique.class, new AnnotationRedefiner<Unique>() {
public void redefine(RedefinitionContext<Unqiue> ctx) {
ctx.getAnnotationBuilder().remove(Unique.class);
}
});
AnnotatedType redefinedType = builder.create();
No doubt, this is a key blade in Solder's army knife arsenal of tools. You can quite effectively change the picture of the type metadata CDI discovers when it scans and processes the classpath of a bean archive.
Sometimes you may need an annotation instance for an annotation whose type is not known at development time.
Solder provides a AnnotationInstanceProvider
class that can create an
AnnotationLiteral
instance for any annotation at runtime. Annotation attributes
are passed in via a Map<String,Object>
. For example given the follow annotation:
@Retention(RetentionPolicy.RUNTIME)
public @interface MultipleMembers {
int intMember();
long longMember();
short shortMember();
float floatMember();
double doubleMember();
byte byteMember();
char charMember();
boolean booleanMember();
int[] intArrayMember();
}
We can create an annotation instance as follows:
/* Create a new provider */
AnnotationInstanceProvider provider = new AnnotationInstanceProvider();
/* Set the value for each of attributes */
Map<String, Object> values = new HashMap<String, Object>();
values.put("intMember", 1);
values.put("longMember", 1);
values.put("shortMember", 1);
values.put("floatMember", 0);
values.put("doubleMember", 0);
values.put("byteMember", ((byte) 1));
values.put("charMember", 'c');
values.put("booleanMember", true);
values.put("intArrayMember", new int[] { 0, 1 });
/* Generate the instance */
MultipleMembers an = provider.get(MultipleMembers.class, values);
The Annotation Inspector allows you to easily discover annotations which are meta-annotated. For example:
/* Discover all annotations on type which are meta-annotated @Constraint */
Set<Annotation> constraints = AnnotationInspector.getAnnotations(type, Constraint.class);
/* Load the annotation instance for @FacesValidator the annotation may declared on the type, */
/* or, if the type has any stereotypes, on the stereotypes */
FacesValidator validator = AnnotationInspector.getAnnotation(
type, FacesValidator.class, true, beanManager);
The utility methods work correctly on Stereotype
s as well. Let's say you're working with a bean
that was decorated @Model
, running the following example will still show you the underlying @Named
// assuming you have a class..
@Model
public class User {
...
}
// Assume type represents the User class
assert AnnotationInspector.isAnnotationPresent(type, Named.class, beanManager);
// Retrieves the underlying @Named instance on the stereotype
Named name = AnnotationInspector.getAnnotation(type, Named.class, true, beanManager);
The search algorithm will first check to see if the annotation is present
directly on the annotated element first, then searches within the stereotype
annotations on the element. If you only want to search for Annotation
s on
Stereotype
s, then you can use either of the methods
AnnotationInspector.getAnnotationFromStereotype
.
There is an overloaded form of isAnnotationPresent
and getAnnotation
to control
whether it will search on Stereotype
s or not.
For both of these methods, a search is performed first directly on the element before searching in stereotypes.
When developing an extension to CDI, it can be useful to detect certain injection points, or bean definitions and based on annotations or other metadata, add qualifiers to further disambiguate the injection point or bean definition for the CDI bean resolver. Solder's synthetic qualifiers can be used to easily generate and track such qualifiers.
In this example, we will create a synthetic qualifier provider, and use it to create a qualifier. The provider will track the qualifier, and if a qualifier is requested again for the same original annotation, the same instance will be returned.
/* Create a provider, giving it a unique namespace */
Synthetic.Provider provider = new Synthetic.Provider("com.acme");
/* Get the a synthetic qualifier for the original annotation instance */
Synthetic synthetic = provider.get(originalAnnotation);
/* Later calls with the same original annotation instance will return the same instance */
/* Alternatively, we can "get and forget" */
Synthetic synthetic2 = provider.get();
Solder comes with a number miscellaneous reflection utilities; these extend JDK reflection, and some
also work on CDI's Annotated metadata. See the javadoc on Reflections
for more.
Solder also includes a simple utility, PrimitiveTypes
for converting between primitive and their
respective wrapper types, which may be useful when performing data type conversion. Sadly, this is
functionality which is missing from the JDK.
InjectableMethod
allows an AnnotatedMethod
to be injected with parameter values
obtained by following the CDI type safe resolution rules, as well as allowing the default parameter values to
be overridden.
When developing a framework that builds on CDI, you may need to obtain the BeanManager
for the
application, you can't simply inject it as you are not working in an object managed by the container. The CDI
specification allows lookup of java:comp/BeanManager
in JNDI, however, some environments don't support
binding to this location (e.g. servlet containers such as Tomcat and Jetty) and some environments don't support
JNDI (e.g. the Weld SE container). For this reason, most framework developers will prefer to avoid a direct JNDI
lookup.
Often it is possible to pass the correct BeanManager
to the object in which you require it, for
example via a context object. For example, you might be able to place the BeanManager
in the
ServletContext
, and retrieve it at a later date.
On some occasions however there is no suitable context to use, and in this case, you can take advantage of the
abstraction over BeanManager
lookup provided by Solder. To lookup up a
BeanManager
, you can extend the abstract BeanManagerAware
class, and call
getBeanManager()
:
public class WicketIntegration extends BeanManagerAware {
public WicketManager getWicketManager() {
Bean<?> bean = getBeanManager().getBeans(IRequestListener.class);
... // and so on to lookup the bean
}
}
The benefit here is that BeanManagerAware
class will first look to see if its
BeanManager
injection point was satisfied before consulting the providers. Thus, if injection
becomes available to the class in the future, it will automatically start the more efficient approach.
Occasionally you will be working in an existing class hierarchy, in which case you can use the accessor on
BeanManagerLocator
. For example:
public class ResourceServlet extends HttpServlet {
protected void doGet(HttpServletRequest req, HttpServletResponse resp)
throws ServletException, IOException {
BeanManager beanManager = new BeanManagerLocator().getBeanManager();
...
}
}
If this lookup fails to resolve a BeanManager
, the BeanManagerUnavailableException
, a
runtime exception, will be thrown. If you want to perform conditional logic based on whether the
BeanManager
is available, you can use this check:
public class ResourceServlet extends HttpServlet {
protected void doGet(HttpServletRequest req, HttpServletResponse resp)
throws ServletException, IOException {
BeanManagerLocator locator = new BeanManagerLocator();
if (locator.isBeanManagerAvailable()) {
BeanManager beanManager = locator.getBeanManager();
... // work with the BeanManager
}
else {
... // work without the BeanManager
}
}
}
However, keep in mind that you can inject into Servlets in Java EE 6!! So it's very likely the lookup isn't necessary, and you can just do this:
public class ResourceServlet extends HttpServlet {
@Inject
private BeanManager beanManager;
protected void doGet(HttpServletRequest req, HttpServletResponse resp)
throws ServletException, IOException {
... // work with the BeanManager
}
}
Solder provides a number of base classes which can be extended to create custom beans. Solder also provides bean builders which can be used to dynamically create beans using a fluent API.
AbstractImmutableBean
An immutable (and hence thread-safe) bean, whose constructor will substitute specification defaults if
null
is passed for a particular attribute. Subclasses must implement the
create()
and destroy()
methods.
AbstractImmutableProducer
An immutable (and hence thread-safe) abstract class for creating producers. Subclasses must implement
produce()
and dispose()
.
BeanBuilder
A builder for creating immutable beans which can read the type and annotations from an
AnnotatedType
.
Beans
A set of utilities for working with beans.
ForwardingBean
A base class for implementing Bean
which forwards all calls to delegate()
.
ForwardingInjectionTarget
A base class for implementing InjectionTarget
which forwards all calls to delegate()
.
ForwardingObserverMethod
A base class for implementing ObserverMethod
which forwards all calls to delegate()
.
ImmutableBean
An immutable (and hence thread-safe) bean, whose constructor will substitute specification defaults if
null
is passed for a particular attribute. An implementation of
ContextualLifecycle
may be registered to receive lifecycle callbacks.
ImmutableInjectionPoint
An immutable (and hence thread-safe) injection point.
ImmutableNarrowingBean
An immutable (and hence thread-safe) narrowing bean. Narrowing beans allow you to build a general purpose bean (likely a producer method), and register it for a narrowed type (or qualifiers).
ImmutablePassivationCapableBean
An immutable (and hence thread-safe) bean, whose constructor will substitute specification defaults if
null
is passed for a particular attribute. An implementation of
ContextualLifecycle
may be registered to receive lifecycle callbacks. The bean implements
PassivationCapable
, and an id must be provided.
ImmutablePassivationCapableNarrowingBean
An immutable (and hence thread-safe) narrowing bean. Narrowing beans allow you to build a general purpose
bean (likely a producer method), and register it for a narrowed type (or qualifiers). The bean implements
PassivationCapable
, and an id must be provided.
NarrowingBeanBuilder
A builder for creating immutable narrowing beans which can read the type and annotations from an
AnnotatedType
.
The use of these classes is in general trivially understood with an understanding of basic programming patterns and the CDI specification, so no in depth explanation is provided here. The JavaDoc for each class and method provides more detail.
Solder provides a number of convenient features for querying and working with JavaBean properties. They can be used with properties exposed via a getter/setter method, or directly via the field of a bean, providing a uniform interface that allows you to work with all properties in the same way.
Property queries allow you to interrogate a class for properties which match certain criteria.
The Property<V>
interface declares a number of methods for interacting with bean properties.
You can use these methods to read or set the property value, and read the property type information. Properties
may be readonly.
Table 12.1. Property methods
Method |
Description | |
---|---|---|
|
Returns the name of the property. | |
|
Returns the property type. | |
|
Returns the property class. | |
|
Returns the annotated element -either the | |
|
Returns the value of the property. | |
|
Sets the value of the property. | |
|
Gets the class declaring the property. | |
|
Check if the property can be written as well as read. | |
|
Get the class member which retrieves the property (i.e. field or getter). | |
void setAccessible
|
Sets the |
Given a class with two properties, personName
and postcode
:'
class Person {
PersonName personName;
Address address;
void setPostcode(String postcode) {
address.setPostcode(postcode);
}
String getPostcode() {
return address.getPostcode();
}
}
You can create two properties:
Property<PersonName> personNameProperty = Properties.createProperty(Person.class.getField("personName"));
Property<String> postcodeProperty = Properties.createProperty(Person.class.getMethod("getPostcode"));
To create a property query, use the PropertyQueries
class to create a new
PropertyQuery
instance:
PropertyQuery<?> query = PropertyQueries.createQuery(Foo.class);
If you know the type of the property that you are querying for, you can specify it via a type parameter:
PropertyQuery<String> query = PropertyQueries.<String>createQuery(identityClass);
Once you have created the PropertyQuery
instance, you can add search criteria. Solder
provides three built-in criteria types, and it is very easy to add your own. A criteria is added to a query via the
addCriteria()
method. This method returns an instance of the PropertyQuery
,
so multiple addCriteria()
invocations can be stacked.
This criteria is used to locate bean properties that are annotated with a certain annotation type. For example, take the following class:
public class Foo { private String accountNumber; private @Scrambled String accountPassword; private String accountName; }
To query for properties of this bean annotated with @Scrambled
, you can use an
AnnotatedPropertyCriteria
, like so:
PropertyQuery<String> query = PropertyQueries.<String>createQuery(Foo.class) .addCriteria(new AnnotatedPropertyCriteria(Scrambled.class));
This query matches the accountPassword
property of the Foo
bean.
This criteria is used to locate a bean property with a particular name. Take the following class:
public class Foo { public String getBar() { return "foobar"; } }
The following query will locate properties with a name of "bar"
:
PropertyQuery<String> query = PropertyQueries.<String>createQuery(Foo.class) .addCriteria(new NamedPropertyCriteria("bar"));
This criteria can be used to locate bean properties with a particular type.
public class Foo { private Bar bar; }
The following query will locate properties with a type of Bar
:
PropertyQuery<Bar> query = PropertyQueries.<Bar>createQuery(Foo.class) .addCriteria(new TypedPropertyCriteria(Bar.class));
To create your own property criteria, simply implement the
org.jboss.solder.properties.query.PropertyCriteria
interface, which declares the
two methods fieldMatches()
and methodMatches
. In the following example, our
custom criteria implementation can be used to locate whole number properties:
public class WholeNumberPropertyCriteria implements PropertyCriteria { public boolean fieldMatches(Field f) { return f.getType() == Integer.class || f.getType() == Integer.TYPE.getClass() || f.getType() == Long.class || f.getType() == Long.TYPE.getClass() || f.getType() == BigInteger.class; } public boolean methodMatches(Method m) { return m.getReturnType() == Integer.class || m.getReturnType() == Integer.TYPE.getClass() || m.getReturnType() == Long.class || m.getReturnType() == Long.TYPE.getClass() || m.getReturnType() == BigInteger.class; } }
After creating the PropertyQuery
and setting the criteria, the query can be executed by invoking
either the getResultList()
or getFirstResult()
methods. The
getResultList()
method returns a List
of Property
objects,
one for each matching property found that matches all the specified criteria:
List<Property<String>> results = PropertyQueries.<String>createQuery(Foo.class) .addCriteria(new TypedPropertyCriteria(String.class)) .getResultList();
If no matching properties are found, getResultList()
will return an empty List
.
If you know that the query will return exactly one result, you can use the getFirstResult()
method
instead:
Property<String> result = PropertyQueries.<String>createQuery(Foo.class) .addCriteria(new NamedPropertyCriteria("bar")) .getFirstResult();
If no properties are found, then getFirstResult()
will return null. Alternatively, if more than one
result is found, then getFirstResult()
will return the first property found.
Alternatively, if you know that the query will return exactly one result, and you want to assert that assumption is true,
you can use the getSingleResult()
method instead:
Property<String> result = PropertyQueries.<String>createQuery(Foo.class) .addCriteria(new NamedPropertyCriteria("bar")) .getSingleResult();
If no properties are found, or more than one property is found, then getSingleResult()
will throw an
exception. Otherwise, getSingleResult()
will return the sole property found.
Sometimes you may not be interested in read only properties, so getResultList()
,getFirstResult()
and getSingleResult()
have corresponding getWritableResultList()
,getWritableFirstResult()
and getWritableSingleResult()
methods, that will only return properties that are not read-only. This means that
if there is a field and a getter method that resolve to the same property, instead of getting a read-only MethodProperty
you will get a writable FieldProperty
.
Unwrapping producer methods allow you to create injectable objects that have "self-managed" lifecycles. An unwrapped injectable object is useful if you need a bean whose lifecycle does not exactly match one of the lifecycles of the existing scopes. The lifecycle of the bean is managed by the bean that defines the producer method, and changes to the unwrapped object are immediately visible to all clients.
You can declare a method to be an unwrapping producer method by annotating it @Unwraps
. The return
type of the managed producer must be proxyable (see Section 5.4.1 of the CDI specification, "Unproxyable bean types"). Every time a method is called on unwrapped object the invocation is forwarded to the result of calling
the unwrapping producer method - the unwrapped object.
Solder implements this by injecting a proxy rather than the original object. Every invocation on the injected proxy will cause the unwrapping producer method to be invoked to obtain the instance on which to invoke the method called. Solder will then invoke the method on unwrapped instance.
Because of this, it is very important the producer method is lightweight.
For example consider a permission manager (that manages the current permission), and a security manager (that checks the current permission level). Any changes to permission in the permission manager are immediately visible to the security manager.
@SessionScoped
class PermissionManager {
Permission permission;
void setPermission(Permission permission) {
this.permission=permission;
}
@Unwraps @Current
Permission getPermission() {
return this.permission;
}
}
@SessionScoped
class SecurityManager {
@Inject @Current
Permission permission;
boolean checkAdminPermission() {
return permission.getName().equals("admin");
}
}
When permission.getName()
is called, the unwrapped Permission forwards the invocation of
getName()
to the result of calling PermissionManager.getPermission()
.
For example you could raise the permission level before performing a sensitive operation, and then lower it again afterwards:
public class SomeSensitiveOperation {
@Inject
PermissionManager permissionManager;
public void perform() {
try {
permissionManager.setPermission(Permissions.ADMIN);
// Do some sensitive operation
} finally {
permissionManager.setPermission(Permissions.USER);
}
}
}
Unwrapping producer methods can have parameters injected, including InjectionPoint
(which represents)
the calling method.
Suppose you have a situation where you want to provide a default implementation of a particular service and allow
the user to override it as needed. Although this may sound like a job for an alternative, they have some
restrictions that may make them undesirable in this situation. If you were to use an alternative it would require
an entry in every beans.xml
file in an application.
Developers consuming the extension will have to open up the any jar file which references the default bean, and
edit the beans.xml
file within, in order to override the service. This is where default beans come
in.
Default beans allow you to create a default bean with a specified type and set of qualifiers. If no other bean is installed that has the same type and qualifiers, then the default bean will be installed.
Let's take a real world example - a module that allows you to evaluate EL (something that Solder
provides!). If JSF is available we want to use the FunctionMapper
provided by the JSF implementation
to resolve functions, otherwise we just want to use a a default FunctionMapper
implementation that
does nothing. We can achieve this as follows:
@DefaultBean(FunctionMapper.class)
@Mapper
class FunctionMapperImpl extends FunctionMapper {
@Override
public Method resolveFunction(String prefix, String localName) {
return null;
}
}
And in the JSF module:
class FunctionMapperProvider {
@Produces
@Mapper
FunctionMapper produceFunctionMapper() {
return FacesContext.getCurrentInstance().getELContext().getFunctionMapper();
}
}
If FunctionMapperProvider
is present then it will be used by default, otherwise the default
FunctionMapperImpl
is used.
A producer method or producer field may be defined to be a default producer by placing the
@DefaultBean
annotation on the producer. For example:
class CacheManager {
@DefaultBean(Cache.class)
Cache getCache() {
...
}
}
Any producer methods or producer fields declared on a default managed bean are automatically registered as default
producers, with Method.getGenericReturnType()
or Field.getGenericType()
determining the
type of the default producer. The default producer type can be overridden by specifying @DefaultBean
on the producer method or field.
Many common services and API's require the use of more than just one class. When exposing these services via CDI, it would be time consuming and error prone to force the end developer to provide producers for all the different classes required. Generic beans provide a solution, allowing a framework author to provide a set of related beans, one for each single configuration point defined by the end developer. The configuration points specifies the qualifiers which are inherited by all beans in the set.
To illustrate the use of generic beans, we'll use the following example. Imagine we are writing an extension to integrate our custom messaging solution "ACME Messaging" with CDI. The ACME Messaging API for sending messages consists of several interfaces:
MessageQueue
The message queue, onto which messages can be placed, and acted upon by ACME Messaging
MessageDispatcher
The dispatcher, responsible for placing messages created by the user onto the queue
DispatcherPolicy
The dispatcher policy, which can be used to tweak the dispatch policy by the client
MessageSystemConfiguration
The messaging system configuration
We want to be able to create as many MessageQueue
configurations as they need, however we do not
want to have to declare each producer and the associated plumbing for every queue. Generic beans are an ideal
solution to this problem.
Before we take a look at creating generic beans, let's see how we will use them.
Generic beans are configured via producer methods and fields. We want to create two queues to interact with
ACME Messaging, a default queue that is installed with qualifier @Default
and a durable queue that
has qualifier @Durable
:
class MyMessageQueues {
@Produces
@ACMEQueue("defaultQueue")
MessageSystemConfiguration defaultQueue = new MessageSystemConfiguration();
@Produces @Durable @ConversationScoped
@ACMEQueue("durableQueue")
MessageSystemConfiguration producerDefaultQueue() {
MessageSystemConfiguration config = new MessageSystemConfiguration();
config.setDurable(true);
return config;
}
}
Looking first at the default queue, in addition to the @Produces
annotation, the generic
configuration annotation ACMEQueue
, is used, which defines this to be a generic configuration
point for ACME messaging (and cause a whole set of beans to be created, exposing for example the dispatcher).
The generic configuration annotation specifies the queue name, and the value of the producer field defines the
messaging system's configuration (in this case we use all the defaults). As no qualifier is placed on the
definition, @Default
qualifier is inherited by all beans in the set.
The durable queue is defined as a producer method (as we want to alter the configuration of the queue before
having Solder use it). Additionally, it specifies that the generic beans created (that allow for
their scope to be overridden) should be placed in the conversation scope. Finally, it specifies that the
generic beans created should inherit the qualifier @Durable
.
We can now inject our generic beans as normal, using the qualifiers specified on the configuration point:
class MessageLogger {
@Inject
MessageDispatcher dispatcher;
void logMessage(Payload payload) {
/* Add metaddata to the message */
Collection<Header> headers = new ArrayList<Header>();
...
Message message = new Message(headers, payload);
dispatcher.send(message);
}
}
class DurableMessageLogger {
@Inject @Durable
MessageDispatcher dispatcher;
@Inject @Durable
DispatcherPolicy policy;
/* Tweak the dispatch policy to enable duplicate removal */
@Inject
void tweakPolicy(@Durable DispatcherPolicy policy) {
policy.removeDuplicates();
}
void logMessage(Payload payload) {
...
}
}
It is also possible to configure generic beans using beans by sub-classing the configuration type, or installing another bean of the configuration type through the SPI (e.g. using Solder Config). For example to configure a durable queue via sub-classing:
@Durable @ConversationScoped
@ACMEQueue("durableQueue")
class DurableQueueConfiguration extends MessageSystemConfiguration {
public DurableQueueConfiguration()
{
this.durable = true;
}
}
And the same thing via Solder Config:
<my:MessageSystemConfiguration>
<my:Durable/>
<s:ConversationScoped/>
<my:ACMEQueue>durableQueue</my:ACMEQueue>
<my:durable>true</my:durable>
</my:MessageSystemConfiguration>
Having seen how we use the generic beans, let's look at how to define them. We start by creating the generic configuration annotation:
@Retention(RUNTIME)
@GenericType(MessageSystemConfiguration.class)
@interface ACMEQueue {
String value();
}
The generic configuration annotation a defines the generic configuration type (in this case
MessageSystemConfiguration
); the type produced by the generic configuration point must be of this
type. Additionally it defines the member name
, used to provide the queue name.
Next, we define the queue manager bean. The manager has one producer method, which creates the queue from the configuration:
@GenericConfiguration(ACMEQueue.class) @ApplyScope
class QueueManager {
@Inject @Generic
MessageSystemConfiguration systemConfig;
@Inject
ACMEQueue config;
MessageQueueFactory factory;
@PostConstruct
void init() {
factory = systemConfig.createMessageQueueFactory();
}
@Produces @ApplyScope
public MessageQueue messageQueueProducer() {
return factory.createMessageQueue(config.name());
}
}
The bean is declared to be a generic bean for the @ACMEQueue
generic configuration type annotation
by placing the @GenericConfiguration
annotation on the class. We can inject the generic configuration
type using the @Generic
qualifier, as well the annotation used to define the queue.
Placing the @ApplyScope
annotation on the bean causes it to inherit the scope from the generic
configuration point. As creating the queue factory is a heavy operation we don't want to do it more than
necessary.
Having created the MessageQueueFactory
, we can then expose the queue, obtaining its name from the
generic configuration annotation. Additionally, we define the scope of the producer method to be inherited from
the generic configuration point by placing the annotation @ApplyScope
on the producer method. The
producer method automatically inherits the qualifiers specified by the generic configuration point.
Finally we define the message manager, which exposes the message dispatcher, as well as allowing the client to inject an object which exposes the policy the dispatcher will use when queuing messages. The client can then tweak the policy should they wish.
@Generic
class MessageManager {
@Inject @Generic
MessageQueue queue;
@Produces @ApplyScope
MessageDispatcher messageDispatcherProducer() {
return queue.createMessageDispatcher();
}
@Produces
DispatcherPolicy getPolicy() {
return queue.getDispatcherPolicy();
}
}
The service handler facility allow you to declare interfaces and abstract classes as automatically implemented beans. Any call to an abstract method on the interface or abstract class will be forwarded to the invocation handler for processing.
If you wish to convert some non-type-safe lookup to a type-safe lookup, then service handlers may be useful for you, as they allow the end user to map a lookup to a method using domain specific annotations.
We will work through using this facility, taking the example of a service which can execute JPA queries upon abstract method calls. First we define the annotation used to mark interfaces as automatically implemented beans. We meta-annotate it, defining the invocation handler to use:
@ServiceHandlerType(QueryHandler.class)
@Retention(RUNTIME)
@Target({TYPE})
@interface QueryService {}
We now define an annotation which provides the query to execute:
@Retention(RUNTIME)
@Target({METHOD})
@interface Query {
String value();
}
And finally, the invocation handler, which simply takes the query, and executes it using JPA, returning the result:
class QueryHandler {
@Inject EntityManager em;
@AroundInvoke
Object handle(InvocationContext ctx) {
return em.createQuery(ctx.getMethod().getAnnotation(Query.class).value()).getResultList();
}
}
The invocation handler is similar to an interceptor. It must have an @AroundInvoke
method that
returns an object and takes an InvocationContext
as an argument.
Do not call InvocationContext.proceed()
as there is no method to proceed to.
Injection is available into the handler class, however the handler is not a bean definition, so observer methods, producer fields and producer methods defined on the handler will not be registered.
Finally, we can define (any number of) interfaces which define our queries:
@QueryService
interface UserQuery {
@Query("select u from User u")
public List<User> getAllUsers();
}
Finally, we can inject the query interface, and call methods, automatically executing the JPA query.
class UserListManager {
@Inject
UserQuery userQuery;
List<User> users;
@PostConstruct
void create() {
users=userQuery.getAllUsers();
}
}
Solder provides a method for configuring CDI beans using alternate metadata sources, such as XML configuration. Currently, the XML provider is the only alternative available. Using a "type-safe" XML syntax, it is possible to add new beans, override existing beans, and add extra configuration to existing beans.
To take advantage of XML Configuration, you need metadata sources in the form of XML files. By default these are discovered from the classpath in the following locations:
/META-INF/beans.xml
/META-INF/seam-beans.xml
The beans.xml
file is the preferred way of
configuring beans via XML; however some CDI implementations will not allow this, so
seam-beans.xml
is provided as an alternative.
Here is a simple example. The following class represents a report:
class Report {
String filename;
@Inject
Datasource datasource;
//getters and setters
}
And the following support classes:
interface Datasource {
public Data getData();
}
@SalesQualifier
class SalesDatasource implements Datasource {
public Data getData()
{
//return sales data
}
}
class BillingDatasource implements Datasource {
public Data getData()
{
//return billing data
}
}
The Report
bean is fairly simple. It has a filename that tells the report engine where to load the
report definition from, and a datasource that provides the data used to fill the report. We are going to
configure up multiple Report
beans via xml.
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://java.sun.com/xml/ns/javaee"
ml_plain"> xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
ml_plain"> xmlns:s="urn:java:ee"
xmlns:r="urn:java:org.example.reports">
ml_plain">
ml_plain"> <r:Report>
ml_plain"> <s:modifies/>
<r:filename>sales.jrxml<r:filename>
ml_plain"> <r:datasource>
<r:SalesQualifier/>
</r:datasource>
</r:Report>
ml_plain">
ml_plain"> <r:Report filename="billing.jrxml">
<s:replaces/>
ml_plain"> <r:datasource>
ml_plain"> <s:Inject/>
<s:Exact>org.example.reports.BillingDatasource</s:Exact>
</r:datasource>
</r:Report>
</beans>
The namespace | |
There are now multiple namespaces in the
The namespace | |
The | |
Beans installed using | |
The | |
The | |
This is the shorthand syntax for setting a field value. | |
Beans installed using | |
The | |
The |
The princess rescue example is a sample web app that uses XML Config. Run it with the following command:
mvn -Pjetty jetty:run
And then navigate to http://localhost:9090/princess-rescue
. The XML configuration for the example
is in src/main/resources/META-INF/seam-beans.xml
.
The main namespace is urn:java:ee
. This namespace contains built-in
tags and types from core packages. The built-in tags are:
Beans
modifies
replaces
parameters
value
key
entry
e
(alias for entry)
v
(alias for value)
k
(alias for key)
array
int
short
long
byte
char
double
float
boolean
as well as classes from the following packages:
java.lang
java.util
javax.annotation
javax.inject
javax.enterprise.inject
javax.enterprise.context
javax.enterprise.event
javax.decorator
javax.interceptor
org.jboss.solder.core
org.jboss.solder.unwraps
org.jboss.solder.resourceLoader
Other namespaces are specified using the following syntax:
xmlns:my="urn:java:com.mydomain.package1:com.mydomain.package2"
This maps the namespace my
to the packages
com.mydomain.package1
and
com.mydomain.package2
. These packages are searched in
order to resolve elements in this namespace.
For example, you have a class com.mydomain.package2.Report
.
To configure a Report
bean you would use
<my:Report>
. Methods and fields on the bean are resolved
from the same namespace as the bean itself. It is possible to distinguish between
overloaded methods by specifying the parameter types, for more information see
Configuring Methods.
By default configuring a bean via XML creates a new bean; however there
may be cases where you want to modify an existing bean rather than
adding a new one. The <s:replaces>
and
<s:modifies>
tags allow you to do this.
The <s:replaces>
tag prevents the existing bean from being
installed, and registers a new one with the given configuration. The
<s:modifies>
tag does the same, except that it merges
the annotations on the bean with the annotations defined in XML. Where the
same annotation is specified on both the class and in XML the annotation in
XML takes precedence. This has almost the same effect as modifying an existing
bean, except it is possible to install multiple beans that modify the same class.
Config ignores beans that have the @Veto
annotation when using
<replaces>
and <modifies>
.
<my:Report>
<s:modifies>
<my:NewQualifier/>
</my:Report>
<my:ReportDatasource>
<s:replaces>
<my:NewQualifier/>
</my:ReportDatasource>
The first entry above adds a new bean with an extra qualifier, in addition
to the qualifiers already present, and prevents the existing
Report
bean from being installed.
The second prevents the existing bean from being installed, and registers a new bean with a single qualifier.
Annotations are resolved in the same way as normal classes. Conceptually, annotations are applied to the object their parent element resolves to. It is possible to set the value of annotation members using the xml attribute that corresponds to the member name. For example:
public @interface OtherQualifier {
String value1();
int value2();
QualifierEnum value();
}
<test:QualifiedBean1>
<test:OtherQualifier value1="AA" value2="1">A</my:OtherQualifier>
</my:QualifiedBean1>
<test:QualifiedBean2>
<test:OtherQualifier value1="BB" value2="2" value="B" />
</my:QualifiedBean2>
The value
member can be set using the inner text of the node, as seen
in the first example. Type conversion is performed automatically.
It is currently not possible set array annotation members.
It is possible to both apply qualifiers to and set the initial value of a field. Fields reside in the same namespace as the declaring bean, and the element name must exactly match the field name. For example if we have the following class:
class RobotFactory {
Robot robot;
}
The following xml will add the @Produces
annotation to the
robot
field:
<my:RobotFactory>
<my:robot>
<s:Produces/>
</my:robot>
</my:RobotFactory/>
Initial field values can be set three different ways as shown below:
<r:MyBean company="Red Hat Inc" />
<r:MyBean>
<r:company>Red Hat Inc</r:company>
</r:MyBean>
<r:MyBean>
<r:company>
<s:value>Red Hat Inc<s:value>
<r:SomeQualifier/>
</r:company>
</r:MyBean>
The third form is the only one that also allows you to add annotations such as qualifiers to the field.
It is possible to set Map
,Array
and
Collection
field values. Some examples:
<my:ArrayFieldValue>
<my:intArrayField>
<s:value>1</s:value>
<s:value>2</s:value>
</my:intArrayField>
<my:classArrayField>
<s:value>java.lang.Integer</s:value>
<s:value>java.lang.Long</s:value>
</my:classArrayField>
<my:stringArrayField>
<s:value>hello</s:value>
<s:value>world</s:value>
</my:stringArrayField>
</my:ArrayFieldValue>
<my:MapFieldValue>
<my:map1>
<s:entry><s:key>1</s:key><s:value>hello</s:value></s:entry>
<s:entry><s:key>2</s:key><s:value>world</s:value></s:entry>
</my:map1>
<my:map2>
<s:e><s:k>1</s:k><s:v>java.lang.Integer</s:v></s:e>
<s:e><s:k>2</s:k><s:v>java.lang.Long</s:v></s:e>
</my:map2>
</my:MapFieldValue>
Type conversion is done automatically for all primitives and primitive wrappers,
Date
, Calendar
,Enum
and
Class
fields.
The use of EL to set field values is also supported:
<m:Report>
<m:name>#{reportName}</m:name>
<m:parameters>
<s:key>#{paramName}</s:key>
<s:value>#{paramValue}</s:key>
</m:parameters>
</m:Report>
Internally, field values are set by wrapping the InjectionTarget
for a bean. This means that the expressions are evaluated once, at bean
creation time.
Inline beans allow you to set field values to another bean that is declared inline inside the field declaration.
This allows for the configuration of complex types with nestled classes. Inline beans can be declared inside both
<s:value>
and <s:key>
elements, and may be used in both collections
and simple field values. Inline beans must not have any qualifier annotations declared on the bean; instead Solder Config
assigns them an artificial qualifier. Inline beans may have any scope, however the default Dependent
scope
is recommended.
<my:Knight>
<my:sword>
<value>
<my:Sword type="sharp"/>
</value>
</my:sword>
<my:horse>
<value>
<my:Horse>
<my:name>
<value>billy</value>
</my:name>
<my:shoe>
<Inject/>
</my:shoe>
</my:Horse>
</value>
</my:horse>
</my:Knight>
It is also possible to configure methods in a similar way to configuring fields:
class MethodBean {
public int doStuff() {
return 1;
}
public int doStuff(MethodValueBean bean) {
return bean.value + 1;
}
public void doStuff(MethodValueBean[][] beans) {
/*do stuff */
}
}
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:s="urn:java:ee"
xmlns:my="urn:java:org.jboss.solder.config.xml.test.method">
<my:MethodBean>
<my:doStuff>
<s:Produces/>
</my:doStuff>
<my:doStuff>
<s:Produces/>
<my:Qualifier1/>
<s:parameters>
<my:MethodValueBean>
<my:Qualifier2/>
</my:MethodValueBean>
</s:parameters>
</my:doStuff>
<my:doStuff>
<s:Produces/>
<my:Qualifier1/>
<s:parameters>
<s:array dimensions="2">
<my:Qualifier2/>
<my:MethodValueBean/>
</s:array>
</s:parameters>
</my:doStuff>
</my:MethodBean>
</beans>
In this example, MethodBean
has three methods. They are all named doStuff
.
The first <test:doStuff>
entry in the XML file configures the method that takes no arguments. The
<s:Produces>
element makes it into a producer method.
The next entry in the file configures the method that takes a
MethodValueBean
as a parameter and the final entry
configures a method that takes a two dimensional array ofMethodValueBean
s as a parameter. For both of these methods, a qualifier was added to the method parameter and they were made into producer methods.
Method parameters are specified inside the <s:parameters>
element. If these parameters have annotation children they are taken to be annotations on
the parameter.
The corresponding Java declaration for the XML above would be:
class MethodBean {
@Produces
public int doStuff() {/*method body */}
@Produces
@Qualifier1
public int doStuff(@Qualifier2 MethodValueBean param) {/*method body */}
@Produces
@Qualifier1
public int doStuff(@Qualifier2 MethodValueBean[][] param) {/*method body */}
}
Array parameters can be represented using the <s:array>
element,
with a child element to represent the type of the array. E.g.
int method(MethodValueBean[] param);
could be configured via xml using
the following:
<my:method>
<s:array>
<my:MethodValueBean/>
</s:array>
</my:method>
If a class has a field and a method of the same name then by default the
field will be resolved. The exception is if the element has a child
<parameters>
element, in which case it is resolved
as a method.
It is also possible to configure the bean constructor in a similar manner. This is done with a
<s:parameters>
element directly on the bean element. The constructor is
resolved in the same way methods are resolved. This constructor will automatically have the
@Inject
annotation applied to it. Annotations can be applied to the constructor
parameters in the same manner as method parameters.
<my:MyBean>
<s:parameters>
<s:Integer>
<my:MyQualifier/>
</s:Integer>
</s:parameters>
</my:MyBean>
The example above is equivalent to the following java:
class MyBean {
@Inject
MyBean(@MyQualifier Integer count)
{
...
}
}
It is possible to limit which bean types are available to inject into a given injection point:
class SomeBean
{
public Object someField;
}
<my:SomeBean>
<my:someField>
<s:Inject/>
<s:Exact>com.mydomain.InjectedBean</s:Exact>
</my:someField>
</my:SomeBean>
In the example above, only beans that are assignable to InjectedBean will be eligible for injection into the field.
This also works for parameter injection points. This functionality is part of Solder, and the
@Exact
annotation can be used directly in java.
It is possible to make existing annotations into qualifiers, stereotypes or interceptor bindings.
This configures a stereotype annotation SomeStereotype
that has a single interceptor
binding and is named:
<my:SomeStereotype>
<s:Stereotype/>
<my:InterceptorBinding/>
<s:Named/>
</my:SomeStereotype>
This configures a qualifier annotation:
<my:SomeQualifier>
<s:Qualifier/>
</my:SomeQualifier>
This configures an interceptor binding:
<my:SomeInterceptorBinding>
<s:InterceptorBinding/>
</my:SomeInterceptorBinding>
Solder XML Config supports configuration of virtual producer fields. These allow for configuration of resource producer fields, Solder generic bean and constant values directly via XML. For example:
<s:EntityManager>
<s:Produces/>
<s:PersistenceContext unitName="customerPu" />
</s:EntityManager>
<s:String>
<s:Produces/>
<my:VersionQualifier />
<value>Version 1.23</value>
</s:String>
The first example configures a resource producer field. The second configures a bean
of type String, with the qualifier @VersionQualifier
and the value
'Version 1.23'
. The corresponding java for the above XML is:
class SomeClass
{
@Produces
@PersistenceContext(unitName="customerPu")
EntityManager field1;
@Produces
@VersionQualifier
String field2 = "Version 1.23";
}
Although these look superficially like normal bean declarations, the <Produces>
declaration means it is treated as a producer field instead of a normal bean.
For further information, look at the units tests in the Solder XML Config distribution. Also see the XML-based metadata chapter in the JSR-299 Public Review Draft, which is where this feature was originally proposed.
The goal of Solder's Servlet integration features is to provide portable enhancements to the Servlet API. Features include
producers for implicit Servlet objects and HTTP request state, propagating Servlet events to the CDI event bus,
forwarding uncaught exceptions to Solder's exception handling chain and binding the BeanManager
to a
Servlet context attribute for convenient access.
If you are using Java EE 5 or some other Servlet 2.5 container, then you need to manually register several Servlet components in your application's web.xml to activate the features provided by this module:
<listener>
<listener-class>org.jboss.solder.servlet.event.ServletEventBridgeListener</listener-class>
</listener>
<servlet>
<servlet-name>Servlet Event Bridge Servlet</servlet-name>
<servlet-class>org.jboss.solder.servlet.event.ServletEventBridgeServlet</servlet-class>
<!-- Make load-on-startup large enough to be initialized last (thus destroyed first) -->
<load-on-startup>99999</load-on-startup>
</servlet>
<servlet-mapping>
<servlet-name>Servlet Event Bridge Servlet</servlet-name>
<url-pattern>/*</url-pattern>
</servlet-mapping>
<filter>
<filter-name>Exception Filter</filter-name>
<filter-class>org.jboss.solder.servlet.exception.CatchExceptionFilter</filter-class>
</filter>
<filter-mapping>
<filter-name>Exception Filter</filter-name>
<url-pattern>/*</url-pattern>
</filter-mapping>
<filter>
<filter-name>Servlet Event Bridge Filter</filter-name>
<filter-class>org.jboss.solder.servlet.event.ServletEventBridgeFilter</filter-class>
</filter>
<filter-mapping>
<filter-name>Servlet Event Bridge Filter</filter-name>
<url-pattern>/*</url-pattern>
</filter-mapping>
In order for the Servlet event bridge to properly fire the ServletContext
initialized event, the CDI
runtime must be started at the time the Servlet listener is invoked. This ordering is guaranteed in a
compliant Java EE 6 environment. If you are using a CDI implementation in a Servlet environment (e.g., Weld
Servlet), and it relies on a Servlet listener to bootstrap, that listener must be registered
before any Servlet listener in web.xml
.
You're now ready to dive into the Servlet enhancements provided for you by Solder!
By including the Solder module in your web application (and performing the necessary listener configuration for pre-Servlet 3.0 environments), the servlet lifecycle events will be propagated to the CDI event bus so you can observe them using observer methods on CDI beans. Solder also fires additional lifecycle events not offered by the Servlet API, such as when the response is initialized and destroyed.
This category of events corresponds to the event receivers on the
javax.servlet.ServletContextListener
interface. The event propagated is a
javax.servlet.ServletContext
(not a javax.servlet.ServletContextEvent
,
since the ServletContext
is the only relevant information this event provides).
There are two qualifiers provided in the org.jboss.solder.servlet.event
package
(@Initialized
and @Destroyed
) that can be used to observe a specific
lifecycle phase of the servlet context.
The servlet context lifecycle events are documented in the table below.
Qualifier | Type | Description |
---|---|---|
@Default (optional) | javax.servlet.ServletContext | The servlet context is initialized or destroyed |
@Initialized | javax.servlet.ServletContext | The servlet context is initialized |
@Destroyed | javax.servlet.ServletContext | The servlet context is destroyed |
If you want to listen to both lifecycle events, leave out the qualifiers on the observer method:
public void observeServletContext(@Observes ServletContext ctx) {
System.out.println(ctx.getServletContextName() + " initialized or destroyed");
}
If you are interested in only a particular lifecycle phase, use one of the provided qualifiers:
public void observeServletContextInitialized(@Observes @Initialized ServletContext ctx) {
System.out.println(ctx.getServletContextName() + " initialized");
}
As with all CDI observers, the name of the method is insignificant.
These events are fired using a built-in servlet context listener. The CDI environment will be active when these events are fired (including when Weld is used in a Servlet container). The listener is configured to come before listeners in other extensions, so the initialized event is fired before other servlet context listeners are notified and the destroyed event is fired after other servlet context listeners are notified. However, this order cannot be not guaranteed if another extension library is also configured to be ordered before others.
The servlet context initialized event described in the previous section provides an ideal opportunity to perform startup logic as an alternative to using an EJB 3.1 startup singleton. Even better, you can configure the bean to be destroyed immediately following the initialization routine by leaving it as dependent scoped (dependent-scoped observers only live for the duration of the observe method invocation).
Here's an example of entering seed data into the database in a development environment (as indicated by a
stereotype annotation named @Development
).
@Stateless
@Development
public class SeedDataImporter {
@PersistenceContext
private EntityManager em;
public void loadData(@Observes @Initialized ServletContext ctx) {
em.persist(new Product(1, "Black Hole", 100.0));
}
}
If you'd rather not tie yourself to the Servlet API, you can observe the org.jboss.solder.servlet.WebApplication
rather than the ServletContext
. WebApplication
is a informational object
provided by Solder that holds select information about the ServletContext
such as the
application name, context path, server info and start time.
The web application lifecycle events are documented in the table below.
Qualifier | Type | Description |
---|---|---|
@Default (optional) | WebApplication | The web application is initialized, started or destroyed |
@Initialized | WebApplication | The web application is initialized |
@Started | WebApplication | The web application is started (ready) |
@Destroyed | WebApplication | The web application is destroyed |
Here's the equivalent of receiving the servlet context initialized event without coupling to the Servlet API:
public void loadData(@Observes @Initialized WebApplication webapp) {
System.out.println(webapp.getName() + " initialized at " + new Date(webapp.getStartTime()));
}
If you want to perform initialization as late as possible, after all other initialization of the application
is complete, you can observe the WebApplication
event qualified with
@Started
.
public void onStartup(@Observes @Started WebApplication webapp) {
System.out.println("Application at " + webapp.getContextPath() + " ready to handle requests");
}
The @Started
event is fired in the init method of a built-in Servlet with a load-on-startup
value of 99999.
You can also use WebApplication
with the @Destroyed
qualifier to be
notified when the web application is stopped. This event is fired by the aforementioned built-in Servlet during
it's destroy method, so likely it should fire when the application is first released.
public void onShutdown(@Observes @Destroyed WebApplication webapp) {
System.out.println("Application at " + webapp.getContextPath() + " no longer handling requests");
}
This category of events corresponds to the event receivers on the
javax.servlet.ServletRequestListener
interface. The event propagated is a
javax.servlet.ServletRequest
(not a javax.servlet.ServletRequestEvent
,
since the ServletRequest
is the only relevant information this event provides).
There are two qualifiers provided in the org.jboss.solder.servlet.event
package
(@Initialized
and @Destroyed
) that can be used to observe a specific
lifecycle phase of the servlet request and a secondary qualifier to filter events by servlet path
(@Path
).
The servlet request lifecycle events are documented in the table below.
Qualifier | Type | Description |
---|---|---|
@Default (optional) | javax.servlet.ServletRequest | A servlet request is initialized or destroyed |
@Initialized | javax.servlet.ServletRequest | A servlet request is initialized |
@Destroyed | javax.servlet.ServletRequest | A servlet request is destroyed |
@Default (optional) | javax.servlet.http.HttpServletRequest | An HTTP servlet request is initialized or destroyed |
@Initialized | javax.servlet.http.HttpServletRequest | An HTTP servlet request is initialized |
@Destroyed | javax.servlet.http.HttpServletRequest | An HTTP servlet request is destroyed |
@Path(PATH) | javax.servlet.http.HttpServletRequest | Selects HTTP request with servlet path matching PATH (drop leading slash) |
If you want to listen to both lifecycle events, leave out the qualifiers on the observer:
public void observeRequest(@Observes ServletRequest request) {
// Do something with the servlet "request" object
}
If you are interested in only a particular lifecycle phase, use a qualifier:
public void observeRequestInitialized(@Observes @Initialized ServletRequest request) {
// Do something with the servlet "request" object upon initialization
}
You can also listen specifically for a javax.servlet.http.HttpServletRequest
simply by changing the expected event type.
public void observeRequestInitialized(@Observes @Initialized HttpServletRequest request) {
// Do something with the HTTP servlet "request" object upon initialization
}
You can associate an observer with a particular servlet request path (exact match, no leading slash).
public void observeRequestInitialized(@Observes @Initialized @Path("offer") HttpServletRequest request) {
// Do something with the HTTP servlet "request" object upon initialization
// only when servlet path /offer is requested
}
As with all CDI observers, the name of the method is insignificant.
These events are fired using a built-in servlet request listener. The listener is configured to come before listeners in other extensions, so the initialized event is fired before other servlet request listeners are notified and the destroyed event is fired after other servlet request listeners are notified. However, this order cannot be not guaranteed if another extension library is also configured to be ordered before others.
The Servlet API does not provide a listener for accessing the lifecycle of a response. Therefore, Solder
simulates a response lifecycle listener using CDI events. The event object fired is a
javax.servlet.ServletResponse
.
There are two qualifiers provided in the org.jboss.solder.servlet.event
package
(@Initialized
and @Destroyed
) that can be used to observe a specific
lifecycle phase of the servlet response and a secondary qualifier to filter events by servlet path
(@Path
).
The servlet response lifecycle events are documented in the table below.
Qualifier | Type | Description |
---|---|---|
@Default (optional) | javax.servlet.ServletResponse | A servlet response is initialized or destroyed |
@Initialized | javax.servlet.ServletResponse | A servlet response is initialized |
@Destroyed | javax.servlet.ServletResponse | A servlet response is destroyed |
@Default (optional) | javax.servlet.http.HttpServletResponse | An HTTP servlet response is initialized or destroyed |
@Initialized | javax.servlet.http.HttpServletResponse | An HTTP servlet response is initialized |
@Destroyed | javax.servlet.http.HttpServletResponse | An HTTP servlet response is destroyed |
@Path(PATH) | javax.servlet.http.HttpServletResponse | Selects HTTP response with servlet path matching PATH (drop leading slash) |
If you want to listen to both lifecycle events, leave out the qualifiers.
public void observeResponse(@Observes ServletResponse response) {
// Do something with the servlet "response" object
}
If you are interested in only a particular one, use a qualifier
public void observeResponseInitialized(@Observes @Initialized ServletResponse response) {
// Do something with the servlet "response" object upon initialization
}
You can also listen specifically for a javax.servlet.http.HttpServletResponse
simply by changing the expected event type.
public void observeResponseInitialized(@Observes @Initialized HttpServletResponse response) {
// Do something with the HTTP servlet "response" object upon initialization
}
If you need access to the ServletRequest
and/or the ServletContext
objects at the same time, you can simply add them as parameters to the observer methods. For instance, let's
assume you want to manually set the character encoding of the request and response.
public void setupEncoding(@Observes @Initialized ServletResponse res, ServletRequest req) throws Exception {
if (this.override || req.getCharacterEncoding() == null) {
req.setCharacterEncoding(encoding);
if (override) {
res.setCharacterEncoding(encoding);
}
}
}
As with all CDI observers, the name of the method is insignificant.
If the response is committed by one of the observers, the request will not be sent to the target Servlet and the filter chain is skipped.
Rather than having to observe the request and response as separate events, or include the request object as an
parameter on a response observer, it would be convenient to be able to observe them as a pair. That's why Solder
fires an synthetic lifecycle event for the wrapper type ServletRequestContext
. The
ServletRequestContext
holds the ServletRequest
and the
ServletResponse
objects, and also provides access to the ServletContext
.
There are two qualifiers provided in the org.jboss.solder.servlet.event
package
(@Initialized
and @Destroyed
) that can be used to observe a specific
lifecycle phase of the servlet request context and a secondary qualifier to filter events by servlet path
(@Path
).
The servlet request context lifecycle events are documented in the table below.
Qualifier | Type | Description |
---|---|---|
@Default (optional) | ServletRequestContext | A request is initialized or destroyed |
@Initialized | ServletRequestContext | A request is initialized |
@Destroyed | ServletRequestContext | A request is destroyed |
@Default (optional) | HttpServletRequestContext | An HTTP request is initialized or destroyed |
@Initialized | HttpServletRequestContext | An HTTP request is initialized |
@Destroyed | HttpServletRequestContext | An HTTP request is destroyed |
@Path(PATH) | HttpServletRequestContext | Selects HTTP request with servlet path matching PATH (drop leading slash) |
Let's revisit the character encoding observer and examine how it can be simplified by this event:
public void setupEncoding(@Observes @Initialized ServletRequestContext ctx) throws Exception {
if (this.override || ctx.getRequest().getCharacterEncoding() == null) {
ctx.getRequest().setCharacterEncoding(encoding);
if (override) {
ctx.getResponse().setCharacterEncoding(encoding);
}
}
}
You can also observe the HttpServletRequestContext
to be notified only on HTTP requests.
If the response is committed by one of the observers, the request will not be sent to the target Servlet and the filter chain is skipped.
Since observers that have access to the response can commit it, an HttpServletRequestContext
observer that receives the initialized event can effectively work as a filter or even a Servlet. Let's consider
a primitive welcome page filter that redirects visitors to the start page:
public void redirectToStartPage(@Observes @Path("") @Initialized HttpServletRequestContext ctx)
throws Exception {
String startPage = ctx.getResponse().encodeRedirectURL(ctx.getContextPath() + "/start.jsf");
ctx.getResponse().sendRedirect(startPage);
}
Now you never have to write a Servlet listener, Servlet or Filter again!
This category of events corresponds to the event receivers on the
javax.servlet.http.HttpSessionListener
interface. The event propagated is a
javax.servlet.http.HttpSession
(not a
javax.servlet.http.HttpSessionEvent
, since the HttpSession
is the only
relevant information this event provides).
There are two qualifiers provided in the org.jboss.solder.servlet.event
package
(@Initialized
and @Destroyed
) that can be used to observe a specific
lifecycle phase of the session.
The session lifecycle events are documented in the table below.
Qualifier | Type | Description |
---|---|---|
@Default (optional) | javax.servlet.http.HttpSession | The session is initialized or destroyed |
@Initialized | javax.servlet.http.HttpSession | The session is initialized |
@Destroyed | javax.servlet.http.HttpSession | The session is destroyed |
If you want to listen to both lifecycle events, leave out the qualifiers. Note that omitting all qualifiers
will observe all events with a HttpSession
as event object.
public void observeSession(@Observes HttpSession session) {
// Do something with the "session" object
}
If you are interested in only a particular one, use a qualifier
public void observeSessionInitialized(@Observes @Initialized HttpSession session) {
// Do something with the "session" object upon being initialized
}
As with all CDI observers, the name of the method is insignificant.
This category of events corresponds to the event receivers on the
javax.servlet.http.HttpSessionActivationListener
interface. The event propagated is a
javax.servlet.http.HttpSession
(not a
javax.servlet.http.HttpSessionEvent
, since the HttpSession
is the only
relevant information this event provides).
There are two qualifiers provided in the org.jboss.solder.servlet.event
package
(@DidActivate
and @WillPassivate
) that can be used to observe a specific
lifecycle phase of the session.
The session activation events are documented in the table below.
Qualifier | Type | Description |
---|---|---|
@Default (optional) | javax.servlet.http.HttpSession | The session is initialized or destroyed |
@DidActivate | javax.servlet.http.HttpSession | The session is activated |
@WillPassivate | javax.servlet.http.HttpSession | The session will passivate |
If you want to listen to both lifecycle events, leave out the qualifiers. Note that omitting all qualifiers will
observe all events with a HttpSession
as event object.
public void observeSession(@Observes HttpSession session) {
// Do something with the "session" object
}
If you are interested in only one particular event, use a qualifier:
public void observeSessionCreated(@Observes @WillPassivate HttpSession session) {
// Do something with the "session" object when it's being passivated
}
As with all CDI observers, the name of the method is insignificant.
Solder provides producers that expose a wide-range of information available in a Servlet environment (e.g.,
implicit objects such as ServletContext
and HttpSession
and state such as
HTTP request parameters) as beans. You access this information by injecting the beans produced. This chapter
documents the Servlet objects and request state that Solder exposes and how to inject them.
The @RequestParam
qualifier allows you to inject an HTTP request parameter (i.e., URI query
string or URL form encoded parameter).
Assume a request URL of /book.jsp?id=1.
@Inject @RequestParam("id")
private String bookId;
The value of the specified request parameter is retrieved using the method
ServletRequest.getParameter(String)
. It is then produced as a dependent-scoped bean of
type String qualified @RequestParam
.
The name of the request parameter to lookup is either the value of the @RequestParam
annotation or, if the
annotation value is empty, the name of the injection point (e.g., the field name).
Here's the example from above modified so that the request parameter name is implied from the field name:
@Inject @RequestParam
private String id;
If the request parameter is not present, and the injection point is annotated with
@DefaultValue
, the value of the @DefaultValue
annotation is returned
instead.
Here's an example that provides a fall-back value:
@Inject @RequestParam @DefaultValue("25")
private String pageSize;
If the request parameter is not present, and the @DefaultValue
annotation is not present, a
null value is injected.
Since the bean produced is dependent-scoped, use of the @RequestParam
annotation on class
fields and bean properties is only safe for request-scoped beans. Beans with wider scopes should wrap this
bean in an Instance
bean and retrieve the value within context of the thread in which
it's needed.
@Inject @RequestParam("id")
private Instance<String> bookIdResolver;
...
String bookId = bookIdResolver.get();
Similar to the @RequestParam
, you can use the @HeaderParam
qualifier to
inject an HTTP header parameter. Here's an example of how you inject the user agent string of the client that
issued the request:
@Inject @HeaderParam("User-Agent")
private String userAgent;
The @HeaderParam
also supports a default value using the @DefaultValue
annotation.
Since the bean produced is dependent-scoped, use of the @HeaderParam
annotation on class
fields and bean properties is only safe for request-scoped beans. Beans with wider scopes should wrap this
bean in an Instance
bean and retrieve the value within context of the thread in which
it's needed.
@Inject @HeaderParam("User-Agent")
private Instance<String> userAgentResolver;
...
String userAgent = userAgentResolver.get();
The ServletContext
is made available as an application-scoped bean. It can be injected
safely into any CDI bean as follows:
@Inject
private ServletContext context;
The producer obtains a reference to the ServletContext
by observing the
@Initialized ServletContext
event raised by this module's Servlet-to-CDI event bridge.
The ServletRequest
is made available as a request-scoped bean. If the current request is an
HTTP request, the produced bean is an HttpServletRequest
. It can be injected safely into
any CDI bean as follows:
@Inject
private ServletRequest request;
or, for HTTP requests
@Inject
private HttpServletRequest httpRequest;
The producer obtains a reference to the ServletRequest
by observing the
@Initialized ServletRequest
event raised by this module's Servlet-to-CDI event bridge.
The ServletResponse
is made available as a request-scoped bean. If the current request is an
HTTP request, the produced bean is an HttpServletResponse
. It can be injected safely into
any CDI bean as follows:
@Inject
private ServletResponse reponse;
or, for HTTP requests
@Inject
private HttpServletResponse httpResponse;
The producer obtains a reference to the ServletResponse
by observing the
@Initialized ServletResponse
event raised by this module's Servlet-to-CDI event bridge.
The HttpSession
is made available as a request-scoped bean. It can be injected
safely into any CDI bean as follows:
@Inject
private HttpSession session;
Injecting the HttpSession
will force the session to be created. The producer obtains a
reference to the HttpSession
by calling the getSession()
on the
HttpServletRequest
. The reference to the HttpServletRequest
is obtained
by observing the @Initialized HttpServletRequest
event raised by this module's
Servlet-to-CDI event bridge.
If you merely want to know whether the HttpSession
exists, you can instead inject
the HttpSessionStatus
bean that Solder provides.
The HttpSessionStatus
is a request-scoped bean that provides access to the status of the
HttpSession
. It can be injected safely into any CDI bean as follows:
@Inject
private HttpSessionStatus sessionStatus;
You can invoke the isActive()
method to check if the session has been created, and the
getSession()
method to retrieve the HttpSession
, which will be created if
necessary.
if (!sessionStatus.isActive()) {
System.out.println("Session does not exist. Creating it now.");
HttpSession session = sessionStatus.get();
assert session.isNew();
}
The context path is made available as a dependent-scoped bean. It can be injected safely into any request-scoped CDI bean as follows:
@Inject @ContextPath
private String contextPath;
You can safely inject the context path into a bean with a wider scope using an instance provider:
@Inject @ContextPath
private Instance<String> contextPathProvider;
...
String contextPath = contextPathProvider.get();
The context path is retrieved from the HttpServletRequest
.
The list of Cookie
objects is made available as a request-scoped bean. It can be injected
safely into any CDI bean as follows:
@Inject
private List<Cookie> cookies;
The producer uses a reference to the request-scoped HttpServletRequest
bean to retrieve the
Cookie
instances by calling getCookie()
.
Similar to the @RequestParam
, you can use the @CookieParam
qualifier to
inject an HTTP header parameter. Here's an example of how you inject the username of the last logged in user
(assuming you have previously stored it in a cookie):
@Inject @CookieParam
private String username;
If the type at the injection point is Cookie
, the Cookie
object will
be injected instead of the value.
@Inject @CookieParam
private Cookie username;
The @CookieParam
also support a default value using the @DefaultValue
annotation.
Since the bean produced is dependent-scoped, use of the @CookieParam
annotation on class
fields and bean properties is only safe for request-scoped beans. Beans with wider scopes should wrap this
bean in an Instance
bean and retrieve the value within context of the thread in which
it's needed.
@Inject @CookieParam("username")
private Instance<String> usernameResolver;
...
String username = usernameResolver.get();
The server info string is made available as a dependent-scoped bean. It can be injected safely into any CDI bean as follows:
@Inject @ServerInfo
private String serverInfo;
The context path is retrieved from the ServletContext
.
Solder provides a simple, yet robust foundation for modules and/or applications to establish a customized exception handling process. Solder's Servlet integration ties into the exception handling model by forwarding all unhandled Servlet exceptions to the exception handling framework so that they can be handled in a centralized, extensible and uniform manner.
The Servlet API is extremely weak when it comes to handling exceptions. You are limited to handling exceptions
using the built-in, declarative controls provided in web.xml
. Those controls give you two options:
send an HTTP status code
forward to an error page (servlet path)
To make matters more painful, you are required to configure these exception mappings in web.xml
. It's really
a dinosaur left over from the past. In general, the Servlet specification seems to be pretty non-chalant about
exceptions, telling you to "handle them appropriately." But how?
That's where the exception handling integration in comes in. Solder's exception handling framework traps all unhandled exceptions (those that bubble outside of the Servlet and any filters) and forwards them on to Solder. Exception handlers are free to handle the exception anyway they like, either programmatically or via a declarative mechanism.
If a exception handler registered with Solder handles the exception, then the integration closes the response without raising any additional exceptions. If the exception is still unhandled after Solder finishes processing it, then the integration allows it to pass through to the normal Servlet exception handler.
You can define an exception handler for a web request using the normal syntax of a Solder exception handler. Let's catch any exception that bubbles to the top and respond with a 500 error.
@HandlesExceptions
public class ExceptionHandlers {
void handleAll(@Handles CaughtException<Throwable> caught, HttpServletResponse response) {
response.sendError(500, "You've been caught by Catch!");
}
}
That's all there is to it! If you only want this handler to be used for exceptions raised by a web request
(excluding web service requests like JAX-RS), then you can add the @WebRequest
qualifier to
the handler:
@HandlesExceptions
public class ExceptionHandlers {
void handleAll(@Handles @WebRequest
CaughtException<Throwable> caught, HttpServletResponse response) {
response.sendError(500, "You've been caught by Solder!");
}
}
@WebRequest
may be added to limit handlers to only catch exceptions initiated by
the Servlet integration.
Let's consider another example. When the custom AccountNotFound
exception is thrown,
we'll send a 404 response using this handler.
void handleAccountNotFound(@Handles @WebRequest
CaughtException<AccountNotFound> caught, HttpServletResponse response) {
response.sendError(404, "Account not found: " + caught.getException().getAccountId());
}
Typically, the BeanManager
is obtained using some form of injection. However, there are
scenarios where the code being executed is outside of a managed bean environment and you need a way in. In these
cases, it's necessary to lookup the BeanManager
from a well-known location.
In general, you should isolate external BeanManager
lookups to integration code.
The standard mechanism for locating the BeanManager
from outside a managed bean environment, as
defined by the JSR-299 specification, is to look it up in JNDI. However, JNDI isn't the most convenient technology
to depend on when you consider all popular deployment environments (think Tomcat and Jetty).
As a simpler alternative, Solder binds the BeanManager
to the following servlet context
attribute (whose name is equivalent to the fully-qualified class name of the BeanManager
interface:
javax.enterprise.inject.spi.BeanManager
Solder also includes a provider that retrieves the BeanManager
from this location.
Anytime the Solder module needs a reference to the BeanManager
, it uses this lookup
mechanism to ensure that the module works consistently across deployment environments, especially in Servlet
containers.
You can retrieve the BeanManager
in the same way. If you want to hide the lookup, you can
extend the BeanManagerAware
class and retrieve the BeanManager
from the the
method getBeanManager()
, as shown here:
public class NonManagedClass extends BeanManagerAware {
public void fireEvent() {
getBeanManager().fireEvent("Send me to a managed bean");
}
}
Alternatively, you can retrieve the BeanManager
from the method
getBeanManager()
on the BeanManagerLocator
class, as shown here:
public class NonManagedClass {
public void fireEvent() {
new BeanManagerLocator().getBeanManager().fireEvent("Send me to a managed bean");
}
}
The best way to transfer execution of the current context to the managed bean environment is to send an event to an observer bean, as this example above suggests.
Under the covers, these classes look for the BeanManager
in the servlet context attribute
covered in this section, among other available strategies. Refer to
Chapter 10, Obtaining a reference to the BeanManager for information on how to leverage the servlet
context attribute provider to access the BeanManager
from outside the CDI environment.
Sometimes developers need to access web application resources from application code. Typically the
ServletContext
is used to load resources by calling getResource()
.
Unfortunately the ServletContext
cannot be accessed in all situations.
Especially CDI extensions can be problematic in this regard as they are executed during a stage in the
application startup in which the ServletContext
may not have been created yet.
Solder offers some help in this situation. The class WebResourceLocator
provides a simple
way to obtain resources from the web application. Under the covers this class uses the
WebResourceLocationProvider
SPI to retrieve the location of the resources.
The following example shows how to use the class:
WebResourceLocator locator = new WebResourceLocator();
InputStream stream = locator.getWebResource("/WEB-INF/web.xml");
if (stream != null) {
// parse the input stream
}
As you can see using the WebResourceLocator
is very easy. Just create an instance of the
class and then use getWebResource()
to retrieve an InputStream.
Please note that you should always prefer to use the standard Servlet API to load resources from the web
application if possible. This Solder API is only intended to be used if it is not possible to use the
ServletContext
(like for example in CDI extensions).
Exceptions are a fact of life. As developers, we need to be prepared to deal with them in the most graceful manner possible. Solder's exception handling framework provides a simple, yet robust foundation for modules and/or applications to establish a customized exception handling process. By employing a delegation model, Solder allows exceptions to be addressed in a centralized, extensible and uniform manner.
In this guide, we'll explore the various options you have for handling exceptions using Solder, as well as how framework authors can offer Solder exception handling integration.
Exception handling in Solder is based around the CDI eventing model. While the implementation of exception handlers may not be the same as a CDI event, and the programming model is not exactly the same as specifying a CDI event / observer, the concepts are very similar. Solder makes use of events for many of its features. Eventing is actually the only way to start using Solder's exception handling.
This event is fired either by the application or a Solder exception handling integration. Solder then hands the exception off to a chain of registered handlers, which deal with the exception appropriately. The use of CDI events to connect exceptions to handlers makes this strategy of exception handling non-invasive and minimally coupled to the exception handling infrastructure.
The exception handling process remains mostly transparent to the developer. In most cases, you register an exception handler simply by annotating a handler method. Alternatively, you can handle an exception programmatically, just as you would observe an event in CDI.
There are other events that are fired during the exception handling process that will allow great customization of the exception, stack trace, and status. This allows the application developer to have the most control possible while still following a defined workflow. These events and other advanced usages will be covered in the next chapter.
The entire exception handling process starts with an event. This helps keep your application minimally coupled to Solder, but also allows for further extension. Exception handling in Solder is all about letting you take care of exceptions the way that makes the most sense for your application. Events provide this delicate balance.
There are three means of firing the event to start the exception handling process:
manual firing of the event
using an interceptor
module integration - no code needs to be changed
Manually firing an event to use Solder's exception handling is primarily used in your own try/catch blocks. It's very painless and also easy. Let's examine an sample that might exist inside of a simple business logic lookup into an inventory database:
@Stateless
public class InventoryActions {
@PersistenceContext private EntityManager em;@Inject private Event<ExceptionToCatch> catchEvent;
public Integer queryForItem(Item item) {
try {
Query q = em.createQuery("SELECT i from Item i where i.id = :id");
q.setParameter("id", item.getId());
return q.getSingleResult();
} catch (PersistenceException e) {catchEvent.fire(new ExceptionToCatch(e));
}
}
}
The | |
The event is fired with a new instance of |
A CDI Interceptor has been added to help with integration of Solder exception handling into your
application. It's used just like any interceptor, and must be enabled in the beans.xml
file for your bean archive. This interceptor can be used at the class or method level.
This interceptor is a typical AroundInvoke
interceptor and is invoked before the method
(which in this case merely wraps the call to the intercepted method in a try / catch block). The intercepted method is called
then, if an exception (actually a Throwable
) occurs during execution of the intercepted
method the exception is passed to Solder (without any qualifiers). Normal flow continues from there, however,
take not of the following warning:
Using the interceptor may cause unexpected behavior to methods that call intercepted methods in which an exception occurs, please see the API docs for more information about returns if an exception occurs.
As an application developer (i.e., an end user of Solder's exception handling), you'll be focused on writing exception handlers. An exception handler is a method on a CDI bean that is invoked to handle a specific type of exception. Within that method, you can implement any logic necessary to handle or respond to the exception.
If there are no exception handlers for an exception, the exception is rethrown.
Given that exception handler beans are CDI beans, they can make use of dependency injection, be scoped, have interceptors or decorators and any other functionality available to CDI beans.
Exception handler methods are designed to follow the syntax and semantics of CDI observers, with some special purpose exceptions explained in this guide. The advantage of this design is that exception handlers will be immediately familiar to you if you are studying or well-versed in CDI.
In this and subsequent chapters, you'll learn how to define an exception handler, explore how and when it gets invoked, modify
an exception and a stack trace, and even extend exception handling further through events that are fired during the handling
workflow. We'll begin by covering the two annotations that are used to declare an exception handler,
@HandlesExceptions
and @Handles
.
Exception handlers are contained within exception handler beans, which are CDI beans annotated with
@HandlesExceptions
. Exception handlers are methods which have a parameter which is an
instance of CaughtException<T extends Throwable>
annotated with the
@Handles
annotation.
The @HandlesException
annotation is simply a marker annotation that instructs the Solder
exception handling CDI extension to scan the bean for handler methods.
Let's designate a CDI bean as an exception handler by annotating it with
@HandlesException
.
@HandlesExceptions
public class MyHandlers {}
That's all there is to it. Now we can begin defining exception handling methods on this bean.
The @HandlesExceptions
annotation may be deprecated in favor of annotation indexing
at a later date.
@Handles
is a method parameter annotation that designates a method as an exception
handler. Exception handler methods are registered on beans annotated with
@HandlesExceptions
. Solder will discover all such methods at deployment time.
Let's look at an example. The following method is invoked for every exception that Solder processes and
prints the exception message to stdout. (Throwable
is the base exception type in Java and
thus represents all exceptions).
@HandlesExceptions
public class MyHandlers
{void printExceptions(@Handles CaughtException<Throwable> evt)
{
System.out.println("Something bad happened: " +evt.getException().getMessage());
evt.markHandled();
}
}
The | |
The | |
The | |
This handler does not modify the invocation of subsequent handlers, as designated by invoking
|
The @Handles
annotation must be placed on a parameter of the method, which must
be of type CaughtException<T extends Throwable>
. Handler methods are similar to CDI
observers and, as such, follow the same principles and guidelines as observers (such as invocation,
injection of parameters, qualifiers, etc) with the following exceptions:
a parameter of a handler method must be a CaughtException
handlers are ordered before they are invoked (invocation order of observers is non-deterministic)
any handler can prevent subsequent handlers from being invoked
In addition to designating a method as exception handler, the @Handles
annotation specifies two pieces of information about when the method should be invoked relative to other
handler methods:
a precedence relative to other handlers for the same exception type. Handlers with higher precedence are invoked before handlers with lower precedence that handle the same exception type. The default precedence (if not specified) is 0.
the type of the traversal mode (i.e., phase) during which the handler is invoked. The default
traversal mode (if not specified) is TraversalMode.DEPTH_FIRST
.
Let's take a look at more sophisticated example that uses all the features of handlers to log all exceptions.
@HandlesExceptions
public class MyHandlers
{void logExceptions(@Handles(during = TraversalMode.BREADTH_FIRST)
@WebRequest CaughtException<Throwable> evt,
Logger log)
{
log.warn("Something bad happened: " + evt.getException().getMessage());
}
}
The
| |
This handler has a default precedence of 0 (the default value of the precedence attribute on
| |
This handler is qualified with | |
Any additional parameters of a handler method are treated as injection points. These parameters are
injected into the handler when it is invoked by Solder. In this case, we are injecting a
|
A handler is guaranteed to only be invoked once per exception (automatically muted), unless it re-enables
itself by invoking the unmute()
method on the CaughtException
instance.
Handlers must not throw checked exceptions, and should avoid throwing unchecked exceptions. Should a handler throw an unchecked exception it will propagate up the stack and all handling done via Solder will cease. Any exception that was being handled will be lost.
When an exception is thrown, chances are it's nested (wrapped) inside other exceptions. (If you've ever examined a server log, you'll appreciate this fact). The collection of exceptions in its entirety is termed an exception chain.
The outermost exception of an exception chain (e.g., EJBException, ServletException, etc) is probably of little use to exception handlers. That's why Solder doesn't simply pass the exception chain directly to the exception handlers. Instead, it intelligently unwraps the chain and treats the root exception cause as the primary exception.
The first exception handlers to be invoked by Solder are those that match the type of root cause. Thus, instead
of seeing a vague EJBException
, your handlers will instead see an meaningful exception such
as ConstraintViolationException
.
This feature, alone, makes Solder's exception handling a worthwhile tool.
Solder continues to work through the exception chain, notifying handlers of each exception in the stack,
until a handler flags the exception as handled. Once an exception is marked as handled, Solder stops processing
the exception. If a handler instructed Solder to rethrow the exception (by invoking
CaughtException#rethrow()
, Solder will rethrow the exception outside the Solder exception handling
infrastructure. Otherwise, it simply returns flow control to the caller.
Consider a exception chain containing the following nested causes (from outer cause to root cause):
EJBException
PersistenceException
SQLGrammarException
Solder will unwrap this exception and notify handlers in the following order:
SQLGrammarException
PersistenceException
EJBException
If there's a handler for PersistenceException
, it will likely prevent the handlers for
EJBException
from being invoked, which is a good thing since what useful information can
really be obtained from EJBException
?
While processing one of the causes in the exception chain, Solder has a specific order it uses to invoke the handlers, operating on two axes:
traversal of exception type hierarchy
relative handler precedence
We'll first address the traversal of the exception type hierarchy, then cover relative handler precedence.
Solder doesn't simply invoke handlers that match the exact type of the exception. Instead, it walks up and down the type hierarchy of the exception. It first notifies least specific handler in breadth first traversal mode, then gradually works down the type hierarchy toward handlers for the actual exception type, still in breadth first traversal. Once all breadth first traversal handlers have been invoked, the process is reversed for depth first traversal, meaning the most specific handlers are notified first and Solder continues walking up the hierarchy tree.
There are two modes of this traversal:
BREADTH_FIRST
DEPTH_FIRST
By default, handlers are registered into the DEPTH_FIRST traversal path. That means in most cases, Solder starts with handlers of the actual exception type and works up toward the handler for the least specific type.
However, when a handler is registered to be notified during the BREADTH_FIRST traversal, as in the example above, Solder will notify that exception handler before the exception handler for the actual type is notified.
Let's consider an example. Assume that Solder is handling the SocketException
. It will
notify handlers in the following order:
Throwable
(BREADTH_FIRST)
Exception
(BREADTH_FIRST)
IOException
(BREADTH_FIRST)
SocketException
(BREADTH_FIRST)
SocketException
(DEPTH_FIRST)
IOException
(DEPTH_FIRST)
Exception
(DEPTH_FIRST)
Throwable
(DEPTH_FIRST)
The same type traversal occurs for each exception processed in the chain.
In order for a handler to be notified of the IOException
before the SocketException
,
it would have to specify the BREADTH_FIRST
traversal path explicitly:
void handleIOException(@Handles(during = TraversalMode.BREADTH_FIRST)
CaughtException<IOException> evt)
{
System.out.println("An I/O exception occurred, but not sure what type yet");
}
BREADTH_FIRST
handlers are typically used for logging exceptions because they are not likely to be
short-circuited (and thus always get invoked).
When Solder finds more than one handler for the same exception type, it orders the handlers by precedence. Handlers with higher precedence are executed before handlers with a lower precedence. If Solder detects two handlers for the same type with the same precedence, it detects it as an error and throws an exception at deployment time.
Let's define two handlers with different precedence:
void handleIOExceptionFirst(@Handles(precedence = 100) CaughtException<IOException> evt)
{
System.out.println("Invoked first");
}
void handleIOExceptionSecond(@Handles CaughtException<IOException> evt)
{
System.out.println("Invoked second");
}
The first method is invoked first since it has a higher precedence (100) than the second method, which has the default precedence (0).
To make specifying precedence values more convenient, Solder provides several built-in constants, available
on the Precedence
class:
BUILT_IN = -100
FRAMEWORK = -50
DEFAULT = 0
LOW = 50
HIGH = 100
To summarize, here's how Solder determines the order of handlers to invoke (until a handler marks exception as handled):
Unwrap exception stack
Begin processing root cause
Find handler for least specific handler marked for BREADTH_FIRST traversal
If multiple handlers for same type, invoke handlers with higher precedence first
Find handler for most specific handler marked for DEPTH_FIRST traversal
If multiple handlers for same type, invoke handlers with higher precedence first
Continue above steps for each exception in stack
There are two APIs provided by Solder that should be familiar to application developers:
CaughtException
ExceptionStack
In addition to providing information about the exception being handled, the
CaughtException
object contains methods to control the exception handling process, such
as rethrowing the exception, aborting the handler chain or unmuting the current handler.
Five methods exist on the CaughtException
object to give flow control to the handler
abort()
- terminate all handling immediately after this handler, does not mark the
exception as handled, does not re-throw the exception.
rethrow()
- continues through all handlers, but once all handlers have been called
(assuming another handler does not call abort() or handled()) the initial exception passed to Solder is
rethrown. Does not mark the exception as handled.
handled()
- marks the exception as handled and terminates further handling.
markHandled()
- default. Marks the exception as handled and proceeds with the rest of the handlers.
dropCause()
- marks the exception as handled, but proceeds to the next cause in
the cause container, without calling other handlers for the current cause.
Once a handler is invoked it is muted, meaning it will not be run again for that exception chain,
unless it's explicitly marked as unmuted via the unmute()
method on
CaughtException
.
ExceptionStack
contains information about the exception causes relative to the current
exception cause. It is also the source of the exception types the invoked handlers are matched against. It
is accessed in handlers by calling the method getExceptionStack()
on the
CaughtException
object. Please see
API docs
for more information, all methods are fairly self-explanatory.
This object is mutable and can be modified before any handlers are invoked by an observer:
public void modifyStack(@Observes ExceptionStack stack) {
...
}
Modifying the ExceptionStack
may be useful to remove exception types that are effectively meaningless
such as EJBException
, changing the exception type to something more meaningful such
as cases like SQLException
, or wrapping exceptions as custom application exception
types.
At times it may be useful to change the exception to something a little more specific or meaningful before
it is sent to handlers. Solder provides the means to make this happen. A prime use case for this behavior is
a persistence-related exception coming from the database. Many times what we get from the database is an
error number inside of a SQLException
, which isn't very helpful.
Before any handlers are notified of an exception, Solder will raise an event of type
ExceptionStack
. This type contains all the exceptions in the chain, and will allow you to
change the exception elements that will be used to notify handlers using the
setCauseElements(Collection)
method. Do not use any of the other methods as they only
return copies of the chain.
When changing the exception, it is strongly recommended you keep the same stack trace for the exceptions you are changing. If the stack trace is not set then the new exception will not contain any stack information save from the time it was created, which is likely to be of little use to any handler.
Stack traces are an everyday occurrence for the Java developer, unfortunately the base stack trace isn't very helpful and can be difficult to understand and see the root problem. Solder helps make this easier by:
turning the stack upside down and showing the root cause first, and
allowing the stack trace to be filtered
The great part about all of this: it's done without a need for CDI! You can use it in a basic Java project, just include the Solder jar. There are four classes to be aware of when using filtering
ExceptionStackOutput
StackFrameFilter
StackFrameFilterResult
StackFrame
There's not much to this, pass it the exception to print and the filter to use in the constructor and call
printTrace()
which returns a string -- the stack trace (filtered or not). If no filter is
passed to the constructor, calling printTrace()
will still unwrap the stack and print the
root cause first. This can be used in place ofThrowable#printStackTrace()
, provided the
returned string is actually printed to standard out or standard error.
This is the workhorse interface that will need to be implemented to do any filtering for a stack trace. It only
has one method:public StackFrameFilterResult process(StackFrame frame)
. Further below are
methods on StackFrame
andStackFrameFilterResult
. Some examples are
included below to get an idea what can be done and how to do it.
This is a simple enumeration of valid return values for the process
method. Please see the
API docs
for definitions of each value.
This contains methods to help aid in determining what to do in the filter, it also allows you to completely
replace the StackTraceElement
if desired. The four "mark" methods deal with marking a stack
trace and are used if "folding" a stack trace is desired, instead of dropping the frame. The StackFrame
will allow for multiple marks to be set. The last method,getIndex()
, will return the index
of the StackTraceElement
from the exception.
Example 27.1. Terminate
@Override
public StackFrameFilterResult process(StackFrame frame) {
return StackFrameFilterResult.TERMINATE;
}
This example will simply show the exception, no stack trace.
Example 27.2. Terminate After
@Override
public StackFrameFilterResult process(StackFrame frame) {
return StackFrameFilterResult.TERMINATE_AFTER;
}
This is similar to the previous example, save the first line of the stack is shown.
Example 27.3. Drop Remaining
@Override
public StackFrameFilterResult process(StackFrame frame) {
if (frame.getIndex() >= 5) {
return StackFrameFilterResult.DROP_REMAINING;
}
return StackFrameFilterResult.INCLUDE;
}
This filter drops all stack elements after the fifth element.
Example 27.4. Folding
@Override
public StackFrameFilterResult process(StackFrame frame) {
if (frame.isMarkSet("reflections.invoke")) {
if (frame.getStackTraceElement().getClassName().contains("java.lang.reflect")) {
frame.clearMark("reflections.invoke");
return StackFrameFilterResult.INCLUDE;
}
else if (frame.getStackTraceElement().getMethodName().startsWith("invoke")) {
return StackFrameFilterResult.DROP;
}
}
if (frame.getStackTraceElement().getMethodName().startsWith("invoke")) {
frame.mark("reflections.invoke");
return StackFrameFilterResult.DROP;
}
return StackFrameFilterResult.INCLUDE;
}
Certainly the most complicated example, however, this shows a possible way of "folding" a stack trace. In the
example any internal reflection invocation methods are folded into a single
java.lang.reflect.Method.invoke()
call, no more internal com.sun calls in the trace.
Integration of Solder's exception handling with other frameworks consists of one main step, and two other optional (but highly encouraged) steps:
creating and firing an ExceptionToCatch
adding any default handlers and qualifiers with annotation literals (optional)
supporting ServiceHandlers for creating exception handlers
An ExceptionToCatch
is constructed by passing a Throwable
and
optionally qualifiers for handlers. Firing the event is done via CDI events (either straight from the
BeanManager
or injecting a Event<ExceptionToCatch>
and calling fire).
To ease the burden on the application developers, the integration should tie into the exception handling
mechanism of the integrating framework, if any exist. By tying into the framework's exception handling,
any uncaught exceptions should be routed through Solder's exception handling system and allow handlers to be invoked.
This is the typical way of using Solder to handle exceptions. Of course, it doesn't stop the application
developer from firing their own ExceptionToCatch
within a catch block.
The integration should check to see if the exception was handled and rethrow the exception if it was not
handled. It should also wrap the firing of the event in a try catch, and unwrap any exceptions that are
thrown. This exception should be javax.enterprise.event.ObserverException
and should
wrap the exception that should be rethrown.
An integration with Solder can define it's own handlers to always be used. It's recommended that any built-in handler from an integration have a very low precedence, be a handler for as generic an exception as is suitable (i.e. Seam Persistence could have a built-in handler for PersistenceExceptions to rollback a transaction, etc), and make use of qualifiers specific for the integration. This helps limit any collisions with handlers the application developer may create.
Solder supports qualifiers for the CaughtException
. To add qualifiers to be used when
notifying handlers, the qualifiers must be added to the ExceptionToCatch
instance via the
constructor (please see API docs for more info). Qualifiers for integrations should be used to avoid
collisions in the application error handling both when defining handlers and when firing events from
the integration.
ServiceHandlers make for a very easy and concise way to define exception handlers. The following example is a possible usage of ServiceHandlers within a JAX-RS application:
@HandlesExceptions
@ExceptionResponseService
public interface DeclarativeRestExceptionHandlers
{
@SendHttpResponse(status = 403, message = "Access to resource denied (Annotation-configured response)")
void onNoAccess(@Handles @RestRequest CaughtException<AccessControlException> e);
@SendHttpResponse(status = 400, message = "Invalid identifier (Annotation-configured response)")
void onInvalidIdentifier(@Handles @RestRequest CaughtException<IllegalArgumentException> e);
}
All the vital information that would normally be done in the handler method is actually contained in the
@SendHttpResponse
annotation. The only thing left is some boiler plate code to setup
the Response
. In a jax-rs application (or even in any web application) this approach helps
developers cut down on the amount of boiler plate code they have to write in their own handlers and should
be implemented in any Solder integration, however, there may be situations where ServiceHandler
s
simply do not make sense.
If ServiceHandlers are implemented make sure to document if any of the methods are called from
CaughtException
, specifically abort()
, handled()
or rethrow()
. These methods affect invocation of other handlers (or rethrowing the
exception in the case of rethrow()
).
Handlers can be registered programatically at runtime instead of solely at deploy time. This done very simply
by injecting HandlerMethodContainer
and calling registerHandlerMethod(HandlerMethod)
.
HandlerMethod
has been relaxed in this version as well, and is not tied directly to Java. It
is therefore feasible handlers written using other JVM based languages could be easily registered and
participate in exception handling.
An exception chain is made up of many different exceptions or causes until the root exception is found at the bottom of the chain. When all of the causes are removed or looked at this forms the causing container. The container may be traversed either ascending (root cause first) or descending (outer most first).
A CDI enabled Bean which contains handler methods.
Annotated with the @HandlesExceptions
annotation.
See Also Handler Method.
A method within a handler bean which is marked as a handler using the @Handler
s on an argument,
which must be an instance of CaughtException
. Handler methods typically are public with a void return.
Other parameters of the method will be treated as injection points and will be resolved
via CDI and injected upon invocation.
See Also Handler Bean.
Table of Contents
Seam provides extensive support for the two most popular persistence architectures for Java: Hibernate3, and the Java Persistence API introduced with EJB 3.0. Seam's unique state-management architecture allows the most sophisticated ORM integration of any web application framework.
Previously the Seam Persistence module provided transactional-related features also, however as transactions are not an exclusive feature of the persistence domain, these features have been moved into a separate module called Seam Transactions.
Seam grew out of the frustration of the Hibernate team with the statelessness typical of the previous generation of Java application architectures. The state management architecture of Seam was originally designed to solve problems relating to persistence — in particular problems associated withoptimistic transaction processing. Scalable online applications always use optimistic transactions. An atomic (database/JTA) level transaction should not span a user interaction unless the application is designed to support only a very small number of concurrent clients. But almost all interesting work involves first displaying data to a user, and then, slightly later, updating the same data. So Hibernate was designed to support the idea of a persistence context which spanned an optimistic transaction.
Unfortunately, the so-called "stateless" architectures that preceded Seam and
EJB 3.0 had no construct for representing an optimistic transaction. So, instead,
these architectures provided persistence contexts scoped to the atomic
transaction. Of course, this resulted in many problems for users, and is the
cause of the number one user complaint about Hibernate: the dreaded
LazyInitializationException
. What we need is a construct
for representing an optimistic transaction in the application tier.
EJB 3.0 recognizes this problem, and introduces the idea of a stateful component (a stateful session bean) with an extended persistence context scoped to the lifetime of the component. This is a partial solution to the problem (and is a useful construct in and of itself) however there are two problems:
The lifecycle of the stateful session bean must be managed manually via code in the web tier (it turns out that this is a subtle problem and much more difficult in practice than it sounds).
Propagation of the persistence context between stateful components in the same optimistic transaction is possible, but tricky.
Seam solves the first problem by providing conversations, and stateful session bean components scoped to the conversation. (Most conversations actually represent optimistic transactions in the data layer.) This is sufficient for many simple applications (such as the Seam booking demo) where persistence context propagation is not needed. For more complex applications, with many loosely-interacting components in each conversation, propagation of the persistence context across components becomes an important issue. So Seam extends the persistence context management model of EJB 3.0, to provide conversation-scoped extended persistence contexts.
To get started with Seam Persistence you need to add seam-persistence.jar
and solder-impl.jar
to your deployment. The relevant Maven configuration
is as follows:
<dependency>
<groupId>org.jboss.seam.persistence</groupId>
<artifactId>seam-persistence-api</artifactId>
<version>${seam.persistence.version}</version>
</dependency>
<dependency>
<groupId>org.jboss.seam.persistence</groupId>
<artifactId>seam-persistence</artifactId>
<version>${seam.persistence.version}</version>
</dependency>
<dependency>
<groupId>org.jboss.solder</groupId>
<artifactId>solder-impl</artifactId>
<version>${solder.version}</version>
</dependency>
You will also need to have a JPA provider on the classpath. If you are using java EE this is taken care of for you. If not, we recommend hibernate.
<dependency>
<groupId>org.hibernate</groupId>
<artifactId>hibernate-core</artifactId>
<version>3.5.1-Final</version>
</dependency>
If you're using Seam outside of a Java EE environment, you can't rely upon the container to manage the persistence context lifecycle for you. Even if you are in an EE environment, you might have a complex application with many loosely coupled components that collaborate together in the scope of a single conversation, and in this case you might find that propagation of the persistence context between component is tricky and error-prone.
In either case, you'll need to use a
managed persistence context
(for JPA) or a
managed session
(for Hibernate) in your components.
A Seam-managed persistence context is just a built-in Seam component that manages an
instance of
EntityManager
or
Session
in the
conversation (or any other) context. You can inject it with@Inject
.
@ExtensionManaged @Produces @PersistenceUnit @ConversationScoped EntityManagerFactory producerField;
This is just an ordinary resource producer field as defined by the CDI
specification, however the presence of the
@ExtensionManaged
annotation tells seam to create a seam managed persistence context from
thisEntityManagerFactory
. This managed
persistence context can be injected normally, and has the same scope and
qualifiers that are specified on the resource producer field.
This will work even in a SE environment where
@PersistenceUnit
injection is not normally supported. This is because the seam persistence
extensions will bootstrap the
EntityManagerFactory
for you.
Now we can have our EntityManager
injected using:
@Inject EntityManager entityManager;
The more eagle eyed among you may have noticed that the resource producer
field appears to be conversation scoped, which the CDI specification does
not require containers to support. This is actually not the case, as the
@ConversationScoped
annotation is removed by the Seam Persistence portable
extension. It only specifies the scope of the created SMPC, not the
EntityManagerFactory
.
If you are using EJB3 and mark your class or method @TransactionAttribute(REQUIRES_NEW)
then the transaction and persistence context shouldn't be propagated to method
calls on this object. However as the Seam-managed persistence
context is propagated to any component within the conversation, it
will be propagated to methods marked REQUIRES_NEW
.
Therefore, if you mark a method REQUIRES_NEW
then you should access the entity manager using @PersistenceContext
.
Persistence contexts scoped to the conversation allows you to program optimistic
transactions that span multiple requests to the server without the need to use the
merge()
operation , without the need to re-load
data at the beginning of each request, and without the need to wrestle with the
LazyInitializationException
or NonUniqueObjectException
.
As with any optimistic transaction management, transaction isolation and consistency
can be achieved via use of optimistic locking. Fortunately, both Hibernate and EJB
3.1 make it very easy to use optimistic locking, by providing the
@Version
annotation.
By default, the persistence context is flushed (synchronized with the database)
at the end of each transaction. This is sometimes the desired behavior. But very
often, we would prefer that all changes are held in memory and only written to
the database when the conversation ends successfully. This allows for truly
atomic conversations. Unfortunately there is currently no simple, usable and
portable way to implement atomic conversations using EJB 3.1 persistence.
However, Hibernate provides this feature as a vendor extension to the
FlushModeType
s defined by the specification, and it is
our expectation that other vendors will soon provide a similar extension.
Seam proxies the EntityManager
or Session
object whenever you use a Seam-managed persistence context. This
lets you use EL expressions in your query strings, safely and efficiently. For
example, this:
User user = em.createQuery("from User where username=#{user.username}")
.getSingleResult();
is equivalent to:
User user = em.createQuery("from User where username=:username")
.setParameter("username", user.getUsername())
.getSingleResult();
Of course, you should never, ever write it like this:
User user = em.createQuery("from User where username=" + user.getUsername()) //BAD!
.getSingleResult();
(It is inefficient and vulnerable to SQL injection attacks.)
This only works with Seam managed persistence contexts, not persistence contexts that are injected
with @PersistenceContext
.
Sometimes you may want to perform some additional setup on the EntityManager
after
it has been created. For example, if you are using Hibernate you may want to set a filter. Seam
persistence fires a
SeamManagedPersistenceContextCreated
event when a Seam managed
persistence context is created. You can observe this event and perform any setup you require in
an observer method. For example:
public void setupEntityManager(@Observes SeamManagedPersistenceContextCreated
event) {
Session session = (Session) event.getEntityManager().getDelegate();
session.enableFilter("myfilter");
}
Table of Contents
Unlike EJB session beans CDI beans are not transactional by default. Seam Transaction
brings declarative transaction management to CDI beans by enabling them to
use @TransactionAttribute
. Seam also provides the @Transactional
annotation, for environments where java EE APIs are not present.
In order to enable declarative transaction management for managed beans you need to list the transaction interceptor in beans.xml:
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="
http://java.sun.com/xml/ns/javaee
http://docs.jboss.org/cdi/beans_1_0.xsd">
<interceptors>
<class>org.jboss.seam.transaction.TransactionInterceptor</class>
</interceptors>
</beans>
If you are in a Java EE 6 environment then you are good to go, no additional configuration is required.
If you are deploying to JBoss AS6 it is important to know that it does not support meta data per bean archive and will throw a deployment error if defined twice. Additionally some Seam 3 modules such as Security already enable this Interceptor and defining it again will result in a deployment error.
This is not an issue with JBoss AS7 or Glassfish.
If you are not in an EE environment you may need to configure some
things with Solder. You may need the following entries in your
beans.xml
file:
<beans xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:s="urn:java:ee"
xmlns:t="urn:java:org.jboss.seam.transaction"
xsi:schemaLocation="
http://java.sun.com/xml/ns/javaee
http://docs.jboss.org/cdi/beans_1_0.xsd">
<t:SeSynchronizations>
<s:modifies/>
</t:SeSynchronizations>
<t:EntityTransaction>
<s:modifies />
</t:EntityTransaction>
</beans>
Let's look at these individually.
<t:SeSynchronizations>
<s:modifies/>
</t:SeSynchronizations>
Seam will attempt to use JTA synchronizations if possible. If not then you need to install the
SeSynchronzations
bean to allow seam to handle synchronizations manually.
Synchronizations allow Seam to respond to transaction events such as
beforeCompletion()
and afterCompletion()
, and are needed
for the proper operation of the Seam Managed Persistence Context.
<t:EntityTransaction>
<s:modifies />
</t:EntityTransaction>
By default Seam will attempt to look up java:comp/UserTransaction
from JNDI (or alternatively retrieve it from the EJBContext
if a container managed transaction is active). Installing EntityTransaction
tells Seam to use the JPA EntityTransaction
instead. To use this you must have a
Seam Managed Persistence Context (see the Seam Persistence documentation for details)
installed with qualifier@Default
.
If your entity manager is installed with a different qualifier, then you need to use the following
configuration (this assumes that my
has been bound to the namespace that contains
the appropriate qualifier, see the Solder documentation for more details):
<t:EntityTransaction>
<s:modifies />
<t:entityManager>
<my:SomeQualifier/>
</t:entityManager>
</t:EntityTransaction>
You should avoid EntityTransaction
if you have more than one persistence unit in your
application. Seam does not support installing multiple EntityTransaction
beans, and the EntityTransaction
interface does not support two phase commit,
so unless you are careful you may have data consistency issues. If you need multiple persistence
units in your application then we highly recommend using an EE 6 compatible server, such as JBoss AS7.
Seam adds declarative transaction support to managed beans. Seam re-uses the EJB
@TransactionAttribute
for this purpose, however it also provides an alternative
@Transactional
annotation for environments where
the EJB API's are not available. An alternative to@ApplicationException
,
@SeamApplicationException
is also provided. Unlike EJBs, managed beans
are not transactional by default, you can change this by adding the
@TransactionAttribute
to the bean class.
Unlike in Seam 2, transactions will not roll back whenever a non-application exception propagates out of a bean, unless the bean has the transaction interceptor enabled.
If you are using seam managed transactions as part of the seam-faces module you do not need to worry about declarative transaction management. Seam will automatically start a transaction for you at the start of the faces request, and commit it before the render response phase.
@SeamApplicationException
will not control transaction rollback
when using EJB container managed transactions. If you are in an EE environment
then you should always use the EJB API's, namely
@TransactionAttribute
and@ApplicationException
.
TransactionAttributeType.REQUIRES_NEW
and
TransactionAttributeType.NOT_SUPPORTED
are not yet supported on managed
beans.
Let's have a look at some code. Annotations applied at a method level override annotations applied at the class level.
@TransactionAttribute /*Defaults to TransactionAttributeType.REQUIRED */
class TransactionalBean
{
/* This is a transactional method, when this method is called a transaction
* will be started if one does not already exist.
* This behavior is inherited from the @TransactionAttribute annotation on
* the class.
*/
void doWork()
{
...
}
/* A transaction will not be started for this method, however it */
/* will not complain if there is an existing transaction active. */
@TransactionAttributeType(TransactionAttributeType.SUPPORTED)
void doMoreWork()
{
...
}
/* This method will throw an exception if there is no transaction active when */
/* it is invoked. */
@TransactionAttributeType(TransactionAttributeType.MANDATORY)
void doEvenMoreWork()
{
...
}
/* This method will throw an exception if there is a transaction active when */
/* it is invoked. */
@TransactionAttributeType(TransactionAttributeType.NOT_SUPPORTED)
void doOtherWork()
{
...
}
}
Seam Transaction has a built in ServletRequestListener
which automatically begins and
commits (or rolls back if the transaction is set to rollback) a transaction for each request! This should
end having to manually specify transactions, or wonder if a transaction is inplace.
Should the need arise for disabling this listener, a context param in web.xml named
org.jboss.seam.transaction.disableListener
set to true
will
disable the listener.
Table of Contents
The Seam Security module provides a number of useful features for securing your Java EE application, which are briefly summarised in the following sections. The rest of the chapters contained in this documentation each focus on one major aspect of each of the following features.
Authentication is the act of establishing, or confirming, the identity of a user. In many applications a user confirms their identity by providing a username and password (also known as their credentials). Seam Security allows the developer to control how users are authenticated, by providing a flexible Authentication API that can be easily configured to allow authentication against any number of sources, including but not limited to databases, LDAP directory servers or some other external authentication service.
If none of the built-in authentication providers are suitable for your application, then it is also possible to write your own custom Authenticator implementation.
Identity Management is a set of useful APIs for managing the users, groups and roles within your application. The identity management features in Seam are provided by PicketLink IDM, and allow you to manage users stored in a variety of backend security stores, such as in a database or LDAP directory.
Seam Security contains an external authentication sub-module that provides a number of features for authenticating your application users against external authentication services, such as OpenID and SAML.
While authentication is used to confirm the identity of the user, authorization is used to control which actions a user may perform within your application. Authorization can be roughly divided into two categories; coarse-grained and fine-grained. An example of a coarse-grained restriction is allowing only members of a certain group or role to perform a privileged operation. A fine-grained restriction on the other hand may allow only a certain individual user to perform a specific action on a specific object within your application.
There are also rule-based permissions, which bridge the gap between fine-grained and coarse-grained restrictions. These permissions may be used to determine a user's privileges based on certain business logic.
The Maven artifacts for all Seam modules are hosted within the JBoss Maven repository. Please refer to the Maven Getting Started Guide for information about configuring your Maven installation to use the JBoss repository.
To use Seam Security within your Maven-based project, it is advised that you import the Seam BOM (Bill of
Materials) which declares the versions for all Seam modules. First declare a property value for
${seam.version}
as follows:
<properties>
<seam.version>3.1.0.Final</seam.version>
</properties>
You can check the JBoss Maven Repository directly to determine the latest version of the Seam BOM to use.
Now add the following lines to the list of dependencies within the dependencyManagement
section of your project's pom.xml
file:
<dependency>
<groupId>org.jboss.seam</groupId>
<artifactId>seam-bom</artifactId>
<version>${seam.version}</version>
<type>pom</type>
<scope>import</scope>
</dependency>
Once that is done, add the following dependency (no version is required as it comes from seam-bom
):
<dependency>
<groupId>org.jboss.seam.security</groupId>
<artifactId>seam-security</artifactId>
</dependency>
If you wish to use the external authentication module in your application to allow authentication using OpenID or SAML, then add the following dependency also:
<dependency>
<groupId>org.jboss.seam.security</groupId>
<artifactId>seam-security-external</artifactId>
</dependency>
To enable many of the features of Seam Security, the Security interceptor must be configured in your
application's beans.xml
file. Add the following configuration to your
beans.xml
to enable the Security Interceptor:
<interceptors> <class>org.jboss.seam.security.SecurityInterceptor</class> </interceptors>
The majority of the Security API is centered around the Identity
bean. This bean represents the
identity of the current user, the default implementation of which is a session-scoped, named bean. This
means that once logged in, a user's identity is scoped to the lifecycle of their current session. The two most
important methods that you need to know about at this stage in regard to authentication are login()
and
logout()
, which as the names suggest are used to log the user in and out, respectively.
As the default implementation of the Identity
bean is named, it may be referenced via an EL
expression, or be used as the target of an EL action. Take the following JSF code snippet for example:
<h:commandButton action="#{identity.login}" value="Log in"/>
This JSF command button would typically be used in a login form (which would also contain inputs for the user's username and password) that allows the user to log into the application.
The bean type of the Identity
bean is org.jboss.seam.security.Identity
. This
interface is what you should inject if you need to access the Identity
bean from your
own beans. The default implementation is org.jboss.seam.security.IdentityImpl
.
The other important bean to know about right now is the Credentials
bean. Its' purpose is to
hold the user's credentials (such as their username and password) before the user logs in. The default implementation
of the Credentials
bean is also a session-scoped, named bean (just like the Identity
bean).
The Credentials
bean has two properties, username
and credential
that are used to hold the current user's username and credential (e.g. a password) values. The default implementation of
the Credentials
bean provides an additional convenience property called password
,
which may be used in lieu of the credential
property when a simple password is required.
The bean type of the Credential
bean is org.jboss.seam.security.Credentials
. The
default implementation for this bean type is org.jboss.seam.security.CredentialsImpl
.
Also, as credentials may come in many forms (such as passwords, biometric data such as that from a fingerprint reader, etc) the
credential
property of the Credentials
bean must be able to support each variation,
not just passwords. To allow for this, any credential that implements the org.picketlink.idm.api.Credential
interface is a valid value for the credential
property.
The Seam Security module provides the following built-in Authenticator
implementations:
org.jboss.seam.security.jaas.JaasAuthenticator
- used to authenticate against a JAAS
configuration defined by the container.
org.jboss.seam.security.management.IdmAuthenticator
- used to authenticate against an
Identity Store using the Identity Management API. See the Identity Management chapter for details on how
to configure this authenticator.
org.jboss.seam.security.external.openid.OpenIdAuthenticator
(provided by the external module) - used
to authenticate against an external OpenID provider, such as Google, Yahoo, etc. See the External Authentication chapter
for details on how to configure this authenticator.
The Identity
bean has an authenticatorClass
property, which if set will be used
to determine which Authenticator
bean implementation to invoke during the
authentication process. This property may be set by configuring it with a predefined authenticator type,
for example by using Solder XML Config. The following XML configuration example shows how you would configure the
Identity
bean to use the com.acme.MyCustomerAuthenticator
bean for authentication:
<beans xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:s="urn:java:ee"
xmlns:security="urn:java:org.jboss.seam.security"
xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://jboss.org/schema/cdi/beans_1_0.xsd">
<security:IdentityImpl>
<s:modifies/>
<security:authenticatorClass>com.acme.MyCustomAuthenticator</security:authenticatorClass>
</security:IdentityImpl>
</beans>
Alternatively, if you wish to be able to select the Authenticator
to authenticate with by
specifying the name of the Authenticator
implementation (i.e. for those annotated with
the @Named
annotation), the authenticatorName
property may be set instead.
This might be useful if you wish to offer your users the choice of how they would like to authenticate, whether it
be through a local user database, an external OpenID provider, or some other method.
The following example shows how you might configure the authenticatorName
property with the
Seam Config module:
<beans xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:s="urn:java:ee"
xmlns:security="urn:java:org.jboss.seam.security"
xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://jboss.org/schema/cdi/beans_1_0.xsd">
<security:IdentityImpl>
<s:modifies/>
<security:authenticatorName>openIdAuthenticator</security:authenticatorName>
</security:IdentityImpl>
</beans>
If neither the authenticatorClass
or authenticatorName
properties are set,
then the authentication process with automatically use a custom Authenticator
implementation, if
the developer has provided one (and only one) within their application.
If neither property is set, and the user has not provided a custom Authenticator
, then the
authentication process will fall back to the Identity Management API to attempt to authenticate the user.
All Authenticator
implementations must implement the org.jboss.seam.security.Authenticator
interface. This interface defines the following methods:
public interface Authenticator {
void authenticate();
void postAuthenticate();
User getUser();
AuthenticationStatus getStatus();
}
The authenticate()
method is invoked during the authentication process and is responsible for performing the
work necessary to validate whether the current user is who they claim to be.
The postAuthenticate()
method is invoked after the authentication process has already completed, and
may be used to perform any post-authentication business logic, such as setting session variables, logging, auditing, etc.
The getUser()
method should return an instance of org.picketlink.idm.api.User
,
which is generally determined during the authentication process.
The getStatus()
method must return the current status of authentication, represented by the
AuthenticationStatus
enum. Possible values are SUCCESS
, FAILURE
and DEFERRED
. The DEFERRED
value should be used for special circumstances, such as
asynchronous authentication as a result of authenticating against a third party as is the case with OpenID, etc.
The easiest way to get started writing your own custom authenticator is to extend the
org.jboss.seam.security.BaseAuthenticator
abstract class. This class implements the
getUser()
and getStatus()
methods for you, and provides
setUser()
and setStatus()
methods for setting both the user and status values.
An Authenticator
implementation cannot be a stateless session bean.
To access the user's credentials from within the authenticate()
method, you can inject the
Credentials
bean like so:
@Inject Credentials credentials;
Once the credentials are injected, the authenticate()
method is responsible for checking that
the provided credentials are valid. Here is a complete example:
public class SimpleAuthenticator extends BaseAuthenticator implements Authenticator {
@Inject Credentials credentials;
@Override
public void authenticate() {
if ("demo".equals(credentials.getUsername()) &&
credentials.getCredential() instanceof PasswordCredential &&
"demo".equals(((PasswordCredential) credentials.getCredential()).getValue())) {
setStatus(AuthenticationStatus.SUCCESS);
setUser(new SimpleUser("demo"));
}
}
}
The above code was taken from the simple authentication example, included in the Seam Security distribution.
In the above code, the authenticate()
method checks that the user has provided a username of
demo and a password of demo. If so, the authentication is deemed as successful
and the status is set to AuthenticationStatus.SUCCESS
, and a new SimpleUser
instance
is created to represent the authenticated user.
The Authenticator
implementation must return a non-null value when
getUser()
is invoked if authentication is successful. Failure to return a non-null value
will result in an AuthenticationException
being thrown.
Identity Management is a feature that allows you to manage the users, groups and roles in your application. The Identity Management features in Seam Security are provided by PicketLink IDM. The best place to find more information about PicketLink IDM is the reference documentation, available here.
PicketLink provides two identity store implementations to allow you to use Hibernate or LDAP to store identity-related data (please refer
to the PicketLink IDM documentation for details on configuring these). Seam Security provides an additional implementation called
JpaIdentityStore
, which allows you to store your identity data using JPA.
In a Seam-based application it probably makes more sense to use the standards-based JpaIdentityStore
rather than
HibernateIdentityStore
, as you will most likely be running in an Java EE container that supports JPA.
JpaIdentityStore
is an implementation of the PicketLink IdentityStore
interface, provided by Seam Security.
This identity store allows you to store your identity model inside a relational database, accessible via JPA. It provides an immense
amount of flexibility in the way you define your identity model, and in most cases should be compatible with existing database schemas.
See the idmconsole example application (included in the Seam distribution) for a demonstration of Seam's Identity Management features.
Like all authentication providers in Seam, Identity Management is supported via a concrete Authenticator
implementation called IdmAuthenticator
. To use Identity Management in your own application, you don't
need to do anything! Simply don't configure any authenticator, and as long as you have an identity store
configured (see the next section), the Identity Management API will be used to authenticate automatically.
While JpaIdentityStore
should be compatible with a large variety of database schemas, the following diagram displays
the recommended database schema to use:
Seam Security provides two annotations for configuring your entity beans for use with JpaIdentityStore
.
The first, @IdentityEntity
is a class annotation used to mark an entity bean so that
JpaIdentityStore
knows it contains identity-related data. It has a single member of type EntityType
,
that tells JpaIdentityStore
what type of identity data it contains. Possible values are:
The second one, IdentityProperty
, is a field or method annotation which is used to configure which
properties of the bean contain identity values. This annotation declares two values, value
and attributeName
:
package org.jboss.seam.security.annotations.management;
public @interface IdentityProperty {
PropertyType value();
String attributeName() default "";
}
The value()
member is of type PropertyType
, which is an enum that defines the following values:
public enum PropertyType {
NAME, TYPE, VALUE, RELATIONSHIP_FROM, RELATIONSHIP_TO, CREDENTIAL,
CREDENTIAL_TYPE, ATTRIBUTE }
By placing the IdentityProperty
annotation on various fields of your entity beans, JpaIdentityStore
can determine how identity-related data must be stored within your database tables.
In the following sections we'll look at how each of the main entities are configured.
Let's start by looking at identity object. In the recommended database schema, the IDENTITY_OBJECT
table
is responsible for storing objects such as users and groups. This table may be represented by the following entity
bean:
@Entity
@IdentityEntity(IDENTITY_OBJECT)
public class IdentityObject implements Serializable {
@Id @GeneratedValue private Long id;
@IdentityProperty(PropertyType.NAME)
private String name;
@ManyToOne @IdentityProperty(PropertyType.TYPE)
@JoinColumn(name = "IDENTITY_OBJECT_TYPE_ID")
private IdentityObjectType type;
// snip getter and setter methods
}
In the above code both the name
and type
fields are annotated with @IdentityProperty
.
This tells JpaIdentityStore
that these two fields are significant in terms of identity management-related
state. By annotating the name
field with @IdentityProperty(PropertyType.NAME)
, JpaIdentityStore
knows that this field is used to store the name of the identity object. Likewise, the
@IdentityProperty(PropertyType.TYPE)
annotation on the type
field indicates that the value of this
field is used to represent the type of identity object.
The IdentityObjectType
entity is simply a lookup table containing the names of the valid identity types. The
field representing the actual name of the type itself should be annotated with @IdentityProperty(PropertyType.NAME)
:
@Entity
public class IdentityObjectType implements Serializable {
@Id @GeneratedValue private Long id;
@IdentityProperty(PropertyType.NAME) private String name;
// snip getter and setter methods
}
The credentials table is used to store user credentials, such as passwords. Here's an example of an entity bean configured to store identity object credentials:
@Entity
@IdentityEntity(IDENTITY_CREDENTIAL)
public class IdentityObjectCredential implements Serializable {
@Id @GeneratedValue private Long id;
@ManyToOne @JoinColumn(name = "IDENTITY_OBJECT_ID")
private IdentityObject identityObject;
@ManyToOne @IdentityProperty(PropertyType.TYPE)
@JoinColumn(name = "CREDENTIAL_TYPE_ID")
private IdentityObjectCredentialType type;
@IdentityProperty(PropertyType.VALUE)
private String value;
// snip getter and setter methods
}
The IdentityObjectCredentialType
entity is used to store a list of valid credential types. Like
IdentityObjectType
, it is a simple lookup table with the field representing the credential type
name annotated with @IdentityProperty(PropertyType.NAME)
:
@Entity
public class IdentityObjectCredentialType implements Serializable
{
@Id @GeneratedValue private Long id;
@IdentityProperty(PropertyType.NAME)
private String name;
// snip getter and setter methods
}
The relationship table stores associations between identity objects. Here's an example of an entity bean that has been configured to store identity object relationships:
@Entity
@IdentityEntity(IDENTITY_RELATIONSHIP)
public class IdentityObjectRelationship implements Serializable
{
@Id @GeneratedValue private Long id;
@IdentityProperty(PropertyType.NAME)
private String name;
@ManyToOne @IdentityProperty(PropertyType.TYPE) @JoinColumn(name = "RELATIONSHIP_TYPE_ID")
private IdentityObjectRelationshipType relationshipType;
@ManyToOne @IdentityProperty(PropertyType.RELATIONSHIP_FROM) @JoinColumn(name = "FROM_IDENTITY_ID")
private IdentityObject from;
@ManyToOne @IdentityProperty(PropertyType.RELATIONSHIP_TO) @JoinColumn(name = "TO_IDENTITY_ID")
private IdentityObject to;
// snip getter and setter methods
}
The name
property is annotated with @IdentityProperty(PropertyType.NAME)
to indicate that this
field contains the name value for named relationships. An example of a named relationship is a role, which uses the
name
property to store the role type name.
The relationshipType
property is annotated with @IdentityProperty(PropertyType.TYPE)
to indicate
that this field represents the type of relationship. This is typically a value in a lookup table.
The from
property is annotated with @IdentityProperty(PropertyType.RELATIONSHIP_FROM)
to indicate
that this field represents the IdentityObject
on the from side of the relationship.
The to
property is annotated with @IdentityProperty(PropertyType.RELATIONSHIP_TO)
to indicate
that this field represents the IdentityObject
on the to side of the relationship.
The IdentityObjectRelationshipType
entity is a lookup table containing the valid relationship types. The
@IdentityProperty(PropertyType.NAME)
annotation is used to indicate the field containing the relationship
type names:
@Entity
public class IdentityObjectRelationshipType implements Serializable {
@Id @GeneratedValue private Long id;
@IdentityProperty(PropertyType.NAME)
private String name;
// snip getter and setter methods
}
The attribute table is used to store any additional information that is to be associated with identity objects. Here's an example of an entity bean used to store attributes:
@Entity
@IdentityEntity(IDENTITY_ATTRIBUTE)
public class IdentityObjectAttribute implements Serializable {
@Id @GeneratedValue private Integer attributeId;
@ManyToOne
@JoinColumn(name = "IDENTITY_OBJECT_ID")
private IdentityObject identityObject;
@IdentityProperty(PropertyType.NAME)
private String name;
@IdentityProperty(PropertyType.VALUE)
private String value;
// snip getter and setter methods
}
The name
field is annotated with @IdentityProperty(PropertyType.NAME)
to indicate that this field
contains the attribute name. The value
field is annotated with @IdentityProperty(PropertyType.VALUE)
to indicate that this field contains the attribute value.
The Identity Management features are provided by a number of manager objects, which can be access from an
IdentitySession
. The IdentitySession
may be injected directly into your beans
like so:
import org.picketlink.idm.api.IdentitySession;
public @Model class IdentityAction {
@Inject IdentitySession identitySession;
// code goes here...
}
Once you have the IdentitySession
object, you can use it to perform various identity management
operations. You should refer to the PicketLink documentation for a complete description of the available features,
however the following sections contain a brief overview.
Users and groups are managed by a PersistenceManager
, which can be obtained by calling
getPersistenceManager()
on the IdentitySession
object:
PersistenceManager pm = identitySession.getPersistenceManager();
Once you have the PersistenceManager
object, you can create User
objects with the
createUser()
method:
User user = pm.createUser("john");
Similarly, you can create Group
objects with the createGroup()
method:
Group headOffice = pm.createGroup("Head Office", "OFFICE");
You can also remove users and groups by calling the removeUser()
or removeGroup()
method.
Relationships are used to associate User
objects with Group
objects. Relationships can
be managed with the RelationshipManager
object, which can be obtained by calling
getRelationshipManager()
on the IdentitySession
:
RelationshipManager rm = identitySession.getRelationshipManager();
Relationships are created by invoking the associateUser()
method, and passing in the group and user
objects that should be associated:
rm.associateUser(headOffice, user);
Roles are managed via the RoleManager
object, which can be obtained by invoke the
getRoleManager()
method on the IdentitySession
object:
RoleManager roleManager = identitySession.getRoleManager();
Roles are an association between a user and a group, however they are slightly more complex than a simple
group membership as the association also has a role type. The role type is generally
used to describe a particular function of the user within the group. Role types are represented by the
RoleType
object, and can be created with the createRoleType()
method:
RoleType manager = roleManager.createRoleType("manager");
Roles can be assigned to users by invoking the createRole()
method, and passing in the
RoleType
, User
and Group
:
Role r = roleManager.createRole(manager, user, headOffice);
The external authentication module is an optional add-on to the core Seam Security module, which provides a number of features that enable your application to authenticate against third party identity services, via a number of supported protocols.
The features described in this chapter are a preview only. The APIs described may change in a subsequent version of Seam, and may not be backwards-compatible with previous versions.
Currently this module supports authentication via OpenID, and other protocols (such as SAML and OAuth) are currently under development for the next version of Seam.
If your project is Maven-based, then add the following dependency to your project:
<dependency> <groupId>org.jboss.seam.security</groupId> <artifactId>seam-security-external</artifactId> </dependency>
If you are not using Maven, you must add the seam-security-external.jar
library to your project, which
can be found in the Seam Security downloadable distribution.
OpenID allows the users of your application to authenticate without requiring them to create an account. When using OpenID, your user is temporarily redirected to the web site of their OpenID provider so that they can enter their password, after which they are redirected back to your application. The OpenID authentication process is safe - at no time is the user's password seen by any site besides their OpenID provider.
The external authentication module provides support for OpenID based on OpenID4Java, an open source OpenID library (licensed under the Apache v2 license) with both Relying Party and Identity Provider capabilities. This feature allows your application to authenticate its users against an external OpenID provider, such as Google or Yahoo, or to turn your application into an OpenID provider itself.
To see the OpenID features in action, take a look at the openid-rp
example included in the Seam Security distribution.
To use OpenID in your own application, you must configure Seam Security to use OpenIdAuthenticator
, an
Authenticator
implementation that performs authentication against an OpenID provider. This authenticator
is a named, session-scoped bean, with the following declaration:
public @Named("openIdAuthenticator") @SessionScoped class OpenIdAuthenticator
If your application only uses OpenID to provide authentication services, then it is recommended
that OpenIdAuthenticator
is selected by configuring the authenticatorClass
property of the Identity
bean. The following code sample demonstrates how this might
be done by using Solder:
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:s="urn:java:ee"
xmlns:security="urn:java:org.jboss.seam.security"
xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://jboss.org/schema/cdi/beans_1_0.xsd">
<security:Identity>
<s:modifies/>
<security:authenticatorClass>org.jboss.seam.security.external.openid.OpenIdAuthenticator</security:authenticatorClass>
</security:Identity>
If your application gives the user a choice of which authentication method to use, then it is not possible to
pre-configure which Authenticator
implementation is used to authenticate. In these circumstances,
it is recommended that you configure the authenticator by specifying a value for the authenticatorName
property of the Identity
bean. This can be done by binding a view-layer control such as a radio group
directly to this property, to allow the user to select the method of authentication they wish to use. See the
following JSF code as an example:
<h:outputLabel value="Authenticate using:"/>
<h:selectOneRadio id="authenticator" value="#{identity.authenticatorName}">
<f:selectItem itemLabel="OpenID" itemValue="openIdAuthenticator" />
<f:selectItem itemLabel="Custom" itemValue="customAuthenticator" />
</h:selectOneRadio>
Seam provides built-in support for a number of well-known OpenID providers. The OpenIdAuthenticator
bean
may be configured to select which OpenID provider will be used to process an authentication request. Each concrete
provider implements the following interface:
public interface OpenIdProvider {
String getCode();
String getName();
String getUrl();
}
The following table lists the providers that come pre-packaged in Seam:
Provider | Code | Name | URL |
---|---|---|---|
CustomOpenIdProvider | custom | ||
GoogleOpenIdProvider | https://www.google.com/accounts/o8/id | ||
MyOpenIdProvider | myopenid | MyOpenID | https://myopenid.com |
YahooOpenIdProvider | yahoo | Yahoo | https://me.yahoo.com |
To select one of the built-in providers to use for an authentication request, the providerCode
property
of the OpenIdAuthenticator
bean should be set to one of the Code values from the above table. The
OpenIdAuthenticator
bean provides a convenience method called getProviders()
that returns
a list of all known providers. This may be used in conjunction with a radio group to allow the user to select which
OpenID provider they wish to authenticate with - see the following JSF snippet for an example:
<h:selectOneRadio value="#{openIdAuthenticator.providerCode}">
<f:selectItems value="#{openIdAuthenticator.providers}" var="p" itemValue="#{p.code}" itemLabel="#{p.name}"/>
</h:selectOneRadio>
If you would like to allow your users to specify an OpenID provider that is not supported out of the box by Seam, then
the CustomOpenIdProvider
may be used. As it is a @Named
bean, it can be accessed directly
from the view layer via EL. The following JSF code shows how you might allow the user to specify their own
OpenID provider:
<h:outputLabel value="If you have selected the Custom OpenID provider, please provide a URL:"/>
<h:inputText value="#{customOpenIdProvider.url}"/>
Your application must provide an implementation of the OpenIdRelyingPartySpi
interface to process
OpenID callback events. This interface declares the following methods:
public interface OpenIdRelyingPartySpi {
void loginSucceeded(OpenIdPrincipal principal, ResponseHolder responseHolder);
void loginFailed(String message, ResponseHolder responseHolder);
The implementation is responsible for processing the response of the OpenID authentication, and is typically used to redirect the user to an appropriate page depending on whether authentication was successful or not.
There are two API calls that must be made in the case of a successful authentication. The first one
should notify the OpenIdAuthenticator
that the authentication attempt was successful, and pass it the
OpenIdPrincipal
object:
If the following two API calls are omitted, unpredictable results may occur!
openIdAuthenticator.success(principal);
Secondly, a DeferredAuthenticationEvent
must be fired to signify that a deferred authentication attempt has
been completed:
deferredAuthentication.fire(new DeferredAuthenticationEvent());
After making these two API calls, the implementation may perform whatever additional logic is required. The following code shows a complete example:
import java.io.IOException;
import javax.enterprise.event.Event;
import javax.inject.Inject;
import javax.servlet.ServletContext;
import org.jboss.seam.security.events.DeferredAuthenticationEvent;
import org.jboss.seam.security.external.api.ResponseHolder;
import org.jboss.seam.security.external.openid.OpenIdAuthenticator;
import org.jboss.seam.security.external.openid.api.OpenIdPrincipal;
import org.jboss.seam.security.external.spi.OpenIdRelyingPartySpi;
public class OpenIdRelyingPartySpiImpl implements OpenIdRelyingPartySpi {
@Inject private ServletContext servletContext;
@Inject OpenIdAuthenticator openIdAuthenticator;
@Inject Event<DeferredAuthenticationEvent> deferredAuthentication;
public void loginSucceeded(OpenIdPrincipal principal, ResponseHolder responseHolder) {
try {
openIdAuthenticator.success(principal);
deferredAuthentication.fire(new DeferredAuthenticationEvent());
responseHolder.getResponse().sendRedirect(servletContext.getContextPath() + "/UserInfo.jsf");
} catch (IOException e) {
throw new RuntimeException(e);
}
}
public void loginFailed(String message, ResponseHolder responseHolder) {
try {
responseHolder.getResponse().sendRedirect(servletContext.getContextPath() + "/AuthenticationFailed.jsf");
} catch (IOException e) {
throw new RuntimeException(e);
}
}
}
Before using any of Seam's authorization features, you must enable the SecurityInterceptor
by adding the following code to your application's beans.xml
:
<interceptors> <class>org.jboss.seam.security.SecurityInterceptor</class> </interceptors>
Seam Security provides a number of facilities for restricting access to certain parts of your application. As mentioned
previously, the security API is centered around the Identity
bean, which is a session-scoped bean used to represent
the identity of the current user.
To be able to restrict the sensitive parts of your code, you may inject the Identity
bean into your class:
@Inject Identity identity;
Once you have injected the Identity
bean, you may invoke its methods to perform various types of authorization.
The following sections will examine each of these in more detail.
The security model in Seam Security is based upon the PicketLink API. Let's briefly examine a few of the core interfaces provided by PicketLink that are used in Seam.
This is the common base interface for both User
and Group
. The getKey()
method should return a unique identifying value for the identity type.
Represents a group. The getName()
method should return the name of the group, while the
getGroupType()
method should return the group type.
Represents a role, which is a direct one-to-one typed relationship between a User and a Group. The
getRoleType()
method should return the role type. The getUser()
method
should return the User for which the role is assigned, and the getGroup()
method should
return the Group that the user is associated with.
This is the simplest type of authorization, used to define coarse-grained privileges for users assigned to a certain role or belonging to a certain group. Users may belong to zero or more roles and groups, and inversely, roles and groups may contain zero or more members.
The concept of a role in Seam Security is based upon the model defined by PicketLink. I.e, a role is a direct relationship between a user and a group, which consists of three aspects - a member, a role name and a group (see the class diagram above). For example, user Bob (the member) may be an admin (the role name) user in the HEAD OFFICE group.
The Identity
bean provides the following two methods for checking role membership:
boolean hasRole(String role, String group, String groupType); void checkRole(String role, String group, String groupType);
These two methods are similar in function, and both accept the same parameter values. Their behaviour differs
when an authorization check fails. The hasRole()
returns a value of false
when the
current user is not a member of the specified role. The checkRole()
method on the other hand,
will throw an AuthorizationException
. Which of the two methods you use will depend on your
requirements.
The following code listing contains a usage example for the hasRole()
method:
if (identity.hasRole("manager", "Head Office", "OFFICE")) { report.addManagementSummary(); }
Groups can be used to define a collection of users that meet some common criteria. For example, an application might use groups to define users in different geographical locations, their role in the company, their department or division or some other criteria which may be significant from a security point of view. As can be seen in the above class diagram, groups consist of a unique combination of group name and group type. Some examples of group types may be "OFFICE", "DEPARTMENT", "SECURITY_LEVEL", etc. An individual user may belong to many different groups.
The Identity
bean provides the following methods for checking group membership:
boolean inGroup(String name, String groupType); void checkGroup(String group, String groupType);
These methods are similar in behaviour to the role-specific methods above. The inGroup()
method
returns a value of false
when the current user isn't in the specified group, and the
checkGroup()
method will throw an exception.
Seam Security provides a way to secure your bean classes and methods by annotating them with a typesafe security binding. Each security binding must have a matching authorizer method, which is responsible for performing the business logic required to determine whether a user has the necessary privileges to invoke a bean method. Creating and applying a security binding is quite simple, and is described in the following steps.
A typesafe security binding is an annotation, meta-annotated with the SecurityBindingType
annotation:
import org.jboss.seam.security.annotations.SecurityBindingType; @SecurityBindingType @Retention(RetentionPolicy.RUNTIME) @Target({ElementType.TYPE, ElementType.METHOD}) public @interface Admin { }
The security binding annotation may also define member values, which are taken into account when matching
the annotated bean class or method with an authorizer method. All member values are taken into consideration,
except for those annotated with @Nonbinding
, in much the same way as a qualifier binding type.
import javax.enterprise.util.Nonbinding; import org.jboss.seam.security.annotations.SecurityBindingType; @SecurityBindingType @Retention(RetentionPolicy.RUNTIME) @Target({ElementType.TYPE, ElementType.METHOD}) public @interface Foo { String bar(); @Nonbinding String other() default ""; }
The next step after creating the security binding type is to create a matching authorizer method. This
method must contain the business logic required to perform the required authorization check, and return
a boolean
value indicating whether the authorization check passed or failed.
An authorizer method must be annotated with the @Secures
annotation, and the security binding
types for which it is performing the authorization check. An authorizer method may declare zero or more
method parameters. Any parameters defined by the authorizer method are treated as injection points, and
are automatically injected by the Seam Security extension. The following example demonstrates an authorizer
method that injects the Identity
bean, which is then used to perform the authorization check.
import org.jboss.seam.security.annotations.Secures; public class Restrictions { public @Secures @Admin boolean isAdmin(Identity identity) { return identity.hasRole("admin", "USERS", "GROUP"); } }
Authorizer methods will generally make use of the security API to perform their security check, however this is not a hard restriction.
Once the security binding annotation and the matching authorizer method have been created, the security binding type may be applied to a bean class or method. If applied at the class level, every method of the bean class will have the security restriction applied. Methods annotated with a security binding type also inherit any security bindings on their declaring class. Both bean classes and methods may be annotated with multiple security bindings.
public @ConversationScoped class UserAction { public @Admin void deleteUser(String userId) { // code } }
If a security check fails when invoking a method annotated with a security binding type, an
AuthorizationException
is thrown. Solder can be used to handle
this exception gracefully, for example by redirecting them to an error page or displaying an error
message. Here's an example of an exception handler that creates a JSF error message:
@HandlesExceptions public class ExceptionHandler { @Inject FacesContext facesContext; public void handleAuthorizationException(@Handles CaughtException<AuthorizationException> evt) { facesContext.addMessage(null, new FacesMessage(FacesMessage.SEVERITY_ERROR, "You do not have the necessary permissions to perform that operation", "")); evt.handled(); } }
Seam Security provides one security binding annotation out of the box, @LoggedIn
. This annotation
may be applied to a bean to restrict its methods to only those users that are currently authenticated.
import org.jboss.seam.security.annotations.LoggedIn; public @LoggedIn class CustomerAction { public void createCustomer() { // code } }
A number of CDI events are fired during the course of many security-related operations, allowing additional business logic to be executed in response to certain security events. This is useful if you would like to generate additional logging or auditing, or produce messages to display to the user.
The following table contains the list of event classes that may be fired by Seam Security, along
with a description of when the event is fired. All event classes are contained in the
org.jboss.seam.security.events
package.
Event | Description |
---|---|
AlreadyLoggedInEvent | Fired when a user who is already logged in attempts to log in again |
AuthorizationCheckEvent | Fired when an authorization check is performed, such as Identity.hasPermission(). |
CredentialsUpdatedEvent | Fired whenever a user's credentials (such as their username or password) are updated. |
DeferredAuthenticationEvent | Fired when a deferred authentication occurs. For example, at the end of the OpenID authentication process when the OpenID provider redirects the user back to the application. |
LoggedInEvent | Fired when the user is successfully logged in. |
LoginFailedEvent | Fired when an authentication attempt by the user fails. |
NotAuthorizedEvent | Fired when the user is not authorized to invoke a particular operation. |
NotLoggedInEvent | Fired when the user attempts to invoke a privileged operation before they have authenticated. |
PreAuthenticateEvent | Fired just before a user is authenticated |
PostAuthenticateEvent | Fired after a user has authenticated successfully. |
PreLoggedOutEvent | Fired just before a user is logged out. |
PostLoggedOutEvent | Fired after a user has logged out. |
PrePersistUserEvent | Fired just before a new user is persisted (when using Identity Management). |
PrePersistUserRoleEvent | Fired just before a new user role is persisted (when using Identity Management). |
QuietLoginEvent | Fired when a user is quietly authenticated. |
SessionInvalidatedEvent | Fired when a user's session is invalidated. |
UserAuthenticatedEvent | Fired when a user is authenticated. |
UserCreatedEvent |
The following code listing shows the SecurityEventMessages
class, from the Seam Security
implementation library. This class (which is disabled by default due to the @Veto
annotation)
uses the Messages API from Seam International to generate user-facing messages in response to certain
security events.
package org.jboss.seam.security; import javax.enterprise.context.ApplicationScoped; import javax.enterprise.event.Observes; import org.jboss.seam.international.status.Messages; import org.jboss.seam.security.events.AlreadyLoggedInEvent; import org.jboss.seam.security.events.LoggedInEvent; import org.jboss.seam.security.events.LoginFailedEvent; import org.jboss.seam.security.events.NotLoggedInEvent; import org.jboss.seam.security.events.PostAuthenticateEvent; import org.jboss.solder.core.Requires; import org.jboss.solder.core.Veto; public @ApplicationScoped @Veto @Requires("org.jboss.seam.international.status.Messages") class SecurityEventMessages { private static final String DEFAULT_LOGIN_FAILED_MESSAGE = "Login failed - please check your username and password before trying again."; private static final String DEFAULT_LOGIN_SUCCESSFUL_MESSAGE = "Welcome, {0}."; private static final String DEFAULT_ALREADY_LOGGED_IN_MESSAGE = "You're already logged in. Please log out first if you wish to log in again."; private static final String DEFAULT_NOT_LOGGED_IN_MESSAGE = "Please log in first."; public void postAuthenticate(@Observes PostAuthenticateEvent event, Messages messages, Identity identity) { messages.info(DEFAULT_LOGIN_SUCCESSFUL_MESSAGE, identity.getUser().getId()); } public void addLoginFailedMessage(@Observes LoginFailedEvent event, Messages messages) { messages.error(DEFAULT_LOGIN_FAILED_MESSAGE); } public void addLoginSuccessMessage(@Observes LoggedInEvent event, Messages messages, Credentials credentials) { messages.info(DEFAULT_LOGIN_SUCCESSFUL_MESSAGE, credentials.getUsername()); } public void addAlreadyLoggedInMessage(@Observes AlreadyLoggedInEvent event, Messages messages) { messages.error(DEFAULT_ALREADY_LOGGED_IN_MESSAGE); } public void addNotLoggedInMessage(@Observes NotLoggedInEvent event, Messages messages) { messages.error(DEFAULT_NOT_LOGGED_IN_MESSAGE); } }
Table of Contents
The goal of Seam International is to provide a unified approach to configuring locale, timezone and language. With features such as Status message propagation to UI, multiple property storage implementations and more.
Most features of Seam International are installed automatically by including seam-international.jar
in the web application library folder. If you are using Maven as your
build tool, you can add the following dependency to your pom.xml
file:
<dependency>
<groupId>org.jboss.seam.international</groupId>
<artifactId>seam-international</artifactId>
<version>${seam-international-version}</version>
</dependency>
Replace ${seam-international-version} with the most recent or appropriate version of Seam International.
In a similar fashion to TimeZones we have an Application Locale
:
@Inject
private java.util.Locale lc;
accessible via EL with "defaultLocale".
By default the Locale
will be set to the JVM default, unless you
produce a String annotated with @DefaultLocale
. This can be achieved
through either the Seam Config module, with any bean that @Produces
a method or field that matches the type and qualifier.
This will set the application language to be English with the country of US:
@Produces
@DefaultLocale
private String defaultLocaleKey = "en_US";
As you can see from the previous example, you can define the Locale
with
lang_country_variant
. It's important to note that the first two parts of the locale definition
are not expected to be greater than 2 characters otherwise an error will be produced
and it will default to the JVM Locale
.
The Locale associated with the User Session can be retrieved by:
@Inject
@Client
private java.util.Locale locale;
which is EL accessible via userLocale
.
By default the Locale
will be that of the Application when the User Session
is initialized. However, changing the User's Locale
is a simple
matter of firing an event to update it. An example would be:
@Inject
@Client
@Alter
private Event<java.util.Locale> localeEvent;
public void setUserLocale() {
Locale canada = Locale.CANADA;
localeEvent.fire(canada);
}
We've also provided a list of available Locales that can be accessed via:
@Inject
private List<java.util.Locale> locales;
The locales that will be returned as available can be defined by extending LocaleConfiguration
.
As seen here:
public class CustomLocaleConfiguration extends LocaleConfiguration {
@PostConstruct
public void setup() {
addSupportedLocaleKey("en");
addSupportedLocaleKey("fr");
}
}
To support a more developer friendly way of handling TimeZones, in
addition to supporting JDK TimeZone
,
we have added support for using Joda-Time through their
DateTimeZone
class. Don't worry, it provides
convenience methods for converting to JDK TimeZone
.
To activate Joda-Time for i18n within your project you will need to add the following Maven dependency:
<dependency>
<groupId>joda-time</groupId>
<artifactId>joda-time</artifactId>
<version>1.6</version>
</dependency>
We have an Application time zone that is available with Joda-Time
(DateTimeZone
) or the JDK (TimeZone
)
that can be retrieved with
@Inject
private DateTimeZone applicationDateTimeZone;
@Inject
private TimeZone applicationTimeZone
It can also be accessed through EL by the name "defaultDateTimeZone" for Joda-Time or "defaultTimeZone" for JDK!
By default the TimeZone
will be set to the JVM default, unless you produce
a String annotated with @DefaultTimeZone
.
This can be achieved through either the Seam Config module or
any bean that @Produces
a method or field that matches
the type and qualifier.
This will set the application time zone to be Tijuana:
@Produces
@DefaultTimeZone
private String defaultTimeZoneId = "America/Tijuana";
In addition to the Application time zone, there is also a time zone assigned to each User Session.
@Inject
@Client
private DateTimeZone userDateTimeZone;
@Inject
@Client
private TimeZone userTimeZone;
It can also be accessed through EL using "userDateTimeZone" for Joda-Time and "userTimeZone" for JDK.
By default the DateTimeZone
and TimeZone
for a User Session is initialized to the same as the Application. However, changing
the User's DateTimeZone
and TimeZone
is a simple matter of firing an event to update it. An example
would be
@Inject
@Client
@Alter
private Event<DateTimeZone> dtzEvent;
@Inject
@Client
@Alter
private Event<TimeZone> tzEvent;
public void setUserDateTimeZone() {
DateTimeZone dtzTijuana = DateTimeZone.forID("America/Tijuana");
dtzEvent.fire(dtzTijuana);
TimeZone tzTijuana = TimeZone.getTimeZone("America/Tijuana");
tzEvent.fire(tzTijuana);
}
There are currently two ways to create a message within the module.
The first would mostly be used when you don't want to add the generated message directly to the UI, but want to log it out, or store it somewhere else
@Inject
private MessageFactory factory;
public String getMessage() {
MessageBuilder builder = factory.info("There are {0} cars, and they are all {1}; {1} is the best color.", 5, "green");
return builder.build().getText();
}
The second is to add the message to a list that will be returned to the UI for display.
@Inject
private Messages messages;
public void setMessage() {
messages.info("There are {0} cars, and they are all {1}; {1} is the best color.", 5, "green");
}
Either of these methods supports the four message levels which are info, warning, error and fatal.
Both MessageFactory and Messages support four ways in which to create a Message:
Examples for each of these are:
messages.info("Simple Text");
messages.info("Simple Text with {0} parameter", 1);
messages.info(new BundleKey("org.jboss.international.seam.test.TestBundle", "key1"));
messages.info(new BundleKey("org.jboss.international.seam.test.TestBundle", "key2"), 1);
The examples in the previous section on how to create a message from a properties file made the assumption that you had already created it! Now we tell you how to actually do that.
When creating a BundleKey
in the previous section, we were passing it a bundle name of
"org.jboss.international.seam.test.TestBundle". This name is essentially the path to the properties file!
Let me explain. As we all know properties files need to be on the classpath for our code to find them, so
"org.jboss.international.seam.test.TestBundle" is telling our code that on the classpath there is a
TestBundle.properties
file located at a path of org/jboss/international/seam/test
.
To create a property file for another language, it's simply a case of appending the name of the locale to
the end of the file name. Such as TestBundle_fr.properties
for French or
TestBundle_en_US.properties
for American English.
Table of Contents
The goal of Seam Faces is to provide a fully integrated CDI programming model to the JavaServer Faces (JSF) 2.0 web-framework. With features such as observing Events, providing injection support for life-cycle artifacts (FacesContext, NavigationHandler,) and more.
To use the Seam Faces module, you need to put the API and implementation JARs on the classpath of your web application. Most of the features of Seam Faces are enabled automatically when it's added to the classpath. Some extra configuration, covered below, is required if you are not using a Servlet 3-compliant container.
If you are using Maven as your build tool, you can add the following single dependency to your pom.xml file to include Seam Faces:
<dependency>
<groupId>org.jboss.seam.faces</groupId>
<artifactId>seam-faces</artifactId>
<version>${seam.faces.version}</version>
</dependency>
Substitute the expression ${seam.faces.version}
with the most recent or appropriate version of
Seam Faces.
Alternatively, you can create a
Maven
user-defined property
to satisfy this substitution so you can centrally manage the version.
Alternatively, you can use the API at compile time and only include the implementation at runtime. This protects you from inadvertently depending on an implementation class.
<dependency>
<groupId>org.jboss.seam.faces</groupId>
<artifactId>seam-faces-api</artifactId>
<version>${seam.faces.version}</version>
<scope>compile</scope>
</dependency>
<dependency>
<groupId>org.jboss.seam.faces</groupId>
<artifactId>seam-faces-impl</artifactId>
<version>${seam.faces.version}</version>
<scope>runtime</scope>
</dependency>
In a Servlet 3.0 or Java EE 6 environment, your configuration is now complete!
If you are using Java EE 5 or some other Servlet 2.5 container, then you need to manually register several Servlet components in your application's web.xml to activate the features provided by this module:
<listener>
<listener-class>org.jboss.seam.faces.beanManager.BeanManagerServletContextListener</listener-class>
</listener>
You're now ready to dive into the JSF enhancements provided for you by the Seam Faces module!
Seam Faces requires a working JSF 2.0 configuration. To get a working JSF 2.0 environment in a Java EE 6 environment, you need one of the following:
Bundle the seam-faces jar in your web-app (this sets up jsf for you)
if not #1, you need empty faces-config.xml, where the root element must be present.
if not #1 or #2, you need a web.xml with the Faces Servlet defined.
The JBoss JSF documentation provides further details on #2 and #3 above, but these steps are unnecessary when you use Seam Faces (#1). this is because Seam Faces scans for the presence of the Seam Servlet, and programatically registers it for you if it's not present.
JSF 2.0 introduced the concept of the Flash object and the @ViewScope; however, JSF 2.0 did not provide annotations accessing the Flash, and CDI does not support the non-standard ViewScope by default. The Seam Faces module does both, in addition to adding a new @RenderScoped context. Beans stored in the Render Scope will survive until the next page is rendered. For the most part, beans stored in the ViewScope will survive as long as a user remains on the same page, and data in the JSF 2 Flash will survive as long as the flash survives).
Beans placed in the @RenderScoped context are effectively scoped to, and live through but not after, "the next Render Response phase".
You should think about using the Render scope if you want to store information that will be relevant to the user even after an action sends them to another view. For instance, when a user submits a form, you may want to invoke JSF navigation and redirect the user to another page in the site; if you needed to store a message to be displayed when the next page is rendered -but no longer- you would store that message in the RenderContext. Fortunately, Seam provides RenderScoped messages by default, via the Seam Messages API.
To place a bean in the Render scope, use the @org.jboss.seam.faces.context.RenderScoped
annotation. This means that your
bean will be stored in the org.jboss.seam.context.RenderContext
object until the next page is rendered,
at which point the RenderScope will be cleared.
@RenderScoped
public class Bean {
// ...
}
@RenderScoped
beans are destroyed when the next JSF RENDER_RESPONSE
phase
ends, however, if a user has multiple browser windows open for the same user-session, multiple
RenderContext
s will be created, one for each incoming request. Seam Faces keeps
track of which RenderContext
belongs to each request, and will restore/destroy them appropriately.
If there is more than one active RenderContext
at the time when you issue a redirect, you will see
a URL parameter ?fid=...
appended to the end of the outbound URL, this is to ensure the correct
context is restored when the request is received by the server, and will not be present if only one context is active.
If you want to use the Render Scope with custom navigation in your application,
be sure to call ExternalContext.encodeRedirectURL(String url, Map<String, List<String>> queryParams)
on any URL before using it to issue a redirect. This will ensure that the RenderContext ID is properly appended to the URL, enabling
the RenderContext to be restored on the subsequent request. This is only necessary if issuing a Servlet Redirect; for the
cases where Faces non-redirecting navigation is used, no URL parameter is necessary, and the context will be destroyed at the end
of the current request.
JSF 2 does not provide proper system events to create a functional @FlashScoped
context annotation integrated with CDI, so until
a workaround can be found, or JSF 2 is enhanced, you can access the Flash via the @Inject annotation. For more information on the
JSF Flash, read
this API doc.
public class Bean {
@Inject private Flash flash;
// ...
}
To scope a bean to the View, use the @javax.faces.bean.ViewScoped
annotation. This means that your bean will be stored in the
javax.faces.component.UIViewRoot
object associated with the view in which it was accessed. Each JSF view (faces-page) will store
its own instance of the bean, just like each HttpServletRequest has its own instance of a @RequestScoped bean.
@ViewScoped
public class Bean {
// ...
}
@ViewScoped beans are destroyed when the JSF UIViewRoot object is destroyed. This means that the
life-span of @ViewScoped beans is dependent on the javax.faces.STATE_SAVING_METHOD
employed by the application itself,
but in general one can assume that the bean will live as long as the user remains on the same page.
While JSF already has the concept of adding FacesMessage
objects to the FacesContext in order for those messages to be
displayed to the user when the view is rendered, Seam Faces takes this concept one step farther with the Messages API provided by the
Seam International module. Messages are template-based, and can be added directly via the code, or templates can be loaded from resource
bundles using a BundleKey
.
Consistent with the CDI programming model, the Messages API is provided via bean injection. To add a new message to be displayed to the user,
inject org.jboss.seam.international.status.Messages
and call one of the Message factory methods. As mentioned earlier,
factory methods accept either a plain-text template, or a BundleKey
, specifying the name of the resource bundle to use, and
the name of the key to use as a message template.
@Named
public class Example
{
@Inject
Messages messages;
public String action()
{
messages.info("This is an {0} message, and will be displayed to {1}.", "INFO", "the user");
return null;
}
}
Adds the message: "This is an INFO message, and will be displayed to the user."
Notice how {0}, {1} ... {N} are replaced with the given parameters, and may be used more than once in a given template. In the case where a
BundleKey
is used to look up a message template, default text may be provided in case the resource cannot be loaded; default
text uses the same parameters supplied for the bundle template. If no default text is supplied, a String representation of the
BundleKey
and its parameters will be displayed instead.
public String action()
{
messages.warn(new BundleKey("org.jboss.seam.faces.exampleBundle", "messageKey"), "unique");
return null;
}
classpath:/org/jboss/seam/faces/exampleBundle.properties
messageKey=This {0} parameter is not so {0}, see?
Adds the message: "This unique parameter is not so unique, see?"
It's great when messages are added to the internal buffer, but it doesn't do much good unless the user actually sees them. In order to display
messages, simply use the <h:messages />
tag from JSF. Any pending messages will be displayed on the page just like normal
FacesMessages
.
<html xmlns="http://www.w3.org/1999/xhtml"
xmlns:f="http://java.sun.com/jsf/core"
xmlns:h="http://java.sun.com/jsf/html"
xmlns:s="http://jboss.org/seam/faces"
xmlns:ui="http://java.sun.com/jsf/facelets">
<h1>Welcome to Seam Faces!</h1>
<p>All Messages and FacesMessages will be displayed below:</p>
<h:messages />
</html>
Messages added to the internal buffer via the Messages API are stored in a central location during each request, and may be displayed
by any view-technology that supports the Messages API. Seam Faces provides an integration that makes all of this automatic for you as a developer,
and in addition, messages will automatically survive JSF navigation and redirects, as long as the redirect URL was encoded using
ExternalContext.encodeRedirectURL(...)
. If you are using JSF-compliant navigation, all of this is handled for you.
In addition to Chapter 38, Locales, Seam Faces provides an additional producer which returns
the supported locale of the UIViewRoot
or ViewHandler
. This
Locale
has the @Faces
qualifier to help distinguish it from other produced
locales.
Seam Faces also provides easy access to the configured list of locales for the application both via injection and
via EL. Using EL thould would be #{supportedLocales}
and #{defaultFacesLocale}
.
Via injection one would use
@Inject @Faces
List<Locale> supportedLocales;
or
@Inject @Faces @DefaultLocale
Locale defaultLocale;
While Seam Faces does not provide layout components or other UI-design related features, it does provide functional components designed to make developing JSF applications easier, more functional, more scalable, and more practical.
For layout and design components, take a look at RichFaces, a UI component library specifically tailored for easy, rich web-interfaces.
In order to use the Seam Faces components, you must first add the namespace to your view file, just like the standard JSF component libraries.
<html xmlns="http://www.w3.org/1999/xhtml"
xmlns:f="http://java.sun.com/jsf/core"
xmlns:h="http://java.sun.com/jsf/html"
xmlns:s="http://jboss.org/seam/faces"
xmlns:ui="http://java.sun.com/jsf/facelets">
<h1>Welcome to Seam Faces!</h1>
<p>
This view imports the Seam Faces component library.
Read on to discover what components it provides.
</p>
</html>
All Seam Faces components use the following namespace:
http://jboss.org/seam/faces
On many occasions you might find yourself needing to compare the values of multiple input fields on a given page submit: confirming a password; re-enter password; address lookups; and so on. Performing cross-field form validation is simple - just place the <s:validateForm> component in the form you wish to validate, then attach your custom Validator.
<h:form id="locationForm">
<h:inputText id="city" value="#{bean.city}" />
<h:inputText id="state" value="#{bean.state}" />
<h:inputText id="zip" value="#{bean.zip}" />
<h:commandButton id="submit" value="Submit" action="#{bean.submitPost}" />
<s:validateForm validatorId="locationValidator" />
</h:form>
The corresponding Validator for the example above would look something like this:
@FacesValidator("locationValidator")
public class LocationValidator implements Validator
{
@Inject
Directory directory;
@Inject
@InputField
private Object city;
@Inject
@InputField
private Object state;
@Inject
@InputField
private ZipCode zip;
@Override
public void validate(final FacesContext context, final UIComponent comp, final Object values)
throws ValidatorException
{
if(!directory.exists(city, state, zip))
{
throw new ValidatorException(
new FacesMessage("Sorry, that location is not in our database. Please try again."));
}
}
}
You may inject the correct type directly.
@Inject @InputField private ZipCode zip;
Notice that the IDs of the inputText components match the IDs of your Validator @InputFields; each @Inject @InputField member will be injected with the value of the form input field who's ID matches the name of the variable.
In other words - the name of the @InputField annotated member variable will automatically be matched to the ID of the input component, unless overridden by using a field ID alias (see below.)
<h:form id="locationForm">
<h:inputText id="cityId" value="#{bean.city}" />
<h:inputText id="stateId" value="#{bean.state}" />
<h:inputText id="zip" value="#{bean.zip}" />
<h:commandButton id="submit" value="Submit" action="#{bean.submitPost}" />
<s:validateForm fields="city=cityId state=stateId" validatorId="locationValidator" />
</h:form>
Notice that "zip" will still be referenced normally; you need only specify aliases for fields that differ in name from the Validator @InputFields.
Using @InputField("customID")
with an ID override can also be used to specify a
custom ID, instead of using the default: the name of the field. This gives you the ability to
change the name of the private field, without worrying about changing the name of input fields in
the View itself.
@Inject @InputField("state") private String sectorTwo;
An alternate way of accessing those fields on the validator by injecting an InputElement. It works similarly to @InputField, but stores the clientId and a JSF UIComponent, along with the field value.
@FacesValidator("fooValidator")
public class FooValidator implements Validator {
@Inject
private InputElement<String> firstNameElement;
@Inject
private InputElement<String> lastNameElement;
@Inject
private InputElement<Date> startDateElement;
@Inject
private InputElement<Date> endDateElement;
...
}
Use get methods to access those information
public void validate(final FacesContext ctx, final UIComponent form, final Object value) throws ValidatorException {
Date startDate = startDateElement.getValue();
Calendar calendar = Calendar.getInstance();
calendar.add(Calendar.DAY_OF_MONTH, -1);
if (startDate.before(calendar.getTime())) {
String message = messageBuilder.get().key(new DefaultBundleKey("booking_checkInNotFutureDate"))
.targets( startDateElement.getClientId() ).build().getText();
throw new ValidatorException(new FacesMessage(message));
}
...
}
The view action component (UIViewAction
) is an ActionSource2
UIComponent
that specifies an application-specific command (or action), using
an EL method expression, to be invoked during one of the JSF lifecycle phases proceeding Render
Response (i.e., view rendering).
View actions provide a lightweight front-controller for JSF, allowing the application to accommodate scenarios such as registration confirmation links, security and sanity checking a request (e.g., ensuring the resource can be loaded). They also allow JSF to work alongside action-oriented frameworks, and existing applications that use them.
JSF employs an event-oriented architecture. Listeners are invoked in response to user-interface events, such as the user clicking on a button or changing the value of a form input. Unfortunately, the most important event on the web, a URL request (initiated by the user clicking on a link, entering a URL into the browser's location bar or selecting a bookmark), has long been overlooked in JSF. Historically, listeners have exclusively been activated on postback, which has led to the common complaint that in JSF, "everything is a POST."
We want to change that perception.
Processing a URL request event is commonly referred to as bookmarkable or GET support. Some GET support was added to JSF 2.0 with the introduction of view parameters and the pre-render view event. View parameters are used to bind query string parameters to model properties. The pre-render view event gives the developer a window to invoke a listener immediately prior to the view being rendered.
That's a start.
Seam brings the GET support full circle by introducing the view action component. A view action is
the compliment of a UICommand
for an initial (non-faces) request. Like its
cohort, it gets executed by default during the Invoke Application phase (now used on both faces
and non-faces requests). A view action can optionally be invoked on postback as well.
View actions (UIViewAction
) are closely tied to view parameters
(UIViewParameter
). Most of the time, the view parameter is used to populate the
model with data that is consumed by the method being invoked by a UIViewAction
component, much like form inputs populate the model with data to support the method being invoked
by a UICommand
component.
Let's consider a typical scenario in web applications. You want to display the contents of a blog entry that matches the identifier specified in the URL. We'll assume the URL is:
http://localhost:8080/blog/entry.jsf?id=10
We'll use a view parameter to capture the identifier of the entry from the query string and a view action to fetch the entry from the database.
<f:metadata>
<f:viewParam name="id" value="#{blogManager.entryId}"/>
<s:viewAction action="#{blogManager.loadEntry}"/>
</f:metadata>
The view action component must be declared as a child of the view metadata facet (i.e.,
<f:metadata>
) so that it gets incorporated into the JSF lifecycle on both
non-faces (initial) requests and faces (postback) requests. If you put it anywhere else in the
page, the behavior is undefined.
The JSF 2 specification specifies that there must be at least one view parameter for the view metadata facet to be processed on an initial request. This requirement was introduced into the JSF specification inadvertently. But not to worry. Seam Faces inserts a placeholder view parameter into the view metadata if it contains other components but no view parameters. That means you can use a view action without a view parameter, contrary to the JSF specification.
What do we do if the blog entry can't be found? View actions support declarative navigation just like
UICommand
components. So you can write a navigation rule that will be consulted before
the page is rendered. If the rule matches, navigation occurs just as though this were a postback.
<navigation-rule>
<from-view-id>/entry.xhtml</from-view-id>
<navigation-case>
<from-action>#{blogManager.loadEntry}</from-action>
<if>#{empty entry}</if>
<to-view-id>/home.xhtml</to-view-id>
<redirect/>
</navigation-case>
</navigation-rule>
After each view action is invoked, the navigation handler looks for a navigation case that matches the action's EL method signature and outcome. If a navigation case is matched, or the response is marked complete by the action, subsequent view actions are short-circuited. The lifecycle then advances appropriately.
By default, a view action is not executed on postback, since the primary intention of a view
action is to support a non-faces request. If your application (or use case) is decidedly stateless,
you may need the view action to execute on any type of request. You can enable the view action
on postback using the onPostback
attribute:
<s:viewAction action="#{blogManager.loadEntry}" onPostback="true"/>
You may only want the view action to be invoked under certain conditions. For instance, you may only
need it to be invoked if the conversation is transient. For that, you can use the
if
attribute, which accepts an EL value expression:
<s:viewAction action="#{blogEditor.loadEntry}" if="#{conversation.transient}"/>
There are two ways to control the phase in which the view action is invoked. You can set the
immediate
attribute to true, which moves the invocation to the Apply Request Values phase
instead of the default, the Invoke Application phase.
<s:viewAction action="#{sessionManager.validateSession}" immediate="true"/>
You can also just specify the phase directly, using the name of the phase constant in the
PhaseId
class (the case does not matter).
<s:viewAction action="#{sessionManager.validateSession}" phase="APPLY_REQUEST_VALUES"/>
The valid phases for a view action are:
APPLY_REQUEST_VALUES
(default if immediate="true"
)
UPDATE_MODEL_VALUES
PROCESS_VALIDATIONS
INVOKE_APPLICATION
(default)
If the phase is set, it takes precedence over the immediate flag.
The purpose of the view action is similar to use of the PreRenderViewEvent. In fact, the code to load a blog entry before the page is rendered could be written as:
<f:metadata>
<f:viewParam name="id" value="#{blogManager.entryId}"/>
<f:event type="preRenderView" listener="#{blogManager.loadEntry}"/>
</f:metadata>
However, the view action has several important advantages:
It's lightweight
It's timing can be controlled
It's contextual
It can trigger navigation
View actions are lightweight because they get processed on a non-faces (initial) request before the full component tree is built. When the view actions are invoked, the component tree only contains view metadata.
As demonstrated above, you can specify a prerequisite condition for invoking the view action, control whether it's invoked on postback, specify the phase in which it's invoked and tie the invocation into the declarative navigation system. The PreRenderViewEvent is quite basic in comparison.
The ObjectConverter
is a simple converter that can be used on any Java Object, including
JPA entities. It can be used via it's converter id org.jboss.seam.faces.conversion.ObjectConverter
or by it's tag <s:objectConverter/>
.
This converter should only be used within a long running conversation to allow conversions happen correctly.
When used with a @ConversationScoped
EntityManager
no merges or re-fetch
should need to occur when using JPA entities.
UIInputContainer is a supplemental component for a JSF 2.0 composite component encapsulating one or more input components (EditableValueHolder), their corresponding message components (UIMessage) and a label (HtmlOutputLabel).
This component takes care of wiring the label to the first input and the messages to each input in sequence. It also assigns two implicit attribute values, "required" and "invalid" to indicate that a required input field is present and whether there are any validation errors, respectively. To determine if a input field is required, both the required attribute is consulted and whether the property has Bean Validation constraints.
Finally, if the "label" attribute is not provided on the composite component, the label value will be derived from the id of the composite component, for convenience.
There's a composite componente that ships with seam-faces under the url:
http://java.sun.com/jsf/composite/components/seamfaces.
xmlns:sc="http://java.sun.com/jsf/composite/components/seamfaces"
<sc:inputContainer label="name" id="name">
<h:inputText id="input" value="#{person.name}"/>
</sc:inputContainer>
If you want to define your own composite component, follow this definition example (minus layout):
<cc:interface componentType="org.jboss.seam.faces.InputContainer"/>
<cc:implementation>
<h:outputLabel id="label" value="#{cc.attrs.label}:" styleClass="#{cc.attrs.invalid ? 'invalid' : ''}">
<h:outputText styleClass="required" rendered="#{cc.attrs.required}" value="*"/>
</h:outputLabel>
<h:panelGroup>
<cc:insertChildren/>
</h:panelGroup>
<h:message id="message" errorClass="invalid message" rendered="#{cc.attrs.invalid}"/>
</cc:implementation>
it's currently required to wrap the insertChildren tag with a jsf panelGroup. Please see http://java.net/jira/browse/JAVASERVERFACES-1991 for more details.
NOTE: Firefox does not properly associate a label with the target input if the input id
contains a colon (:), the default separator character in JSF. JSF 2 allows developers to
set the value via an initialization parameter (context-param in web.xml) keyed to
javax.faces.SEPARATOR_CHAR
. We recommend that you override this setting to make the
separator an underscore (_).
One of the goals of the Seam Faces Module is to make support for CDI a more ubiquitous experience, by allowing injection of JSF Lifecycle Artifacts into managed beans, and also by providing support for @Inject where it would not normally be available. This section describes the additional CDI integration for faces artifact injection
Frequently when performing complex validation, it is necessary to access data stored in a database
or in other contextual objects within the application itself. JSF does not, by default, provide
support for @Inject
in Converters and Validators, but Seam Faces makes this
available. In addition to injection, it is sometimes convenient to be able to scope a validator
just as we would scope a managed bean; this feature is also added by Seam Faces.
Notice how the Validator below is actually @RequestScoped
, in addition to using
injection to obtain an instance of the UserService
with which to perform an email
database lookup.
@RequestScoped
@FacesValidator("emailAvailabilityValidator")
public class EmailAvailabilityValidator implements Validator
{
@Inject
UserService us;
@Override
public void validate(final FacesContext context, final UIComponent component, final Object value)
throws ValidatorException
{
String field = value.toString();
try
{
us.getUserByEmail(field);
FacesMessage msg = new FacesMessage("That email address is unavailable");
throw new ValidatorException(msg);
}
catch (NoSuchObjectException e)
{
}
}
}
We recommend to always use @RequestScoped
converters/validators unless a
longer scope is required, in which case you should use the appropriate scope annotation, but
it should not be omitted.
Because of the way JSF persists Validators between requests, particularly when using
@Inject
inside a validator or converter, forgetting to use a
@*Scoped
annotation could in fact cause @Inject
'ed
objects to become null.
An example Converter using @Inject
@SessionScoped
@FacesConverter("authorConverter")
public class UserConverter implements Converter
{
@Inject
private UserService service;
@PostConstruct
public void setup()
{
System.out.println("UserConverter started up");
}
@PreDestroy
public void shutdown()
{
System.out.println("UserConverter shutting down");
}
@Override
public Object getAsObject(final FacesContext arg0, final UIComponent arg1, final String userName)
{
// ...
return service.getUserByName(userName);
}
@Override
public String getAsString(final FacesContext context, final UIComponent comp, final Object user)
{
// ...
return ((User)user).getUsername();
}
}
This is the list of inject-able artifacts provided through Seam Faces. These objects would normally require static method-calls in order to obtain handles, but Seam Faces attempts to break that coupling by providing @Inject'able artifacts. This means it will be possible to more easily provide mocked objects during unit and integration testing, and also simplify bean code in the application itself.
Artifact Class | Example |
---|---|
javax.faces.context.FacesContext | public class Bean { @Inject FacesContext context; } |
javax.faces.context.ExternalContext | public class Bean { @Inject ExternalContext context; } |
javax.faces.application.NavigationHandler | public class Bean { @Inject NavigationHandler handler; } |
javax.faces.context.Flash | public class Bean { @Inject Flash flash; } |
When the seam-faces module is installed in a web application, JSF events will automatically be propagated via the CDI event-bridge, enabling managed beans to easily observe all Faces events.
There are two categories of events: JSF phase events, and JSF system events. Phase events are triggered as JSF processes each lifecycle phase, while system events are raised at more specific, fine-grained events during request processing.
A JSF phase listener is a class that implements javax.faces.event.PhaseListener
and
is registered in the web application's faces-config.xml
file. By implementing the methods of the
interfaces, the user can observe events fired before or after any of the six lifecycle phases of a JSF request:
restore view
, apply request values
, process validations
,
update model values
, invoke application
or render view
.
In order to observe events in an EJB JAR, the beans.xml file must be in both the WEB-INF folder of the WAR, and inside the EJB JAR containing the observer.
What Seam provides is propagation of these Phase events to the CDI event bus; therefore, you can observe events
using normal CDI @Observes
methods. Bringing the events to CDI beans removes the need to
register phase listener classes via XML, and gives the added benefit of injection, alternatives, interceptors
and access to all other features of CDI.
Creating an observer method in CDI is simple; just provide a method in a managed bean that is annotated with
@Observes
. Each observer method must accept at least one method parameter: the event object;
the type of this object determines the type of event being observed. Additional parameters may also be specified,
and their values will be automatically injected by the container as per the CDI specification.
In this case, the event object passed along from the phase listener is a
javax.faces.event.PhaseEvent
. The following example observes all Phase events.
public void observeAll(@Observes PhaseEvent e)
{
// Do something with the event object
}
Events can be further filtered by adding Qualifiers. The name of the method itself is not significant. (See the CDI Reference Guide for more information on events and observing.)
Since the example above simply processes all events, however, it might be appropriate to filter out some events
that we aren't interested in. As stated earlier, there are six phases in the JSF lifecycle, and an event is
fired before and after each, for a total of 12 events. The @Before
and
@After
"temporal" qualifiers can be used to observe events occurring only before or only after
a Phase event. For example:
public void observeBefore(@Observes @Before PhaseEvent e)
{
// Do something with the "before" event object
}
public void observeAfter(@Observes @After PhaseEvent e)
{
// Do something with the "after" event object
}
If we are interested in both the "before" and "after" event of a particular phase, we can limit them by adding a "lifecycle" qualifier that corresponds to the phase:
public void observeRenderResponse(@Observes @RenderResponse PhaseEvent e)
{
// Do something with the "render response" event object
}
By combining a temporal and lifecycle qualifier, we can achieve the most specific qualification:
public void observeBeforeRenderResponse(@Observes @Before @RenderResponse PhaseEvent e)
{
// Do something with the "before render response" event object
}
This is the full list of temporal and lifecycle qualifiers
Qualifier | Type | Description |
---|---|---|
@Before | temporal | Qualifies events before lifecycle phases |
@After | temporal | Qualifies events after lifecycle phases |
@RestoreView | lifecycle | Qualifies events from the "restore view" phase |
@ApplyRequestValues | lifecycle | Qualifies events from the "apply request values" phase |
@ProcessValidations | lifecycle | Qualifies events from the "process validations" phase |
@UpdateModelValues | lifecycle | Qualifies events from the "update model values" phase |
@InvokeApplication | lifecycle | Qualifies events from the "invoke application" phase |
@RenderResponse | lifecycle | Qualifies events from the "render response" phase |
The event object is always a javax.faces.event.PhaseEvent
and according to the general
CDI principle, filtering is tightened by adding qualifiers and loosened by omitting them.
Similar to JSF Phase Events, System Events take place when specific events occur within the JSF life-cycle. Seam Faces provides a bridge for all JSF System Events, and propagates these events to CDI.
This is an example of observing a Faces system event:
public void observesThisEvent(@Observes ExceptionQueuedEvent e)
{
// Do something with the event object
}
Since all JSF system event objects are distinct, no qualifiers are needed to observe them. The following events may be observed:
Event object | Context | Description |
---|---|---|
SystemEvent | all | All events |
ComponentSystemEvent | component | All component events |
PostAddToViewEvent | component | After a component was added to the view |
PostConstructViewMapEvent | component | After a view map was created |
PostRestoreStateEvent | component | After a component has its state restored |
PostValidateEvent | component | After a component has been validated |
PreDestroyViewMapEvent | component | Before a view map has been restored |
PreRemoveFromViewEvent | component | Before a component has been removed from the view |
PreRenderComponentEvent | component | After a component has been rendered |
PreRenderViewEvent | component | Before a view has been rendered |
PreValidateEvent | component | Before a component has been validated |
ExceptionQueuedEvent | system | When an exception has been queued |
PostConstructApplicationEvent | system | After the application has been constructed |
PostConstructCustomScopeEvent | system | After a custom scope has been constructed |
PreDestroyApplicationEvent | system | Before the application is destroyed |
PreDestroyCustomScopeEvent | system | Before a custom scope is destroyed |
There is one qualifier, @Component
that can be used with component events by specifying the component ID. Note that
view-centric component events PreRenderViewEvent
, PostConstructViewMapEvent
and
PreDestroyViewMapEvent
do not fire with the @Component
qualifier.
public void observePrePasswordValidation(@Observes @Component("form:password") PreValidateEvent e)
{
// Do something with the "before password is validated" event object
}
Global system events are observer without the component qualifier
public void observeApplicationConstructed(@Observes PostConstructApplicationEvent e)
{
// Do something with the "after application is constructed" event object
}
The name of the observing method is not relevant; observers are defined solely via annotations.
The Seam Faces module provides integration with the JSF project stage system. Beside the injection of the current project stage into beans, Seam Faces also allows to enable specific beans only for certain project stages.
Seam Faces supports the injection of the current project stage directly into CDI managed beans. This allows to implement special behavior for certain project stages very easily.
public class Bean {
@Inject
private ProjectStage projectStage;
public void someMethod() {
if (projectStage == ProjectStage.Development) {
/* do something special for development mode here */
}
}
}
Seam Faces provides a set of annotations that can be used to activate beans only in specific project stages. The following table shows the JSF project stages and the corresponding Seam Faces annotations.
Project Stage | ProjectStage Enum | Seam Faces Anntotation |
---|---|---|
Production | ProjectStage.Production | @Production |
Development | ProjectStage.Development | @Development |
UnitTest | ProjectStage.UnitTest | @UnitTest |
SystemTest | ProjectStage.SystemTest | @SystemTest |
To restrict a bean to a project stage just place the correspoding annotation on the class.
The following example shows a bean that logs the beginning and end of each JSF lifecycle phase.
As the bean is annotated with @Development
, it will only be activated
if the application runs in the Development
project stage.
@Development
public class PhaseEventLogBean {
public void before(@Observes @Before PhaseEvent event) {
log.debug("Before: " + event.getPhaseId());
}
public void after(@Observes @After PhaseEvent event) {
log.debug("After: " + event.getPhaseId());
}
}
You can place more than one project stage annotation on a bean. So if a bean should be active in all
project stages except for Production
, define it like this:
</span> <!-- --><br/><span class="java_plain">@</span><span class="java_type">Development</span><span class="java_plain"> @</span><span class="java_type">SystemTest</span><span class="java_plain"> @</span><span class="java_type">UnitTest</span> <!-- --><br/><span class="java_keyword">public</span><span class="java_plain"> </span><span class="java_keyword">class</span><span class="java_plain"> </span><span class="java_type">Bean</span><span class="java_plain"> </span><span class="java_separator">{</span> </span> <!-- --><br/><span class="java_separator">}</span> <!-- --><br/><span class="java_plain"> </span>
Seam Faces will automatically detect the project stage that is used for the application. If you want Seam Faces to use a different project stage, you can use one of the following two ways.
The first possibility to change the project stage for Seam Faces is to set the system property
org.jboss.seam.faces.PROJECT_STAGE
. This option is the most easiest to use but
is also very unflexible because the project stage be set for all applications running in a container.
-Dorg.jboss.seam.faces.PROJECT_STAGE=Development
If you need more control over the project stage that is used you can implement the Seam Faces
SPI org.jboss.seam.faces.projectstage.ProjectStageDetector
. Just implement
this interface and add the fully-qualified classname of the class to the file
META-INF/services/org.jboss.seam.faces.projectstage.ProjectStageDetector
.
See the following class for an example:
public class MyProjectStageDetector implements ProjectStageDetector {
@Override
public int getPrecedence() {
return 10;
}
@Override
public ProjectStage getProjectStage() {
if (System.getProperty("user.name").startsWith("dev-")) {
return ProjectStage.Development;
}
return ProjectStage.Production;
}
}
Seam Faces aims to provide JSF web developers with a truly worthy framework for web development by ironing out some of the JSF pain points, integrating tightly with CDI, and offering out of the box integration with the other Seam Modules. The view configuration presented here provides a central means of configuring seemingly disparate concerns.
Adhering to the CDI core tenet of type safety, Seam Faces offers a type-safe way to configure the behaviour of your JSF views. So far these configurable behaviors include:
Configuring view access by integrating with Seam Security
Configuring URL rewriting by integrating with Pretty Faces (or any other pluggable URL rewriting framework)
A personal favorite of the Seam Faces lead: setting faces-direct=true
when
navigating to a view.
The Seam Faces example application faces-viewconfig
, demonstrates all the view configuration
techniques discussed in this chapter.
Faces pages are configured by placing annotations on the properties of an Java enum
.
The annotation @ViewConfig
is placed on a Java interface
, which
contains a static enum. It is the properties of this static enum that hold the individual annotations used
to configure the view.
@ViewConfig
public interface Pages {
static enum Pages1 {
@ViewPattern("/admin.xhtml")
@Admin
ADMIN,
@UrlMapping(pattern="/item/#{item}/")
@ViewPattern("/item.xhtml")
@Owner
ITEM,
@FacesRedirect
@ViewPattern("/*")
@AccessDeniedView("/denied.xhtml")
@LoginView("/login.xhtml")
ALL;
}
}
The interface
containing the enum is required due to a limitation in version 1.0 of the
CDI specification. If the @ViewConfig
is placed directly on the enum, the CDI
specification does not require the annotations to be scanned.
Each property of the enum is annotated with at least the @ViewPattern
annotation. This
view pattern is used to match against the JSF view ids, to determine which annotations apply to a given view
id. The view patterns themselves support the *
wild character. A view is matched against
all view parameters that apply to determine the relevant annotations. If conflicting annotations are found,
the annotation paired with the most specific matching view pattern takes precedence.
Securing view access is achieved through integration with Seam Security, which must be explicitly bundled with your web application. Refer to the Seam Security documentation for details on how to setup authentication. What we'll cover here is the authorisation to JSF views.
To secure a view, we start by
writing an annotation qualified with a @SecurityBindingType
qualifier:
@SecurityBindingType
@Retention(RetentionPolicy.RUNTIME)
@Target({ElementType.FIELD, ElementType.METHOD, ElementType.TYPE})
public @interface Owner {
}
This @SecurityBindingType
qualified annotation is placed on an enum property in the
@ViewConfig
annotated interface
, adjacent to the @ViewPattern
to which the security restriction applies. View patterns with wildcards are supported for security
based annotations.
Methods that enforce the Security restriction are annotated with the @Secures
annotation, as well as the same @SecurityBindingType
qualified annotation used on the
@ViewConfig enum
property.
public @Secures @Owner boolean ownerChecker(Identity identity, @Current Item item) {
if (item == null || identity.getUser() == null) {
return false;
} else {
return item.getOwner().equals(identity.getUser().getId());
}
}
When a JSF view is visited, matching @ViewPattern
patterns are found, and their
associated @SecurityBindingType
qualified annotations are looked up. The
corresponding method is invoked, and access is either granted or denied. If access is denied, and the
user is not yet logged in, the user will be redirected to a view specified in a
@LoginView
annotation for that view. However if access is denied, and the user is
logged in, navigation will be redirected to a view specified in the @AccessDeined
annotation.
Refer to the Seam Security documentation for further details on writing @Secures
methods for restricting view access, including support for parameter injection.
By default, Security restrictions are enforced before the Invoke Application
phase,
and before the Render Response
phase. Restrictions are enforced twice per lifecycle,
as the view id normally changes at the end of the Invoke Application
phase. However,
use cases exist requiring enforcement of a Security restriction at a different phase. For instance it is
desirable to enforce a role-based restriction as early in the lifecycle as possible, to prevent any
unnecessary computations from occurring. This is achieved using the @RestrictAtView
annotation.
By qualifying a @SecurityBindingType
qualified annotation with the
@RestrictAtView
qualifier, one is able to specify at which phase that individual
Security restriction should be applied. Additionally, the @RestrictAtView
annotation
can be applied directly to a @ViewConfig enum
property, to determine the restriction
phase of all associated @SecurityBindingType
qualified annotations.
Seam Faces delegates URL Rewriting to Pretty Faces.
The Rewriting mechanism however is pluggable, and an alternate URL Rewriting engine could easily be used
instead. What makes SeamFaces unique in it's approach to URL rewriting, is that the rewrite configuration
is done via the @ViewConfig
mechanism, so all view configuration is done consistently.
To configure UrlRewriting, use the @UrlRewrite
Seam Faces annotation:
...
@UrlMapping(pattern="/item/#{item}/")
@ViewPattern("/item.xhtml")
ITEM;
...
The above listing would rewrite the url /item.jsf/item=2
into
/item/2/
. See the Pretty Faces documentation for further details on configuring URL
rewriting.
A @ViewPattern
annotated with @FacesRedirect
will cause all
navigations to views that match that pattern to have their faces-redirect property set to true. This
alleviates the requirement to append ?faces-redirect=true
to all implicit navigation
rules, and neither does it have to be specified in the navigation rules defined in the faces-config.xml.
Table of Contents
The goal of Seam Reports is to provide a fully integrated CDI programming model portable extension for Java EE that provides APIs for compiling, populating and rendering reports from existing report frameworks.
Seam Reports contains similar functionality to that of the Excel and PDF templates of Seam 2, however, the creation and compilation of the reports is quite different. Seam Reports aligns much better with existing tools in a business, making use of knowledge and expertise that exists outside of development. The functionality in Seam 2 was largely targeted to creating flyers and simple pages. Seam Reports can accomplish this, but also allows for easy creation of multi-page business reports by integrating with JasperReports, Pentaho, and XDocReports. Integration with other reporting solutions can also be done easily by implementing five small interfaces provided by Seam Reports, see chapter 3 for more information about adding reporting engines.
Most features of Seam Reports are installed automatically by including the seam-reports-api.jar and the respective provider implementation (along with its dependencies) in the web application library folder. If you are using Maven as your build tool, you can add the following dependency to your pom.xml file:
<dependency>
<groupId>org.jboss.seam.reports</groupId>
<artifactId>seam-reports-api</artifactId>
<version>${seam-reports-version}</version>
</dependency>
<!-- If you are using Jasper Reports, add the following dependency -->
<dependency>
<groupId>org.jboss.seam.reports</groupId>
<artifactId>seam-reports-jasper</artifactId>
<version>${seam-reports-version}</version>
</dependency>
<!-- If you are using Pentaho, add the following dependency -->
<dependency>
<groupId>org.jboss.seam.reports</groupId>
<artifactId>seam-reports-pentaho</artifactId>
<version>${seam-reports-version}</version>
</dependency>
Replace ${seam-reports-version} with the most recent or appropriate version of Seam Reports.
If you are using Seam Forge, you may use the seam-reports plugin to help with the setup.
If not already installed yet on Forge, you may install the plugin by running the following command inside Forge:
forge git-plugin git://github.com/forge/plugin-seam-reports.git
Using Seam Reports is a simple four step process. These steps are the same regardless of the reporting engine being used.
Create a report using a favorite report editor
Load the created report
Fill the report with data
Render the report
Of course some of these steps will have different ways of accomplishing the task, but at a high level they are
all the same. For simplicity this quick start will use JasperReports and the first step will be assumed to have
already taken place and the report is available in the deployed archive. The location of the report isn't
important, the ability to pull it into an InputStream
is all that really matters.
The following code demonstrates a basic way of fulfilling the last three steps in using Seam Reports using JasperReports as the reporting engine. The report has already been created and is bundled inside the deployable archive. There are no paramaters for the report. The report is a simple listing of people's names and contact information.
@Model
public class PersonContactReport {@Inject @Resource("WEB-INF/jasperreports/personContact.jrxml")
private InputStream reportTemplate;@Inject @Jasper
private ReportCompiler reportCompiler;@Inject @Jasper @PDF
private ReportRenderer pdfRenderer;
@Inject
private EntityManager em;![]()
public OutputStream render() {
final Report filledReport = this.fillReport();
final OutputStream os = new ByteArrayOutputStream();
this.pdfRenderer.render(filledReport, os);
return os;
}![]()
private Report fillReport() {
final ReportDefinition rd = this.reportCompiler.compile(reportTemplate);
return rd.fill(this.createDatasource(), Collections.EMPTY_MAP);
}![]()
private JRDataSource createDatasource() {
final List<Person> personList = this.em.createQuery("select p from Person", Person.class).getResultList();
return new JRBeanCollectionDataSource(personList);
}
}
Solder allows easy resource injection for files available in the archive. This injects the report template which has been created previously (perhaps by someone else in the business) and added to the deployable archive. | |
A | |
This is an instance of using both qualifers ( | |
The | |
At this stage data to populate the report is retrieved and added to the compiled
| |
This last stage of using Seam Reports is the only place that may require the application to use the report engine API. In this example a list of JPA entities is retrieved and added to a JasperReports datasource, which is then used by the calling method to populate the report template as mentioned above. |
There are four API level annotations to be aware of when using Seam Reports. All four of them declare metadata about objects that are being injected. They're also all CDI qualifiers which instruct the implementing renderer the mimetype that should be used.
CSV
HTML
XLS
XML
These annotations are only used when injecting a ReportRenderer
. Only one of them may be used
per renderer. Multiple renderers must be injected if multiple renderering types are desired.
Table of Contents
Seam mail is an portable CDI extension designed to make working with Java Mail easier via standard
methods or plugable
templating engines.
No better way to start off then with a simple example to show what we are talking about.
@Inject
private Instance<MailMessage> mailMessage;
public void sendMail() {
MailMessage m = mailMessage.get();
m.from("John Doe<john@test.com>")
.to("Jane Doe<jane@test.com>")
.subject(subject)
.bodyHtml(htmlBody)
.importance(MessagePriority.HIGH)
.send();
}
Very little is required to enable this level of functionality in your application. Let's start off with a little required configuration.
By default the configuration parameters for Seam Mail are handled via configuration read from your application's seam-beans.xml. This file is then parsed by Seam Solder to configure the MailConfig class. You can override this and provide your own configuration outside of Seam Mail but we will get into that later.
First lets add the relevant maven configuration to your pom.xml
<dependency>
<groupId>org.jboss.seam.mail</groupId>
<artifactId>seam-mail-impl</artifactId>
<version>${seam.mail.version}</version>
</dependency>
Now now that is out of the way lets provide JavaMail
with the details of your SMTP
server
so that it can connect and send your mail on it's way.
This configuration is handled via Seam Solder which reads in the configuration from your
application's seam-beans.xml
and configures the MailConfig
class prior to injection.
<beans xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:s="urn:java:ee"
xmlns:mail="urn:java:org.jboss.seam.mail.core"
xsi:schemaLocation="
http://java.sun.com/xml/ns/javaee
http://docs.jboss.org/cdi/beans_1_0.xsd">
<mail:MailConfig
serverHost="my-server.test.com"
serverPort="25">
<s:modifies/>
</mail:MailConfig>
</beans>
That is all the configuration necessary to send a simple email message. Next we will take a look at how to configure and use the supported templating engines.
JBoss AS 7.0.x does not correctly load all the modules to support sending mail AS7-1375. This is easily fixed By replacing the module definition at $JBOSS_HOME/modules/javax/activation/api/main/module.xml with the following
<module xmlns="urn:jboss:module:1.0" name="javax.activation.api">
<dependencies>
<module name="javax.api" />
<module name="javax.mail.api" >
<imports><include path="META-INF"/></imports>
</module>
</dependencies>
<resources>
<resource-root path="activation-1.1.1.jar"/>
<!-- Insert resources here -->
</resources>
</module>
This will be fixed in AS 7.1.x
While Seam Mail does provide methods to produce templated email, there is a core set of functionality that is shared whether you use a templating engine or not.
At it's base an email consists of various destinations and content. Seam Mail provides a wide varerity of methods of ways to configure the following address fields
From
To
CC
BCC
REPLY-TO
Seam Mail leverages the JavaMail InternetAddress object internally for parsing and storage and provides a varargs method for each of the contact types. Thus you can provide either a String, multiple Strings or a String []. Addresses are parsed as RFC 822 addresses and can be a valid Email Address or a Name + Email Address.
MailMessage m = mailMessage.get();
m.from("John Doe<john@test.com>")
.to("jane@test.com")
.cc("Dan<dan@test.com", "bill@test.com")
Since we leverage standard InternetAddress object we might as well provide a method to use it.
MailMessage m = mailMessage.get();
m.from(new InternetAddress("John Doe<john@test.com>"))
Since applications frequently have their own object to represent a user who will have an email set to them we provide a simple interface which your object can implement.
public interface EmailContact {
public String getName();
public String getAddress();
}
Let's define this interface on an example user entity
@Entity
public class User implements EmailContact {
private String username; //"john@test.com"
private String firstName; //"John"
private String lastName; //"Doe"
public String getName() {
return firstName + " " + lastName;
}
public String getAddress() {
return username;
}
}
Now we can use our User object directly in an of the contact methods
User user;
MailMessage m = mailMessage.get();
m.from("John Doe<john@test.com>")
.to(user)
Table of Contents
Seam provides a convenient method of remotely accessing CDI beans from a web page, using AJAX (Asynchronous Javascript and XML). The framework for this functionality is provided with almost no up-front development effort - your beans only require simple annotating to become accessible via AJAX. This chapter describes the steps required to build an AJAX-enabled web page, then goes on to explain the features of the Seam Remoting framework in more detail.
To use remoting, the Seam Remoting servlet must first be configured in your web.xml
file:
<servlet>
<servlet-name>Remoting Servlet</servlet-name>
<servlet-class>org.jboss.seam.remoting.Remoting</servlet-class>
<load-on-startup>1</load-on-startup>
</servlet>
<servlet-mapping>
<servlet-name>Remoting Servlet</servlet-name>
<url-pattern>/seam/resource/remoting/*</url-pattern>
</servlet-mapping>
web-fragment.xml
that configures the Remoting servlet automatically.
The next step is to import the necessary Javascript into your web page. There are a minimum of two scripts that must be imported. The first one contains all the client-side framework code that enables remoting functionality:
<script type="text/javascript" src="seam/resource/remoting/resource/remote.js"></script>
By default, the client-side JavaScript is served in compressed form, with white space compacted and JavaScript comments
removed. For a development environment, you may wish to use the uncompressed version of remote.js
for
debugging and testing purposes. To do this, simply add the compress=false
parameter to the end of the url:
<script type="text/javascript" src="seam/resource/remoting/resource/remote.js?compress=false"></script>
The second script that you need contains the stubs and type definitions for the beans you wish to call. It is
generated dynamically based on the method signatures of your beans, and includes type definitions for all of
the classes that can be used to call its remotable methods. The name of the script reflects the
name of your bean. For example, if you have a named bean annotated with @Named
, then your script
tag should look like this (for a bean class called CustomerAction
):
<script type="text/javascript"
src="seam/resource/remoting/interface.js?customerAction"></script>
Otherwise, you can simply specify the fully qualified class name of the bean:
<script type="text/javascript"
src="seam/resource/remoting/interface.js?com.acme.myapp.CustomerAction"></script>
If you wish to access more than one bean from the same page, then include them all as parameters of your script tag:
<script type="text/javascript"
src="seam/resource/remoting/interface.js?customerAction&accountAction"></script>
Client-side interaction with your beans is all performed via the Seam
Javascript
object. This object is defined in remote.js
, and you'll be using it to make asynchronous calls
against your bean. It contains methods for creating client-side bean objects and also methods for executing remote
requests. The easiest way to become familiar with this object is to start with a simple example.
Let's step through a simple example to see how the Seam
object works. First of all,
let's create a new bean called helloAction
:
@Named
public class HelloAction implements HelloLocal {
@WebRemote public String sayHello(String name) {
return "Hello, " + name;
}
}
Take note of the @WebRemote
annotation on the sayHello()
method in the
above listing. This annotation makes the method accessible via the Remoting API. Besides this annotation, there's
nothing else required on your bean to enable it for remoting.
If you are performing a persistence operation in the method marked @WebRemote
you will
also need to add a @Transactional
annotation to the method. Otherwise, your method would
execute outside of a transaction without this extra hint.That's because unlike a JSF request, Seam does not
wrap the remoting request in a transaction automatically.
Now for our web page - create a new JSF page and import the helloAction
bean:
<script type="text/javascript"
src="seam/resource/remoting/interface.js?helloAction
To make this a fully interactive user experience, let's add a button to our page:
<button onclick="javascript:sayHello()">Say Hello</button>
We'll also need to add some more script to make our button actually do something when it's clicked:
<script type="text/javascript">
//<![CDATA[
function sayHello() {
var name = prompt("What is your name?");
Seam.createBean("helloAction").sayHello(name, sayHelloCallback);
}
function sayHelloCallback(result) {
alert(result);
}
// ]]>
</script>
We're done! Deploy your application and open the page in a web browser. Click the button, and enter a name when
prompted. A message box will display the hello message confirming that the call was successful. If you want to
save some time, you'll find the full source code for this Hello World example in the
/examples/helloworld
directory.
So what does the code of our script actually do? Let's break it down into smaller pieces. To start with, you can see from the Javascript code listing that we have implemented two methods - the first method is responsible for prompting the user for their name and then making a remote request. Take a look at the following line:
Seam.createBean("helloAction").sayHello(name, sayHelloCallback);
The first section of this line, Seam.createBean("helloAction")
returns a
proxy, or "stub" for our helloAction
bean. We can invoke the methods of our bean
against this stub, which is exactly what happens with the remainder of the line:
sayHello(name, sayHelloCallback);
.
What this line of code in its completeness does, is invoke the sayHello
method of our
bean, passing in name
as a parameter. The second parameter,
sayHelloCallback
isn't a parameter of our bean's sayHello
method,
instead it tells the Seam Remoting framework that once it receives the response to our request, it should pass
it to the sayHelloCallback
Javascript method. This callback parameter is entirely optional,
so feel free to leave it out if you're calling a method with a void
return type or if you
don't care about the result.
The sayHelloCallback
method, once receiving the response to our remote request then pops
up an alert message displaying the result of our method call.
The Seam.createBean
JavaScript method is used to create client-side instances of both
action and "state" beans. For action beans (which are those that contain one or more methods annotated with
@WebRemote
), the stub object provides all of the remotable methods exposed by the bean.
For "state" beans (i.e. beans that simply carry state, for example Entity beans) the stub object provides all
the same accessible properties as its server-side equivalent. Each property also has a corresponding
getter/setter method so you can work with the object in JavaScript in much the same way as you would in Java.
The Seam Remoting Context contains additional information which is sent and received as part of a remoting request/response cycle. It currently contains the conversation ID and Call ID, and may be expanded to include other properties in the future.
If you intend on using remote calls within the scope of a conversation then you need to be able to read or
set the conversation ID in the Seam Remoting Context. To read the conversation ID after making a remote request
call Seam.context.getConversationId()
. To set the conversation ID before making a
request, call Seam.context.setConversationId()
.
If the conversation ID hasn't been explicitly set with
Seam.context.setConversationId()
, then it will be automatically assigned the
first valid conversation ID that is returned by any remoting call. If you are working with multiple conversations
within your page, then you may need to explicitly set the conversation ID before each call. If you are working
with just a single conversation, then you don't need to do anything special.
In some circumstances it may be required to make a remote call within the scope of the current view's conversation. To do this, you must explicitly set the conversation ID to that of the view before making the remote call. This small snippet of JavaScript will set the conversation ID that is used for remoting calls to the current view's conversation ID:
Seam.context.setConversationId( #{conversation.id} );
This section describes the support for basic data types. On the server side these values as a rule are compatible with either their primitive type or their corresponding wrapper class.
There is support for all number types supported by Java. On the client side, number values are always
serialized as their String representation and then on the server side they are converted to the correct
destination type. Conversion into either a primitive or wrapper type is supported for Byte
,
Double
, Float
, Integer
, Long
and
Short
types.
In general these will be either entity beans or JavaBean classes, or some other non-bean class. Use
Seam.createBean()
to create a new instance of the object.
Date values are serialized into a String representation that is accurate to the millisecond. On the client
side, use a JavaScript Date
object to work with date values. On the server side, use any
java.util.Date
(or descendent, such as java.sql.Date
or
java.sql.Timestamp
class.
On the client side, enums are treated the same as String
s. When setting the value for an enum parameter,
simply use the String
representation of the enum. Take the following bean as an example:
@Named
public class paintAction {
public enum Color {red, green, blue, yellow, orange, purple};
public void paint(Color color) {
// code
}
}
To call the paint()
method with the color red
, pass the parameter
value as a String
literal:
Seam.createBean("paintAction").paint("red");
The inverse is also true - that is, if a bean method returns an enum parameter (or contains an enum
field anywhere in the returned object graph) then on the client-side it will be converted to a String
.
Bags cover all collection types including arrays, collections, lists, sets, (but excluding Maps - see the next section for those), and are implemented client-side as a JavaScript array. When calling a bean method that accepts one of these types as a parameter, your parameter should be a JavaScript array. If a bean method returns one of these types, then the return value will also be a JavaScript array. The remoting framework is clever enough on the server side to convert the bag to an appropriate type (including sophisticated support for generics) for the bean method call.
As there is no native support for Maps within JavaScript, a simple Map implementation is provided with
the Seam Remoting framework. To create a Map which can be used as a parameter to a remote call, create a new
Seam.Map
object:
var map = new Seam.Map();
This JavaScript implementation provides basic methods for working with Maps: size()
,
isEmpty()
, keySet()
, values()
,
get(key)
, put(key, value)
, remove(key)
and
contains(key)
. Each of these methods are equivalent to their Java counterpart. Where the
method returns a collection, such as keySet()
and values()
, a JavaScript
Array object will be returned that contains the key or value objects (respectively).
To aid in tracking down bugs, it is possible to enable a debug mode which will display the contents of all
the packets send back and forth between the client and server in a popup window. To enable debug mode, set the
Seam.debug
property to true
in Javascript:
Seam.debug = true;
If you want to write your own messages to the debug log, call
Seam.log(message)
.
The Seam International module provides a Messages API that allows generation of view-independent messages. This is useful if you want to convey additional information to a user that is not returned directly from the result of a method invocation.
Using the Messages API is extremely easy. Simply add the Seam International libraries to your application
(see the Seam International configuration chapter to learn how to do this), then inject the Messages
object into your bean. The Messages
object provides several methods for adding messages, see
the Seam International documentation for more information. Here's a simple example showing how to create
an info
message (messages generally follow the same DEBUG, INFO, WARN, ERROR levels that a typical
logging framework would provide):
import javax.inject.Inject;
import org.jboss.seam.international.status.Messages;
import org.jboss.seam.remoting.annotations.WebRemote;
public class HelloAction {
@Inject Messages messages;
@WebRemote
public String sayHello(String name) {
messages.info("Invoked HelloAction.sayHello()");
return "Hello, " + name;
}
}
After creating the message in your server-side code, you still need to write some client-side code
to handle any messages that are returned by your remote invocations. Thankfully this is also simple,
you just need to write a JavaScript handler function and assign it to Seam.messageHandler
.
If any messages are returned from a remote method invocation, the message handler function will be invoked
and passed a list of Message objects. These objects declare three methods for retrieving various properties
of the message - getLevel()
returns the message level (such as DEBUG, INFO, etc). The
getTargets()
method returns the targets of the message - these may be the ID's for specific
user interface controls, which is helpful for conveying validation failures for certain field values.
The getTargets()
method may return null, if the message is not specific to any field value.
Lastly, the getText()
method returns the actual text of the message.
Here's a really simple example showing how you would display an alert box for any messages returned:
function handleMessages(msgs) { for (var i = 0; i < msgs.length; i++) { alert("Received message - Level: " + msgs[i].getLevel() + " Text: " + msgs[i].getText(); } } Seam.messageHandler = handleMessages;
You can see the Messages API in action in the HelloWorld example. Simply choose the "Formal" option for the Formality, and "Localized (English)" for the Localization. Invoking this combination will cause a server-side message to be created, which you will then see in the Messages list at the top of the screen.
When invoking a remote bean method, it is possible to specify an exception handler which will process the response in the event of an exception during bean invocation. To specify an exception handler function, include a reference to it after the callback parameter in your JavaScript:
var callback = function(result) { alert(result); }; var exceptionHandler = function(ex) { alert("An exception occurred: " + ex.getMessage()); }; Seam.createBean("helloAction").sayHello(name, callback, exceptionHandler);
If you do not have a callback handler defined, you must specify null
in its place:
var exceptionHandler = function(ex) { alert("An exception occurred: " + ex.getMessage()); }; Seam.createBean("helloAction").sayHello(name, null, exceptionHandler);
The exception object that is passed to the exception handler exposes two methods, getExceptionClass()
which returns the name of the exception class that was thrown, and getMessage()
, which
returns the exception message which is produced by the exception thrown by the @WebRemote
method.
It is also possible to register a global exception handler, which will be invoked if there is no exception handler defined for an individual invocation. By default, the global exception handler will display an alert message notifying the user that there was an exception - here's what the default exception handler looks like:
Seam.defaultExceptionHandler = function(exception) { alert("An exception has occurred while executing a remote request: " + exception.getExceptionClass() + ":" + exception.getMessage()); };
If you would like to provide your own global exception handler, then simply override the value of
Seam.exceptionHandler
with your own custom exception handler, as in the following example:
function customExceptionHandler(exception) { alert("Uh oh, something bad has happened! [" + exception.getExceptionClass() + ":" + exception.getMessage() + "]"); } Seam.exceptionHandler = customExceptionHandler;
The default loading message that appears in the top right corner of the screen can be modified, its rendering customised or even turned off completely.
To change the message from the default "Please Wait..." to something different, set the value of
Seam.loadingMessage
:
Seam.loadingMessage = "Loading...";
To completely suppress the display of the loading message, override the implementation of
displayLoadingMessage()
and hideLoadingMessage()
with functions that
instead do nothing:
// don't display the loading indicator
Seam.displayLoadingMessage = function() {};
Seam.hideLoadingMessage = function() {};
It is also possible to override the loading indicator to display an animated icon, or anything else that
you want. To do this override the displayLoadingMessage()
and
hideLoadingMessage()
messages with your own implementation:
Seam.displayLoadingMessage = function() {
// Write code here to display the indicator
};
Seam.hideLoadingMessage = function() {
// Write code here to hide the indicator
};
When a remote method is executed, the result is serialized into an XML response that is returned to the client. This response is then unmarshaled by the client into a JavaScript object. For complex types (i.e. Javabeans) that include references to other objects, all of these referenced objects are also serialized as part of the response. These objects may reference other objects, which may reference other objects, and so forth. If left unchecked, this object "graph" could potentially be enormous, depending on what relationships exist between your objects. And as a side issue (besides the potential verbosity of the response), you might also wish to prevent sensitive information from being exposed to the client.
Seam Remoting provides a simple means to "constrain" the object graph, by specifying the
exclude
field of the remote method's @WebRemote
annotation. This field
accepts a String array containing one or more paths specified using dot notation. When invoking a remote method,
the objects in the result's object graph that match these paths are excluded from the serialized result packet.
For all our examples, we'll use the following Widget
class:
public class Widget
{
private String value;
private String secret;
private Widget child;
private Map<String,Widget> widgetMap;
private List<Widget> widgetList;
// getters and setters for all fields
}
If your remote method returns an instance of Widget
, but you don't want to expose the
secret
field because it contains sensitive information, you would constrain it like this:
@WebRemote(exclude = {"secret"})
public Widget getWidget();
The value "secret" refers to the secret
field of the returned object. Now, suppose that
we don't care about exposing this particular field to the client. Instead, notice that the
Widget
value that is returned has a field child
that is also a
Widget
. What if we want to hide the child
's secret
value instead? We can do this by using dot notation to specify this field's path within the result's object
graph:
@WebRemote(exclude = {"child.secret"})
public Widget getWidget();
The other place that objects can exist within an object graph are within a Map
or some
kind of collection (List
, Set
, Array
, etc). Collections
are easy, and are treated like any other field. For example, if our Widget
contained a list
of other Widget
s in its widgetList
field, to constrain the
secret
field of the Widget
s in this list the annotation would look like
this:
@WebRemote(exclude = {"widgetList.secret"})
public Widget getWidget();
To constrain a Map
's key or value, the notation is slightly different. Appending
[key]
after the Map
's field name will constrain the
Map
's key object values, while [value]
will constrain the value object
values. The following example demonstrates how the values of the widgetMap
field have their
secret
field constrained:
@WebRemote(exclude = {"widgetMap[value].secret"})
public Widget getWidget();
There is one last notation that can be used to constrain the fields of a type of object no matter where in the result's object graph it appears. This notation uses either the name of the bean (if the object is a named bean) or the fully qualified class name (only if the object is not a named bean) and is expressed using square brackets:
@WebRemote(exclude = {"[widget].secret"})
public Widget getWidget();
The Model API builds on top of Seam Remoting's object serialization features to provide a component-based approach to working with a server-side object model, as opposed to the RPC-based approach provided by the standard Remoting API. This allows a client-side representation of a server-side object graph to be modified ad hoc by the client, after which the changes made to the objects in the graph can be applied to the corresponding server-side objects. When applying the changes the client determines exactly which objects have been modified by recursively walking the client-side object tree and generating a delta by comparing the original property values of the objects with their new property values.
This approach, when used in conjunction with the extended persistence context provided by Seam elegantly solves a number of problems faced by AJAX developers when working remotely with persistent objects. A persistent, managed object graph can be loaded at the start of a new conversation, and then across multiple requests the client can fetch the objects, make incremental changes to them and apply those changes to the same managed objects after which the transaction can be committed, thereby persisting the changes made.
One other useful feature of the Model API is its ability to expand a model.
For example, if you are working with entities with lazy-loaded associations it is usually not a good idea
to blindly fetch the associated objects (which may in turn themselves contain associations
to other entities, ad nauseum), as you may inadvertently end up fetching the bulk of your database.
Seam Remoting already knows how to deal with lazy-loaded associations by automatically excluding
them when marshalling instances of entity beans, and assigning them a client-side value of
undefined
(which is a special JavaScript value, distinct from null
).
The Model API goes one step further by giving the client the option of manipulating the associated objects
also. By providing an expand operation, it allows for the initialization of a
previously-uninitialized object property (such as a lazy-loaded collection), by dynamically "grafting"
the initialized value onto the object graph. By expanding the model in this way,
we have at our disposal a powerful tool for building dynamic client interfaces.
For the methods of the Model API that accept action parameters, an instance of
Seam.Action
should be used. The constructor for
Seam.Action
takes no parameters:
var action = new Seam.Action();
The following table lists the methods used to define the action. Each of the following methods
return a reference to the Seam.Action
object, so methods can be chained.
Table 58.1. Seam.Action method reference
Method |
Description |
---|---|
|
Sets the class name of the bean to be invoked.
|
|
Sets the qualifiers for the bean to be invoked.
|
|
Sets the name of the bean method.
|
|
Adds a parameter value for the action method. This method should be called once for each parameter value to be added, in the correct parameter order.
|
The following table describes the methods provided by the Seam.Model
object. To work with
the Model API in JavaScript you must first create a new Model object:
var model = new Seam.Model();
Table 58.2. Seam.Model method reference
Method |
Description |
---|---|
|
Adds a bean value to the model. When the model is fetched, the value of the specified bean
will be read and placed into the model, where it may be accessed by using the
Can only be used before the model is fetched.
|
|
Adds a bean property value to the model. When the model is fetched, the value of the specified
property on the specified bean will be read and placed into the model, where it may be accessed
by using the Can only be used before the model is fetched. Example: addBeanProperty("account", "AccountAction", "account", "@Qualifier1", "@Qualifier2");
|
|
Fetches the model - this operation causes an asynchronous request to be sent to the server.
The request contains a list of the beans and bean properties (set by calling the
A model should only be fetched once.
|
|
This method returns the value of the object with the specified alias.
|
|
Expands the model by initializing a property value that was previously uninitialized. This operation causes an asynchronous request to be sent to the server, where the uninitialized property value (such as a lazy-loaded collection within an entity bean association) is initialized and the resulting value is returned to the client. Once the response is received, the callback method (if specified) will be invoked, passing in a reference to the model as a parameter.
|
|
Applies the changes made to the objects contained in the model. This method causes an asynchronous request to be sent to the server containing a delta consisting of a list of the changes made to the client-side objects.
|
To fetch a model, one or more values must first be specified using addBean()
or
addBeanProperty()
before invoking the fetch()
operation.
Let's work through an example - here we have an entity bean called Customer
:
@Entity Customer implements Serializable {
private Integer customerId;
private String firstName;
private String lastName;
@Id @GeneratedValue public Integer getCustomerId() { return customerId; }
public void setCustomerId(Integer customerId) { this.customerId = customerId; }
public String getFirstName() { return firstName; }
public void setFirstName(String firstName) { this.firstName = firstName; }
public String getLastName() { return lastName; }
public void setLastName(String lastName) { this.lastName = lastName; }
}
We also have a bean called CustomerAction
, which is responsible for creating and editing
Customer
instances. Since we're only interested in editing a customer right now, the
following code only shows the editCustomer()
method:
@ConversationScoped @Named
public class CustomerAction {
@Inject Conversation conversation;
@PersistenceContext EntityManager entityManager;
public Customer customer;
public void editCustomer(Integer customerId) {
conversation.begin();
customer = entityManager.find(Customer.class, customerId);
}
public void saveCustomer() {
entityManager.merge(customer);
conversation.end();
}
}
In the client section of this example, we wish to make changes to an existing Customer
instance, so we need to use the editCustomer()
method of CustomerAction
to first load the customer entity, after which we can access it via the public customer
field. Our model object must therefore be configured to fetch the CustomerAction.customer
property, and to invoke the editCustomer()
method when the model is fetched. We start
by using the addBeanProperty()
method to add a bean property to the model:
var model = new Seam.Model();
model.addBeanProperty("customer", "CustomerAction", "customer");
The first parameter of addBeanProperty()
is the alias (in this case
customer
), which is used to access the value via the getValue()
method.
The addBeanProperty()
and addBean()
methods can be called multiple times
to bind multiple values to the model. An important thing to note is that the values may come from multiple
server-side beans, they aren't all required to come from the same bean.
We also specify the action that we wish to invoke (i.e. the editCustomer()
method).
In this example we know the value of the customerId
that we wish to edit, so we can
specify this value as an action method parameter:
var action = new Seam.Action()
.setBeanType("CustomerAction")
.setMethod("editCustomer")
.addParam(123);
Once we've specified the bean properties we wish to fetch and the action to invoke, we can then fetch the
model. We pass in a reference to the action object as the first parameter of the fetch()
method. Also, since this is an asynchronous request we need to provide a callback method to deal with the
response. The callback method is passed a reference to the model object as a parameter.
var callback = function(model) { alert("Fetched customer: " model.getValue("customer").firstName +
" " + model.getValue("customer").lastName); };
model.fetch(action, callback);
When the server receives a model fetch request, it first invokes the action (if one is specified) before reading the requested property values and returning them to the client.
Alternatively, if you don't wish to fetch a bean property but rather a bean itself
(such as a value created by a producer method) then the addBean()
method is used instead.
Let's say we have a producer method that returns a qualified UserSettings
value:
@Produces @ConversationScoped @Settings UserSettings getUserSettings() {
/* snip code */
}
We would add this value to our model with the following code:
model.addBean("settings", "UserSettings", "@Settings");
The first parameter is the local alias for the value, the second parameter is the fully qualified class of the bean, and the third (and subsequent) parameter/s are optional bean qualifiers.
Once a model has been fetched its values may be read using the getValue()
method.
Continuing on with the previous example, we would retrieve the Customer
object via
it's local alias (customer
) like this:
var customer = model.getValue("customer");
We are then free to read or modify the properties of the value (or any of the other values within its object graph).
alert("Customer name is: " + customer.firstName + " " + customer.lastName);
customer.setLastName("Jones"); // was Smith, but Peggy got married on the weekend
We can use the Model API's ability to expand a model to load uninitialized branches of the objects in
the model's object graph. To understand how this works exactly, let's flesh out our example a little
more by adding an Address
entity class, and creating a one-to-many relationship
between Customer
and Address
.
@Entity Address implements Serializable {
private Integer addressId;
private Customer customer;
private String unitNumber;
private String streetNumber;
private String streetName;
private String suburb;
private String zip;
private String state;
private String country;
@Id @GeneratedValue public Integer getAddressId() { return addressId; }
public void setAddressId(Integer addressId) { this.addressId = addressId; }
@ManyToOne public Customer getCustomer() { return customer; }
public void setCustomer(Customer customer) { this.customer = customer; }
/* Snipped other getter/setter methods */
}
Here's the new field and methods that we also need to add to the Customer
class:
private Collection<Address> addresses;
@OneToMany(fetch = FetchType.LAZY, mappedBy = "customer", cascade = CascadeType.ALL)
public Collection<Address> getAddresses() { return addresses; }
public void setAddresses(Collection<Address> addresses) { this.addresses = addresses; }
As we can see, the @OneToMany
annotation on the getAddresses()
method specifies a fetch
attribute of LAZY
, meaning that by
default the customer's addresses won't be loaded automatically when the customer is. When reading the
uninitialized addresses
property value from a newly-fetched
Customer
object in JavaScript, a value of undefined
will be returned.
getValue("customer").addresses == undefined; // returns true
We can expand the model by making a special request to initialize this uninitialized
property value. The expand()
operation takes three parameters - the value containing
the property to be initialized, the name of the property and an optional callback method. The following
example shows us how the customer's addresses
property can be initialized:
model.expand(model.getValue("customer"), "addresses");
The expand()
operation makes an asynchronous request to the server, where the
property value is initialized and the value returned to the client. When the client receives the
response, it reads the initialized value and appends it to the model.
// The addresses property now contains an array of address objects
alert(model.getValue("customer").addresses.length + " addresses loaded");
Once you have finished making changes to the values in the model, you can apply them with the
applyUpdates()
method. This method scans all of the objects in the model, compares
them with their original values and generates a delta which may contain one or more changesets to
send to the server. A changeset is simply a list of property value changes for a single object.
Like the fetch()
command you can also specify an action to invoke when applying updates,
although the action is invoked after the model updates have been applied. In a
typical situation the invoked action would do things like commit a database transaction, end the current
conversation, etc.
Since the applyUpdates()
method sends an asynchronous request like the
fetch()
and expand()
methods, we also need to specify a callback
function if we wish to do something when the operation completes.
var action = new Seam.Action();
.setBeanType("CustomerAction")
.setMethod("saveCustomer");
var callback = function() { alert("Customer saved."); };
model.applyUpdates(action, callback);
The applyUpdates()
method performs a refresh of the model, retrieving the latest
state of the objects contained in the model after all updates have been applied and the action method
(if specified) invoked.
Seam Remoting provides integrated support for JSR-303 Bean Validation, which defines a standard approach for validating Java Beans no matter where they are used; web tier or persistence tier, server or client. Bean validation for remoting delivers JSR-303's vision by making all of the validation constraints declared by the server-side beans available on the client side, and allows developers to perform client-side bean validation in an easy to use, consistent fashion.
Client-side validation by its very nature is an asynchronous operation, as it is possible that the client may encounter a custom validation constraint for which it has no knowledge of the corresponding validation logic. Under these circumstances, the client will make a request to the server for the validation to be performed server-side, after which it receives the result will forward it to the client-side callback method. All built-in validation types defined by the JSR-303 specification are executed client-side without requiring a round-trip to the server. It is also possible to provide the client-side validation API with custom JavaScript to allow client-side execution of custom validations.
The Seam.validateBean()
method may be used to validate a single object. It accepts
the following parameter values:
Seam.validateBean(bean, callback, groups);
The bean
parameter is the object to validate.
The callback
parameter should contain a reference to the callback method to
invoke once validation is complete.
The groups
parameter is optional, however may be specified if only certain validation groups
should be validated. The groups
parameter may be a String
or an array
of String
values for when multiple groups are to be validated.
Here's an example showing how a bean called customer
is validated:
function test() { var customer = Seam.createBean("com.acme.model.Customer"); customer.setFirstName("John"); customer.setLastName("Smith"); Seam.validateBean(customer, validationCallback); } function validationCallback(violations) { if (violations.length == 0) alert("All validations passed!"); }
By default, when Seam Remoting performs validation for a single bean it will traverse the entire object graph for that bean and validate each unique object that it finds. If you don't wish to validate the entire object graph, then please refer to the section on validating multiple objects later in this chapter for an alternative.
Sometimes it might not be desirable to perform validation for all properties of a bean. For example, you might
have a dynamic form which displays validation errors as the user tabs between fields. In this situation, you may use
the Seam.validateProperty()
method to validate a single bean property.
Seam.validateProperty(bean, property, callback, groups)
The bean
parameter is the object containing the property that is to be validated.
The property
parameter is the name of the property to validate.
The callback
parameter is a reference to the callback function to invoke once the property has
been validated.
The groups
parameter is optional, however may be specified if validating the property against
a certain validation group. The groups
parameter may be a String
or an array
of String
values for multiple groups.
Here's an example showing how to validate the firstName
property of a bean called
customer
:
function test() { var customer = Seam.createBean("com.acme.model.Customer"); customer.setFirstName("John"); Seam.validateProperty(customer, "firstName", validationCallback); } function validationCallback(violations) { if (violations.length == 0) alert("All validations passed!"); }
It is also possible to perform multiple validations for beans and bean properties in one go. This might be useful
for example to perform validation of forms that present data from more than one bean.
The Seam.validate()
method takes the following parameters:
Seam.validate(validations, callback, groups);
The validations
parameter should contain a list of the validations to perform. It may either
be an associative array (for a single validation), or an array of associative arrays (for multiple validations)
which define the validations that should be performed. We'll look at this parameter more closely in just a moment.
The callback
parameter should contain a reference to the callback function to invoke once
validation is complete. The optional groups
parameter should contain the group name/s
for which to perform validation.
The groups
parameter allows one or more validation groups (specified by providing a
String
or array of String
values) to be validated. The validation groups
specified here will be applied to all bean values contained in the validations
parameter.
The simplest example, in which we wish to validate a single object would look like this:
Seam.validate({bean:customer}, callback);
In the above example, validation will be performed for the customer
object, after which
the function named validationCallback
will be invoked.
Validate multiple beans is done by passing in an array of validations:
Seam.validate([{bean:customer}, {bean:order}], callback);
Single properties can be validated by specifying a property
name:
Seam.validate({bean:customer, property: "firstName"}, callback);
To prevent the entire object graph from being validated, the traverse
property may be set to false
:
Seam.validate({bean:customer, traverse: false}, callback);
Validation groups may also be set for each individual validation, by setting the groups
property to a
String
or array of String
s value:
Seam.validate({bean:customer, groups: "default"}, callback);
Validation group names should be the unqualified class name of the group class. For example, for the class
com.acme.InternalRegistration
, the client-side group name should be specified as
InternalRegistration
:
Seam.validateBean(user, callback, "InternalRegistration"
It is also possible to set the default validation groups against which all validations will be performed,
by setting the Seam.ValidationGroups
property:
Seam.ValidationGroups = ["Default", "ExternalRegistration"];
If no explicit group is set for the default, and no group is specified when performing validation, then the validation process will be executed against the 'Default' group.
If any validations fail during the validation process, then the callback method specified in the validation function will be invoked with an array of constraint violations. If all validations pass, this array will be empty. Each object in the array represents a single constraint violation, and contains the following property values:
bean
- the bean object for which the validation failed.
property
- the name of the property that failed validation
value
- the value of the property that failed validation
message
- a message string describing the nature of the validation failure
The callback method should contain business logic that will process the constraint violations and update the user interface accordingly to inform the user that validation has failed. The following minimalistic example demonstrates how the validation errors can be displayed to the user as popup alerts:
function validationCallback(violations) { for (var i = 0; i < violations.length; i++) { alert(violations[i].property + "=" + violations[i].value + " [violation] -> " + violations[i].message);
Table of Contents
Seam REST is a lightweight module that provides additional integration of technologies within the Java EE platform as well as third party technologies.
Seam REST is independent from CDI and JAX-RS implementations and thus fully portable between Java EE 6 environments.
The Seam REST module runs only on Java EE 6 compliant servers such as JBoss Application Server or GlassFish .
To use the Seam REST module, add
seam-rest
and
seam-rest-api
jars into the web application.
If using Maven, add the following
dependency
into the web application's
pom.xml
configuration file.
Example 60.1. Dependency added to pom.xml
<dependency>
<groupId>org.jboss.seam.rest</groupId>
<artifactId>seam-rest</artifactId>
<version>${seam.rest.version}</version>
</dependency>
Substitute the expression ${seam.rest.version} with the most recent or appropriate version of Seam REST. Alternatively, you can create a Maven user-defined property to satisfy this substitution so you can centrally manage the version.
Besides, Seam REST has several transitive dependencies (which are added automatically when using maven). Refer to Section 65.1, “Transitive Dependencies” for more details.
The Seam REST module registers
SeamExceptionMapper
to hook into the exception processing mechanism of JAX-RS and
TemplatingMessageBodyWriter
to provide templating support.
These components are registered by default if classpath scanning
of JAX-RS resources and providers is enabled (an empty
javax.ws.rs.core.Application
subclass is provided).
@ApplicationPath("/api/*")
public class MyApplication extends Application {}
Otherwise, if the Application's
getClasses()
method is overridden to select resources and providers explicitly
add
SeamExceptionMapper
and
TemplatingMessageBodyWriter
.
@ApplicationPath("/api/*")
public class MyApplication extends Application
{
@Override
public Set<Class<?>> getClasses()
{
Set<Class<?>> classes = new HashSet<Class<?>>();
...
...
...
classes.add(SeamExceptionMapper.class);
classes.add(TemplatingMessageBodyWriter.class);
return classes;
}
}
Seam REST can be used with plain Servlet containers such as Apache Tomcat 7. Firstly, we need to enhance the
Servlet container
capabilities. This is done by bundling Weld and RESTEasy within the application and configuring
them. See the
jaxrs-exceptions example and its tomcat
build profile for more details.
In a EE6-compliant environment, Seam REST would be bootstrapped by a Servlet listener. However,
weld-servlet
does not support CDI injection into Servlet listeners. Therefore, add the following line to your application's
web.xml
file to bootstrap Seam REST using Servlet.
<servlet>
<display-name>Servlet REST Listener Startup</display-name>
<servlet-class>org.jboss.seam.rest.SeamRestStartupListener</servlet-class>
<load-on-startup>1</load-on-startup>
</servlet>
The JAX-RS specification defines the mechanism for exception mapping providers as the standard mechanism for Java exception handling. The Seam REST module comes with an alternative approach, which is more consistent with the CDI programming model. It is also easier to use and still remains portable.
The Seam REST module allows you to:
integrate with Solder exception handling framework and thus handle exceptions that occur in different parts of an application uniformly;
define exception handling rules declaratively with annotations or XML.
Solder exception handling framework handles exceptions within the Seam REST module: as result, an exception that occurs during an invocation of a JAX-RS service is routed through the Solder exception handling mechanism similar to the CDI event bus. This allows you to implement the exception handling logic in a loosely-coupled fashion.
The following code sample demonstrates a simple exception handler
that converts the
NoResultException
exception to a 404 HTTP response.
Example 61.1.
Solder Integration -
NoResultException
handler
@HandlesExceptions
public class ExceptionHandler
{
@Inject @RestResourceResponseBuilder builder
public void handleException(@Handles @RestRequest CaughtException<NoResultException> event)
{
builder.status(404).entity("The requested resource does not exist.");
}
}
The
| |
The
| |
A method for handling
|
Similarly to the CDI event bus, exceptions handled by a handler
method can be filtered by qualifiers. The example
above treats
only exceptions that occur in a JAX-RS service
invocation (as opposed to all exceptions of the given type
that
occur in the application, for example in the view layer). Thus, the
@RestRequest
qualifier is used to enable the handler only for exceptions that occur
during JAX-RS service invocation.
For more information on Solder exception handling, refer to Solder reference documentation .
Exception-mapping rules are often fairly simple. Thus, instead of being implemented programmatically, they can be expressed declaratively through metadata such as Java annotations or XML. The Seam REST module supports both ways of declarative configurations.
For each exception type, you can specify a status code and an error message of the HTTP response.
You can configure Seam REST exception mapping directly in your Java code
with Java Annotations.
An exception
mapping rule is defined as a
@ExceptionMapping
annotation. Use an
@ExceptionMapping.List
annotation to define multiple
exception mappings.
Example 61.2. Annotation-based exception mapping configuration
@ExceptionMapping.List({
@ExceptionMapping(exceptionType = NoResultException.class, status = 404, message = "Requested resource does not exist."),
@ExceptionMapping(exceptionType = IllegalArgumentException.class, status = 400, message = "Illegal argument value.")
})
@ApplicationPath("/api")
public MyApplication extends Application {
The
@ExceptionMapping
annotation can be applied on any Java class in the deployment.
However, it
is recommended to keep all exception
mapping
declarations in the same place, for example, in the
javax.ws.rs.core.Application
subclass.
Table 61.1.
@ExceptionMapping
properties
Name | Required | Default value | Description |
---|---|---|---|
exceptionType
| true | - | Fully-qualified class name of the exception class |
status
| true | - | HTTP status code |
message
| false | - | Error message sent within the HTTP response |
useExceptionMessage
| false | false | Exception error message |
interpolateMessageBody
| false | true | Enabling/disabling the EL interpolation of the error message |
useJaxb
| false | true | Enabling/disabling wrapping of the error message within a JAXB object. This allows
marshalling to various media formats such as application/xml , application/json , etc. |
As an alternative to the annotation-based configuration, you can use the configuration facilities provided by Solder to configure the
SeamRestConfiguration
class in XML.
For more information on how to use Solder for configuring beans, refer to the
Solder reference documentation
.
Once you have added the Seam XML module, specify the configuration in the
seam-beans.xml
file, located in the
WEB-INF
folder of the web archive.
Example 61.3. Exception mapping configuration in seam-beans.xml
<rest:SeamRestConfiguration>
<rest:mappings>
<s:value>
<rest:Mapping exceptionType="javax.persistence.NoResultException" statusCode="404">
<rest:message>Requested resource does not exist.</rest:message>
</rest:Mapping>
</s:value>
<s:value>
<rest:Mapping exceptionType="java.lang.IllegalArgumentException" statusCode="400">
<rest:message>Illegal value.</rest:message>
</rest:Mapping>
</s:value>
</rest:mappings>
</rest:SeamRestConfiguration>
Furthermore, you can use EL expressions in message templates to provide dynamic and more descriptive error messages.
Example 61.4. Exception mapping configuration in seam-beans.xml
<rest:Mapping exceptionType="javax.persistence.NoResultException" statusCode="404">
<rest:message>Requested resource (#{uriInfo.path}) does not exist.</rest:message>
</rest:Mapping>
When an exception occurs at runtime, the
SeamExceptionMapper
first looks for a matching exception mapping rule.
If it finds one, it creates an HTTP response with the
specified
status
code and error message.
The error message is marshalled within a JAXB object and is thus available in multiple media formats. The most commonly used formats are XML and JSON. Most JAX-RS implementations provide media providers for both of these formats. In addition, the error message is also available in plain text.
Example 61.5. Sample HTTP response
HTTP/1.1 404 Not Found
Content-Type: application/xml
Content-Length: 123
<?xml version="1.0" encoding="UTF-8" standalone="yes"?>
<error>
<message>Requested resource does not exist.</message>
</error>
Bean Validation (JSR-303) is a specification introduced as a part of Java EE 6. It aims to provide a standardized way of validating the domain model across all application layers.
The Seam REST module follows the Bean Validation specification and the incoming HTTP requests can be validated with this standardized mechanism.
Firstly, enable the
ValidationInterceptor
in the
beans.xml
configuration
file.
<interceptors>
<class>org.jboss.seam.rest.validation.ValidationInterceptor</class>
</interceptors>
Then, enable validation of a particular method by decorating
it with
the
@ValidateRequest
annotation.
@PUT
@ValidateRequest
public void updateTask(Task incommingTask)
{
...
}
Now, the HTTP request's entity body (the
incomingTask
parameter) will be validated prior to invoking the method.
By default, the entity parameter (the parameter with no annotations
that represent the body of the HTTP request)
is
validated. If the
object is valid, the web service method is
executed.
Otherwise, a
ValidationException
exception
is thrown.
The
ValidationException
exception
is a simple carrier of constraint violations found by the
Bean
Validation provider. The exception can be
handled by an
ExceptionMapper
or Solder exception handler.
Seam REST comes with a built-in
ValidationException
handler,
which is registered by default. The exception handler converts the
ValidationException
to an HTTP response with the 400 (Bad request) status code. Furthermore,
it sends messages relevant to the
violated constraints within the
message body of the HTTP response.
Example 62.1. HTTP response
HTTP/1.1 400 Bad Request
Content-Type: application/xml
Content-Length: 129
<?xml version="1.0" encoding="UTF-8" standalone="yes"?>
<error>
<messages>
<message>Name length must be between 1 and 100.</message>
</messages>
</error>
Besides the message body, the JAX-RS specification allows various parts of the HTTP request to be injected into the JAX-RS resource or passed as method parameters. These parameters are usually HTTP form parameters, query parameters, path parameters, headers, etc.
Example 62.2. JAX-RS resource
public class PersonResource
{
@QueryParam("search")
@Size(min = 1, max = 30)
private String query;
@QueryParam("start")
@DefaultValue("0")
@Min(0)
private int start;
@QueryParam("limit")
@DefaultValue("20")
@Min(0) @Max(50)
private int limit;
...
If a method of a resource is annotated with an
@ValidateRequest
annotation, the fields
of a resource are validated by default.
Since the JAX-RS injection occurs only at resource creation time,
do
not use the
JAX-RS field injection for
other than
@RequestScoped
resources.
The JAX-RS specification allows path parameters, query parameters, matrix parameters, cookie parameters and headers to be passed as parameters of a resource method.
Example 62.3. JAX-RS method parameters
@GET
public List<Person>search(@QueryParam("search") String query,
@QueryParam("start") @DefaultValue("0") int start,
@QueryParam("limit") @DefaultValue("20") int limit)
Currently, Seam REST validates only JavaBean parameters (as opposed to primitive types, Strings and so on). Therefore, to validate these types of parameters, either use resource field validation described in Section 62.1.2, “Validating resource fields” or read further and use parameter objects.
In order to prevent an oversized method
signature when the number of
parameters is too large, JAX-RS
implementations provide
implementations of the
Parameter Object pattern
. These objects aggregate multiple parameters into a single
object, for example
RESTEasy Form Object
or
Apache CXF Parameter Bean
.
These parameters can be validated by Seam REST. To trigger the validation, annotate the parameter with a
javax.validation.Valid
annotation.
Example 62.4. RESTEasy parameter object
public class MyForm {
@FormParam("stuff")
@Size(min = 1, max = 30)
private int stuff;
@HeaderParam("myHeader")
private String header;
@PathParam("foo")
public void setFoo(String foo) {...}
}
@POST
@Path("/myservice")
@ValidateRequest
public void post(@Valid @Form MyForm form) {...}
Table 62.1.
@ValidateRequest
annotation properties
@ValidateRequest
attribute
| Description | Default value |
---|---|---|
validateMessageBody
| Enabling/disabling validation of message body parameters | true |
validateResourceFields
| Enabling/disabling validation of fields of a JAX-RS resource | true |
groups
| Validation groups to be used for validation | javax.validation.groups.Default |
In some cases, it is desired to have a specific group of constraints used for validation of web service parameters. These constraints are usually weaker than the default constraints of a domain model. Take partial updates as an example.
Consider the following example:
Example 62.5. Employee.java
public class Employee {
@NotNull
@Size(min = 2, max = 30)
private String name;
@NotNull
private String email;
@NotNull
private Department department;
// getters and setters
}
The Employee resource in the example above is not allowed to have the null value specified in any of its fields. Thus, the entire representation of a resource (including the department and related object graph) must be sent to update the resource.
When using partial updates, only values of modified fields
are required to be
sent within the update request, while
the non-null
values of the
received object are updated. Therefore, two groups of
constraints are
needed: group for
partial updates
(including
@Size
and
@Email
, excluding @NotNull
) and the
default group
(@NotNull).
A validation group is a simple Java interface:
Example 62.7. Employee.java
@GroupSequence({ Default.class, PartialUpdateGroup.class })
public class Employee {@NotNull
@Size(min = 2, max = 30, groups = PartialUpdateGroup.class)
private String name;
@NotNull
@Email(groups = PartialUpdateGroup.class)
private String email;
@NotNull
private Department department;
// getters and setters
}
The
| |
The
| |
The
|
Finally, the
ValidationInterceptor
is configured to validate the
PartialUpdateGroup
group
only.
Example 62.8.
EmployeeResource.java
@Path("/{id}")
@PUT
@Consumes("application/xml")@ValidateRequest(groups = PartialUpdateGroup.class)
public void updateEmployee(Employee e, @PathParam("id") long id)
{
Employee employee = em.find(Employee.class, id);if (e.getName() != null)
{
employee.setName(e.getName());
}
if (e.getEmail() != null)
{
employee.setEmail(e.getEmail());
}
}
The partial update validation group is used for web service parameter validation. | |
Partial update — only the not-null fields of the transferred representation are used for update. The null fields are not updated. |
Seam REST allows to create HTTP responses based on the defined templates. Instead of being bound to a particular templating engine, Seam REST comes with a support for multiple templating engines and support for others can be plugged in.
REST-based web services are often expected to return multiple representations of a resource. The templating support is useful for producing media formats such as XHTML and it can be also used instead of JAXB to produce domain-specific XML representations of a resource. Besides, almost any other representation of a resource can be described in a template.
To enable templating for a particular method, decorate the method with the
@ResponseTemplate
annotation. Path to a template file to be used for rendering is required.
Example 63.1.
@ResponseTemplate
in action
@ResponseTemplate("/freemarker/task.ftl")
public Task getTask(@PathParam("taskId") long taskId) {
...
}
The
@ResponseTemplate
annotation offers several other options. For example, it is possible for a method
to offer multiple representations
of a resource, each rendered with a different template.
In the example below, the
produces
member of the
@ResponseTemplate
annotation is used
to distinguish between produced media types.
Example 63.2.
Multiple
@ResponseTemplate
s
@GET
@Produces( { "application/json", "application/categories+xml", "application/categories-short+xml" })
@ResponseTemplate.List({
@ResponseTemplate(value = "/freemarker/categories.ftl", produces = "application/categories+xml"),
@ResponseTemplate(value = "/freemarker/categories-short.ftl", produces = "application/categories-short+xml")
})
public List<Category> getCategories()
Table 63.1.
@ResponseTemplate
options
Name | Required | Default value | Description |
---|---|---|---|
value
| true | - |
Path to the template (for example
/freemarker/categories.ftl
)
|
produces
| false | */* | Restriction of media type produced by the template (useful in situations when a method produces multiple media types, with different templates) |
responseName
| false | response | Name under which the object returned by the JAX-RS method is available in the template (for example, Hello ${response.name}) |
There are several ways of accessing the domain data within a template.
Firstly, the object returned by the JAX-RS method is available under the "response" name by default.
The object
can be made available under a different name using the
responseName
member of the
@ResponseTemplate
annotation.
Secondly, every bean reachable via an EL expression is available within a template.
Example 63.4. Using EL names in a template
#foreach(${student} in ${university.students})
<student>${student.name}</student>
#end
Note that the syntax of the expression depends on the particular
templating engine and mostly differs from
the syntax of EL expressions. For example,
${university.students}
must be used instead of
#{university.students}
in a FreeMarker template.
Last but not least, the model can be populated programmatically. In order to do that, inject the
TemplatingModel
bean and put the desired objects into the underlying
data
map. In the following example, the list of professors is available under the "professors" name.
Example 63.5. Defining model programmatically
@Inject
private TemplatingModel model;
@GET
@ResponseTemplate("/freemarker/university.ftl")
public University getUniversity()
{
// load university and professors
University university = ...
List<Professor> professors = ...
model.getData().put("professors", professors);
return university;
}
When using JAXB-annotated classes as a return type for JAX-RS methods, you may see the
following RESTEasy message:
“Could not find JAXBContextFinder for media type: text/html”
. This is caused by the built-in JAXB
provider being too eager. You can prevent the built-in JAXB provider from being used for a method by adding the
@DoNotUseJAXBProvider
annotation on the method.
Seam REST currently comes with built-in templating providers for FreeMarker and Apache Velocity.
FreeMarker is one of the most popular templating engines. To enable Seam REST FreeMarker support, bundle the FreeMarker jar with the web application.
For more information on writing FreeMarker templates, refer to the FreeMarker Manual .
Apache Velocity is another popular Java-based templating engine. Similarly to FreeMarker support, Velocity support is enabled automatically if Velocity libraries are detected on the classpath.
For more information on writing Velocity templates, refer to the Apache Velocity User Guide
All that needs to be done to extend the set of supported templating engines is to implement
the
TemplatingProvider
interface. Refer to
Javadoc
for hints.
In certain deployment scenarios it is not possible to control the classpath completely and multiple template engines may be available at the same time. If that happens, Seam REST fails to operate with the following message:
Multiple TemplatingProviders found on classpath. Select the preferred one.
In such case, define the preferred templating engine in the XML
configuration as demonstrated below to resolve
the TemplatingProvider
ambiguity.
Example 63.6. Preferred provider
<beans xmlns:rest="urn:java:org.jboss.seam.rest:org.jboss.seam.rest.exceptions">
<rest:SeamRestConfiguration preferedTemplatingProvider="org.jboss.seam.rest.templating.freemarker.FreeMarkerProvider">
</beans>
Table 63.2. Built-in templating providers
Name | FQCN |
---|---|
FreeMarker | org.jboss.seam.rest.templating.freemarker.FreeMarkerProvider |
Apache Velocity | org.jboss.seam.rest.templating.velocity.VelocityProvider |
The RESTEasy Client Framework is a framework for writing clients for REST-based web services. It reuses JAX-RS metadata for creating HTTP requests. For more information about the framework, refer to the project documentation .
Integration with the RESTEasy Client Framework is optional in Seam REST and only available when RESTEasy is available on classpath.
Although RESTEasy is part of JBoss AS 7, not all of the required dependencies are exposed to the application
classpath automatically. To enable RESTEasy Client Framework on JBoss AS 7, add the following line to
META-INF/MANIFEST.MF
Dependencies: org.apache.httpcomponents
Let us assume as an example that a remote server exposes a web service for providing task details to the client
through the
TaskService
interface below.
Example 64.1. Sample JAX-RS annotated interface
@Path("/task")
@Produces("application/xml")
public interface TaskService
{
@GET
@Path("/{id}")
Task getTask(@PathParam("id")long id);
}
To access the remote web service, Seam REST builds and injects a client object of the web service.
Example 64.2. Injecting REST Client
@Inject @RestClient("http://example.com")
private TaskService taskService;
...
Task task = taskService.getTask(1);
The Seam REST module injects a
proxied
TaskService
interface and the RESTEasy Client
Framework converts every method invocation on the
TaskService
to an
HTTP request and sends it over the wire to
http://example.com
. The
HTTP response is unmarshalled automatically and the response object
is returned by the method call.
URI definition supports EL expressions.
@Inject @RestClient("#{example.service.uri}")
Besides proxying JAX-RS interfaces, the RESTEasy Client Framework provides the ClientRequest API for manual building of HTTP requests. For more information on the ClientRequest API, refer to the project documentation .
Example 64.3. Injecting ClientRequest
@Inject @RestClient("http://localhost:8080/test/ping")
private ClientRequest request;
...
request.accept(MediaType.TEXT_PLAIN_TYPE);
ClientResponse<String> response = request.get(String.class);
If not specified otherwise, every request is executed by the default Apache HTTP Client 4 configuration.
Provide an alternative ClientExecutor
implementation to change this.
Example 64.4. Custom Apache HTTP Client 4 configuration
@Produces
public ClientExecutor createExecutor()
{
HttpParams params = new BasicHttpParams();
ConnManagerParams.setMaxTotalConnections(params, 3);
ConnManagerParams.setTimeout(params, 1000);
SchemeRegistry schemeRegistry = new SchemeRegistry();
schemeRegistry.register(new Scheme("http", PlainSocketFactory.getSocketFactory(), 80));
ClientConnectionManager cm = new ThreadSafeClientConnManager(params, schemeRegistry);
HttpClient httpClient = new DefaultHttpClient(cm, params);
return new ApacheHttpClient4Executor(httpClient);
}
The Seam REST module depends on the Seam Solder module.
FreeMarker can be used for rendering HTTP responses. For more information on using FreeMarker with Seam REST, refer to Section 63.2.1, “FreeMarker”
<dependency>
<groupId>org.freemarker</groupId>
<artifactId>freemarker</artifactId>
<version>${freemarker.version}</version>
</dependency>
Apache Velocity can be used for rendering HTTP responses. For more information on using Velocity with Seam REST, refer to Section 63.2.2, “Apache Velocity”
<dependency>
<groupId>org.apache.velocity</groupId>
<artifactId>velocity</artifactId>
<version>${velocity.version}</version>
</dependency>
<dependency>
<groupId>org.apache.velocity</groupId>
<artifactId>velocity-tools</artifactId>
<version>${velocity.tools.version}</version>
</dependency>
RESTEasy Client Framework can be used for building clients of RESTful web services. For more information on using RESTEasy Client Framework, refer to Chapter 64, RESTEasy Client Framework Integration
<dependency>
<groupId>org.jboss.resteasy</groupId>
<artifactId>resteasy-jaxrs</artifactId>
<version>${resteasy.version}</version>
</dependency>
Note that RESTEasy is provided on JBoss Application Server 6 and 7 and thus you do not need to bundle it with the web application.
Table of Contents
The Seam JCR Module aims to simplify the integration points between JCR implementations and CDI applications.
The Seam JCR module is compatible with JCR 2.0 implementations. It strictly compiles against JCR 2.0. However, test cases are executed against both ModeShape and JackRabbit to ensure compatibility.
If you are using Maven as your build tool, you can add the following single dependency to your pom.xml file to include Seam JCR:
<dependency>
<groupId>org.jboss.seam.jcr</groupId>
<artifactId>seam-jcr</artifactId>
<version>${seam.jcr.version}</version>
</dependency>
Substitute the expression ${seam.jcr.version} with the most recent or appropriate version of Seam JCR. Alternatively, you can create a Maven user-defined property to satisfy this substitution so you can centrally manage the version.
Alternatively, you can use the API at compile time and only include the implementation at runtime. This protects you from inadvertantly depending on an implementation class.
<dependency>
<groupId>org.jboss.seam.jcr</groupId>
<artifactId>seam-jcr-api</artifactId>
<version>${seam.jcr.version}</version>
<scope>compile</scope>
</dependency>
<dependency>
<groupId>org.jboss.seam.jcr</groupId>
<artifactId>seam-jcr</artifactId>
<version>${seam.jcr.version}</version>
<scope>runtime</scope>
</dependency>
In addition to your Seam JCR dependencies, you must also declare a dependency on a JCR Implementation.
In order to activate ModeShape support within your application, you need to include ModeShape on your classpath. At a minimum, the following maven dependencies must be satisfied.
<dependency>
<groupId>org.modeshape</groupId>
<artifactId>modeshape-jcr</artifactId>
<version>${modeshape.version}</version>
</dependency>
<dependency>
<groupId>org.apache.lucene</groupId>
<artifactId>lucene-core</artifactId>
<version>${lucene.version}</version>
</dependency>
Substitute ${modeshape.version} for the ModeShape version you are running against. Currently, Seam JCR tests against 2.5.0.Final. In addition, Lucene is required to run ModeShape. Please consult the ModeShape Getting Started Guide for exact versions.
In order to use ModeShape's Repository and Session objects in your application, you must define an injection point using the JcrConfiguration annotation based on ModeShape's required configuration parameters. Please review the ModeShape Getting Started Guide for further details.
@Inject @JcrConfiguration(name="org.modeshape.jcr.URL",value="file:path/to/modeshape.xml?repositoryName=MyRepo") Repository repository; @Inject @JcrConfiguration(name="org.modeshape.jcr.URL",value="file:path/to/modeshape.xml?repositoryName=MyRepo") Session session;
In order to activate JackRabbit support within your application, you need to include JackRabbit on your classpath. At a minimum, the following maven dependency must be satisfied.
<dependency>
<groupId>org.apache.jackrabbit</groupId>
<artifactId>jackrabbit-core</artifactId>
<version>${jackrabbit.version}</version>
</dependency>
Substitute ${jackrabbit.version} for the JackRabbit version you are running against. Currently, Seam JCR tests against 2.2.4. Please review the JackRabbit documentation to determine any additional dependencies.
In order to use JackRabbit's Repository and Session objects in your application, you must define an injection point using the JcrConfiguration
annotation based on JackRabbit's required configuration parameters.
@Inject @JcrConfiguration(name="org.apache.jackrabbit.repository.home",value="target") Repository repository; @Inject @JcrConfiguration(name="org.apache.jackrabbit.repository.home",value="target") Session session;
Seam JCR provides functionality to fire CDI Events based on events found in JCR. The rules of how events are fired are based around the underlying implementation.
To observe an event, use the @Observes
and the additional qualifiers from the
seam-jcr-api
module (Check package org.jboss.seam.jcr.annotations.events
).
If you need to watch any JCR event, then avoid using any qualifier at all.
import javax.jcr.observation.Event; public void observeAdded(@Observes @NodeAdded Event evt) { // Called when a node is added } public void observeAll(@Observes javax.jcr.observation.Event evt) { // Called when any node event occurs }
Object Content Mapping is a design paradigm, in the same light as ORM (Object Relational Mapping) frameworks such as JPA or Hibernate, where statically typed objects are bound to a storage mechanism, in this case a JCR store. Seam JCR OCM is provided as annotations only on top of entities that are discovered during the CDI Phase ProcessAnnotatedType. In addition, Seam JCR's OCM implementation provides ServiceHandlers for working with entities over JCR.
The mapping API is very simple and designed to be clean. In order to define an entity, you simply need to use the
annotation org.jboss.seam.jcr.annotations.ocm.JcrNode
to define that this is an entity to map. All fields
by default will be mapped to their field names. You can override this behavior by using the annotation org.jboss.seam.jcr.annotations.ocm.JcrProperty
which will map the property to a different property name. The JcrProperty
annotation can be placed on both field and getter method.
You can define a special property uuid
of type String that will represent the identifier for the node. This is a sample node mapping:
@JcrNode("nt:unstructured")
public class BasicNode implements java.io.Serializable {
@JcrProperty("myvalue")
private String value;
private String uuid;
private String lordy;
public String getValue() {
return value;
}
public void setValue(String value) {
this.value = value;
}
public String getUuid() {
return uuid;
}
public void setUuid(String uuid) {
this.uuid = uuid;
}
@JcrProperty("notaproperty")
public String getLordy() {
return lordy;
}
public void setLordy(String lordy) {
this.lordy = lordy;
}
}
The simplest way to convert entities is to use CDI Events. There are two event objects that can be fired to support
parsing, org.jboss.seam.jcr.ocm.ConvertToNode
and org.jboss.seam.jcr.ocm.ConvertToObject
.
By passing in a node and a pre-constructed object you can convert the full node to object or object to node depending on your
need. Here is a sample parsing (from our test cases):
@Inject Event<ConvertToObject< objectEvent;
@Inject Event<ConvertToNode< nodeEvent;
....
Node root = session.getRootNode();
Node ocmnode1 = root.addNode("ocmnode1","nt:unstructured");
BasicNode bn = new BasicNode();
bn.setValue("Hello, World!");
bn.setLordy("this was saved.");
nodeEvent.fire(new ConvertToNode(bn,ocmnode1));
Node hello2 = root.getNode("ocmnode1");
BasicNode bn2 = new BasicNode();
objectEvent.fire(new ConvertToObject(hello2,bn2));
If you have ever worked with entities, the term DAO should be very familiar to you. Seam JCR OCM supports DAOs in a highly automated fashion. Using annotations and interfaces only, you can automate querying, finds and saving entities into their mapped node types. There are four annotations to support DAOs:
org.jboss.seam.jcr.annotations.ocm.JcrDao
Defines this interface as a DAO interface. The ServiceHandler will be used to process these methods.
This annotation should be placed at the interface level.
org.jboss.seam.jcr.annotations.ocm.JcrFind
Defines this method as a find method, loading by identifier. The method should take a single String parameter
and return a mapped node type.
org.jboss.seam.jcr.annotations.ocm.JcrQuery
Defines this method as returning a java.util.List
of mapped entities that can be mapped using the query results.
Has properties defining the type to return, query to use, and the query language.
org.jboss.seam.jcr.annotations.ocm.JcrParam
JcrParams are placed on the parameter arguments to a method annotated JcrQuery. Each argument should be a Value object
and map based on bind parameters in the query.
Here is a sample definition of an interface, describing the objects that can be used:
import static org.jboss.seam.jcr.ConfigParams.MODESHAPE_URL;
import java.util.List;
import org.jboss.seam.jcr.annotations.JcrConfiguration;
import org.jboss.seam.jcr.annotations.ocm.JcrDao;
import org.jboss.seam.jcr.annotations.ocm.JcrFind;
import org.jboss.seam.jcr.annotations.ocm.JcrQuery;
import org.jboss.seam.jcr.annotations.ocm.JcrSave;
import org.jboss.seam.jcr.test.ocm.BasicNode;
@JcrDao(
@JcrConfiguration(name = MODESHAPE_URL,
value = "file:target/test-classes/modeshape.xml?repositoryName=CarRepo")
)
public interface BasicNodeDAO {
@JcrFind
public BasicNode findBasicNode(String uuid);
@JcrQuery(query="select * from [nt:unstructured]",language="JCR-SQL2",resultClass=BasicNode.class)
public List<BasicNode> findAllNodes();
@JcrSave
public String save(String path, BasicNode basicNode);
}
In this case, we are telling the JcrDao BasicNodeDAO to use the JCR Session based on the annotated JcrConfiguration noted. Since BasicNode is mapped to nt:unstructured, we can map any nt:unstructured to it by calling findAllNodes. We can save a basic node to a given path as well as find based on uuid. The best part is that there is no implementation necessary on your side. You can use this interface as is.
@Inject
BasicNodeDAO basicDAO;
....
BasicNode bn = new BasicNode();
bn.setValue("this is my node.");
String uuid = basicDAO.save("/anypathone",bn);
System.out.println("The UUID is: "+uuid);
BasicNode bn2 = basicDAO.findBasicNode(uuid);
System.out.printf("The original node was %s and the new node is \n",bn.getValue(), bn2.getValue());
List<BasicNode> nodes = basicDAO.findAllNodes();
System.out.println(nodes);
Table of Contents
Seam extends the CDI programming model into the messaging world by allowing you to inject JMS resources into your beans. Furthermore, Seam bridges the CDI event bus over JMS; this gives you the benefits of CDI-style type-safety for inter-application communication.
The JMS module for Seam 3 is to provide injection of JMS resources and the necessary scaffolding for a bidirectional propagation of CDI event over JMS.
The general goals can be divided into two categories: injection of JMS resources and bridging of events:
JMS Resource Injection
ConnectionFactory
Connection
Session
Topics & Queues
Message Producer
Message Consumer
Event Bridge
Inbound: Routes CDI events to JMS destinations
Outbound: Fires CDI events based on the reception of JMS messages
Seam JMS can be used by including a few libraries in your application's library folder:
seam-jms-api.jar
seam-jms.jar
solder-api.jar
solder-impl.jar
solder-logging.jar
If you are using Maven as your build tool use the following dependency, which will bring in both API and Implementation for Seam JMS:
<dependency>
<groupId>org.jboss.seam.jms</groupId>
<artifactId>seam-jms</artifactId>
<version>${seam.jms.version}</version>
</dependency>
Define or replace the property ${seam.jms.version} with a valid version of Seam JMS.
The runtime of Seam JMS is defined in two sections. The first section is related to creating observers, which happens within the Seam JMS CDI Extension. Observers need to be defined prior to starting up the container, and cannot be created once the application is running. This part happens automatically. The second section is related to creating listeners. This is managed in the component org.jboss.seam.jms.bridge.RouteBuilder.
In order to start any listeners, you may need to inject an instance of the RouteBuilder in to your class.
If you are running within a Servlet Container, and include the Solder, RouteBuilder will automatically start up.
The default implementation expects to find a ConnectionFactory at the JNDI location /ConnectionFactory
. This
can be changed by using Solder Config by using a snippet similar to the one below in seam-beans.xml. This will
change the JNDI location Seam JMS looks to jms/ConnectionFactory
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://java.sun.com/xml/ns/javaee"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:s="urn:java:ee"
xmlns:jmsi="urn:java:org.jboss.seam.jms.inject"
xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://docs.jboss.org/cdi/beans_1_0.xsd">
<jmsi:JmsConnectionFactoryProducer>
<s:modifies />
<jmsi:connectionFactoryJNDILocation>jms/ConnectionFactory</jmsi:connectionFactoryJNDILocation>
</jmsi:JmsConnectionFactoryProducer>
</beans>
In this chapter we'll look at how to inject some of the common JMS resource types.
The following JMS resources are available for injection:
javax.jms.Connection
javax.jms.Session
Destination-based resources:
javax.jms.Topic
javax.jms.Queue
The qualifier @JmsDestination
is available to decorate JNDI oriented objects. This includes instances of javax.jms.Destination
as well as MessageConsumers and MessageProducers.
@Inject @JmsDestination(jndiName="jms/MyTopic") Topic t; @Inject @JmsDestination(jndiName="jms/MyQueue") Queue q;
The Seam JMS module has certain points of extension, where the application developer can customize the behavior to match their needs. This is done by extending any of three base classes:
org.jboss.seam.jms.inject.JmsConnectionFactoryProducer
org.jboss.seam.jms.inject.JmsConnectionProducer
org.jboss.seam.jms.inject.JmsSessionProducer
This can be done using CDI specializations and extending the base class to change the produced object.
This allows the application developer to customize the produced behavior.
For example, the base implementation assumes a Java EE container, however an extension to the JmsConnectionFactoryProducer could bootstrap a JMS container for you
or change the default JNDI location of the ConnectionFactory
Each producer in these classes generates an instance based on The @JmsDefault
annotation. This object is used within other places of the API, so you can control the Session generated that is injected into a MessageManager this way.
The Seam JMS Messaging API is a higher level abstraction of the JMS API to provide a number of convenient methods for creating consumers, producers, etc.
The QueueBuilder
and TopicBuilder
interfaces are meant to ease the integration of JMS while still sticking close to the base APIs.
Within the single class you can work with both listeners and send messages.
References to these classes can be injected.
Some example usages.
@RequestScoped
@Named
public class FormBean {
private String formData;
@Inject QueueBuilder queueBuilder;
@Inject TopicBuilder topicBuilder;
@Resource(mappedName="jms/SomeQueue") Queue someQueue;
@Resource(mappedName="jms/SomeTopic") Topic someTopic;
@Resource(mappedName="jms/ConnectionFactory") ConnectionFactory cf;
public void sendFormDataToQueue() {
queueBuilder.connectionFactory(cf).destination(someQueue).sendString(formData);
}
public void sendFormDataToTopic() {
topicBuilder.connectionFactory(cf).destination(someTopic).sendString(formData);
}
}
It is strongly recommended that you proxy the injection of the builders to avoid repeating your configuration. If you are often times connecting to the same queues/topics, you can provide your own producer method.
public class OrderTopicProducer {
@Inject BuilderFactory factory;
@Resource(mappedName="jms/OrderTopic") Topic orderTopic;
@Resource(mappedName="jms/ConnectionFactory") ConnectionFactory cf;
@Produces @OrderTopic
public TopicBuilder sendFormDataToQueue() {
return factory.newTopicBuilder().connectionFactory(cf).destination(orderTopic);
}
}
The MessageManager
interface (org.jboss.seam.jms.MessageManager
) is the main consolidated API for Seam JMS.
It provides almost all of the background functionality for Seam JMS's features (Observer Interfaces, Routing API).
The default implementation works against javax.naming.Context
assuming running within the same local application server.
public interface MessageManager {
public ObjectMessage createObjectMessage(Object object);
public TextMessage createTextMessage(String string);
public MapMessage createMapMessage(Map<Object,Object> map);
public BytesMessage createBytesMessage(byte[] bytes);
public void sendMessage(Message message, String... destinations);
public void sendObjectToDestinations(Object object, String... destinations);
public void sendTextToDestinations(String string, String... destinations);
public void sendMapToDestinations(Map map, String... destinations);
public void sendBytesToDestinations(byte[] bytes, String... destinations);
public void sendMessage(Message message, Destination... destinations);
public void sendObjectToDestinations(Object object, Destination... destinations);
public void sendTextToDestinations(String string, Destination... destinations);
public void sendMapToDestinations(Map map, Destination... destinations);
public void sendBytesToDestinations(byte[] bytes, Destination... destinations);
public Session getSession();
public MessageProducer createMessageProducer(String destination);
public TopicPublisher createTopicPublisher(String destination);
public QueueSender createQueueSender(String destination);
public MessageConsumer createMessageConsumer(String destination, MessageListener... listeners);
public MessageConsumer createMessageConsumer(Destination destination, MessageListener... listeners);
public TopicSubscriber createTopicSubscriber(String destination, MessageListener... listeners);
public QueueReceiver createQueueReceiver(String destination, MessageListener... listeners);
}
The interface above defines a full set of capabilities for creating and sending messages. In addition, we expose methods for creating producers (and A destination specific publisher and sender) as well as consumers (and A destination specific subscriber and receiver). In addition, if injected within a session scoped object, or similar, you can define a durable subscriber and unsubscriber for that subscriber. Below is an example.
The durable subscriber pattern works very well for session based message management. If you want to define a durable subscriber per user session, this is the easiest way to do it.
@SessionScoped
public class UserSession {
@Inject MessageManager messageManager;
@Inject MySessionJMSListener listener;
private String clientId;
@PostConstruct
public void registerListener() {
clientId = UUID.randomUUID().toString();
messageManager.createDurableSubscriber("jms/UserTopic",clientId,listener);
}
@PreDestroy
public void shutdownListener() {
messageManager.unsubscribe(clientId);
}
}
Seam JMS provides a Messaging API around the JMS Durable Topic Subscriber concept. In order to use it within your code, you need to inject a DurableMessageManager.
@Inject @Durable DurableMessageManager durableMsgManager;
This implementation of MessageManager
provides additional methods to
first login to the connection with a ClientID
, additional methods to create
subscribers and an unsubscribe that can be called to unsubscribe a listener.
public void login(String clientId);
public TopicSubscriber createDurableSubscriber(String topic, String id, MessageListener... listeners);
public TopicSubscriber createDurableSubscriber(Topic topic, String id, MessageListener... listeners);
public void unsubscribe(String id);
From a design pattern standpoint, it makes sense to create an ApplicationScoped
object that
all subscribers are created from, injecting a DurableMessageManager
for use across the application,
producing SessionScoped
sessions for use by clients.
One of the difficult choices we had to make was support for Message-Driven Beans.
MDBs are a little complicated in CDI as they are not managed within the CDI life cycle.
This makes integration with them a bit cumbersome. We wouldn't be able to work with a
JMS Session in these cases, as an example. As a result, Seam JMS only supports
defining instances of javax.jms.MessageListener
. To support this, we have
created a partial implementation - org.jboss.seam.jms.AbstractMessageListener
.
This special MessageListener is designed for bridging the external context of a JMS
Message into the application you are working with. We do this by tweaking classloaders.
The best way to work with MessageListeners is to simply instantiate your own based on our base implementation.
//where cl is the class loader, and beanManager is the BeanManager
MessageListener ml = new SessionListener(beanManager,cl,this);
messageManager.createTopicSubscriber("/jms/myTopic", ml);
Or you may define your own subclass that makes specific invocations to the parent. Here is an example of that:
@SessionScoped
public class SessionListener extends AbstractMessageListener {
private MySessionObject mso;
public SessionListener(BeanManager beanManager, ClassLoader classLoader,
MySessionObject mso){
super(beanManager,classLoader);
this.mso = mso;
}
@Override
protected void handlMessage(Message msg) throws JMSException {
//your business logic goes here
}
}
This chapter is designed to detail how to configure the CDI to JMS event bridge. Routing has two sides, sending of events to JMS destinations and translating received messages from JMS destinations back into CDI events. The sections of this chapter describe how to achieve both.
Simply sending or receiving a message over JMS involves a few players: Connection, Session, Destination, and the message itself. Surely you can inject all required resources and perform the routing yourself but that takes away from the whole reason you're using a tool in the first place!
Routing CDI events to and from JMS can be configured by defining a
Route
. As you would
normally create an observer method for an event you can define a route to control which events get
forwarded to what destination. Or conversely, what message types sent to which destinations generate CDI
events.
public interface Route { public <D extends Destination> Route connectTo(Class<D> d, D destination); public Route addQualifiers(Annotation... qualifiers); ... }
Routes allows for simple mapping of event types, complete with qualifiers, to a set of destinations. They
can be configured by adding qualifiers and providing destinations they should interact with and are created
from a
RouteManager
. Here's a simple route that forwards CDI events on to a queue:
@EventRouting public Route registerMyRoute(RouteManager routeManager) { Queue myQueue = lookupQueue("/jms/MyQueue"); return routeManager.createRoute(RouteType.EGRESS, MyEvent.class).connectTo(Queue.class, myQueue); }
A RouteManager
is a factory object for creating new Routes. An instance of it is injected
into every @EventRouting
method. Classes with methods that are decorated with EventRouting
must meet a few criteria items:
A default, no arg constructor.
Be a non bean (no dependencies on injection)
Return either Route
instances or Collection<Route>
instances.
These requirements exist because of when the generation of Route
s must happen.
There are no CDI beans active within the context. A class identified for routing will automatically
be veto'd from the context.
Routes are registered by returning them from a non-bean method annotated with
@EventRouting
:
@EventRouting public Route myConfig() { return bridge.createRoute(RouteType.INGRESS, MyEvent.class).addDestinationJndiName("/jms/MyTopic"); }
Forwarding CDI events to JMS is configured by creating an egress route. Let's say you wanted to forward all
MyEvent
events with
@Bridged
qualifier to the queue
jms/EventQueue
. Simple, register a route:
AnnotationLiteral<Bridged> BRIDGED = new AnnotationLiteral<Bridged>() {}; @EventRouting public Route registerMyEventRoute(RouteManager routeManager) { return routeManager.createRoute(RouteType.EGRESS, MyEvent.class).addQualifiers(BRIDGED).addDestinationJndiName("/jms/EventQueue"); }
With your routing defined you can simply fire events that match the route's payload type and
qualifiers and these events will be forwarded over JMS as object messages. A special note,
we have added the qualifier
@Routing(RouteType.EGRESS)
. This is necessary
to avoid circular routings.
@Inject @Bridged @Routing(RouteType.EGRESS) Event<MyEvent> event; ... event.fire(myEvent);
Similar to egress routes, ingress routes are defined the same way. In this case, they listen for messages on the specified destination(s) and fire events. All of the data will be type safe, assuming you have defined your routes correctly.
Similar to the above example, this creates ingress routes from the Queue jms/EventQueue and fires events based on the MyEvent objects that are carried over the wire.
AnnotationLiteral<Bridged> BRIDGED = new AnnotationLiteral<Bridged>() {}; @EventRouting public Route registerMyEventRoute(RouteManager routeManager) { return routeManager.createRoute(RouteType.INGRESS, MyEvent.class).addQualifiers(BRIDGED).addDestinationJndiName("/jms/EventQueue"); }
Once you define an ingress route, you handle it using an observer method. We use the same payload type
and qualifiers, however we need to add the same qualifier, but for ingress
@Routing(RouteType.INGRESS)
public void handleInboundMyEvent(@Observes @Routing(RouteType.INGRESS) MyEvent e) { .... }
This chapter is meant to describe the behavior of mapping interfaces, where event mapping to data flowing through JMS Queues and Topics are handled via events. These APIs are an alternate way to define routes as mentioned earlier in the document.
Observer Method Interfaces are simple Plain Old Java Interfaces (POJIs) that define either a route. These interfaces exist within your code and are read at deployment time. This is a sample interface:
public interface MappingInterface { @Inbound public void routeStringsFromTopic(@Observes String s, @JmsDestination(jndiName="jms/MyTopic") Topic t); @Outbound public void routeLongsToQueue(@Observes Long l, @JmsDestination(jndiName="jms/MyQueue") Queue q); public void bidirectionRouteDoublesToQueue(@Observes Double d, @JmsDestination(jndiName="jms/DblQueue") Queue q); }
This interface defines three routes. The first one being an ingress route - messages coming in to the topic jms/MyTopic will be fired as events with the type String. We indicate this by using the @Inbound annotation or @Routing(RouteType.INGRESS). The second being an egress route - events fired of type Long will be turned into ObjectMessages and using a MessageProducer sent to the queue jms/MyQueue. We indicate this by using the @Outbound annotation or @Routing(RouteType.EGRESS). The last is a bidirectional route, it defines messages that get fired in both directions. You can leave the method unannotated or use the @Routing(RouteType.BOTH) annotation.
The object being observed can have qualifiers. These qualifiers will be carried over in the fired event and follow the CDI rules for observer method selection. In all cases, the return type of the method is ignored.
The destinations can have any qualifier. In addition, there is basic support for @Resource on the method level to define the destination. This in general not 100% portable from the application developer perspective, we recommend heavy testing of the behavior on your application server.
In order to work with these routes, you raise events in CDI. In order to fire an event, first inject the Event
object into your code with necessary annotations, for any egress route. For ingress routes, you need to define an observer
method. Taking the third route as an example, here is how you would raise events to it
@Inject @Outbound Event<Double> doubleEvent ... doubleEvent.fire(d);
and this is the appropriate observer method to handle the incoming messages.
public class MyEventObserverBean { public void sendMessage(@Observes @Inbound Double d) { System.out.println(d); } }
Table of Contents
The Seam Validation module aims at integrating Hibernate Validator, the reference implementation for the Bean Validation API (JSR 303), with CDI (JSR 299).
This integration falls into two main areas:
Enhanced dependency injection services for validators, validator factories and constraint validators
Automatic validation of method parameters and return values based on Hibernate Validator's method validation feature
The Seam Validation module is based on version 4.2 or later of Hibernate Validator. As of March 2011 Hibernate Validator 4.2 is still in the works and no final release exists yet.
This means that - though unlikely - also changes to the API of the Seam Validation module might become necessary.
The Seam Validation module is therefore released as a technology preview with the Seam 3 release train, with a final version following soon. Nevertheless you should give it a try already today and see what the Seam Validation module and especially the automatic method validation feature can do for you. Please refer to the module home page for any news on Seam Validation.
The remainder of this reference guide covers the following topics:
Installation of Seam Validation
Dependency injection services for Hibernate Validator
Automatic method validation
This chapter describes the steps required to getting started with the Seam Validation Module.
Not very much is needed in order to use the Seam Validation Module. Just be sure to run on JDK 5 or later, as the Bean Validation API and therefore this Seam module are heavily based on Java annotations.
The recommended way for setting up Seam Validation is using Apache Maven. The Seam Validation
Module artifacts are deployed to the JBoss Maven repository. If not yet
the case, therefore add this repository to your
settings.xml
file (typically in
~/.m2/settings.xml
) in order to download the
dependencies from there:
Example 78.1. Setting up the JBoss Maven repository in settings.xml
...
<profiles>
<profile>
<repositories>
<repository>
<id>jboss-public</id>
<url>http://repository.jboss.org/nexus/content/groups/public-jboss/</url>
<releases>
<enabled>true</enabled>
</releases>
<snapshots>
<enabled>false</enabled>
</snapshots>
</repository>
</repositories>
</profile>
</profiles>
<activeProfiles>
<activeProfile>jboss-public</activeProfile>
</activeProfiles>
...
General information on the JBoss Maven repository is available in
the JBoss
community wiki, more information on Maven's
settings.xml
file can be found in the settings reference.
Having set up the repository you can add the Seam Validation Module
as dependency to the pom.xml
of your project. As most
Seam modules the validation module is split into two parts, API and
implementation. Generally you should be using only the types from the API
within your application code. In order to avoid unintended imports from
the implementation it is recommended to add the API as compile-time
dependency, while the implementation should be added as runtime dependency
only:
Example 78.2. Specifying the Seam Validation Module dependencies in pom.xml
...
<properties>
<seam.validation.version>x.y.z</weld.version>
</properties>
...
<dependencies>
...
<dependency>
<groupId>${project.groupId}</groupId>
<artifactId>seam-validation-api</artifactId>
<version>${seam.validation.version}</version>
<scope>compile</scope>
</dependency>
<dependency>
<groupId>${project.groupId}</groupId>
<artifactId>seam-validation</artifactId>
<version>${seam.validation.version}</version>
<scope>runtime</scope>
</dependency>
...
</dependencies>
...
Replace "x.y.z" in the properties block with the Seam Validation version you want to use.
In case you are not working with Maven or a comparable build management tool you can also add Seam Validation manually to you project.
Just download the latest distribution file from SourceForge, un-zip it and add seam-validation.jar api as well as all JARs contained in the lib folder of the distribution to the classpath of your project.
The Seam Validation module provides enhanced support for dependency injection services related to bean validation. This support falls into two areas:
Retrieval of
javax.validation.ValidatorFactory
and
javax.validation.Validator
via dependency
injection in non-Java EE environments
Dependency injection for constraint validators
As the Bean Validation API is part of Java EE 6 there is an out-of-the-box support for retrieving validator factories and validators instances via dependency injection in any Java EE 6 container.
The Seam Validation module provides the same service for non-Java EE
environments such as for instance stand-alone web containers. Just
annotate any field of type
javax.validation.ValidatorFactory
with
@Inject
to have the default validator factory
injected:
Example 79.1. Injection of default validator factory
package com.mycompany;
import javax.inject.Inject;
import javax.validation.Validator;
import javax.validation.ValidatorFactory;
public class MyBean {
@Inject
private ValidatorFactory validatorFactory;
public void doSomething() {
Validator validator = validatorFactory.getValidator();
//...
}
}
The injected factory is the default validator factory returned by
the Bean Validation bootstrapping mechanism. This factory can customized
with help of the configuration file
META-INF/validation.xml
. The Hibernate Validator
Reference Guide describes
in detail the available configuration options.
It is also possible to directly inject a validator created by the default validator factory:
Example 79.2. Injection of a validator from the default validator factory
package com.mycompany;
import java.util.Set;
import javax.inject.Inject;
import javax.validation.ConstraintViolation;
import javax.validation.Validator;
public class MyBean {
@Inject
private Validator validator;
public void doSomething(Foo bar) {
Set<ConstraintViolation<Foo>> constraintViolations = validator.validate(bar);
//...
}
}
The Seam Validation module provides support for dependency injection
within javax.validation.ConstraintValidator
implementations. This is very useful if you need to access other CDI beans
within you constraint validator such as business services etc. In order to
make use of dependency injection within a constraint validator
implementation it must be a valid bean type as described by the CDI
specification, in particular it must be defined within a bean deployment
archive.
Relying on dependency injection reduces portability of a validator implementation, i.e. it won't function properly without the Seam Validation module or a similar solution.
To make use of dependency injection in constraint validators you
have to configure
org.jboss.seam.validation.InjectingConstraintValidatorFactory
as the constraint validator factory to be used by the bean validation
provider. To do so create the file
META-INF/validation.xml
with the following
contents:
Example 79.3. Configuration of InjectingConstraintValidatorFactory in META-INF/validation.xml
<?xml version="1.0" encoding="UTF-8"?>
<validation-config
xmlns="http://jboss.org/xml/ns/javax/validation/configuration" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://jboss.org/xml/ns/javax/validation/configuration validation-configuration-1.0.xsd">
<constraint-validator-factory>
org.jboss.seam.validation.InjectingConstraintValidatorFactory
</constraint-validator-factory>
</validation-config>
Having configured the constraint validator factory you can inject
arbitrary CDI beans into you validator implementations. Listing Example 79.4, “Dependency injection within ConstraintValidator
implementation” shows a
ConstraintValidator
implementation for the
@Past
constraint which uses an injected time
service instead of relying on the JVM's current time to determine whether
a given date is in the past or not.
Example 79.4. Dependency injection within ConstraintValidator implementation
package com.mycompany;
import java.util.Date;
import javax.inject.Inject;
import javax.validation.ConstraintValidator;
import javax.validation.ConstraintValidatorContext;
import javax.validation.constraints.Past;
import com.mycompany.services.TimeService;
public class CustomPastValidator implements ConstraintValidator<Past, Date>
{
@Inject
private TimeService timeService;
@Override
public void initialize(Past constraintAnnotation)
{
}
@Override
public boolean isValid(Date value, ConstraintValidatorContext context)
{
if (value == null)
{
return true;
}
return value.before(timeService.getCurrentTime());
}
}
If you want to redefine the constraint validators for built-in
constraints such as @Past
these validator
implementations have to be registered with a custom constraint mapping.
More information can be found in the Hibernate
Validator Reference Guide.
Hibernate Validator provides several advanced validation features and related functionality which go beyond what is defined by JSR 303 ("Bean Validation API"). One of these additional features is a facility for the validation of method parameters and return values. With that API a style of program design known as "Programming by Contract" can be implemented using the concepts defined by the Bean Validation API.
This means that any Bean Validation constraints can be used to describe
any preconditions that must be met before a method may legally be invoked (by annotating method parameters with constraints) and
any postconditions that are guaranteed after a method invocation returns (by annotating methods)
To give an example listing Example 80.1, “Exemplary repository with constraint annotations” shows a fictional repository class which retrieves customer objects for a given name. Constraint annotations are used here to express the following pre-/postconditions:
The value for the name parameter may not be null and must be at least three characters long
The method may never return null and each Customer object contained in the returned set is valid with respect to all constraints it hosts
Example 80.1. Exemplary repository with constraint annotations
@AutoValidating
public class CustomerRepository {
@NotNull @Valid Set<Customer> findCustomersByName(@NotNull @Size(min=3) String name);
}
Hibernate Validator itself provides only an API for validating method parameters and return values, but it does not trigger this validation itself.
This is where Seam Validation comes into play. Seam Validation provides a so called business method interceptor which intercepts client invocations of a method and performs a validation of the method arguments before as well as a validation of the return value after the actual method invocation.
To control for which types such a validation shall be performed, Seam
Validation provides an interceptor binding,
@AutoValidating
. If this annotation is declared on a
given type an automatic validation of each invocation of any this type's
methods will be performed.
If either during the parameter or the return value validation at least
one constraint violation is detected (e.g. because
findCustomersByName()
from listing Example 80.1, “Exemplary repository with constraint annotations” was invoked with a String only
two characters long), a
MethodConstraintViolationException
is thrown. That
way it is ensured that all parameter constraints are fulfilled when the call
flow comes to the method implementation (so it is not necessary to perform
any parameter null checks manually for instance) and all return value
constraints are fulfilled when the call flow returns to the caller of the
method.
The exception thrown by Seam Validation (which would typically be written to a log file) gives a clear overview what went wrong during method invocation:
Example 80.2. Output of MethodConstraintViolationException
org.hibernate.validator.MethodConstraintViolationException: 1 constraint violation(s) occurred during method invocation. Method: public java.lang.Set com.mycompany.service.CustomerRepository.findCustomersByName(java.lang.String) Argument values: [B] Constraint violations: (1) Kind: PARAMETER parameter index: 0 message: size must be between 3 and 2147483647 root bean: com.mycompany.service.org$jboss$weld$bean-flat-ManagedBean-class_com$mycompany$service$$CustomerRepository_$$_WeldSubclass@3f72c47b property path: CustomerRepository#findCustomersByName(arg0) constraint: @javax.validation.constraints.Size(message={javax.validation.constraints.Size.message}, min=3, max=2147483647, payload=[], groups=[])
To make use of Seam Validation's validation interceptor it has to be registered in your component's beans.xml descriptor as shown in listing Example 80.3, “Registering the validation interceptor in beans.xml”:
Example 80.3. Registering the validation interceptor in beans.xml
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://java.sun.com/xml/ns/javaee" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/beans_1_0.xsd">
<interceptors>
<class>org.jboss.seam.validation.ValidationInterceptor</class>
</interceptors>
</beans>
It is recommended that you consult the Hibernate Validator reference guide to learn more about the method validation feature in general or for instance the rules that apply for constraining methods in inheritance hierarchies in particular.
Table of Contents
Seam Social Provides CDI Beans and extensions for interacting with a number of major social networks. Currently it provides these services and eases mixing them:
Seam Social is independent of CDI implementation and fully portable between Java EE 6 and Servlet environments enhanced with CDI. It can be also used with CDI in Java SE (desktop application).
If you are using Maven, you need to add the Seam Social core libraries to your pom.xml
:
<dependency> <groupId>org.jboss.seam.social</groupId> <artifactId>seam-social-api</artifactId> <version> ${seam.social.version}</version> <scope>compile</scope> </dependency> <dependency> <groupId>org.jboss.seam.social</groupId> <artifactId>seam-social</artifactId> <version> ${seam.social.version}</version> <scope>runtime</scope> </dependency>You also have to add specific dependencies on the services you need in your code
<dependency> <groupId>org.jboss.seam.social</groupId> <artifactId>seam-social-twitter</artifactId> <version> ${seam.social.version}</version> <scope>runtime</scope> </dependency> <dependency> <groupId>org.jboss.seam.social</groupId> <artifactId>seam-social-facebook</artifactId> <version> ${seam.social.version}</version> <scope>runtime</scope> </dependency> <dependency> <groupId>org.jboss.seam.social</groupId> <artifactId>seam-social-linkedin</artifactId> <version> ${seam.social.version}</version> <scope>runtime</scope> </dependency>
The Web example app is quite simple and gives a good idea of the possibilities with Seam Social. The main steps you need to take to use Seam Social are:
OAuthService
beanOAuthService
bean and initialize the access tokenShould you need to fully understand each step, the complete OAuth lifecycle can be found here or here.
To consume an OAuth service you need to declare an application on the service platform (i.e. for
Twitter you can do this at https://dev.twitter.com/apps/new. The declaration of an
application is done with the @OAuthApplication
annotation which must contain at least:
If you don't know what this is about, please refer to the OAuth concepts in your service documentation.
To use an OAuth Service Bean in Seam Social you need to provide the following configuration information
by producing the right OAuthService
bean:
The simplest way to configure your service is to create a producer method like so:
@OAuthApplication(apiKey = "FQzlQC49UhvbMZoxUIvHTQ", apiSecret = "VQ5CZHG4qUoAkUUmckPn4iN4yyjBKcORTW0wnok4r1k") @Twitter @Produces TwitterService twitterServiceProducer(TwitterService ts) { return ts; }
You can also create a bean by subclassing the implementation of the service like this:
@OAuthApplication(apiKey = "FQzlQC49UhvbMZoxUIvHTQ", apiSecret = "VQ5CZHG4qUoAkUUmckPn4iN4yyjBKcORTW0wnok4r1k") @Twitter public class MyTwitterBean extends TwitterServiceJackson { … }
The API key and API secret are provided by the service you want to consume (here Twitter). You can use the values above since they're coming from the "Seam Social" Twitter application. The callback depends on your application - it's the URL that will collect the OAuth verifier.
You can now inject the bean with the right service qualifier:
@Named @SessionScoped public class mySessionBean implements Serializable { ... @Inject @Twitter TwitterService service; ... }
You can now ask for the authorization URL for your service:
String authURL = service.getAuthorizationUrl();
Calling this URL will bring the user on the service connection page and right delegation for the application. If the user gives rights to the application to use the service on their behalf the service will send you back a special code (verifier) that you must inject into the service to initiate the connection.
As the verifier comes back to the application after an action of the final user, you have to set up a servlet or a JSF page (the URL of which is the callback URL you configured when you set up the service) to catch it and add it to the current session. Here is an example with JSF:
<f:metadata> <f:viewParam name="#{mySessionBean.twitterService.verifierParamName}" value="#{mySessionBean.twitterService.verifier}" required="true" requiredMessage="Error with Twitter. Retry later"/> <f:event type="preRenderView" listener="#{mySessionBean.twitterService.initAccessToken()}"/> </f:metadata>
The service is now connected - you have an access token.
Each OAuth Application needs a specific qualifier bearing the @ServiceRelated
Meta annotation.
Out of the box Seam Social provides one default OAuth application qualifier for each social services provides
(@Twitter
, @LinkedIn
, @Facebook
). Should you need to support more than one
application for a given service, you’d have to create a new service related qualifier (@TwitterMyApp
for instance). Please refer to the "Extending Seam Social" section to learn more about this.
Those qualifiers will be used on all the bean attached to a given OAuth application. They are useful to avoid
ambiguous injection in the generic part of the API :
@Inject @Twitter OAuthService twiterService;
and
@Inject @Facebook OAuthService fbService;
Inject two different beans implementing the same interface (OAuthService).
JSON exchanges are managed by two beans:
JsonMapper
which deals with the implementation of JSON parser (Right now Jackson)JsonService
which has a higher function and uses JsonMapper
to provide
decoupling from the Json parser.Seam social uses the Generic bean functionality provided by Solder. Thus when you write :
@OAuthApplication(apiKey = "FQzlQC49UhvbMZoxUIvHTQ", apiSecret = "VQ5CZHG4qUoAkUUmckPn4iN4yyjBKcORTW0wnok4r1k") @Twitter @Produces TwitterService twitterServiceProducer(TwitterService ts) { return ts; }
The Generic extension creates the followings CDI beans with the same qualifier as the produced services
(@Twitter
in the example above) for you :
Seam Social provides a MultiServicesManager
bean that can help you to manage multiple services and
sessions for one user. Without this bean you’ll be able to have multiple services but only one session for each
service. The web app example application is a good starting point to learn how to use MultiServicesManager
bean.
Right now Seam Social comes with 3 basic service modules : Twitter, Facebook and LinkedIn. For this first Seam Social release (3.1.0), our main goal was to create a good core API for identification so provided modules have very basic functionalities. Check the JavaDoc to learn about them. We’ll provide more functionalities and modules for the next release.
To extend Seam Social by supporting a new service you’ll have to provide the following class or ressources :
@SocialRelated
meta annotation and the corresponding
literal. You’ll also need to create a properties file having the same name than your Qualifier. All of these
should reside in the org.jboss.seam.social
package.
OAuthService
interface. Extending the OAuthServiceBase
is
probably the easiest way to get it. It’s good practice to create an interface for this bean to have an easy way
to switch implementations if needed.
ServiceConfiguration
having the service qualifier. Implements the
getServiceClass()
method by returning the class you created in step 2.
The Facebook module is a good example of such an extension.
Table of Contents
The Seam Spring module aims to provide a mechanism for integrating the Spring development model with CDI.
The current version of the module provides support for:
bootstrapping a Spring application context and making it accessible as a CDI bean;
registering an independently bootstrapped application context as a CDI bean;
making Spring beans accessible via CDI (i.e. as managed beans) - for injection and lookup;
accessing CDI beans from within a Spring application context;
If you are using Maven as your build tool, you can add the following single dependency to your pom.xml file to include the Seam Spring module.
<dependency>
<groupId>org.jboss.seam.spring</groupId>
<artifactId>seam-spring-core</artifactId>
<version>${seam.spring.version}</version>
</dependency>
Substitute the expression ${seam.spring.version} with the most recent or appropriate version of Seam Spring.
The functionality of the Seam Spring module is provided by two sets of components:
A CDI portable extension for accessing Spring application contexts and managing Spring beans;
A FactoryBean and corresponding namespace for accessing BeanManagers and importing CDI beans into Spring.
The Seam Spring module uses the resource producer pattern for accessing Spring contexts and beans from within CDI. The Spring extension is responsible for producing the actual instances. This mechanism allows the Spring beans to participate in regular CDI injection and the injection targets to be agnostic of the provenience of the injected references, enforcing true separation of concerns. Through this mechanisms Spring contexts can be injected as Spring beans too, if necessary.
The resource producer pattern is used for:
producing Spring application context instances;
producing Spring beans;
The registration of Spring application contexts as CDI beans is a prerequisite for accessing the Spring beans that are created by them.
The Seam Spring module can access two types of contexts:
contexts created by the application (e.g. bootstrapped by
Spring's ContextLoaderListener
); and
contexts bootstrapped by the extension itself.
As a general rule, Spring ApplicationContext
instances that the extension is interacting with are installed as CDI
beans with a @SpringContext
qualifier, with the following
structure:
@Qualifier
@Inherited
@Documented
@Retention(RetentionPolicy.RUNTIME)
@Target({ElementType.FIELD, ElementType.METHOD, ElementType.PARAMETER})
public @interface SpringContext {
String name() default "default";
}
The name attribute of the context helps identifying between different ApplicationContexts, if the extension needs to deal with multiple such instances.
Table 87.1. Attributes of @org.jboss.seam.spring.context.SpringContext
Attribute | Type | Significance |
---|---|---|
name | String | Unique identifier for a Spring application context bean |
CDI applications can install Spring contexts as CDI beans by defining producer fields with the following general pattern:
@Produces
@SpringContext
@<Context-Type>
ApplicationContext context;
This will create a CDI bean of the ApplicationContext type. The nature of the context (bootstrapped by the extension, or looked up elsewhere) is controlled by a specific annotation. The supported annotations are detailed in the following subsections.
As a reminder, if the name
attribute of the
@SpringContext
qualifier is not set, it will be set to
'default'.
The Seam Spring extension can install a web application context (the application context created by a ContextLoaderListener) by defining a producer field, as follows:
package org.jboss.seam.spring.test.bootstrap;
import javax.enterprise.context.ApplicationScoped;
import javax.enterprise.inject.Produces;
import org.jboss.seam.spring.context.SpringContext;
import org.jboss.seam.spring.context.Web;
import org.springframework.context.ApplicationContext;
public class WebContextProducer {
@Produces
@SpringContext
@Web
ApplicationContext context;
}
The example above will work only in a web application with a Spring application context boostrapped by a ContextLoaderListener.
The @org.jboss.seam.spring.context.Web
annotation
must be placed only on the producer field for the
ApplicationContext
, and it will register a producer
that looks up the parent web ApplicationContext
.
The Seam Spring extension can create a Spring application ad-hoc and install it as a Spring context as follows:
package org.jboss.seam.spring.test.bootstrap;
import javax.enterprise.inject.Produces;
import org.jboss.seam.spring.context.Configuration;
import org.jboss.seam.spring.bocontextpringContext;
import org.springframework.context.ApplicationContext;
public class ConfigurationContextProducer {
@Produces
@SpringContext
@Configuration(locations = "classpath*:org/jboss/seam/spring/test/bootstrap/applicationContext.xml")
ApplicationContext context;
}
The @org.jboss.seam.spring.context.Configuration
annotation
must be placed only on the producer field of the
ApplicationContext
, and it will register a producer
that creates an ApplicationContext
from the files in
the locations attribute of the annotation.
The attributes supported by @org.jboss.seam.spring.bootstrap.Configuration are listed in the following table:
Table 87.2. Attributes of the @org.jboss.seam.spring.context.Configuration
Attribute | Type | Significance |
---|---|---|
locations | String | Comma-separated list of file locations. Observes the conventions regarding the 'classpath:', 'classpath*:' and 'file:' prefixes of Spring |
The producer fields provide a convenient and accesible way of registering a Spring ApplicationContext, especially for looking up contexts created externally (although direct bootstrap is supported as well). A number of Spring ApplicationContexts can also be created by the extension itself.
This can be done by creating a file named /META-INF/org.jboss.seam.spring.contexts which contains a number of key-value pairs, with the keys representing context names and values representing context locations, as follows:
default=classpath*:org/jboss/seam/spring/test/bootstrap/applicationContext.xml
The extension supports the registration of multiple application contexts.
An important feature of Spring context bootstrapping is that Spring beans will be automatically vetoed as CDI beans.
The main difference between implicit bootstrapping and producer-field based bootstrapping is that implicit bootstrapping creates the Spring context during CDI deployment and explicit bootstrapping creates a Spring context after deployment. As such, implicit deployment can do various tasks such as auto-vetoing Spring beans and preventing them to be deployed as CDI beans.
Spring beans can be added as CDI beans explicitly, using a producer field. In order to do so, a Spring ApplicationContext must be registered if they are created by one of the CDI-accessible Spring contexts, as shown in the previous section. This can be done by producer fields and the @SpringBean annotation, as in the following example:
public class SimpleBeanProducer {
@Produces @SpringBean(fromContext = "context2") SimpleBean simpleBean;
@Produces @SpringBean ComplicatedBean complicatedBean;
}
The result is that two CDI beans are available for injection and lookup: one based on the SimpleBean Spring bean defined in the Spring context registered as 'context2' and the other, based on the ComplicatedBean defined in the Spring context registered as 'default'.
The Seam Spring module also supports the registration of CDI beans as Spring beans as well. Once CDI beans are imported into a Spring ApplicationContext, they can be injected as regular Spring beans, either via XML or by annotations.
This can be done by using the dedicated CDI namespace, which can be defined as in the following example:
<beans xmlns="http://www.springframework.org/schema/beans"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:cdi="http://www.jboss.org/schema/seam/spring"
xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd
http://www.jboss.org/schema/seam/spring http://www.jboss.org/schema/seam/spring/seam-spring.xsd">
<!-- bean definitions -->
</beans>
Spring applications can get access to a BeanManager through the following bean definition.
<cdi:bean-manager/>
The bean has the id 'beanManager' by default.
A CDI bean can be imported as a Spring bean by using a namespace element as follows:
<cdi:bean-reference id="cdiBean" type="org.jboss.seam.spring.test.injection.CdiBean"/>
A CDI bean with qualfiers can be imported as follows:
<cdi:bean-reference id="secondCdiBean" type="org.jboss.seam.spring.test.injection.SecondCdiBean">
<cdi:qualifier type="org.jboss.seam.spring.test.injection.CdiQualifier"/>
</cdi:bean-reference>
If the qualifiers have attributes, the bean can be imported as follows:
<cdi:bean-reference id="thirdCdiBean" type="org.jboss.seam.spring.test.injection.ThirdCdiBean">
<cdi:qualifier type="org.jboss.seam.spring.test.injection.CdiQualifierWithAttributes">
<cdi:attribute name="name" value="myBean"/>
</cdi:qualifier>
</cdi:bean-reference>
The conversion from String to the actual type of the attribute is handled by Spring's ConversionService.
CDI beans are imported as prototype-scoped Spring beans, which means that a new reference is acquired every time the bean is injected into a Spring bean. This is done in order to preserve the original scope of the CDI bean.
Table of Contents
The goal of Seam for Apache Wicket is to provide a fully integrated CDI programming model to the Apache Wicket web framework.
Although Apache components (pages, panels, buttons, etc.) are created by direct construction using "new", and therefore are
not themselves CDI contextual instances, with seam-wicket they can receive injections of scoped contextual instances
via @Inject
. In addition, conversation propagation is supported to allow a conversation scope to be tied to a wicket
page and propagated across pages.
The seam-wicket.jar
should be placed in the web application library folder. If you are using
Maven as your build tool, you can add the
following dependency to your pom.xml
file:
<dependency>
<groupId>org.jboss.seam.wicket</groupId>
<artifactId>seam-wicket</artifactId>
<version>${seam-wicket-version}</version>
</dependency>
Replace ${seam-wicket-version}
with the most recent or appropriate version of Seam for Apache Wicket.
As Wicket is normally used in a servlet (non-JavaEE) environment, you most likely will need to bootstrap the CDI container yourself. This is most easily accomplished using the Weld Servlet integration, described in the Weld Reference Guide.
You must extend org.jboss.seam.wicket.SeamApplication
rather than
org.apache.wicket.protocol.http.WebApplication
. In addition:
newRequestCycleProcessor()
to return your own IRequestCycleProcessor
subclass, you must instead override getWebRequestCycleProcessorClass()
and return the class of your processor,
and your processor must extend SeamWebRequestCycleProcessor
.newRequestCycle
to return your own RequestCycle
subclass, you must
make that subclass extend SeamRequestCycle
.
If you can't extend SeamApplication
, for example if you use an alternate Application
superclass
for which you do not control the source, you can duplicate the three steps SeamApplication
takes, i.e. return a
SeamWebRequestCycleProcessor
NonContextual instance in newRequestCycleProcessor()
, return a
SeamRequestCycle
instance in newRequestCycle()
, and add a
SeamComponentInstantiationListener
with addComponentInstantiationListener()
.
Seam's integration with Wicket is focused on two tasks: conversation propagation through Wicket page metadata and contextual injection of Wicket components.
Any object that extends org.apache.wicket.Component
or one of its subclasses is eligible for injection with
CDI beans. This is accomplished by annotating fields of the component with the @javax.inject.Inject
annotation:
public class MyPage extends WebPage {
@Inject SomeDependency dependency;
public MyPage()
{
depedency.doSomeWork();
}
Note that since Wicket components must be serializable, any non-transient field of a Wicket component must be serializable.
In the case of injected dependencies, the injected object itself will be serializable if the scope of the dependency is not
@Dependent
, because the object injected will be a serializable proxy, as required by the CDI specification.
For injections of non-serializable @Dependent
objects, the field should be marked transient and the injection
should be looked up again in a component-specific attach() override, using the BeanManager
API.
Upon startup, the CDI container will examine your component classes to ensure that the injections you use are resolvable and unambiguous, as per the CDI specification. If any injections fail this check, your application will fail to bootstrap.
The scopes available are similar to those in a JSF application, and are described by the CDI specification. The container, in a Java EE
environment, or the Servlet listeners, in a Servlet environment, will set up the application, session, and request scopes. The
conversation scope is set up by the SeamWebRequestCycle
as outlined in the next two sections.
Application conversation control is accomplished as per the CDI specification. By default, like JSF/CDI, each Wicket HTTP
request (whether AJAX or not) has a transient conversation, which is destroyed at the end of the request.
A conversation is marked long-running by injecting the
javax.enterprise.context.Conversation
bean and calling its begin()
method.
public class MyPage extends WebPage {
@Inject Conversation conversation;
public MyPage()
{
conversation.begin();
//set up components here
}
Similarly, a conversation is ended with the Conversation
bean's end()
method.
A transient conversation is created when the first Wicket IRequestTarget
is set during a request. If the
request target is an IPageRequestTarget
for a page which has previously marked a conversation as
non-transient, or if the cid parameter is present in the request, the specified conversation will be
activated. If the conversation is missing (i.e. has timed out and been destroyed),
SeamRequestCycle.handleMissingConversation()
will be invoked. By default this does nothing, and your
conversation will be new and transient. You can however override this, for example to throw a
PageExpiredException
or something similar. Upon the end of a response,
SeamRequestCycleProcessor
will store the cid of a long running conversation, if one
exists, to the current page's metadata map, if there is a current page. The key for the cid in the
metadata map is the singleton SeamMetaData.CID
. Finally, upon detach()
, the
SeamRequestCycle
will invalidate and deactive the conversation context.
Note that the above process indicates that after a conversation is marked long-running by a page, requests made back to that page
(whether AJAX or not) will activate that conversation. It also means that new Page
objects assigned as a RequestTarget
,
whether directly via setResponsePage(somePageInstance)
or with
setResponsePage(SomePage.class, pageParameters)
, will have the conversation propagated to them. This can
be avoided by:
PageParameters
when using setResponsePage()
.
The final case also provides a mechanism for switching conversations: if a cid is specified in
PageParameters
, it will be used by bookmarkable pages, rather than the current conversation.
