Seam includes a number of JSF controls that are useful for working with Seam. These are intended to complement the built-in JSF controls, and controls from other third-party libraries. We recommend JBoss RichFaces, ICEsoft ICEfaces and Apache MyFaces Trinidad tag libraries for use with Seam. We do not recommend the use of the Tomahawk tag library.
To use these tags, define the "s
" namespace in your page
as follows (facelets only):
<html xmlns="http://www.w3.org/1999/xhtml"
xmlns:s="http://jboss.com/products/seam/taglib">
The ui example demonstrates the use of a number of these tags.
Description
A button that supports invocation of an action with control over conversation propagation. Does not submit the form.
Attributes
value
— the label.
action
— a method binding that
specified the action
listener.
view
— the JSF view id to link to.
fragment
— the fragment
identifier to link to.
disabled
— is the link disabled?
propagation
— determines the
conversation propagation style: begin
,
join
, nest
,
none
or end
.
pageflow
— a pageflow definition
to begin. (This is only useful when
propagation="begin"
or
propagation="join"
is used).
Usage
<s:button id="cancel"
value="Cancel"
action="#{hotelBooking.cancel}"/>
You can specify both view
and
action
on <s:link />
.
In this case, the action will be called once the redirect to the
specified view has occured.
The use of action listeners (including the default JSF action
listener) is not supported with <s:button />
.
Description
Add the conversation id to JSF link or button (e.g.
<h:commandLink />
,
<s:button />
).
Attributes
None
Description
Add the task id to an output link (or similar JSF control),
when the task is available via #{task}
.
Attributes
None.
Description
A link that supports invocation of an action with control over conversation propagation. Does not submit the form.
The use of action listeners (including the default JSF action
listener) is not supported with <s:link />
.
Attributes
value
— the label.
action
— a method binding that
specified the action listener.
view
— the JSF view id to link to.
fragment
— the fragment identifier
to link to.
disabled
— is the link disabled?
propagation
— determines the
conversation propagation style: begin
,
join
, nest
,
none
or end
.
pageflow
— a pageflow definition
to begin. (This is only useful when using
propagation="begin"
or
propagation="join"
.)
Usage
<s:link id="register" view="/register.xhtml"
value="Register New User"/>
You can specify both view
and
action
on <s:link />
.
In this case, the action will be called once the redirect to the
specified view has occured.
Description
Customize the conversation propagation for a command link or button (or similar JSF control). Facelets only.
Attributes
type
— determines the conversation
propagation style: begin
,
join
, nest
,
none
or end
.
pageflow
— a pageflow definition to
begin. (This is only useful when using
propagation="begin"
or
propagation="join"
.)
Usage
<h:commandButton value="Apply" action="#{personHome.update}">
<s:conversationPropagation type="join" />
</h:commandButton>
Description
Specify the default action to run when the form is submitted using the enter key.
Currently you can only nest it inside buttons (e.g.
<h:commandButton />
,
<a:commandButton />
or
<tr:commandButton />
).
You must specify an id on the action source. You can only have one default action per form.
Attributes
None.
Usage
<h:commandButton id="foo" value="Foo" action="#{manager.foo}">
<s:defaultAction />
</h:commandButton>
Description
Perform date or time conversions in the Seam timezone.
Attributes
None.
Usage
<h:outputText value="#{item.orderDate}">
<s:convertDateTime type="both" dateStyle="full"/>
</h:outputText>
Description
Assigns an entity converter to the current component. This is useful for radio button and dropdown controls.
The converter works with any managed entity - either simple or composite. The converter should be able to find the items declared in the JSF controls on form submission, otherwise you will receive a validation error.
Attributes
None.
Configuration
You must use Seam managed transactions (see
Section 9.2, “Seam managed transactions”) with
<s:convertEntity />
.
If your Managed Persistence Context isn't
called entityManager
, then you need to set it
in components.xml:
<components xmlns="http://jboss.com/products/seam/components" xmlns:ui="http://jboss.com/products/seam/ui"> <ui:jpa-entity-loader entity-manager="#{em}" />
If you are using a Managed Hibernate Session then you need to set it in components.xml:
<components xmlns="http://jboss.com/products/seam/components" xmlns:ui="http://jboss.com/products/seam/ui"> <ui:hibernate-entity-loader />
If your Managed Hibernate Session isn't
called session
, then you need to set it
in components.xml:
<components xmlns="http://jboss.com/products/seam/components" xmlns:ui="http://jboss.com/products/seam/ui"> <ui:hibernate-entity-loader session="#{hibernateSession}" />
If you want to use more than one entity manager with the entity
converter, you can create a copy of the entity converter for each
entity manager in components.xml
- note how
the entity converter delegates to the entity loader to perform
persistence operations:
<components xmlns="http://jboss.com/products/seam/components" xmlns:ui="http://jboss.com/products/seam/ui"> <ui:entity-converter name="standardEntityConverter" entity-loader="#{standardEntityLoader}" /> <ui:jpa-entity-loader name="standardEntityLoader" entity-manager="#{standardEntityManager}" /> <ui:entity-converter name="restrictedEntityConverter" entity-loader="#{restrictedEntityLoader}" /> <ui:jpa-entity-loader name="restrictedEntityLoader" entity-manager="#{restrictedEntityManager}" />
<h:selectOneMenu value="#{person.continent}"> <s:selectItems value="#{continents.resultList}" var="continent" label="#{continent.name}" /> <f:converter converterId="standardEntityConverter" /> </h:selectOneMenu>
Usage
<h:selectOneMenu value="#{person.continent}" required="true">
<s:selectItems value="#{continents.resultList}" var="continent"
label="#{continent.name}"
noSelectionLabel="Please Select..."/>
<s:convertEntity />
</h:selectOneMenu>
Description
Assigns an enum converter to the current component. This is primarily useful for radio button and dropdown controls.
Attributes
None.
Usage
<h:selectOneMenu value="#{person.honorific}">
<s:selectItems value="#{honorifics}" var="honorific"
label="#{honorific.label}"
noSelectionLabel="Please select" />
<s:convertEnum />
</h:selectOneMenu>
Description
javax.faces.convert.Converter
for
java.util.concurrent.atomic.AtomicBoolean
.
Attributes
None.
Usage
<h:outputText value="#{item.valid}"> <s:convertAtomicBoolean /> </h:outputText>
Description
javax.faces.convert.Converter
for
java.util.concurrent.atomic.AtomicInteger
.
Attributes
None.
Usage
<h:outputText value="#{item.id}"> <s:convertAtomicInteger /> </h:outputText>
Description
javax.faces.convert.Converter
for
java.util.concurrent.atomic.AtomicLong
.
Attributes
None.
Usage
<h:outputText value="#{item.id}"> <s:convertAtomicLong /> </h:outputText>
Description
Tag to nest inside an input control to validate that its parent's value is the same as the referenced control's value.
Attributes
for
— The id of a control to validate against.
message
— Message to show on failure.
messageId
— Message id to show on failure.
Usage
<h:inputText id="name" value="#{bean.name}"/> <h:inputText id="nameVerification" > <s:validateEquality for="name" /> </h:inputText>
Description
A non-visual control, validates a JSF input field against the bound property using Hibernate Validator.
Attributes
None.
Usage
<h:inputText id="userName" required="true"
value="#{customer.userName}">
<s:validate />
</h:inputText>
<h:message for="userName" styleClass="error" />
Description
A non-visual control, validates all child JSF input fields against their bound properties using Hibernate Validator.
Attributes
None.
Usage
<s:validateAll>
<div class="entry">
<h:outputLabel for="username">Username:</h:outputLabel>
<h:inputText id="username" value="#{user.username}"
required="true"/>
<h:message for="username" styleClass="error" />
</div>
<div class="entry">
<h:outputLabel for="password">Password:</h:outputLabel>
<h:inputSecret id="password" value="#{user.password}"
required="true"/>
<h:message for="password" styleClass="error" />
</div>
<div class="entry">
<h:outputLabel for="verify">Verify Password:</h:outputLabel>
<h:inputSecret id="verify" value="#{register.verify}"
required="true"/>
<h:message for="verify" styleClass="error" />
</div>
</s:validateAll>
Description
"Decorate" a JSF input field when validation fails or when
required="true"
is set.
Attributes
template
— the facelets template
to use to decorate the component
#{invalid}
and #{required}
are available inside s:decorate
;
#{required}
evaluates to
true
if you have set the input component being
decorated as required, and #{invalid}
evaluates to true
if a validation error occurs.
Usage
<s:decorate template="edit.xhtml">
<ui:define name="label">Country:</ui:define>
<h:inputText value="#{location.country}" required="true"/>
</s:decorate>
<ui:composition xmlns="http://www.w3.org/1999/xhtml"
xmlns:ui="http://java.sun.com/jsf/facelets"
xmlns:h="http://java.sun.com/jsf/html"
xmlns:f="http://java.sun.com/jsf/core"
xmlns:s="http://jboss.com/products/seam/taglib">
<div>
<s:label styleClass="#{invalid?'error':''}">
<ui:insert name="label"/>
<s:span styleClass="required" rendered="#{required}">*</s:span>
</s:label>
<span class="#{invalid?'error':''}">
<s:validateAll>
<ui:insert/>
</s:validateAll>
</span>
<s:message styleClass="error"/>
</div>
</ui:composition>
Description
Render a HTML <div>
.
Attributes
None.
Usage
<s:div rendered="#{selectedMember == null}">
Sorry, but this member does not exist.
</s:div>
Description
Render a HTML <span>
.
Attributes
title
— Title for a span.
Usage
<s:span styleClass="required" rendered="#{required}" title="Small tooltip">*</s:span>
Description
A non-rendering component useful for enabling/disabling rendering of it's children.
Attributes
None.
Usage
<s:fragment rendered="#{auction.highBidder ne null}">
Current bid:
</s:fragment>
Description
"Decorate" a JSF input field with the label. The label is placed
inside the HTML <label>
tag, and is
associated with the nearest JSF input component. It is often
used with <s:decorate>
.
Attributes
style
— The control's style
styleClass
— The control's style class
Usage
<s:label styleClass="label">
Country:
</s:label>
<h:inputText value="#{location.country}" required="true"/>
Description
Checks that the submitted value is valid Seam Text
Attributes
None.
Description
Outputs Seam Text, a rich text markup useful for blogs, wikis and other applications that might use rich text. See the Seam Text chapter for full usage.
Attributes
value
— an EL expression specifying
the rich text markup to render.
Usage
<s:formattedText value="#{blog.text}"/>
Example
Description
Creates a SelectItem
from an enum value.
Attributes
enumValue
— the string
representation of the enum value.
label
— the label to be used when
rendering the SelectItem
.
Usage
<h:selectOneRadio id="radioList"
layout="lineDirection"
value="#{newPayment.paymentFrequency}">
<s:convertEnum />
<s:enumItem enumValue="ONCE" label="Only Once" />
<s:enumItem enumValue="EVERY_MINUTE" label="Every Minute" />
<s:enumItem enumValue="HOURLY" label="Every Hour" />
<s:enumItem enumValue="DAILY" label="Every Day" />
<s:enumItem enumValue="WEEKLY" label="Every Week" />
</h:selectOneRadio>
Description
Creates a List<SelectItem>
from a List, Set, DataModel or Array.
Attributes
value
— an EL expression
specifying the data that backs the
List<SelectItem>
var
— defines the name of the local
variable that holds the current object during iteration
label
— the label to be used when
rendering the SelectItem
. Can reference
the var
variable.
itemValue
— Value to return to the
server if this option is selected. Optional, by default the
var
object is used. Can reference the
var
variable.
disabled
— if true the SelectItem
will be
rendered disabled. Can reference the var
variable.
noSelectionLabel
— specifies the
(optional) label to place at the top of list (if
required="true"
is also specified then
selecting this value will cause a validation error).
hideNoSelectionLabel
— if true,
the noSelectionLabel
will be hidden when
a value is selected
Usage
<h:selectOneMenu value="#{person.age}"
converter="ageConverter">
<s:selectItems value="#{ages}" var="age" label="#{age}" />
</h:selectOneMenu>
Description
Cache the rendered page fragment using JBoss Cache. Note that
<s:cache>
actually uses the instance
of JBoss Cache managed by the built-in
pojoCache
component.
Attributes
key
— the key to cache rendered
content, often a value expression. For example, if we were
caching a page fragment that displays a document, we might
use key="Document-#{document.id}"
.
enabled
— a value expression that
determines if the cache should be used.
region
— a JBoss Cache node to use
(different nodes can have different expiry policies).
Usage
<s:cache key="entry-#{blogEntry.id}" region="pageFragments">
<div class="blogEntry">
<h3>#{blogEntry.title}</h3>
<div>
<s:formattedText value="#{blogEntry.body}"/>
</div>
<p>
[Posted on
<h:outputText value="#{blogEntry.date}">
<f:convertDateTime timezone="#{blog.timeZone}" locale="#{blog.locale}"
type="both"/>
</h:outputText>]
</p>
</div>
</s:cache>
Description
Renders a file upload control. This control must be used within
a form with an encoding type of
multipart/form-data
, i.e:
<h:form enctype="multipart/form-data">
For multipart requests, the Seam Multipart servlet filter must
also be configured in web.xml
:
<filter>
<filter-name>Seam Filter</filter-name>
<filter-class>org.jboss.seam.servlet.SeamFilter</filter-class>
</filter>
<filter-mapping>
<filter-name>Seam Filter</filter-name>
<url-pattern>/*</url-pattern>
</filter-mapping>
Configuration
The following configuration options for multipart requests may be configured in components.xml:
createTempFiles
— if this option
is set to true, uploaded files are streamed to a temporary
file instead of in memory.
maxRequestSize
— the maximum size
of a file upload request, in bytes.
Here's an example:
<component class="org.jboss.seam.web.MultipartFilter">
<property name="createTempFiles">true</property>
<property name="maxRequestSize">1000000</property>
</component>
Attributes
data
— this value binding receives
the binary file data. The receiving field should be
declared as a byte[]
or
InputStream
(required).
contentType
— this value binding
receives the file's content type (optional).
fileName
— this value binding
receives the filename (optional).
fileSize
— this value binding
receives the file size (optional).
accept
— a comma-separated list of
content types to accept, may not be supported by the
browser. E.g. "images/png,images/jpg"
,
"images/*"
.
style
— The control's style
styleClass
— The control's style
class
Usage
<s:fileUpload id="picture" data="#{register.picture}"
accept="image/png"
contentType="#{register.pictureContentType}" />
Description
An extended <h:graphicImage>
that allows
the image to be created in a Seam Component; further transforms
can be applied to the image.
All attributes for <h:graphicImage>
are
supported, as well as:
Attributes
value
— image to display. Can be
a path String
(loaded from the
classpath), a byte[]
, a
java.io.File
, a
java.io.InputStream
or a
java.net.URL
. Currently supported image
formats are image/png
,
image/jpeg
and
image/gif
.
fileName
— if not specified the
served image will have a generated file name. If you want
to name your file, you should specify it here. This name
should be unique
Transformations
To apply a transform to the image, you would nest a tag specifying the transform to apply. Seam currently supports these transforms:
<s:transformImageSize>
width
— new width of the
height
— new height of the
maintainRatio
— if
true
, and
one of
width
/height
are specified, the image will be resized with the
dimension not specified being calculated to
maintain the aspect ratio.
factor
— scale the image
by the given factor
<s:transformImageBlur>
radius
— perform a
convolution blur with the given radius
<s:transformImageType>
contentType
— alter the
type of the image to either
image/jpeg
or
image/png
It's easy to create your own transform - create a
UIComponent
which implements
org.jboss.seam.ui.graphicImage.ImageTransform
.
Inside the applyTransform()
method use
image.getBufferedImage()
to get the original
image and image.setBufferedImage()
to set your
transformed image. Transforms are applied in the order specified
in the view.
Usage
<s:graphicImage rendered="#{auction.image ne null}"
value="#{auction.image.data}">
<s:transformImageSize width="200" maintainRatio="true"/>
</s:graphicImage>
Description
Generates the Javascript stubs required to use Seam Remoting.
Attributes
include
— a comma-separated list
of the component names (or fully qualified class names)for
which to generate Seam Remoting Javascript stubs. See
Chapter 25, Remoting for more details.
Usage
<s:remote include="customerAction,accountAction,com.acme.MyBean"/>
Seam also provides annotations to allow you to use Seam components as JSF converters and validators:
@Converter
@Name("itemConverter")
@BypassInterceptors
@Converter
public class ItemConverter implements Converter {
@Transactional
public Object getAsObject(FacesContext context, UIComponent cmp, String value) {
EntityManager entityManager = (EntityManager) Component.getInstance("entityManager");
entityManager.joinTransaction();
// Do the conversion
}
public String getAsString(FacesContext context, UIComponent cmp, Object value) {
// Do the conversion
}
}
<h:inputText value="#{shop.item}" converter="itemConverter" />
Registers the Seam component as a JSF converter. Shown here is a converter which is able to access the JPA EntityManager inside a JTA transaction, when converting the value back to it's object representation.
@Validator
@Name("itemValidator")
@BypassInterceptors
@org.jboss.seam.annotations.faces.Validator
public class ItemValidator implements javax.faces.validator.Validator {
public void validate(FacesContext context, UIComponent cmp, Object value)
throws ValidatorException {
ItemController ItemController = (ItemController) Component.getInstance("itemController");
boolean valid = itemController.validate(value);
if (!valid) {
throw ValidatorException("Invalid value " + value);
}
}
}
<h:inputText value="#{shop.item}" validator="itemValidator" />
Registers the Seam component as a JSF validator. Shown here is a validator which injects another Seam component; the injected component is used to validate the value.
