org.jboss.netty.handler.timeout
Class ReadTimeoutHandler

java.lang.Object
  org.jboss.netty.channel.SimpleChannelUpstreamHandler
      org.jboss.netty.handler.timeout.ReadTimeoutHandler

All Implemented Interfaces:

ChannelHandler, ChannelUpstreamHandler, LifeCycleAwareChannelHandler, ExternalResourceReleasable

@ChannelHandler.Sharable
public class ReadTimeoutHandler
extends SimpleChannelUpstreamHandler
implements LifeCycleAwareChannelHandler, ExternalResourceReleasable

Raises a ReadTimeoutException when no data was read within a certain period of time.

 public class MyPipelineFactory implements ChannelPipelineFactory {

     private final Timer timer;
     private final ChannelHandler timeoutHandler;

     public MyPipelineFactory(Timer timer) {
         this.timer = timer;
         this.timeoutHandler = new ReadTimeoutHandler(timer, 30), // timer must be shared.
     }

     public ChannelPipeline getPipeline() {
         // An example configuration that implements 30-second read timeout:
         return Channels.pipeline(
             timeoutHandler,
             new MyHandler());
     }
 }

 ServerBootstrap bootstrap = ...;
 Timer timer = new HashedWheelTimer();
 ...
 bootstrap.setPipelineFactory(new MyPipelineFactory(timer));
 ...


The Timer which was specified when the ReadTimeoutHandler is created should be stopped manually by calling releaseExternalResources() or Timer.stop() when your application shuts down.

Version:

$Rev: 2222 $, $Date: 2010-03-24 14:07:27 +0900 (Wed, 24 Mar 2010) $

Author:

The Netty Project, Trustin Lee

See Also:

WriteTimeoutHandler, IdleStateHandler

Nested Class Summary

Nested classes/interfaces inherited from interface org.jboss.netty.channel.ChannelHandler

ChannelHandler.Sharable

Constructor Summary

ReadTimeoutHandler(Timer timer, int timeoutSeconds)
Creates a new instance.

ReadTimeoutHandler(Timer timer, long timeout, TimeUnit unit)
Creates a new instance.

Method Summary

void	afterAdd(ChannelHandlerContext ctx)
void	afterRemove(ChannelHandlerContext ctx)
void	beforeAdd(ChannelHandlerContext ctx)
void	beforeRemove(ChannelHandlerContext ctx)
void	channelClosed(ChannelHandlerContext ctx, ChannelStateEvent e) Invoked when a Channel was closed and all its related resources were released.
void	channelOpen(ChannelHandlerContext ctx, ChannelStateEvent e) Invoked when a Channel is open, but not bound nor connected.
void	messageReceived(ChannelHandlerContext ctx, MessageEvent e) Invoked when a message object (e.g: ChannelBuffer) was received from a remote peer.
protected void	readTimedOut(ChannelHandlerContext ctx)
void	releaseExternalResources() Stops the Timer which was specified in the constructor of this handler.

Methods inherited from class org.jboss.netty.channel.SimpleChannelUpstreamHandler

channelBound, channelConnected, channelDisconnected, channelInterestChanged, channelUnbound, childChannelClosed, childChannelOpen, exceptionCaught, handleUpstream, writeComplete

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, toString, wait, wait, wait

Constructor Detail

ReadTimeoutHandler

public ReadTimeoutHandler(Timer timer,
                          int timeoutSeconds)

Creates a new instance.

Parameters:

timer - the Timer that is used to trigger the scheduled event. The recommended Timer implementation is HashedWheelTimer.

timeoutSeconds - read timeout in seconds

ReadTimeoutHandler

public ReadTimeoutHandler(Timer timer,
                          long timeout,
                          TimeUnit unit)

Creates a new instance.

Parameters:

timer - the Timer that is used to trigger the scheduled event. The recommended Timer implementation is HashedWheelTimer.

timeout - read timeout

unit - the TimeUnit of timeout

Method Detail

releaseExternalResources

public void releaseExternalResources()

Stops the Timer which was specified in the constructor of this handler. You should not call this method if the Timer is in use by other objects.

Specified by:

releaseExternalResources in interface ExternalResourceReleasable

beforeAdd

public void beforeAdd(ChannelHandlerContext ctx)
               throws Exception

Specified by:

beforeAdd in interface LifeCycleAwareChannelHandler

Throws:

Exception

afterAdd

public void afterAdd(ChannelHandlerContext ctx)
              throws Exception

Specified by:

afterAdd in interface LifeCycleAwareChannelHandler

Throws:

Exception

beforeRemove

public void beforeRemove(ChannelHandlerContext ctx)
                  throws Exception

Specified by:

beforeRemove in interface LifeCycleAwareChannelHandler

Throws:

Exception

afterRemove

public void afterRemove(ChannelHandlerContext ctx)
                 throws Exception

Specified by:

afterRemove in interface LifeCycleAwareChannelHandler

Throws:

Exception

channelOpen

public void channelOpen(ChannelHandlerContext ctx,
                        ChannelStateEvent e)
                 throws Exception

Description copied from class: SimpleChannelUpstreamHandler

Invoked when a Channel is open, but not bound nor connected.
Be aware that this event is fired from within the Boss-Thread so you should not execute any heavy operation in there as it will block the dispatching to other workers!

Overrides:

channelOpen in class SimpleChannelUpstreamHandler

Throws:

Exception

channelClosed

public void channelClosed(ChannelHandlerContext ctx,
                          ChannelStateEvent e)
                   throws Exception

Description copied from class: SimpleChannelUpstreamHandler

Invoked when a Channel was closed and all its related resources were released.

Overrides:

channelClosed in class SimpleChannelUpstreamHandler

Throws:

Exception

messageReceived

public void messageReceived(ChannelHandlerContext ctx,
                            MessageEvent e)
                     throws Exception

Description copied from class: SimpleChannelUpstreamHandler

Invoked when a message object (e.g: ChannelBuffer) was received from a remote peer.

Overrides:

messageReceived in class SimpleChannelUpstreamHandler

Throws:

Exception

readTimedOut

protected void readTimedOut(ChannelHandlerContext ctx)
                     throws Exception

Throws:

Exception
